Intel Compute Card Apollo Lake and Kaby Lake SKUs, Block Diagrams, and Specifications

Intel Compute cards are the latest ultra-thin CPU cards introduced by Intel at the beginning of the year, with a concept similar to EOMA68 CPU cards, that it to allow  CPU card upgrades or replacements, and interoperability across compatible devices such as smart kiosks, IoT gateways, and so on. But at the time, Intel did not reveal that many details about the different cards, although we know NexDock is working on laptop dock compatible with Intel Compute Cards. But I’ve recently received some block diagrams for Apollo Lake Pentium/Celeron, and Kaby Lake Core M/Core i5 compute cards.There will two SKUs for Apollo Lake compute cards sharing the same specifications, except for the processor: SoC CD1C64GK SKU – Intel Celeron N3450 quad core processor @ 1.1 / 2.2 GHz (base/turbo) with 12EU Intel HD Graphics Gen9; 7.5W TDP CD1P64GK SKU – Intel Pentium N4200 quad core processor @ 1.1 / 2.5 GHz […]

Intel To Make Thunderbolt 3 Royalty-free, Release Specifications

Intel Thunderbolt 3 is a single port connect that supports multiple standards (Thunderbolt, USB 3.1, DisplayPort, PCIe), leverages USB-C connector, and offers up to 40 Gbps throughput. So far, it’s mostly found in higher end computers and laptops, but Intel has now announced plans to make it royalty-free, and “release the  specifications to the industry” (so maybe not completely free/public) in order to increase adoption of the standard. Thunderbolt-3 main features: Thunderbolt, USB, DisplayPort, and power on USB-C USB-C connector and cables (small, reversible) 40 Gbps Thunderbolt 3 – double the speed of Thunderbolt 2 Bi-directional, dual-protocol (PCI Express and DisplayPort) 4 lanes of PCI Express Gen 3 8 lanes of DisplayPort 1.2 (HBR2 and MST) Supports two 4K displays (4096 x 2160 30bpp @ 60 Hz) USB 3.1 (10 Gbps) – compatible with existing USB devices and cables DisplayPort 1.2 – compatible with existing DisplayPort displays, devices, and cables […]

Zotac CI327 Nano Apollo Lake Fanless mini PC Features HDMI 2.0, DisplayPort 1.2, and VGA Video Outputs

While many Apollo Lake mini PCs have been launched, few support 4K @ 60 Hz video output, but Zotac CI327 Nano mini PC does even better than that thanks to HDMI 2.0 and DisplayPort 1.2 outputs allowing for dual 4K UHD @ 60 Hz setups, and it also adds an extra VGA port to enable triple display setups. The rest of the specifications are not too bad either with three models CI327 Nano (windows / no windows) and CI327 Nano Plus with slightly different hardware specifications: SoC – Intel Celeron N3450 quad-core  processor @ 1.1GHz / 2.2GHz with Intel HD Graphics 500 System Memory Nano with Windows and Nano PLUS – 4GB DDR3L (one slot occupied, up to 8GB) Nano – 2x 204-pin DDR3L-1866 SO-DIMM slots (up to 8GB) Storage – 1x 2.5″ SATA 6.0 Gbps SSD/HDD slot; 3-in-1 (SD/SDHC/SDXC); Nano with WINDOWS only: 32GB M.2 on-board SATA SSD Video […]

Targus Universal DisplayLink Docking Stations Support Up to Six 4K Monitors via a Single USB Cable

USB type C connectors are becoming more and more common and beside transmitting data and power, some devices also support video over USB which requires a dock, and if you have some serious display requirements, Targus docking stations over USB-C or USB 3.0 might be what you are looking for, as they support two 4K monitors at the same time thanks to their multiple HDMI 2.0, DisplayPort 1.2a and DVI outputs, and you can even daisy-chain three docking stations over USB 3.0 type A cables in order to control six 4K monitors from one USB port. Targus has several models, but let’s check out the specifications of their “USB 3.0 DV4K DOCK160USZ dock station” pictured above: Chipset – DisplayLink DL-6950 Video Output Ports – 2x HDMI 2.0 ports, 2x DisplayPort 1.2a ports supporting up to dual 4K Ultra HD video @ 4096×2160 60Hz 24 bpp Audio – 1x 3.5 mm […]

Firefly-RK3399 Rockchip RK3399 Development Board Launched on Kickstarter for $139 and Up

