Overview and List of System-on-Module and Computer-on-Module Standards – Q7, SMARC, COM HPC, and More

QSeven_vs_SMARC

A System-on-Module (SoM), also known as a Computer-on-Module (CoM), is a small board with the key components of a computer such as SoC, memory, and possibly others components such as PMIC (Power Management IC), an Ethernet PHY, as well as one or more connectors used to connect to a baseboard, also called carrier board, which features standard ports such as Ethernet (RJ45), USB ports, SATA, power jack and so on. The advantages of using of baseboard + SoM design compared to a single board are at least twofold: Most of the PCB design complexity is often around the CPU/SoC and high-speed buses connected to the CPU/SoC. So you could buy an SoM, design your own baseboard and get a complete design relatively in a short amount of time, with reduced development resources and costs. The design is modular, so you could easily upgrade from one SoM to another one. For […]

Toradex extends Torizon to Development and Operation (DevOps) Platform for IoT Linux Devices (Sponsored)

Torizon Platform DevOps Linux IoT Devices

Toradex is extending its Torizon to a full IoT Development and Operations (DevOps) Platform for Linux Devices, including free hosted remote updates, device monitoring, and fleet management solution. Torizon enables modern, iterative product development by seamlessly integrating hardware, a Linux OS, development tools, remote updates, and fleet operations. Thereby creating a scalable solution for devices requiring high reliability and security. In a paper from May 2021, Forrester Consulting finds that Traditional embedded development practices are insufficient when building smarter, digital products and that 79% of decision-makers say challenges with smart product development and delivery negatively impact their firms in delivering digital products. Torizon brings state-of-the-art product development principles to demanding applications in industries such as Industrial Automation, Healthcare, Smart City, and Transportation. Torizon allows for faster shipping of products, continuous improvements in customers’ user experience, bug fixes, and patching of security vulnerabilities in a secure and robust way. Software Developers […]

Combining OSTree and SW Containers for reliable IoT Device updates

OSTree IoT devices

CNXSoft: This is a guest post by Drew Moseley, Technical Solutions Architect at Toradex, explaining how the company updates Linux IoT devices firmware with OSTree (aka libostree) open-source operating system build and deployment tool, as well as Docker software containers. Every day more and more connected devices are being brought to market and estimates for the total size of the Internet of Things (IoT) market are as high as $1.5 trillion by 2027. Gas pumps, medical devices, and point of sale systems are increasingly connected, making it virtually impossible to avoid interacting with these devices, even for complete Luddites. In the home, devices such as power meters, light switches, and security cameras are commonly internet-enabled allowing for smart home functionality. The level of complexity in the software for these devices increases with the functionality, and the number of devices with software defects in the field is growing. In many cases, […]

It’s raining i.MX 8M Plus systems-on-module at Embedded World 2021

i.MX 8M Plus Systems-on-Module

NXP introduced i.MX 8M Plus AI SoC with a built-in 2.3 TOPS neural processing unit (NPU) last year, and we’ve already covered several early announcements about i.MX 8M Plus systems-on-module (SoM) with Variscite VAR-SOM-MX8M-PLUS and DART-MX8M-PLUS, TechNexion EDM-G-IMX8M-PLUS and AXON-E-IMX8M-PLUS respectively using SO-DIMM edge connectors and board-to-board connectors, as well as SolidRun i.MX 8M Plus SoM that was announced together with the HummindBoard Mate carrier board with dual Gigabit Ethernet. But as Embedded World 2021 Digital is taking place virtually until Friday, other companies have now made their own announcements of i.MX 8M Plus SoMs as the processor enters mass production this month, and since as far as I know, it’s pin-to-pin and software compatible with earlier i.MX 8M Nano/Mini SoCs, the update must have been easy. That means we’ve got a longish list of modules, and I have probably missed some. Supported operating systems are basically the same across […]

Reading Vehicle OBD-II data through CAN within a containerized application in Embedded Linux

telematics applications overview-GNSS CAN Cloud embedded Linux

CNXSoft: This is a guest about OBD-II and CAN support in embedded Linux by Andre Márcio de Lima Curvello, Sr. FAE and Technical Evangelist, Toradex A connected world makes it possible to track your online orders being shipped to your home through your smartphone in real-time, and getting information about your vehicle such as tire pressure, outside temperature, and even details like if a lamp is broken – has begun to be possible via smartphones in modern vehicle models. But behind the magic of knowing where the truck carrying your package is at all times and other details of the vehicle, there is a very complex world made of embedded devices ‘talking’ to each other so the information makes its way from the device to you. In this article, you will learn how to create an application to communicate with a vehicle through CAN via the OBD-II standard. We use […]

Toradex Launches New Verdin Arm SoM Family Starting with iMX8M Mini/Nano Modules

Verdin iMX8M Mini / Nano

So far, Toradex had two Arm-based system-on-module families with the smaller, lower-power Colibri and more powerful Apalis modules. The Colibri form factor was first defined in 2005, and the company is still maintaining it, but since then new interfaces have emerged, so Toradex has now designed a new low-power module family called Verdin. Toradex Verdin modules offer more I/Os with a 260-pin edge connector, include a battery-ready design with a wide input voltage range (3.3 to 5V), low power 1.8V IOs, the ability to easily extend power management to carrier board peripherals, and off-the-shelf thermal solutions. The modules are also tested for EMC, shock and vibration tolerance, and “Toradex Direct Breakout” is said to simplify signal routing on carrier boards as high speed, impedance critical signals are routed from the source IC to the edge connector on the Verdin module in such a ways to limit complexity on the carrier […]

Toradex AI Embedded Vision Starter Kit Leverages Amazon Web Services for AI and ML Applications

Toradex AI Embedded Vision AWS Starter Kit

Toradex, Amazon Web Services (AWS), and NXP Semiconductors collaborated to create the AI Embedded Vision Starter Kit aiming to ease the development of cloud-connected computer vision and machine learning applications in industries such as industrial automation, agriculture, medical equipment, and many more. The AI Embedded Vision Starter Kit includes the following items: Toradex Apalis iMX8 System on Module (SoM) powered by NXP i.MX 8QuadMax applications processor Toradex Ixora Carrier Board Allied Vision Alvium 1500 industrial-grade MIPI CSI-2 camera All required cables and a 12VDC (30W) power supply Full software stack, including source code for running the device as well as for cloud deployment Extensive documentation 50 USD AWS credit The kit will help developers meet the must-have requirements of smart connected devices including secure connectivity, remote monitoring, OTA updates, maximum uptime & reliability, compact form factor, cost-optimized hardware, computer vision and machine learning algorithms optimized for low-power hardware, and more. […]

Wear Estimation for Devices with eMMC Flash Memory

flash wear leveling & garbage collection

CNXSoft: This is a guest post by Marcel Ziswiler, Platform Manager – Embedded Linux, Toradex and Leonardo Graboski Veiga, Technical Marketing Engineer, Toradex related to Marcel’s upcoming talk “Wear Estimation for Devices with eMMC Flash Memory” at the Embedded Linux Conference 2019 later this month. Flash memory has been an important topic in embedded systems for decades. It allows for drastic improvements to the size and robustness of electronic devices compared to other storage technologies. Other benefits of flash storage include a lack of moving parts and reduced power consumption. However, the challenges that come with flash memory are not as widely publicized in consumer electronics. Among them are limited durability and greater software complexity. As shown in Figure 1, flash memory is everywhere in our daily lives, ranging from devices used specifically to store data, such as thumb drives, SD cards and SSDs, to other consumer electronics that use […]
