alder lake

Posted on by Jean-Luc Aufranc (CNXSoft) - 34 Comments on Radxa X4 low-cost, credit card-sized Intel N100 SBC goes for $60 and up

Radxa X4 low-cost, credit card-sized Intel N100 SBC goes for $60 and up

Radxa X4 x86 Raspberry Pi 5 SBC

Radxa X4 is a credit card-sized Intel Processor N100 single board computer (SBC) that costs almost the same as a Raspberry Pi 5 with the 4GB RAM model going for about $60 and the 8GB RAM variant around $80. The x86 SBC offers many of the same features as the Raspberry Pi 5 including dual micro HDMI output, four USB 3.2/2.0 ports, Ethernet and WiFi networking, and the 40-pin GPIO header handled through a Raspberry Pi RP2040 microcontroller.  Networking is better with 2.5GbE and WiFi 6, M.2 SSD support is built-in and four to eight times faster compared to PCIe HAT for the Pi 5, and the USB 3.2 ports are capable of 10 Gbps speed. So let’s little not too like, and the main downside is the lack of MIPI CSI and DSI connectors for projects requiring those camera and display interfaces. Radxa X4 specifications: SoC – Intel Processor […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 6 Comments on MW-100-NAS Intel N100 motherboard features six SATA ports, two M.2 PCIe sockets, 2.5GbE and 10GbE interfaces

MW-100-NAS Intel N100 motherboard features six SATA ports, two M.2 PCIe sockets, 2.5GbE and 10GbE interfaces

MW-100-NAS motherboard

The MW-100-NAS mini-ITX motherboard is powered by an Intel Processor N100 Alder Lake-N CPU and seems especially suited for NAS (networked-attached storage) applications with six SATA connectors, two M.2 Key-M sockets for NVMe drivers, one 10GbE port, and two 2.5GbE RJ45 jacks. The motherboard supports up to 32GB DDR5 memory, features HDMI and DisplayPort video output ports, a COM port header, and plenty of external and internal USB interfaces. It takes power from a standard ATX connector. NW-N100-NAS motherboard specifications: SoC – Intel Processor N100 quad-core Alder Lake-N processor @ up to 3.4 GHz (Turbo) with 6MB cache, 24EU Intel HD graphics @ up to 750 MHz; TDP: 6W System Memory – Up to 32GB DDR5-4800 via SO-DIMM socket Storage 2x M.2 sockets for NVMe SSDs onboard 6x SATA connectors MicroSD card slot Video Output – 1x HDMI, 1x DisplayPort  Networking 2x 2.5GbE RJ45 ports via Intel i226-V controllers 1x […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on AAEON AQ7-ADN – A Qseven 2.1 system-on-module with Intel Alder Lake-N CPU, four PCIe Gen 3 x1 interfaces

AAEON AQ7-ADN – A Qseven 2.1 system-on-module with Intel Alder Lake-N CPU, four PCIe Gen 3 x1 interfaces

AAEON AQ7-ADN Alder Lake-N Qseven system-on-module

AAEON AQ7-ADN is a Qseven 2.1-compliant system-on-module based on Atom Processors x7425E, Intel Processor N, or Intel Core i3-N305 Alder Lake-N processor equipped with up to 8GB LPDDR5x and 64GB of eMMC flash storage. AAEON has already introduced Alder Lake-N COM Express and SMARC modules with the COM-ADNC6 and uCOM-ADN respectively, and the AQ7-ADN adds another system-on-module standard to its list of Alder Lake N-Series modules with a Qseven 2.1 SoM that offers four PCIe Gen x1 interfaces and a SATA storage interface. AAEON AQ7-ADN specifications: Alder Lake N-series SoC (one or the other) Intel Atom x7425E quad-core processor up to 3.4 GHz with 6MB cache, 24EU Intel UHD Graphics @ 1.00 GHz; TDP: 12W Intel Processor N50 dual-core processor up to 3.4 GHz with 6MB cache, 16EU Intel UHD Graphics @ 750 MHz; TDP: 6W Intel Processor N97 quad-core processor up to 3.6 GHz with 6MB cache, 24EU Intel […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 10 Comments on ODROID-H3/H4 x86 SBCs get M.2 PCIe Gen 3 x4 expansion cards with two or four M.2 sockets

ODROID-H3/H4 x86 SBCs get M.2 PCIe Gen 3 x4 expansion cards with two or four M.2 sockets

ODROID-H4 M.2 4x1 card

ODROID-H3 and ODROID-H4 x86 single board computers have gotten two affordable M.2 expansion cards with the M.2 2×2 card adding two PCIe Gen 3 x2 slots and the M.2 4×1 adding four PCIe Gen 3 x1 slots (ODROID-H4 only) to the Intel SBCs. We’ve seen plenty of PCIe HAT+ boards for the Raspberry Pi 5 since the launch of the Arm SBC last year, but it’s limited by its PCIe Gen2/Gen3 x1 interfaces, and Hardkernel now provides two new M.2 cards leveraging the M.2 PCIe Gen3 x4 socket of the ODROID-H3/H4 family allowing users to add up to four M.2 PCIe modules for storage, wired or wireless connectivity, and/or AI acceleration. M.2 2×2 card  for ODROID-H3 and H4 series The M.2 2×2 card also named “M.2 – NVME” adds two M.2 Key-M PCIe sockets for 2280 size modules with each having a PCIe 3.0 x2 interface supporting up to 16GT/s. […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on DFI ASL9A2 COM Express Mini Type 10 module features Intel Atom x7000RE Amston Lake processor