Firefly-RK3399 is the first, and for now the only one, development board equipped with the latest Rockchip RK3399 hexa-core Cortex A72 & A53 processor. It’s just not available yet, but the board has now been launched on Kickstarter where it is offered for $139 to $199 depending on options. Firefly-RK3399 board specifications: SoC – Rockchip RK3399 hexa-core big.LITTLE processor with dual core ARM Cortex A72 up to 2.0 GHz and quad core Cortex A53 processor with ARM Mali-T860 MP4 GPU with OpenGL 1.1 to 3.1 support, OpenVG1.1, OpenCL and DX 11 support System Memory Standard – 2 GB DDR3 Plus devkit – 4 GB DDR3 Storage Standard – 16 GB eMMC flash, micro SD card, M.2 socket Plus devkit – 32 GB eMMC flash, micro SD card, M.2 socket Video Output & Display Interfaces 1x HDMI 2.0 up to 4K @ 60 Hz 1x DisplayPort (DP) 1.2 interface up to […]

Zotac PI330 Cherry Trail mini PC Supports Dual Monitor Setups with HDMI and DisplayPort Outputs

Several low power Intel mini PCs coming out of Chinese manufacturers support dual monitor setups, but usually they combine HDMI and VGA with models such as Vorke V1 or MeLE PCG03. Zotac PI330 mini PC powered by an Intel Atom x5-Z8500 processor offers instead dual independent display support via HDMI and DisplayPort connectors. Zotac PI330 hardware specifications: SoC – Intel Atom x5-Z8500 quad core processor @ 1.44 GHz / 2.24 GHz) with 2M Cache and Intel Gen8 Graphics System Memory –  2GB LPDDR3 Storage – 32GB eMMC flash + micro SD/SDHC/SDXC card reader Video Output – DP1.1a, HDMI 1.4b Audio – DisplayPort, HDMI and 3.5mm headphone/microphone combo jack Connectivity – Gigabit Ethernet, 802.11ac WiFi and Bluetooth 4.0 USB – 1x USB 3.0 Type-C, 2x USB 3.0 port Misc – Power LED, Power Supply – 5V/3A Dimensions – 115 x 76 x 20.7 mm The fanless mini PC is pre-loaded with […]

DisplayPort 1.4 To Support 8K Displays over USB-C, 4K@120 Hz, 32 Audio Channels

Just as 4K UHD televisions are getting more affordable with prices ever closer to their Full HD equivalent, the Video Electronics Standards Association (VESA) has published DisplayPort 1.4 specifications with support for 8K QUHD (7680 x 4320) resolution, High Dynamic Range (HDR), video compression and more. Some of the key enhancements or new features of the new specifications include: Up to 8Kp60Hz HDR deep color and 4Kp120Hz HDR deep color Display Stream Compression (DSC) – DSC 1.2 natively supports YCbCr 4:2:0 and 4:2:2 coding, and offers nearly lossless 3:1 compression ratio Forward Error Correction – FEC, which overlays the DSC 1.2 transport, addresses the transport error resiliency needed for compressed video transport to external displays. HDR meta transport – HDR meta transport uses the “secondary data packet” transport inherent in the DisplayPort standard to provide support for the current CTA 861.3 standard, which is useful for DP to HDMI 2.0a protocol […]

More Details about Rockchip RK3399 Cortex A72 SoC: 4K H.264/H.265/VP9, USB 3.0, PCIe, and DisplayPort

We already knew Rockchip RK3399 was going to be a powerful processor with two Cortex A72 cores clocked at up to 2.0GHz, and four Cortex A53 cores teamed with a Mali-T860MP4 GPU. The processor was also said to support 4K H.265 video decoding up to 60 fps, HDMI 2.0 video output, and Gigabit Ethernet. But the company is now at Mobile World Congress 2016, and has disclosed more details. Some of the newly introduced features include: Multi-media 4K @ 60fps 10-bit H.265/H.264/VP9 video decoder 1080p video encoding with H.264 or VP8 Display HDMI 2.0 with HDCP 1.4/2.2 DisplayPort 1.2 and eDP 1.3 with PSR (Panel Self Refresh) Dual channel MIPI-DSI Camera – 8MP ISP, dual channel MIPI-CSI2 External Interfaces 2x USB 3.0 ports with type-C support PCIe 2.1, 4 lanes, 5Gbps per lane 8 channels TX/RX audio for playback and record Embedded low power MCU for other applications (power control?) […]
