Gumstix Introduces CM4 to CM3 Adapter, Carrier Boards for Raspberry Pi Compute Module 4

Raspberry Pi Trading has just launched 32 different models of Raspberry Pi CM4 and CM4Lite systems-on-module, as well as the “IO board” carrier board. But the company has also worked with third-parties, and Gumstix, an Altium company, has unveiled four different carrier boards for the Raspberry Pi Compute Module 4, as well as a convenient CM4 to CM3 adapter board that enables the use of Raspberry Pi CM4 on all/most carrier boards for the Compute Module 3/3+. Raspberry Pi CM4 Uprev & UprevAI CM3 adapter board Gumstix Raspberry Pi CM4 Uprev follows the Raspberry Pi Compute Module 3 form factor but includes two Hirose connectors for Computer Module 4. The signals are simply routed from the Hirose connectors to the 200-pin SODIMM edge connector used with CM3. Gumstix Raspberry Pi CM4 Uprev is the same except it adds a Google Coral accelerator module. Gumstix Raspberry Pi CM4 Development Board Specifications: […]

PCIe adapter adds four USB 3.2 ports to Raspberry Pi CM4 IO board

Waveshare has introduced a non-standard PCIe adapter that adds four USB 3.2 ports to the Raspberry Pi Compute Module 4 IO carrier board in a way that does not take too much height. It’s non-standard as it can not be inserted directly into a typical computer PCIe slot, and Waveshare recommends a PCIe extension cable to connect it to a motherboard. Having said that It looks much better on the IO board. Waveshare USB PCIe adapter features: PCIe host interface 4x USB 3.2 Gen1 ports, USB 3.0 / 2.0 / 1.1 compatible Onboard VIA Labs VL805 chip as found on Raspberry Pi 4 SBC Power supply – 12V via PCIe connector or 4-pin header Designed for Raspberry Pi Compute Module 4 IO Board Dimensions – 82×39 mm   Since it’s basically using the same design as Raspberry Pi 4 providing USB ports through the same VL805 PCIe chip, there’s no […]

Advertisement

PiKVM v3 Raspberry Pi HAT offers KVM over IP on the cheap (Crowdfunding)

Last December, we wrote about the inexpensive DIY Pi-KVM board to add KVM over IP to the Raspberry Pi board mentioning PiKVM v3 was in the works with extra features such as onboard ATX power control. It turns out PiKVM v3 HAT has been on Kickstarter for about a month and raised close to $600,000 US from over 2,500 backers with just about two days to go at the time of writing. PiKVM v3 hardware features and specifications: Video & audio capture port – 1x HDMI input up to 1080p50 MIPI CSI-2 interface to Pi to visualize HDMI input USB 1x USB-C console port 1x USB-C power input port USB-OTG pins USB-C OTG port doing the emulation of a USB keyboard, mouse, Virtual CD-ROM or USB Flash Drive, USB-Ethernet, USB-Serial port, etc… Console – RJ45 console port Debugging – UART access pins Expansion SPI and an extra GPIO for the […]

Turing Pi V2 mini-ITX cluster board takes four Raspberry Pi CM4 or NVIDIA Jetson SoMs

The Turing Pi V2 is a mini-ITX cluster board that builds on the  Turing Pi mini-ITX cluster board taking up to 7 Raspberry Pi Compute Modules introduced in 2019, but instead supports up to four Raspberry Pi CM4 (Compute Modules 4) or NVIDIA Jetson Nano/TX2 NX/Xavier NX SO-DIMM system-on-modules. The Turing Pi 2 board is equipped with two Mini PCIe sockets, two Gigabit Ethernet ports, two SATA III ports, four USB 3.0 ports, a 40-pin GPIO header, and a 24-pin ATX connector for power. Since board-to-board connectors – as found in Raspberry Pi Computer Module 4 – are not ideal for density, the company went with a design including 260-pin SO-DIMM connectors plus CM4 adapter boards, a design that allows them to also integrate other SoMs like the NVIDIA Jetson SO-DIMM modules. Turing Pi V2 specifications: SoM interface – 4x 260-pin SO-DIMM slot for up to four Raspberry Pi CM4 […]

