Orange Pi 3G-IoT SBC Launched for $24.90

Orange Pi 3G-IOT

We had two Arm Linux SBCs with cellular connectivity from Shenzhen Xunlong so far: Orange Pi 2G-IoT for 2G connectivity, and Orange Pi 4G-IoT with LTE support in Asia and Europe. But what if you needed 3G connectivity, and did not want to spend $45 on the 4G board? There was no option until today, but the company has just launched Orange Pi 3G-IoT with WCDMA (UMTS), TD-CDMA and CDMA2000 support. Orange Pi 3G-IoT-B board specifications: SoC – MediaTek MT6572 dual core Cortex A7 processor @ up to 1.2 GHz with Arm Mali-400 GPU System Memory – 512MB DDR2 Storage – 4GB eMMC flash, micro SD slot Display I/F – FPC connector for FWVGA display (854×480) Camera I/F – MIPI connector Audio – 3.5mm audio jack, built-in microphone, 2x solder pads for optional speakers Connectivity Cellular Nano SIM card slot 2G GSM – 850/900/1800/1900 MHz 3G WCDMA -(B1/B2/B5/B8), TD-CDMA, CDMA2000 WiFi, Bluetooth, FM and GPS all in one USB – […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

hIoTron Modular & Enterprise IoT Development Kit is Designed for Fast Prototyping

Hi-Nodes

hIoTron modular & enterprise IoT development kit is described by the company has a “fully pre-programmed prototyping kit for quickly building and testing your IoT concept” with plug-n-play module allowing for flexible prototyping. Beside the hardware comprises of a gateway and nodes, the kit also integrates with the company’s enterprise IoT Platform enabling easy design of custom mobile application & GUI dashboard. The company offers standard, advanced, and custom kits, but to keep things simple, let’s focus on the content of their standard kit first: Hi-Gate IoT gateway: WiSoC – Texas Instruments CC3200 Arm Cortex-M4 @ 80 MHz with 1MB flash, 256KB RAM Storage – 1MB serial flash, 512KB EEPROM Connectivity 802.11 n/g/n Wi-Fi,  2G GSM/GPRS (optional 3G/4G), ZigBee, BLE 4.0, sub-1GHz RF/NON RF to REST/MQTT gateway Expansion – 2x GPIO port pins, 2x analog port pins Power Supply – 9-12V DC 3x modular Hi-Nodes (up to 25 supported per gateway) based on Microchip/Atmel ATmega328P MCU: Powering node – via […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

1NCE to Offer a 10 Euros Plan for 10-Year of Cellular IoT Connectivity in Europe

For the Internet of Things to be successful, prices need to come down sharply, and eventually LPWAN connectivity should be possible with $1 to $2 modules, $5 to $10 development boards like we can get for WiFi today. Cellular IoT hardware is likely to be a bit more expensive – even when using NB-IoT – but hardware prices have to come down to acceptable levels, and so is connectivity. 1NCE brings us in the right direction for the latter with a SIM card selling for 10 Euros offering 10-year of 2G/3G/NB-IoT connectivity (1 Euro per year) with 500MB data included.  That’s about 140KB of data per day, which should be OK for applications like smart meters. There are no other fees, except if your device goes over the limit,  but the company has not provided any pricing details for the extra data. The service will cover 30 countries in Europe. The SIM cards will start selling in August 2018, and […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

A List of Cellular IoT Development Boards

We’re starting to have a decent choice of cellular development boards, and as the number of products is getting larger having some sort of list would be useful. That’s exactly what Hologram has done. While the list is not quite exhaustive, they’ve pushed the csv list to Github, and plans to update it. Hologram also encourage pull requests, so manufacturers may consider updating it with their own boards. The list focuses on development boards acting as cellular IoT end points, so you won’t find gateways, WiFi hotspots, end user devices and modules that needs to be soldered onto your own board. I have imported the list to WordPress to make it searchable, let people select the number of rows to display, and customize visible fields. The table is not automatically synchronized, so for the latest version always check out Github. Jean-Luc Aufranc (CNXSoft)Jean-Luc started CNX Software in 2010 as a part-time endeavor, before quitting his job as a software engineering […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

X99 Android TV Box is Based on Rockchip RK3399 Processor, Equipped with a SIM Card Slot

