Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on LibreVNA open-source USB vector network analyzer (VNA) works in the 100kHz to 6GHz range

LibreVNA open-source USB vector network analyzer (VNA) works in the 100kHz to 6GHz range

LibreVNA Open source hardware vector network analyzer vna

Jan Käberich’s LibreVNA is an open-source hardware USB vector network analyzer (VNA) based on a Spartan-6 FPGA, an STM32 microcontroller, and RF circuitry with MAX2871 and Si5351C chips. The open-source VNA supports two channels and works in the 100kHz to 6GHz frequency range. Vector network analyzers are expensive pieces of electronic test equipment used to measure the magnitude and phase of high-frequency electrical networks costing several thousand dollars. They are commonly used in radio frequency (RF) and microwave engineering applications. Last year, we wrote that Pico Technology released PicoVNA 5 software for Linux, Raspberry Pi, and macOS instead of only providing a Windows program for their commercial PicoVNA devices. I thought it was already a good development even if it was closed-sourced, but LibreVNA goes all the way with an open-source hardware design with hardware design files, the FPGA code, STM32 firmware, and PC software (GUI) all open-source. LivreVNA hardware […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 14 Comments on $166 Mustool MT13S thermal imager doubles as multimeter

$166 Mustool MT13S thermal imager doubles as multimeter

Mustool MT13S 2-In-1 Thermal Imager Multimeter

Mustool MT13S is a relatively inexpensive 2-in-1 thermal imager and multimeter with a 2.8-inch touchscreen display and an IR camera with a 192×192 resolution. Thermal cameras used to be quite expensive, but in recent years, we’ve seen cheaper models such as the HT-102 thermal camera for Android smartphones and M5Stack T-Lite Wi-Fi thermal camera, but those integrate fairly small 32×32 and 32×24 pixels IR arrays, The Mustool MT13S provides a higher resolution 192×192 thermal camera and doubles as a 10,000-count multimeter for about $166 plus shipping on Banggood or around $177 including shipping on Aliexpress. Mustool MT13S specifications: Thermal imaging Sensor – Uncooled focal plane Image capture frequency – 20Hz Thermal imaging resolution – 192 x 192 Display image resolution – 240 x 240 Field of view (FoV) – 50.0(H) × 50(V)/72.1(D) Emissivity – 0.1-0.99 is tunable and 0.95 is the default Temperature Range – -20°C to +550°C Accuracy – […]

Khadas Edge2 Arm mini PC
Posted on by Jean-Luc Aufranc (CNXSoft) - 6 Comments on STMicro ST60A3H0 and ST60A3H1 60 GHz transceiver ICs aim to replace USB cables

STMicro ST60A3H0 and ST60A3H1 60 GHz transceiver ICs aim to replace USB cables

ST60A3H0 ST60A3H1 60 GHz transceivers

STMicro ST60A3H0 and ST60A3H1 are short-range 60 GHz transceiver ICs that tunnel eUSB2, I2C, SPI, UART, and GPIO signals and aim to replace USB and other cables in consumer devices such as digital cameras, wearables, portable hard drives, and small gaming terminals. They should also find their way into industrial applications such as rotating machinery where cable use may be challenging. The smaller ST60A3H0 chip provides more flexibility and requires an external antenna, while the ST60A3H1 chip is a fully integrated solution with a built-in linear antenna. Both are capable of USB 2.0 speeds of up to 480 Mbps and support UART, GPIO, and/or I2C signals so they are not limited to USB cables and can be used in a range of applications. ST60A3H0 and ST60A3H1 key features and specifications: 60 GHz V-Band transceiver for short-range contactless connectivity up to 480 Mbit/s eUSB2, UART, GPIO, or I2C RF tunneling Low […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on Waveshare R7FA4 PLUS A and B boards are clones of the Arduino UNO R4 Minima and WiFi

Waveshare R7FA4 PLUS A and B boards are clones of the Arduino UNO R4 Minima and WiFi

Arduino UNO R4 WiFi clone

Arduino board clones have been around for many years, but I don’t think I have ever seen clones of the new Renesas-based Arduino boards so far. Waveshare changes that with the R7FA4 PLUS A that clones with Arduino UNO R4 Minima, and the R7FA4 PLUS B board duplicating the Arduino UNO R4 WiFi. The Waveshare boards are not 100% clones with some small differences in the PCB layout, support for 5V and 3.3V shields, an additional 6-pin “power output header” with 5V, 3.3V, and GND signals, and a USB communication jumper to select between the Espressif ESP32-S3 and Renesas RA4M1 microcontrollers. Waveshare R7FA4 PLUS A and B specifications: Microcontroller – Renesas RA4M1 Arm Cortex-M4F MCU @ 48 MHz with 32KB SRAM, 256KB flash Wireless (B model only) – ESP32-S3-MINI-1 module based on ESP32-S3 dual-core Xtensa LX7 microcontroller with 512KB SRAM, 384KB ROM, WiFi 4 and Bluetooth 5.0 connectivity, PCB antenna […]

