HackBerry AllWinner A10 Board is Now Available for $60

The Hackberry “development board” is now available for sale on Miniand. This board powered by AllWinner A10 processor comes in 2 versions: 512 MB RAM version – Available now for $60 1GB RAM version – Available by the end of the month for $65. Both boards features a 4GB Flash, a SDHC slot, 2x USB 2.0 port, 10/100 Ethernet, Wi-Fi, HDMI & composite outputs,  headphone & microphone ports and a IR sensor. The good thing is that serial interface and FEL connectors will be soldered on the board for easy debugging and recovery. The FEL recovery port allows to reflash the board using Livesuit. As a side note, Henrik, a developer involved in Allwinner A10 software development, has done some work to reverse engineer FEL USB protocol, wrote a small program to enter into Livesuit mode with an SD card (Go to the bottom of the page section “Forcing FEL boot mode without bsp/recovery/usbboot button” for details) and the fel […]

Editing AllWinner A10 Board Configuration Files (script.bin)

AllWinner A10 based devices all have board configuration files in binary format, sometimes refereed to as script.bin, evb.bin, sys_config.{product_nane}.bin store in the FAT partition with the kernel. You may want to decode those binary files to configure your hardware and/or disable/enable peripherals. For the Ubuntu image provided for the Mele A1000 set-top box, the file is called evb.bin and the two other files (mele.bin and sys_config1.mele_mod.bin) are not used. The filename can change since it is configurable in u-boot e.g.: load1=fatload mmc 0 43000000 evb.bin bootcmd=run load1 boot_mmc If you want to decrypt the binary files into text format (fex), you can retrieve bin2fex tool: git clone https://github.com/amery/sunxi-tools Build it: cd sunxi-tools make This will compile both bin2fex (binary to fex text files) and fex2bin (fex files to bin), but the later does not seem to work right now. fex2bin also works now. If you want to decrypt a configuration files type this command line: ./bin2fex evb.bin > evb.fex The […]

55 USD 7″ Capacitive Touch Screen Android 4.0 Tablet Based on Allwinner A13

YOOE, a Chinese manufacturer, has designed a new Android 4.0 (ICS) tablet with a 7″ 5-point capacitive touch screen (1024×600) for about 55 USD (Factory price MOQ: 1000). This tablet is powered by AllWinner A13 (Cortex A8) processor, a cut down version of the AllWinner A10 without HDMI output nor SATA. This white brand tablet also features a 2,600 mAh battery which should last over 4 hours in typical usage and a front camera. The full specifications do not appear to be available right now. You can watch the video below to have a look at the device whose performance seems acceptable. Charbax also said the company expects the price to drop further to around 300 CNY (47 USD) by June 2012. If you are an individual interested to buy this tablet close to factory price (excluding shipping), charbax organizes group buying on his blog, just leave a comment over there if you are interested. [Update: I wonder if this could […]

Mele A2000 Android 2.3 Media Player Powered by AllWinner A10

Last month, I ordered a Mele A1000 in order to hack it to run Linux as it uses the same processor – the Cortex A8/Mali-400MP based AllWinner A10 – as the one planned for the low cost Rhombus Tech board. I have yet to receive the device, but Mele (迈乐) has already released  the Mele A2000, an Android 2.3 set-box box also powered by AllWinner A10. Here are Mele A2000 specifications: CPU: ARM Cortex A8 AllWinner A10 @ 1 GHz (It can be apparently be overclocked up to @ 1.5GHz) GPU: Mali 4000 Memory: DDR3 512MB RAM / 4GB Nand Flash OS System: Android 2.3.4 (Upgradable to Android 4.0) External Storage: Supports SD card up to 32GB, supports 2.5″ SATA HDD up to 1TB, Supports max 16GB USB flash disk Video codecs: HD MPEG-1/2/4. H.264. HD AVC/VC-1, RM/RMVB, Xvid/DviX 4/5/6, RealVideo 8/9/10, VP6 Video Formats: ts, m2ts, tp, trp, mkv, mp4, mov, avi, rm/rmvb, wmv, vob, asf, flv, dat, mpf and […]