MinCab is the smallest Raspberry Pi CM4 carrier board ever

Carrier boards for Raspberry Pi CM4 modules are all over the place for routers, NAS, industrial gateways, and more. Here’s another one with the Minimal Carrier Board for Raspberry Pi Compute Module 4, or MinCab, that powers the RPi CM4 module via a USB Type-C port. That’s about all it does, although you would also be able to access some GPIOs, 5V,  3.3V, and GND signals via pads on the carrier board. Specifically, eight GPIOs are accessible with IO14, IO15, IO2, IO3, IO4, IO12, IO13, and IO18. Ivan Kuleshov explains this can be useful for Smart Home systems for instance, but it could be anything that requires WiFI and/or Bluetooth connectivity, a powerful Linux capable processor (as opposed to something like ESP32), and a few I/Os. The MinCab might be a good alternative to the upcoming (and delayed) Raspberry Pi 4 Model A for people wanting to use Broadcom BCM2711 […]

Raspberry Pi Compute Module 4 mini router keeps cool with aluminum alloy cover

There are many hardware platforms based on Raspberry Pi CM4 system-on-module, but in most instances, only the baseboard is provided, and you have to handle mounting and/or make an enclosure by yourself. One of those boards was Seeed Studio’s “Dual Gigabit Ethernet Carrier Board for Raspberry Pi Compute Module 4”, which as the name implies, offers two Gigabit Ethernet ports, as well as two USB 3.0 ports, and a micro HDMI port for video output. I say “was” because the company has now designed a PC/ABS case with an aluminum alloy cover acting as a heatsink to keep the RPi CM4 module cool. Raspberry Pi Compute Module 4 mini router’s specifications: SoM – Raspberry Pi CM4 with up to 8GB RAM, 32GB eMMC flash, dual-band WiFi 5 and Bluetooth 5.0 module; replaceable by any Raspberry Pi Compute Module 4 Storage – MicroSD card slot (only accessible with RPi CM4Lite module) […]

Advertisement
Search for development board and IC part on Utsource

SOQuartz is a Raspberry Pi CM4 compatible SoM powered by Rockchip RK3566 SoC

We’ve previously written about Pine64’s Quartz64 model A and model B SBC‘s, but the community has now announced another Rockchip RK3566 hardware platform with SOQuartz Compute Module compatible with Raspberry Pi CM4. We learned about the module in Pine64’s June update, where they also announced Quartz64 was now available to developers and enthusiasts with 4GB or 8GB RAM for respectively $59.99 and $79.99. But let’s have a look at the upcoming SOQuartz SoM in more detail. SOQuartz system-on-module preliminary specifications: SoC – Rockchip RK3566 quad-core Cortex-A55 processor up to 1.8 GHz with Arm Mali-G52 GPU supporting OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1, 0.8 TOPS NPU for AI acceleration System Memory – 2GB to 8GB LPDDR4 Storage 128 Mbit SPI Flash Optional eMMC module from 16GB up to 128GB capacity or soldered-on eMMC module  (see bottom of board) Wireless module – Azurewave AW-CM256SM WiFi 5 802.11ac & Bluetooth 4.2 wireless […]

CatsPi Industrial Lite RPi CM4 carrier board features GbE, RS485, Watchdog MCU

We’ve seen a fair deal of Raspberry Pi CM4 carrier boards, and here’s another one courtesy of QwaveSystems with CatsPi Industrial Lite board following Raspberry Pi SBC form factor/dimensions, and equipped with Gigabit Ethernet, RS485, USB ports, as well as a watchdog MCU among other interfaces and features. Contrary to what the name implies, CatsPi Industrial Lite only works with Raspberry Pi CM4 with eMMC flash, but not the CM4 Lite module since there’s no MicroSD card on the baseboard. It’s not the first Raspberry Pi Compute Module 4 carrier board with RS485, however, as we previously covered CM Hunter also including CAN and 1-wire interfaces, but QwaveSystems’ solution is more compact and mostly mechanically compatible with Raspberry Pi model B SBC’s. CatsPi Industrial Lite board specifications: Compatible SoMs – Raspberry Pi CM4 with eMMC flash only Video Output – Micro HDMI port Connectivity – Gigabit Ethernet, optional 802.11b/g/n/ac WiFi […]
