Getting Started with LinkIt ONE Development Kit for Wearables & IoT

After going through WRTnode Quick Start Guide, it’s now time to play with LinkIt ONE, the IoT development board from Mediatek designed by Seeed Studio. LinkIt ONE is the first Hardware Development Kit (HDK) for Mediatek LinkIt, so there may be a LinkIt TWO, and/or other hardware platforms in the future. LinkIt ONE specifications Let’s quickly go through the specifications first: Processor – Mediatek MT2502A (Aster) ARM7 EJ-STM processor @ 260 MHz System Memory – 4 MB Storage – 16MB Flash for firmware + micro SD slot shared with SIM slot for up to 32GB additional storage Connectivity: Wi-Fi – 802.11 b/g/n (MT5931) with external antenna Bluetooth – BR/EDR/BLE(Dual Mode) GPS – Mediatek MT3332 with external antenna GSM/GPRS – 850/900/1800/1900 MHz band, Class 12 GPS with external antenna Audio – 3.5mm headphone jack (including mic support) – Support for MP3, AAC, and AMR codecs. Serial – Software Serial (Serial), and […]

Mediatek Releases Linux Source Code for Android One Smartphones

Android One is a program by Google aiming at bringing low cost smartphones to the emerging markets with firmware updates to the latest Android version guaranteed for two years. Three phones part of Android One program have recently been announced for the Indian market: Micromax Canvas A1, Karbonn Sparkle V, and Spice Dream Uno, and Android One phones will be available in Indonesia, the Philippines and South Asia (Bangladesh, Nepal, Pakistan, and Sri Lanka) by the year of the year. The three phones currently available sell for $100, which based on the specs (quad core processor, 1GB RAM, 4GB flash, 4.5″ display) is not exactly an aggressive pricing compared to what is already available from Aliexpress, but the main advantage here is clearly Google support with promised firmware updates, and currently Android 4.4.4. All these phones appear to be powered by Mediatek MT6582, and company decided to release the Linux […]

xWifi Open Source Hardware Wi-Fi Module and Dock for the Internet of Things (Crowdfunding)

For some reasons, Wi-Fi modules are pretty popular this year. After modules such as VoCore, AsiaRF AWM002, and ESP8622, here’s come xWifi. This module is based on Mediatek MT7681 SoC which includes a TCP/IP stack like Espressif ESP8622 or TI CC3300, so it won’t run OpenWRT like VoCore or AsiaRF modules. The module only consumes about 350mW during transfer, it will be open source hardware, and the xWifi module plus a dock with a 10A relay, a humidity and temperature sensor, and a LED will go for as low as $17. xWifi module only specifications: SoC – Mediatek MT7681 802.11 b/g/n SoC with 32-bit RISC CPU. Support for Client/softAP mode. Package size 5×5 mm Storage – 512KB SPI Flash (for firmware) I/Os via headers: UART and SPI interfaces. 5x GPIOs PWM Power – 3.3V, GND Power Consumption – ~70mA  @ 5V (during RX active) Dimensions – 14 x 17 mm The […]

More Details on Mediatek MT2502 Aster SoC and Linkit Platform for Wearables (Video)

Last month, Mediatek announced their Mediatek MT2502 SoC for wearables, codenamed Aster, as well as the Linkit development platform targeting the developer’s community. But at the time they did show the actual hardware, and thanks to Charbax we know have more interesting details about Aster and Linkit. First they compare a design based on Aster to Samsung Galaxy Fit wearable band, and show why it uses less space, will cost less, and they claim  over twice the battery life. Simple and smaller design (~36% reduction in size) Aster solution – MT2504 (6.2 x 5.4 mm) plus all required resistors, capacitors and inductors require 89.97 mm2 Galaxy Fit – MCU. Bluetooth Transceiver,  external memory, a linear charger, and all required resistors, capacitors and inductors require 140.97 mm2 Battery life – Samsung Galaxy Fit is supposed to last between 1 and 1.5 days on a charge, whereas devices based on Aster should last about […]

