Freescale LS1021A-IOT IoT Gateway Reference Design Powered by QorIQ LS1021A Dual ARM Cortex A7 SoC

Freescale has just launched a an IoT gateway reference design powered by their QorIQ LS1021A communication processors running Linux/OpenWRT, designed in partnership with TechNexion, and targeting various IoT applications such as building/home management, smart cities, networked industrial services, etc… Beside the dual core Cortex A7 QoirIQ processor, the board features six Gigabit Ethernet ports, two USB 3.0 ports, a SATA 3 port, two mini PCIe connector, an LVDS interface, HDMI output, Arduino UNO compatible headers, and various others expansions headers. LS1021A-IOT IoT gateway Specifications: SoC – Freescale QorIQ LS1021A dual core Cortex A7 communication processor @ 1 GHz (5,000 coremarks) MCU – Freescale Kinetis K20 Cortex M micro-controller System Memory – 1 GB DDR3L Storage – 1 Gb QSPI NOR Flash, SDHC slot (up to 32 GB) populated with a 4GB SD card, 1x mSATA 3 slot Connectivity – 6x Gigabit ports via SGMII (Serial Gigabit Media Independent Interface) and RGMII (Reduced Gigabit Media Independent Interface) interfaces Display I/F 24-bit […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

Freescale To Give Away StarterTRAK Development Boards for Automotive Applications

Freescale StarterTRAK development boards are based on the company’s Kinetis EA Cortex M0+ MUCs or Qorivva 32-bit MCU targeting automotive applications with support a wide temperature range (–40° to +125°C) and interfaces such as LIN (Local Interconnect Network) and CAN. These development boards can be used for body and security, powertrain, and safety & chassis applications. Freescale has decided to giveaway 60 StarterTRACK development board to random winners, so if you are knowledgeable in this field it could be an opportunity to try the platform. There will be 5 different kits given away, all based on Kinetis MCU: TRK‐KEA8, TRK‐KEA64, TRK‐KEA128, KEA128LEDLIGHTRD and KEA128BLDCRD. Let’s have a closer look at TRK-KEA128 development board. Key features and specifications of  TRK-KEA128 board: MCU – Kinetis KEA128 ARM Cortex M0+ MCU @ 48MHz with 16KB RAM and 128KB flash in a 80 LQFP package On-board openSDA debugging and programming circuit using the PK20DX128 MCU LIN communications interface Analog interface with ambient light sensor 4 […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

Freescale WaRPBoard Reference Platform for Wearables is Now Available for Pre-order

Back in January, Freescale announced WaRP (Wearable Reference Platform) comprised of the WaRPboard, a tiny board based on Freescale i.MX 6SoloLite running Android, and a daughter board with KL16 Cortex M0+ MCU and several sensors. The company collaborated with Revolution Robotics for the hardware design, and Kynetics for the software, and the platform is now available for pre-order for $149, and a few more details have surfaced since my first article. The hardware specifications of WaRP are as follows: WaRPboard: SoC – Freescale i.MX 6SoloLite Cortex A9 processor @ 1GHz with 2D graphics Vivante GC355 and  GC320 GPUs. System Memory – LPDDR2 (Micron Multi-Chip Package) Storage – 4Gbit eMMC  (Same Micron MCP chip as for RAM) Connectivity – WLAN and Bluetooth 4.0 LE via Murata LBEH17YSHC Display I/F: MIPI DSI for LCD display + touchscreen EPCD for E-Ink Display Sensors – Xtrinsic FXOS8700CQ, 6-Axis Sensor with Integrated Linear Accelerometer and Magnetometer. Daughtercard: MCU – Freescale Kinertis KL16 Cortex M0+ MCU Sensors – […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

ARM TechCon 2014 Schedule – 64-Bit, IoT, Optimization & Debugging, Security and More

ARM Technology Conference (TechCon) 2014 will take place on October 1 – 3, 2014, in Santa Clara, and as every year, there will be a conference with various sessions for suitable engineers and managers, as well as an exposition where companies showcase their latest ARM based products and solutions. The detailed schedule for the conference has just been made available. Last year,  there were 90 sessions organized into 15 tracks, but this year, despite received 300 applications,  the organizers decided to scale it down a bit, and there will be 75 session in the following 11 tracks: Chip Implementation Debugging Graphics Heterogeneous Compute New Frontiers Power Efficiency Safety and Security Software Development and Optimization Software Optimization for Infrastructure and Cloud System Design Verification There are also some paid workshops that take all day with topics such as “Android (NDK) and ARM overview”, “ARM and the Internet of Things”, or “ARM Accredited Engineer Programs”. As usual, I’ve gone through the schedule […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

