Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Taradov’s open-source hardware pocket USB sniffer works with Wireshark

Taradov’s open-source hardware pocket USB sniffer works with Wireshark

Taradov USB Sniffer v6

Alex Taradov has designed a low-cost, open-source hardware USB sniffer compatible with the popular Wireshark packet capture utility, and also controllable from the command line, capturing data in the standard PcapNG format in either case. Wireshark has had built-in USB capture capability for many years, and I used it myself to reverse-engineer the software for a USB video capture card around 2007, but it’s not perfect since it does not capture low-level packets. For that, you need extra hardware, and last year we covered the tinysniffer USB sniffer based on a WiFi-connected Linux SBC. It does the job, but it’s sold for $199, and you don’t need an application processor to handle USB 2.0 speeds. Alex’s design is optimized for cost and built around three main components: Cypress CY7C68013A 8051 MCU, Lattice MachXO2 LCMXO2 FPGA, and Microchip USB3343 USB PHY. Taradov’s USB sniffer specifications: Microcontroller – Cypress CY7C68013A enhanced 8051 […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on Icepi Zero – A Lattice ECP5 FPGA board in Raspberry Pi Zero form factor (Crowdfunding)

Icepi Zero – A Lattice ECP5 FPGA board in Raspberry Pi Zero form factor (Crowdfunding)

Icepi Zero Lattice LFE5U FPGA board Raspberry Pi Zero form factor

The Icepi Zero is a compact Lattice ECP5 FPGA open-source hardware development board following the Raspberry Pi Zero form factor, and equipped with a microSD card slot, three USB-C ports, a GPDI mini connector for video output, and a 40-pin GPIO header. I was confused at first, since Debashis wrote about the Pico2-ice board a few days ago, but it’s a different design with an RP2350B MCU and a Lattice ICE40U5K FPGA with 5.3K LUTs. Made by Icy Electronics, the Icepi Zero is a pure FPGA board with 24K LUTs, 32MB SRAM, and 16MB QSPI flash that can be used for retro gaming/computer and general FPGA gateware experimentation. Icepi Zero specifications: FPGA – Lattice Semi ECP5U 24k LUTs 112 KiB of RAM 28x 18 x 18 Multipliers Memory – 256 Mbit (32 MB) of 166 MHz SDRAM Storage 128 Mbit (16 MB) of QSPI Flash microSD card slot Video Output […]

Posted on by Debashis Das - No Comments on Pico2-Ice development board combines Raspberry Pi RP2350B with Lattice iCE40UP5K FPGA

Pico2-Ice development board combines Raspberry Pi RP2350B with Lattice iCE40UP5K FPGA

pico2 ice Raspberry Pi RP2350B + iCE40UP5K FPGA development baord

tinyVision.ai has recently released the second-generation ot its open-source hardware pico-ice FPGA development board, upgrading the Raspberry Pi RP2040 to the newer RP2350B along with dedicated user LEDs and buttons for both the MCU and the FPGA. The Pico2-Ice also exposes the RP2350B’s HSTX interface through a 22-pin connector, while keeping the same Lattice iCE40UP5K FPGA. The onboard iCE40UP5K FPGA features 5.3k LUTs, 1 MB SPRAM, and 120 KB DPRAM, along with 4MB SPI flash and 8MB low-power PSRAM. The board also exposes all RP2350 pins and 32 FPGA GPIOs via 2.54mm pitch headers in Pmod format. It includes two RGB LEDs and two pushbuttons (separately mapped to the MCU and the FPGA), and integrates onboard 3.3V/1.2V regulators for power. These features make this board suitable for exploring HDLs, embedded systems, and FPGA programming with open-source tools. Pico2-Ice specifications: Microcontroller – Raspberry Pi RP2350B MCU CPU – Dual-core Arm Cortex-M33 processor @ […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Tiliqua – An hackable Lattice ECP5 FPGA-based audio multitool for Eurorack (Crowdfunding)

Tiliqua – An hackable Lattice ECP5 FPGA-based audio multitool for Eurorack (Crowdfunding)

Tiliqua FPGA based audio multitool

Tiliqua is a Lattice ECP5 FPGA multitool board designed for audio and visual synthesis and compatible with the Eurorack modular synthesizer format. The board features four audio input jacks and four audio output jacks, all of which can be used as touch-sensitive inputs when not connected.  Other interfaces include a USB 2.0 Host/Device port, MIDI support, two PMOD expansion connectors, and a display interface to connect the Tiliqua screen for visual effects. All those features make it suitable for audio-rate modulation, low-latency effects, video synthesis, high-speed USB audio, or emulating retro hardware. Tiliqua specifications: FPGA –  Lattice ECP5 (LFE5U-25F-6BG256) FPGA supported by the open-source FPGA flow System Memory – 32MB PSRAM (tested up to 200MHz DDR / 400MB/s) Storage 16MB SPI flash for the FPGA 16MB SPI flash for the Raspberry Pi RP2040 2Kbit I2C EEPROM: for storing calibration constants Video Output – Digital video GPDI (General Purpose Differential Interface) […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Lattice unveils Nexus 2 small FPGA platform, Lattice Avant 30 and Avant 50 mid-range devices, updated Lattice design software tools