Mediatek MT6795 Octa Core ARM Cortex A53 Processor to Launch in Q4 2014

Mediatek had already announced two 64-bit ARM SoCs with MT6732 and MT6752 boasting respectively four and eight Cortex A53 cores for mainstream and premium smartphones. There are now reports that the company will launch an eight core 64-bit LTE SoC with HMP architecture. Since HMP (Heterogeneous Multi-Processing) is only used for big.LITTLE processing, and Mediatek does not have an history of making their own custom ARM cores, we can safely assume the processor will feature four Cortex A53 little core, and four Cortex A57 big cores. [Update: finally it’s eight ARM Cortex A53 cores, no HMP here]. What we know about MT6795 so far: Processor – 64-bit Octa core ARM Cortex A53 cores @ 2.2 GHz GPU- Imagination Technology G6200 @ 700 MHz Memory I/F – 2x LPDDR3 @ 933 MHz (PoP) Camera I/F – 20MP@30fps using a dual ISP Display – Up to WQXGA (2560×1600) Video Decoding – 4K2K […]

iNew V8 Smartphone Features Mediatek MT6591T Hexa Core Processor, and a Rotating Camera

In case you find four cores are not quite enough, but eight cores are just too many, Mediatek added MT6591 hexa core processor to its roadmap, and the first phones are starting to be up for pre-order. iNew V8 is an hexa core smartphone with a 5.5″ display, 1GB RAM, 16 GB flash, and an interesting camera that can rotate by up to 210 degrees, and can be used both as a rear and front facing camera. So no more low quality selfies at 2MP, and welcome to 13MP selfies with flash! 🙂 iNew V8 Specifications: SoC – Mediatek MT6591T hexa Cortex A7 processor @ 1.5GHz with Mali-450 MP GPU System Memory – 1GB RAM Storage – 16 GB flash + micro SD slot (up to 16? or 32GB) Display – 5.5″ IPS capacitive touchscreen (5 points) with 1280×720 resolution. Cellular Network – 2G: GSM 850/900/1800/1900MHz; 3G: WCDMA 850/2100MHz. Dual […]

Teclast P98 3G Tablet is Powered by Mediatek MT8135 big.LITTLE SoC

Several companies have announced processors with big.LITTLE processing technology, but until recently only some Samsung Exynos 5 processors (Exynos 5420, 5422, and 5260) are found in products available for purchase. Available a few weeks ago, Teclast P98 3G tablet changes that as it is powered by Mediatek MT8135 quad core processor featuring big.LITTLE processing. Teclast P98 3G specifications: SoC – Mediatek MT8135 (aka MTK8135) with two ARM Cortex A15 cores @ 1.5 GHz (1MB L2 cache), two ARM Cortex A7 cores @ 1.2 GHz (256KB L2 cache) in big.LITTLE configuration, and Imagination PowerVR GC6200 GPU System Memory –  2GB DDR3 Storage – 32GB eMMC (UP to 120 MB/s) + micro SD slot Display – 9.7″ 2048×1536 IPS screen Video Output – HDMI Audio – Earphone jack, and AAC stereo speakers Connectivity – WiFi 802.11b/g/n, Bluetooth 4.0, GPS, FM Cellular – Built-in 3G WCDMA modem and one SIM card slot (Not for Wi-Fi only version) USB – 1x […]

MediaTek Unveils LinkIt Platform with MT2502 Aster SoC for Wearables and IoT Applications

After Ineda Systems Dhanush SoC and SHASTRA Devkit, here’s another Wearable SoC and development kit for today with Mediatek announcement of their LinkIt platform providing both hardware and software to develop wearables and IoT applications using their Aster SoC for wearables. Key features of LinkIt platform listed on Mediatek Labs: MediaTek Aster (MT2502) measures only 5.4 x 6.2mm and is specifically designed for wearable devices Developer platform supported by reference designs that enable creation of various form factors, functionalities and internet connected services Synergies between microprocessor unit and communication modules, facilitating development and saving time in new device creation Modularity in software architecture provides developers with high degree of flexibility Supports over-the-air (OTA) updates for apps, algorithms and drivers Plug-in software development kit (SDK) for Arduino and VisualStudio; planned (Q4 2014) support for Eclipse Hardware Development Kit (HDK) based on LinkIt board by third party No details have been provided for […]