DFI ASL9A2 COM Express Mini Type 10 module features Intel Atom x7000RE Amston Lake processor

DFI ASL9A2 COM Express Mini Type 10 Amston Lake module

DFI ASL9A2 is a COM Express Mini Type 10 module based on Intel Atom x7000RE Amston Lake processors which are pin-to-pin compatible with the Alder Lake-N Series processors and designed for the embedded market with a wider operating temperature range. The credit card-sized COM Express Mini module supports up to 16GB LPDDR5 memory, up to 128GB an eMMC flash, and exposes various interfaces such as 2.5GbE, PCIe Gen3, SATA 3.0, DDI and eDP/LVDS for dual display support, ten USB 3.2/2.0, and more. DFI ASL9A2 specifications: SoC (one or the other) Amston Lake Intel Atom x7211RE dual-core processor @ 1.0 to 3.2 GHz with 6MB cache, 16EU Intel UHD graphics; 6W TDP Intel Atom x7213RE dual-core processor @ 2.0 to 3.4 GHz with 6MB cache, 16EU Intel UHD graphics; 9W TDP Intel Atom x7433RE quad-core processor @ 1.5 to 3.4 GHz with 6MB cache, 32EU Intel UHD graphics; 9W TDP Intel […]

Posted on by Sponsored Post - No Comments on $60 coupon code for the GEEKOM Mini IT12 mini PC with Intel Core i7-12650H, 32GB RAM, 1TB NVMe SSD (Sponsored)

$60 coupon code for the GEEKOM Mini IT12 mini PC with Intel Core i7-12650H, 32GB RAM, 1TB NVMe SSD (Sponsored)

GEEKOM Mini IT12 $60 discount coupon code

GEEKOM is offering a $60 discount coupon code as part of a Prime Day promotion for the GEEKOM Mini IT12 mini PC powered by an Intel Core i7-12650H 10-core Alder Lake processor and equipped with 32GB DDR4 memory, a 1TB NVMe SSD, and an Intel AX211 WiFI 6E and Bluetooth 5.3 module. US customers can make use of the CNXIT12 $60 off coupon on GEEKOM US to get the mini PC for $489, and British users can also benefit from the same coupon on GEEKOM UK to purchase the mini PC for £489. GEEKOM Mini IT12 specifications: SoC – Intel Core i7-12650H 10-core/16-thread Alder Lake hybrid processor up to 4.70 GHz with 24MB Cache, 64 EU Intel UHD Graphics @ up to 1.4 GHz; PBP: 45W System Memory – 32 GB dual-channel DDR4-3200 via SODIMM sockets upgradeable up to 64GB Storage 1TB M.2 2280 PCIe Gen 4 x4 SSD, expandable […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 5 Comments on Cincoze DS-1402 review: Part 3: Ubuntu 24.04 tested on an Intel Core i9-12900E embedded system

Cincoze DS-1402 review: Part 3: Ubuntu 24.04 tested on an Intel Core i9-12900E embedded system

Cincoze DS-1402 Ubuntu 24.04 review

In part one of the Cincoze DS-1402 review, I checked out the hardware of the modular rugged computer before testing the Intel Core i9-12900E embedded computer with Windows 11 Pro in the second part, and I’ve now had time to test the Cincoze DS-1402 embedded system with Ubuntu 24.04. I’ve tested most features in Linux, ran some benchmarks, evaluated the gigabit Ethernet performance of some of the ten Ethernet ports, checked CPU temperature under a stress test with and without the fan, measured power consumption, and more. Ubuntu 24.04 system information I installed Ubuntu 24.04 with the official x86_64 ISO in dual boot configuration with Windows 11 Pro. The installation process was smooth, and I have nothing specific to report here. Going to the Settings->About window confirms we have a CINCOZE-DS-1400 system (DS-1402 is part of the DS-1400 family) with a 24-thread 12th Gen Intel Core i9-12900E processor and 64GB […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 5 Comments on Meenhong JX5 Intel N100 mini PC looks like a (thick) smartphone with a 5.5-inch touchscreen display

Meenhong JX5 Intel N100 mini PC looks like a (thick) smartphone with a 5.5-inch touchscreen display

MeenHong JX5 vs iPhone 15 Pro Max

Meenhong JX5 is another Intel N100 mini PC with an integrated touchscreen display, but the 5.5-inch Full HD LCD used in this smartphone-like model is even smaller than the 7-inch display found in the HIGOLE F9B Pro and SZBOX S7 variants. The JX5 is equipped with 12GB LPDDR5 soldered-on memory, an up to 2TB SSD, HDMI and USB-C ports for connecting larger displays, built-in stereo speakers and microphone, and a few USB ports. Network connectivity is provided by a gigabit Ethernet port and a Wi-Fi 6 and Bluetooth 5.2 module, and a G-sensor is used to automatically set the display to portrait or landscape mode. Meenhong JX5 specifications: SoC – Intel N100 quad-core Alder Lake-N processor @ up to 3.4 GHz (Turbo) with 6MB cache, 24EU Intel HD graphics @ 750 MHz; TDP: 6W System Memory – 12GB LPDDR5 4800 MHz Storage – Optional 128GB, 256GB, 512GB, 1TB, or 2TB […]