Lattice unveils Nexus 2 small FPGA platform, Lattice Avant 30 and Avant 50 mid-range devices, updated Lattice design software tools

Lattice Nexus 2

Lattice Semiconductors announced several new FPGAs and software tools at the Lattice Developers Conference 2024 which took place on December 10-11. First, the company unveiled the Nexus 2 small FPGA platform starting with the Certus-N2 general-purpose FPGAs offering significant efficiency and performance improvements in this category of devices. The Lattice Avant 30 and Avant 50 were also introduced as mid-range FPGA devices with new capacity options to enable edge-optimized and advanced connectivity applications. Finally, the company releases new versions of Lattice design software tools and application-specific solution stacks to help accelerate customer time-to-market such for edge AI, embedded vision, factory automation, and automotive designs with Lattice Drive. Let’s have a look at the highlights of each announcement. Lattice Nexus 2 small FPGA platform and Certus-N2 FPGA Highlights and benefits of the Lattice Nexus 2 small FPGA platform: Power Efficiency against similar class competitive devices Up to 3x lower power Up […]

Posted on by Tomisin Olujinmi - 3 Comments on Signaloid C0-microSD is an iCE40UP5K FPGA SoM in the microSD card form factor (Crowdfunding)

Signaloid C0-microSD is an iCE40UP5K FPGA SoM in the microSD card form factor (Crowdfunding)

Signaloid iCE40UP5K FPGA SoM in use

Cambridge-based hardware and cloud computing company, Signaloid has begun crowdfunding for the C0-microSD – a tiny, programmable iCE40UP5K FPGA system-on-module (SoM) in a microSD card form factor. It comes preloaded with a RISC-V softcore and users can also load custom FPGA designs onto the board. Part of the Signaloid C0-microSD’s unique appeal is its SD card form factor, which allows it to fit in unused full SD or microSD slots. This allows the implementation of FPGA-based hardware acceleration in systems without traditional expansion interfaces like PCIe M.2 slots. It can also be interfaced with as a standard SD block device and used to bring hardware-accelerated data processing to existing industrial automation, manufacturing, and robotics systems. The iCE40UP5K FPGA SoM has two main use cases: a hot-pluggable FPGA module or a hot-pluggable RISC-V co-processor module. The SD interface allows you to load custom FPGA bitstreams and applications onto the module from […]

Posted on by Debashis Das - 1 Comment on Lattice MachXO5D-NX FPGA family enables Hardware Security in Programmable FPGAs

Lattice MachXO5D-NX FPGA family enables Hardware Security in Programmable FPGAs

Lattice MachXO5D NX FPGA dev board

Lattice Semiconductor has recently introduced the MachXO5D-NX FPGA family, which integrates a hardware root of trust (RoT) into low-power FPGAs. This addresses security challenges by combining on-chip Flash memory and hardware encryption to minimize code capture risks during load time. The MachXO5D-NX family includes three variants with logic cell counts of 27k (FMXO5-25), 53k (LFMXO5-55T), and 96k (LFMXO5-100T). These FPGAs feature built-in hardware encryption, a cryptographic engine supporting AES-256, ECDSA-384/521, SHA2-256/384/512, and RSA 3072/4096, and a unique secret identity (USID) for device identity protection. Built on a 28-nm fully-depleted silicon-on-insulator (FD-SOI) process, these FPGAs reduce power consumption by 75% and lower soft error rates by 100x(as the company mentions). They support interfaces such as MIPI D-PHY (CSI-2, DSI), LVDS, Gigabit Ethernet, and PCIe, making them suitable for secure edge applications. Lattice MachXO5D-NX FPGA family specifications FPGA – Lattice Semi MachXO5D-NX FPGA family (27k (FMXO5-25), 53k (LFMXO5-55T), and 96k (LFMXO5-100T)) Programmable […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Lattice Semi Certus-NX-09 and Certus-NX-28 small footprint, low-power FPGAs feature optional PCIe Gen2 interface

Lattice Semi Certus-NX-09 and Certus-NX-28 small footprint, low-power FPGAs feature optional PCIe Gen2 interface

Lattice Certux-NX FPGA

Lattice Semiconductor has added two new devices to its small, low-power Lattice Certus-NX FPGA family, namely the Certus-NX-28 and Certus-NX-09 available in multiple packages and designed for communications, computing, industrial, and automotive applications. The Certus-NX FPGAs enable power-efficient PCIe Gen 2 with up to 4 times lower power compared to other FPGAs, and ultra-small form factor with up to 2 times more I/O per mm2 and PCIe and Gigabit Ethernet implementation in packages as small as 36 mm2. The company also claims high reliability and security with up to 100 times lower soft error rate, built-in SEC (Soft Error Correction) and memory block ECC for SEU (Single-Even Upset) protection, and up to 12 times faster instant-on configuration performance. The Lattice Certus-NX family is now comprised of four SKUs: LFD2NX-9, LFD2NX-17, LFD2NX-28, and LFD2NX-40 whose main highlights are shown in the comparison table below. The Certus-NX are available in various packages […]
