June 23, 2017 by Jean-Luc Aufranc (CNXSoft) - 9 Comments

GR-LYCHEE Development Board to Combine Renesas RZ/A1LU Processor, ESP32 Module, and a VGA Camera

Japanese semiconductor vendors have mostly stayed away from the maker market, at least outside Japan, as most people would be hard-pressed to come up with a hobbyist development board powered by processor or micro-controller from Toshiba, Sony, Renesas or other Japanese companies, despite the three aforementioned names being in the top 20 semiconductors companies. I can only remember having written about Fujitsu F-Cue 96Boards, as well as Renesas GR-PEACH mbed board since I started this blog 7 years ago. Renesas seems to be the only company to have a real community behind with their “Gadget Renesas” pink-colored development boards, and the latest and seventh board is GR-LYCHEE powered by Renesas RZ/A1LU ARM Cortex-A9 processor, and equipped with a WiFi & Bluetooth module, and a camera. Renesas GR-LYCHEE board preliminary specifications: Micro-processor – Renesas RZ / A1LU (R7S721030VCFP 176-pin QFP) ARM Cortex-A9 Processor @ 384 MHz with 3MB on-chip SRAM Storage […]

June 16, 2017June 16, 2017 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

HD3S Android-on-TV Box with HD Webcam is Powered by Amlogic S905X Processor

What I call “Android-on-TV” boxes are some sort of TV boxes, usually with a webcam, that are meant to be placed on top of the TV instead of on the furniture, and apart from being used to watch videos like other TV boxes, are also well-suited for videoconference over Skype or Google Hangout. Over the years. we’ve had a few of those products such as HD23 TV box, but recently I don’t recall having seen new Android-on-TV boxes. That’s until today, and I found out about HD3S TV box running Android 6.0 on Amlogic S905X processor. HD3S specifications: SoC – Amlogic S905X quad core ARM Cortex-A53 @ up to 1.5GHz with a penta-core Mali-450MP GPU System Memory – 1GB DDR3 Storage – 8GB eMMC flash + micro SD card slot up to 64GB Video Output – HDMI 2.0a up to 4K @ 60 Hz, and AV port (composite video) Audio […]

May 23, 2017May 23, 2017 by Jean-Luc Aufranc (CNXSoft) - 10 Comments

RAK WisCam is a $20 Arduino Compatible WiFi Camera Linux Board Powered by Nuvoton N32905 ARM9 Processor

A couple of weeks ago I wrote about Rakwireless’ RAK CREATOR Pro development board based on Realtek Ameba RTL8711AM Wireless MCU, and part of their Wiskey family of development boards. Sub-family include WisNode for IoT boards, WisAP for OpenWrt boards, WisPLC for PLC hardware, and WisCam for WiFi video camera boards. The company has recently introduced Wiscam RAK5281 Arduino compatible Linux board powered by a Nuvoton ARM9 MCU, and supporting a camera module or an SD card + USB module. RAK WisCam specifications: SoC – Nuvoton N32905R3DN ARM926EJ processor @ 200 MHz with 8KB internal SRAM, 16KB IBR internal booting ROM, 16Mbit x16 DDR2 memory Storage – 128 MBit SPI flash, included sub-module adds micro SD card Connectivity – 802.11 b/g/n WiFi via Realtek RTL8189FTV module Camera via sub-module 648×488 pixel VGA CMOS Image Sensor (GC0308); 102° FOV Video – QVGA (320×240) 30FPS, VGA(640×480) 30FPS, MJPEG encoding Photo – JPEG, […]

May 22, 2017May 22, 2017 by Jean-Luc Aufranc (CNXSoft) - No Comments

$399 Intel Euclid Robotics Devkit Runs Ubuntu & ROS on Intel Atom x7-Z8700 Processor

We’ve seen many mini PC based on Intel Atom x5/x7 “Cherry Trail” processor in the last year, but Intel has also integrated their low power processor into hardware aimed at robotics, such as Intel RealSense development kit based on Atom x5 UP Board and RealSense R200 depth camera. The company has now launched its one-in-all Intel Euclid development kit combining Atom X7-Z8700 processor with a RealSense camera in a single enclosure. Intel Euclid specifications: SoC – Intel Atom x7-Z8700 Cherry Trail quad core processor @ up to 2.4GHz with Intel HD Graphics Gen 8 System Memory – 4GB LPDDR3-1600 Storage – 32GB eMMC 5.0 flash, Micro SD slot up to 128GB Video Output – micro HDMI port up to 4K @ 30 Hz Audio – 2x I2S interfaces, 1W mono speaker, 3x DMIC with noise cancellation Camera – Intel RealSense ZR300 camera RGB camera – 2MP up to 1080p@30fps, 16:9 […]