Mele A1000: AllWinner A10 (Cortex A8) Based Hackable Android STB

The Mele A1000 is an Android 2.3 IP Set-top Box (STB) powered by AllWinner A10 (Cortex A8) CPU with 512 MB RAM and 2 GB NAND Flash.  AllWinner A10 is the CPU to be used by the 15 USD (BOM Cost) Rhombus Tech Linux Computer, an alternative to the Raspberry-Pi. Since they do not have an alpha board yet, the Mele A1000 STB is apparently the development platform chosen by developers involved in Rhombus Tech low cost board while they wait for the hardware. Let’s have a look at the device specifications: CPU: ARM CortexA8 1GHz (AllWinner A10) Memory: DDR3 512MB RAM / 2 4GB Nand Flash OS System: Android 2.3 External Storage: Supports SD card up to 32GB, supports 2.5″ SATA HDD up to 1TB, Supports max 16GB USB flash disk Video coding: HD MPEG1/2/4.H.264.HD AVC/VC-1,RM/RMVB, Xvid/DviX4/5/6, RealVideo8/9/10, VP6 Video Format: ts/m2ts/tp/trp/mkv/mp4/mov/avi/rm/rmvb/wmv/vob/asf/flv/dat/mpf/mpeg Audio Format: MP3/WMA/WMV/OGG/FLAC/MKV Subtitle Format: SRT/SMI/SSA/ASS Network interface: RJ45(10/100Mbps) WiFi: 802.11b/g/n Interfaces: SD/SDHC + 3 x USB […]

AllWinner A10/A1X Processor Resources, Development Board and SDK

AllWinner A10 (part of A1X series) is an ARM Cortex A8 SoC targetting multimedia products such as tablets, HD STB or digital signage. It is currently found in some low cost Android tablets such as Momo9C and will be used in Rhombus Tech’s Raspberry Pi alternative. The processor features an ARM Cortex A8 clocked at 1.5 Ghz with a Mali-400 GPU. It can support 1080p encoding/decoding, provides HDMI, Component, Composite, VGA and LVDS video outputs,  USB2.0 ports, a SATA 2.0 port and more… Here are the key features of the Allwinner A10: VPU (Video Processing Unit) HD Video Decoding (Super HD 2160P/3D Film) Support all popular video formats, including VP8, AVS, H. 264 AVC, VC-1, MPEG-1/2/4, … HD Video Encoding (H.264 High Profile) Support encoding in H.264 format DPU (Display Processing Unit) MULTI-CHANNEL HD displays Built-in HDMI YPbPr, CVBS, VGA LCD interfaces: CPU, RGB, LVDS up to Full HD Memory DDR2,DDR3 SDRAM, 32-bit SLC/MLC/TLC/DDR NAND Connectivity USB2.0 Port CSI (Camera […]

15 USD ARM Cortex A8 Linux Computer by Rhombus Tech

Many of you already probably know the Raspberry Pi Foundation 25 USD ARM Linux Computer. Rhombus Tech, another non-profit organization, is planning to design a 15 USD ARM Linux computer (excluding casing, power supply, shipping, VAT and custom duties) that the company claims would be at least 3 times faster that the Raspberry Pi. This computer would be an EOMA-PCMCIA CPU card powered by an Allwinner A10 ARM Cortex A8 CPU clocked at 1.5ghz. Here are the (expected) specifications of this board: Approximately Credit-card size format (56mm x 90mm) An Allwinner A10, 1.5ghz ARM Cortex A8 1GB of RAM At least 1gb of NAND Flash (possibly up to 16gb) Operation as a stand-alone computer (USB-OTG powered) 2160p (double 1080p) Video playback MALI 400MP 3D Graphics, OpenGL ES 2.0 compliant. HDMI, Micro-SD, Headphones Socket, EOMA-PCMCIA-compliant interfaces (RGB/TTL, I2C, USB2, SATA-II, 10/100 Eth) Expansion Header (similar to Beagleboard, IMX53QSB, Origen etc.) With this kind of specifications, it’s hard to believe they’ll achieve their […]