Posted on by Debashis Das - 2 Comments on 52Pi NVdigi Expansion Board for Raspberry Pi 5 combines HiFiBerry Digi+ audio output with M.2 PCIe x1 slot

52Pi NVdigi Expansion Board for Raspberry Pi 5 combines HiFiBerry Digi+ audio output with M.2 PCIe x1 slot

52Pi NVDigi Extension Adapter Board

The 52Pi NVdigi is another PCIe expansion board for the Raspberry Pi 5 which integrates HiFiBerry Digi+ to provide high-quality S/PDIF output. It also features an M.2 PCIe x1 slot that supports NVMe 2242/2230 SSDs. Furthermore, it offers an optical output (TOSLink) and an RCA output for versatile audio connections. The HiFiBerry Digi+ is a high-quality S/PDIF output for the Raspberry Pi. It uses the I2S sound port that connects directly to the CPU without the need for an additional USB conversion. It supports sample rates up to 192kHz/24bit. 52Pi NVdigi Expansion Board Specification: HiFiBerry Digi+ Integration – Provides high-quality S/PDIF output for Raspberry Pi 5. Direct I2S Connection – Connects directly to the CPU via the I2S sound port for optimal audio. High-Resolution Audio – Supports sample rates up to 192kHz and 24-bit depth for immersive audio. Multiple Audio Outputs – Features both optical (TOSLink) and electrical (RCA) outputs. M.2 […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 13 Comments on Banana Pi BPI-M6 SBC features SenaryTech SN3680 quad-core Cortex-A73 AI processor

Banana Pi BPI-M6 SBC features SenaryTech SN3680 quad-core Cortex-A73 AI processor

Banana Pi BPI-M6

Banana Pi BPI-M6 is a credit-card single board computer based on SenaryTech SN3680 SoC comprised of a quad-core Arm Cortex-A73 processor, an Arm Cortex-M3 real-time core, an Imagination GE9920 GPU, and an NPU delivering up to 6.75 TOPS. The board ships with 4GB LPDDR4 RAM and 16GB eMMC flash. Its layout is fairly similar to the one of the Raspberry Pi 4 with four USB ports, Gigabit Ethernet, a 40-pin GPIO header, a USB Type-C port for power, and two micro HDMI ports. However, only one of those is for HDMI output, as the second is for HDMI input, and there’s also an M.2 Key-E socket for expansion. Banana Pi BPI-M6 specifications: SoC – SenaryTech SN3680 (also known as Synaptics VS680) with CPU – Quad-core Arm Cortex-A73 processor up to 2.1GHz MCU – Arm Cortex-M3 real-time security core @ 250MHz GPU – Imagination PowerVR Series9XE GE9920 GPU VPU – 4Kp60 […]

Advertisement

Posted on by Jean-Luc Aufranc (CNXSoft) - 5 Comments on ESP32-C6-Bug WiFi 6, Bluetooth LE, and 802.15.4 board takes a PoE Ethernet shield (Crowdfunding)

ESP32-C6-Bug WiFi 6, Bluetooth LE, and 802.15.4 board takes a PoE Ethernet shield (Crowdfunding)

ESP32-C6 PoE board

We’ve already covered a range of ESP32-C6 boards, but none supporting Ethernet and PoE so far, and the ESP32-C6-Bug board brings that to the table thanks to the Esp32-Bug-Eth shield with a W5500 Ethernet chip, an RJ45 jack and a PoE power module. Like other ESP32-C6 devices, the little board supports Wi-Fi 6, Bluetooth LE 5, as well as Thread and Zigbee through its 802.15.4 radio, but it also integrates some other interesting features such as castellated holes for easy soldering on a carrier board and support for LiPo batteries with built-in battery charging and protection circuits. ESP32-C6-Bug board specifications: SoC – ESP32-C6FH4 MCU cores 32-bit RISC-V core @ 160 MHz 32-bit RISC-V core @ 20 MHz low-power coprocessor can run tasks even when the main system is in deep sleep state Memory – 512 KB SRAM Storage – 4 MB Flash Wireless – WiFi 6, Bluetooth LE 5, and […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on Rockchip RK3568-powered ASUS Tinker Board 3N is now available in three variants

Rockchip RK3568-powered ASUS Tinker Board 3N is now available in three variants

ASUS Tinker Board 3N

The ASUS Tinker board 3 was first unveiled in April 2023 before being renamed as Tinker Board 3N later that year, and the three variants of the Rockchip RK3568 single board computer (SBC) are now available. The standard configuration is the Tinker Board 3N in the commercial temperature range, while the Tinker Board 3N Plus has the same features, except it can operate in the industrial temperature range (-40°C to 85°C). The Tinker Board 3N Lite is a cost-down version in the same form factor, but with a single gigabit Ethernet port without PoE support, no M.2 B-key socket for an NVMe SSD or 4G/5G cellular connectivity, no 16MB SPI flash, fewer serial interfaces, and no CAN Bus. You’ll find a comparison of the specifications for the three variants in the table below. Note the prices above are from Amazon with a 10% discount when applicable. ASUS provides support for […]