May 16, 2017 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

HTC U11 Android Smartphone Adds “Edge Sense” Squeeze Input, Ranks Best at DxOMark Mobile Camera Benchmark

We’ve come so far in the smartphone market that most hardware releases are rather boring with a processor a little faster, maybe a higher resolution screen and so on, without real exciting innovations. HTC U11 does change that somewhat as the smartphone allows to interaction by squeezing the edges for example to quickly take a picture. The company calls that “Edge Sense” technology. HTC U11 specifications: SoC – Qualcomm Snapdragon 835 octa-core processor @ up to 2.45 GHz System Memory – 4GB / 6GB RAM Storage – 64GB / 128GB flash, micro SD slot up to 2TB (shared with SIM2 slot), flex storage (aka adoptable) supported Display – 5.5″ Quad HD (2560 x 1440 pixels) Super LCD; 3D Corning Gorilla Glass 5 Cellular Connectivity Dual nano SIM 2G/2.5G – GSM/GPRS/EDGE @ 850/900/1800/1900 MHz 3G – UMTS @ 800/900/1900/2100 (B5/B8/B2/B1), HSDPA 42, HSUPA 5.76 4G LTE – Cat 15 LTE up […]

April 30, 2017April 30, 2017 by Jean-Luc Aufranc (CNXSoft) - 6 Comments

GPU Accelerated Object Recognition on Raspberry Pi 3 & Raspberry Pi Zero

You’ve probably already seen one or more object recognition demos, where a system equipped with a camera detects the type of object using deep learning algorithms either locally or in the cloud. It’s for example used in autonomous cars to detect pedestrian, pets, other cars and so on. Kochi Nakamura and his team have developed software based on GoogleNet deep neural network with a a 1000-class image classification model running on Raspberry Pi Zero and Raspberry Pi 3 and leveraging the VideoCore IV GPU found in Broadcom BCM283x processor in order to detect objects faster than with the CPU, more exactly about 3 times faster than using the four Cortex A53 cores in RPi 3. They just connected a battery, a display, and the official Raspberry Pi camera to the Raspberry Pi boards to be able to recognize various objects and animals. The first demo is with Raspberry Pi Zero. […]

April 25, 2017June 18, 2018 by Jean-Luc Aufranc (CNXSoft) - No Comments

ARM Introduces Mali-C71 ISP (Image Signal Processor) for Automotive Applications

A camera in an embedded system is normally connected to an ISP (image signal processing) block inside an SoC to handle the data coming from the sensor, and with recent cars now requiring more and more cameras for car DVRs, car parking systems, and self-driving vehicles, ARM has now unveiled Mali-C71 ISP specifically designed for automotive applications with support for 4 real-time cameras and 16 camera streams with a single pipeline. ARM explains that you can’t simply use smartphone cameras in automobile, as automotive requirements in terms of clarity and reliability are much more stringent. For example, Mali-C71 supports UWDR (Ultra-wide dynamic range) up to 24 stops, against 15 stops for the best DSLR cameras, which removes noise and process multiple exposures from the camera, and allows the processor/computer vision engine to detect objects such as a pedestrian, while others systems may not detect it. The image is also much […]

April 16, 2017 by Jean-Luc Aufranc (CNXSoft) - 13 Comments

Wandboard QuadPLUS Development Board Gets i.MX 6QuadPlus Processor, 802.11ac WiFi and Bluetooth 4.1

The first Wandboard development boards launched in 2012 nearly 5 years ago based on Freescale i.MX6 Solo and Dual processor, with Wandboard Quad launched a few months later. The boards were fairly popular at the time due to their better specifications, and especially Freescale’s much better documentation and software compared to the competition such as Broadcom (Raspberry Pi) and Allwinner (Cubieboard). Since the boards are based on TechNexion EDM system-on-modules they could also be used by companies working on their own products based on the system-on-module. It’s also a good platform if you want to test various version of Android, because the company released Jelly Bean, Kitkat, Lollipop, and Marshmallow images for the boards, and I’m expecting a Lollipop version soon. However, albeit the company worked on other NXP boards such as PICO-IM6UL Android Things, there had not been any hardware upgrade for Wandboard for nearly 4 years, but last […]
