Sipeed Maix4 HAT RPI5 AI HAT
Posted on

Sipeed Maix4-HAT – A Raspberry Pi 5 PCIe AI module with up to 72 TOPS AI power, 4K video output

The Maix4-HAT is a compact AI HAT for the Raspberry Pi 5 built around the MAIX-IV core board, which includes AXERA’s AX650N/C octa-core Cortex-A55 CPU, SoC, delivering up to 72 TOPS (INT4) or 18 TOPS (INT8) with 8K video encode/decode support. It features 8 GB LPDDR4x RAM and 32 GB eMMC storage, as well as interfaces such as PCIe 2.0, HDMI 2.0a (4Kp60), USB 3.0, USB 2.0, multiple camera inputs, SPI LCD, I²C touch, speaker, and fan connectors. Designed for plug-and-play use with Raspberry Pi 5 and other boards, it accelerates Transformer-based models, making it ideal for space-constrained edge AI tasks in smart cameras, industrial inspection, and multimodal AI applications. Sipeed Maix4-HAT Specifications: SoC – AXera AX650N CPU – Octa-core Arm Cortex-A55 @ 1.7 GHz with NEON support NPU – 43.2 TOPS @ INT4, 10.8 TOPS @ INT8 with support for INT4, INT8, INT16, FP16, and FP32 inputs; Equivalent to NVIDIA […]

Waveshare PCIe TO MiniPCIe GbE USB3.2 HAT+
Posted on

Raspberry Pi 5 PCIe HAT+ board features gigabit Ethernet, 4G LTE (mini PCIe), two USB 3.2 ports

Waveshare has recently introduced the PCIe to MiniPCIe GbE USB3.2 HAT+ for Raspberry Pi 5 adding gigabit Ethernet, a mini PCIe socket for 4G LTE, and two USB 3.2 Gen1 ports to the popular Arm single board computer. The HAT+ is compatible with IM7600G-H-PCIE/EG25-G-mPCIe series 4G LTE modules with 4G/3G/2G global band and GNSS positioning. Additionally, it has a gigabit Ethernet with an onboard RJ45 port, two USB 3.2 Gen1 ports, an onboard power monitoring chip, and EEPROM. All these features make this HAT useful for applications such as industrial routers, home gateways, set-top boxes, industrial laptops, industrial PDAs, and much more. We have previously written about many different types of HATs for the Raspberry Pi 5 designed by Waveshare including the Waveshare UPS HAT (E), the Waveshare PoE HAT (G), the Waveshare PCIe to USB 3.2 HAT+, and many other products. Feel free to check those out if you […]

Advertisement
Pineboards Raspberry Pi 5 HAT
Posted on

Pineboards adds four more Raspberry Pi 5 PCIe HAT+ boards with PCIe x4 slot, mPCIe socket, Coral Dual Edge TPU support, and audio ports

Pineboards, previously known as PineBerry, has launched four new Raspberry Pi HAT+ with a PCIe interface: the Hat uPCIty Lite, HatDrive! Piano, Hat mPCIe, and Hat Ai! Dual. The Polish company decided to change the name from Pineberry to Pineboards since the “berry” name implied they were manufacturing single-board computers, while Pineboards, not to be confused with Pine64 boards, apparently does not :). Nevertheless, let’s have a look at the four new HAT+ boards. Hat uPCIty Lite – PCIe x4 slot and ATX power supply Specifications: Supported SBCs – Raspberry Pi 5 and other SBCs with a compatible 16-pin PCIe FPC connector and form factor PCIe 16-pin PCIe FPC connector (input) PCIe X4 slot (output) to connect PCIe cards such as NVIDIA or AMD graphics cards; Note: only PCIe x1 Gen2 and Gen3 are supported Misc – 12V and PWR LEDs Power Supply 12V/8A via ATX power connector 12V/8A via […]

Waveshare PCIe TO 2.5G ETH Board (C)
Posted on

$9.99 2.5GbE PCIe adapter for Raspberry Pi 5 uses Realtek RTL8125 controller

Waveshare PCIe TO 2.5G ETH Board (C) low-cost PCIe x1 adapter adds a 2.5GbE port to the Raspberry Pi 5 using the board’s 16-pin PCIe interface. It’s plug-and-play and doesn’t require any additional drivers, making it a practical upgrade for DIY NAS, routers, or edge-networking applications. The board is built around a Realtek RTL8125 controller and offers a 10/100/1000/2500 Mbps RJ45 port with link/activity LEDs. It includes a transparent acrylic mounting plate at the bottom to save space above the board. It relies on a PCIe Gen2 x1 interface, takes 5V power through the PCIe cable or 5V power connectors, and works out of the box in Raspberry Pi OS. PCIe TO 2.5G ETH Board (C) specifications: Compatibility – Raspberry Pi 5 or other boards with a compatible 16-pin PCIe connector Ethernet 10/100/1000/2500 Mbps Ethernet RJ45 port via Realtek RTL8125 2.5GbE PCIe network controller Link/activity LEDs (yellow = link, green […]