Thread is a New IP-based Wireless Protocol Leveraging 6LoWPAN and 802.15.4 Standards

Wi-Fi is a neat way to connect devices to Internet, but it has two main inconveniences: relatively high cost and power consumption. Luckily there are standards that addresses the cost and power consumption issues. Radio chips based on IEEE 802.15.4, a standard which specifies the physical layer and media access control for low-rate wireless personal area networks, are common place and found in many existing devices relying on higher level wireless protocols such as ZigBee, ISA100.11a, WirelessHART, and MiWi. AFAIK, Zigbee is the most popular of the aforementioned protocols, but is hindered by the requirements of the license for commercial products (annual fee), Zigbee membership requirements conflict with many open source license such as GPL, and the standard suffers from lack of interoperability and IPv6 support, and power requirements that are too high for some applications. So a consortium of seven companies namely ARM, Big Ass Fans, Freescale, Nest, Samsung, Silicon Labs, and Yale Security, have come together to start […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

EzeeCube is a Modular XBMC Media Hub with Up to 9TB Storage (Crowdfunding)

EzeeCube is a media hub that automatically synchronizes photos, videos and contacts from your iOS and Android phones or tablets. The hardware is based on Freescale i.MX6 Dual SoC, includes a 1 TB hard drive upgradable to 9TB with 4 extra drives, can be upgraded with hardware modules, and runs a custom version of XBMC on top of Linux built with the Yocto Project. EzeeCube specifications: SoC – Freescale i.MX6 Dual with two ARM Cortex A9 cores @ 1 GHz and Vivante 3D GPU System Memory – 1GB DDR3 @ 1066MHz Storage – 4GB eMMC,  1TB 2.5″ hard drive @ 5400rpm, and SD/SDXC card slot Connectivity – Gigabit Ethernet, 802.11n Wi-Fi (2.4GHz), and Bluetooth 3.0 Video Output – HDMI 1.4 with CEC support Audio Output – HDMI and optical S/PDIF Video Containers – AVI, MPEG, WMV, ASF, FLV, MKV/MKA, QuickTime, MP4, M4A, AAC, NUT, OGG, RealMedia RAM/RM/RV/RA/RMV8, OGM, 3gp, VIVO, PVA, NUV, NSV, NSA, FLI, FLC, DVR-MS and WTV Video […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

Novena Open Source Hardware ARM Laptop Gets Crowdfunded for $1995

In 2012, Andrew Huang (“Bunnie”) decided to build an open source hardware and software laptop codenamed Novena powered by Freescale i.MX6 as a side project. The goal of the project was to be fully open source, both in terms of hardware and software, and the components have been selected so that the datasheets can be downloaded without NDA. Design has now been completed, and a crowdfunding campaign has now been launched on Crowd Supply, but since finding low cost part was not priority, you’ll have to fork $1,995 to get the complete laptop, $1,195 will get you the desktop version, and $500 the motherboard only. There’s also a version of the laptop called “Heirloom Laptop” with a hand-crafted wood and aluminum case that goes for $5,000. Let’s go through the board specs first: SoC – Freescale iMX6 Quad-core Cortex A9 CPU with NEON FPU @ 1.2 GHz. – NDA-free datasheet and programming manual System Memory – 64-bit, DDR3-1066 SO-DIMM slot. […]

Support CNX Software – Donate via PayPal, become a Patron on Patreon, or buy review samples

Meet Freescale Kinetis KL03, the Smallest Ever ARM MCU

Last year at Embedded World 2013, Freescale announced Kinetis KL02, an ARM Cortex M0+ MCU measuring just 1.9 x 2.0mm. Customer must have complained that it’s not small enough, as the company has just unveiled Kinetis KL03 MCU, 15% smaller or 1.6 x 2.0 mm, at Embedded World 2014. Just like its predecessor KL03 targets space-constraint IoT applications such as ingestible healthcare sensing, portable consumer devices, remote sensing nodes, and wearable devices.   Kinetis KL03 MCU features include: 48 MHz ARM Cortex-M0+ core, 1.71-3.6V operation Bit manipulation engine for faster, more code-efficient handling of peripheral registers 8 to 32 KB flash memory, 2 KB RAM, 8K ROM with on-chip boot loader High-speed 12-bit ADC Internal voltage reference for high ADC accuracy High-speed analog comparator Up to 22 GPIOs with pin interrupt support Low-power UART, SPI, I2C (high speed) Low power wake up Secure real time clock Timers for a broad range of applications including motor control -40 °C to +85 °C operation […]
