$200 Direct Insight Triton-TXEK EvalKit for iMX6 Features Freescale i.MX 6Quad Processor

With Wandboard Quad, SABRE Lite, Nitrogen6X, and UDOO, we already have some choices when it comes to low cost Freescale i.MX 6Quad development platforms. Direct Insight, a British company, has developed another called TRITON-TXEK EvalKit for iMX6 that includes the company’s Triton-TX6Q SoM, for 130 GBP (about $200).

Direct Insight TRITON-TXEK for iMX6

Direct Insight TRITON-TXEK for iMX6 (Carrier Board + TRITON-TX6Q SoM)

TRITON-TXEK for iMX6 Specifications:

Specifications listed for the Triton-TXEK evaluation kit include:

  • SoC – Freescale i.MX 6Quad quad core Cortex-A9 @ 1GHz with Vivante GC2000 GPU
  • System Memory – 1GB DDR3
  • Storage – 128MB NAND flash + SD card slot
  • Display – TFT panel via 40-pin LCD flat cable header
  • Connectivity – 10/100M Ethernet
  • USB – USB 2.0 host + mini USB 2.0 host/device
  • Serial – RS232on D-Sub connector
  • Audio – 3.5mm headphone jack
  • Power Supply – 5V
  • Dimensions – Module: 68mm × 31mm, Baseboard: Who knows…
  • Operating temperature – -20 to 70°C

Since the only easily accessible display option is the LCD interface, the company also provides three optional displays to be connected to the evaluation kit:

  • 4.3″, 480 × 272, Capacitive Multi-Touch (Price not available)
  • 5.7″, 640 × 480, Capacitive Multi-Touch (125 GBP)
  • 7.0″, 800 × 480, Capacitive Multi-Touch (125 GBP)

The company provides a Linux BSP standard with source, toolchain, and schematics, and Linux comes pre-installed in the SoM. Windows Embedded Compact 7 and Android 4 support will be available later for an extra charge.

TRITONTX6Q SoM

TRITON-TX6Q SoM

Based on the features above, the board is unlikely to be appealing to hobbyists. However, if you plan to develop a product, it could be an option, as you could use the company SoM with your custom based board, and many i.MX6Q pins appear to be easily accessible (TBC) via the numerous through holes on the carrier board. The carrier board is also compatible with all TRITON-TX SoM based on Freescale i.MX283, TI Sitata AM3354, and Freescale i.MX6. If you need a more advanced development board, the company also provides TRITON-TX StarterKit-5 for 855 GBP ($1,339).

You can find (not that much) more information on Direct Insight’s TRITON-TXEK for iMX6 page, and my earlier post about the company’s TRITON-TXQ6 SoM.

Thanks to Allan for the tip.

Digg This
Reddit This
Stumble Now!
Buzz This
Vote on DZone
Share on Facebook
Bookmark this on Delicious
Kick It on DotNetKicks.com
Share on LinkedIn
Bookmark this on Technorati
Post on Twitter

  1. Germ
    August 21st, 2013 at 15:20 | #1

    Astonish similarities with http://www.karo-electronics.com/tx6.html

  2. adem
    August 21st, 2013 at 16:57 | #2

    how would this compare to the arndale board or the ifc6410 i know they are all dev boards but cpu gpu and all the input output and so on

  3. August 21st, 2013 at 17:05 | #3

    @Germ
    Lol… It turns out Karo Electronics is indeed the manufacturer, and Direct Insight just a reseller. We can actually see karo-electronics.de on the first picture, but I did not notice while writing about it.

    @adem
    i.MX6 is a quad core Cortex A9, the performance will be slower than Arndale and IFC6410 boards. The board above also does not have many ports available.