4 Ch PCIe FFC Adapter Board for Raspberry Pi 5
Posted on

Use four PCIe FFC connectors on the Raspberry Pi 5 with Waveshare PCIe TO 4-CH HAT

The 4-Ch PCIe FFC Adapter Board expands the PCIe interface of the Raspberry Pi 5 to four PCIe FFC connectors using the ASM1184e PCI Express packet switch chip, which we’ve seen in HATs like the Geekworm X1011 board, adding four NVMe SSDs, and the Waveshare PCIe-Packet-Switch-4P, adding four PCIe x1 slots. The HAT supports PCIe Gen2 speeds and features onboard power monitoring to track power consumption. There is also an EEPROM for storing configuration data, and the option to stack multiple PCIe HATs. Additionally, users can install a heatsink on the HAT to manage thermal performance, making it well-suited for embedded solutions that require multiple PCIe devices. Waveshare PCIe TO 4-CH HAT specifications: Compatibility – Designed for Raspberry Pi 5 Storage – Onboard EEPROM for configuration data storage PCIe switch – ASMedia ASM1184e PCI express packet switch with 1x PCIe Gen2 x1 upstream port and 4x PCIe Gen2 x1 downstream […]

Pironman 5-Max
Posted on

Pironman 5-Max tower PC case for the Raspberry Pi 5 gets dual M.2 PCIe sockets, programmable RGB LEDs, new black design

Pironman 5-Max is an update of the Pironman 5 tower PC case for the Raspberry Pi 5 with a new sleeker design made of black aluminum and semi-transparent black acrylic panels. Other improvements include a new dual NVMe PiP expansion board for two M.2 NVMe SSDs in RAID 0/1 configuration, or one NVMe SSD and one AI accelerator module, a Tap-to-Wake feature for the OLED information display, and programmable RGB LEDs for the two fans. Pironman 5-Max specifications: Designed for the Raspberry Pi 5 and compatible SBCs Storage Pironman 5  Dual NVMe PiP supporting 2x M.2 2230, 2242, 2260, or 2280 NVMe SSDs at up to PCIe 2.0 x1 speeds due to switch used; RAID 0/1 support MicroSD card slot equipped with a spring-loaded socket for easy card removal Video Output – 2x full-size HDMI ports Display – 0.96-inch OLED Display showing Raspberry Pi’s CPU usage, temperature, disk usage, IP […]

Advertisement

Raspberry Pi 5 PCIe to PCIe x1 Boards
Posted on

PCIe x1 slot adapters let the Raspberry Pi 5 SBC interface with standard PCIe cards

Waveshare has recently launched the PCIe TO PCIe x1 Board (C) which is a PCIe FFC connector to standard PCIe x1 slot adapter board for the Raspberry Pi 5. But while searching for more details about the board, I also found out about other solutions from 52Pi and Spotpear, which are a bit older, but still worth taking a look because of their unique features and low cost. These Raspberry Pi PCIe x1 slot adapters allow users to connect expansion cards such as network cards, storage controllers, and other PCIe peripherals to the Raspberry Pi 5. Additionally, the board features a dedicated 12V power header and DC jack, which supplies power to the 12V pins of the PCIe slot, for power-hungry devices. These features allow for applications like AI acceleration, high-speed networking, and storage expansion. Waveshare PCIe TO PCIe x1 Board (C) The Waveshare PCIe FFC to PCIe x1 Adapter […]

PCIe 3.0 to dual M.2 HAT for Raspberry Pi 5
Posted on

PCIe3.0 to Dual M.2 HAT+ for Raspberry Pi 5 features ASMedia ASM2806 PCIe 3.0 switch

We’ve already covered Raspberry Pi HAT+ boards with multiple M.2 sockets with various keyings including the Geekworm X1004 HAT+, Pineboards HatDrive! AI, and  HatDrive! Dual with two sockets, and the Geekworm X1011 with four M.2 Key-M sockets. So when I saw Seeed Studio introduced a dual M.2 HAT+ board I initially thought it was uninteresting being a very similar board. However, all aforementioned PCIe to M.2 HAT+ boards are based on either the ASMedia ASM1182e or ASM1184e PCIe Gen2 x1 packet switches with 5GT/s shared bandwidth, and Seeed Studio’s PCIe3.0 to Dual M.2 HAT+ for Raspberry Pi 5 features instead an ASMedia ASM2806 PCIe 3.0 switch supporting up to 8GT/s shared bandwidth through the Raspberry Pi 5’s PCIe Gen3 x1 interface. Seeed Studio PCIe 3.0 to Dual M.2 HAT+ key features and specifications: Supported SBC – Raspberry Pi 5 and potentially other SBCs with a PCIe FFC connector like the […]