RK3399-Cellular-TV-Box

We’ve previously seen a fair amount of TV boxes / mini PCs based on Rockchip RK3399 processor like Yundoo Y8 or Vorke Z3,  which perform very well for tasks like web browsing and gaming, but  required more work when it comes to video playback, at least in 2017 when I reviewed the devices. X99 is another one of those TV boxes with RK3399 SoC, 4GB RAM, 32GB storage, HDMI 2.0 output, Gigabit Ethernet, and so on, but interestingly enough it adds a SIM card slot too. The photo above appears to show a modem module close to the SIM card, but somehow none of the website explains which type (2G/3G/4G) of modem that is in X99 TV box specifications: SoC – Rockchip RK3399 hexa core processor with 2x ARM Cortex A72 cores @ up to 1.8 GHz, 4x ARM Cortex A53 cores, Mali-T860MP4 GPU System Memory – 4GB DDR3 Storage – 32 GB eMMC flash + SD card slot up […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

STMicro Introduces Two STM32 Discovery Kits with 2G/3G or 4G LTE-IoT Cat M1/NB1 Connectivity

Embedded World 2018 trade fair will take place on  on take place on February 27 – March 1 in Nuremberg, Germany, and we’re starting to see some company announce new products and solutions for the embedded market. STMicro has just announced their showcase their very first cellular development kits at the event, based on a display-less variant on their 32L496GDISCOVERY Discovery board with cellular add-on boards: P-L496G-CELL01 Discovery kit with with a 2G/3G modem P-L496G-CELL02 Discovery kit with with an LTE-IoT Cat M1 (eMTC) / NB1 (NB-IoT) / 2G model Now the company has not started designed their own cellular modem, but instead relying on QUECTEL modems. Both kits share most of the same specifications: MCU – STMicro STM32L496AGI6 Arm Cortex M4F [email protected] 80 MHz with 1 MB Flash, 320 KB RAM in a UFBGA169 package On-board memory – 8 Mbit PSRAM On-board + external storage – 32 KB I2 C EEPROM with OTP page preloaded with board ID and […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

How to Use 3G and GPS on Raspberry Pi with ThaiEasyElec 3G HAT Expansion Board

Venus Supply is an embedded systems company based in Bangkok, Thailand that sells products through their ThaiEasyElec website/brand, as well as a act as a local distributor for popular DIY electronics items. I previously tested their ESPino32 ESP32 board, and the company has now send me another of their new product called “3G HAT Expansion for Raspberry Pi” and based on Quectel UC20-G that support 3G and GPS/GLONASS connectivity globally, meaning it should work in any country with 2G or 3G coverage. After listing the specifications, going through unboxing and assembly with a Raspberry Pi 2/3 board, I’ll write some quick start guide to show what I had to do to use GPS and connect to 3G with a Hologram SIM card. 3G HAT Expansion for Raspberry Pi Specifications Quectel UC20-G wireless module supporting Cellular 3G – UMTS @ 800/850/900/1900/2100 MHz 2G – GSM @ 850/900/1800/1900 MHz Data – HSPA+ up to 14.4 Mbps Downlink, 5.76 Mbps Uplink, EDGE, GPRS […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

TECHBASE ModBerry​ M300 IoT Gateway Adds Support for NanoPi and Orange Pi Allwinner H5 Boards

Announced at the end of last year TECHBASE launched the ModBerry​ M300, a Linux IoT gateway powered by FriendlyELEC NanoPi NEO board equipped with Allwinner H3 Cortex A7 processor. The company has now made four extra variants of the gateway with Allwinner H5 quad core Cortex A53 based development boards from FriendlyELEC and Shenzhen Xunlong: Modberry M300 N2 – Based on NanoPi NEO2 Modberry M300 N2+ – Based on NanoPi NEO Plus2 adding 8GB eMMC flash, WiFi & Bluetooth 4.0, and an extra USB port over the N2 model Modberry M300 O1 – Based on Orange Pi Zero Plus Modberry M300 O2 – Based on Orange Pi Zero Plus2 adding 8GB eMMC flash, HDMI, one extra USB port, and Bluetooth 4.0 over the O1 model, but falling back to 10/100 Ethernet, while all three models above come with Gigabit Ethernet To avoid confusion, the original NanoPi NEO model has changed name to ModBerry M300 N1. The specifications summary / comparison […]
