October 27, 2020 by Ian W MORRISON (Linuxium) - 4 Comments

MINISFORUM EliteMini H31G Coffee Lake Mini PC Review with Windows & Linux

MINISFORUM have launched their EliteMini H31G which combines a desktop CPU with a discrete graphics card in a mini PC form factor. It supports various Intel 9th and 8th gen desktop processors combined with an NVIDIA Geforce GTX1050 Ti graphics card and targets both gamers and content creators. Available as a barebones device and in various configurations MINISFORUM sent a fully configured model for review. Hardware overview The MINISFORUM EliteMini H31G is a remarkably small mini PC for what it offers and physically consists of a 154 mm x 153 mm x 62 mm (6.06 x 6.02 x 2.44 inches) rectangular plastic case with a metal base. It is an actively cooled mini PC that uses Intel’s LGA 1151 socket and supports desktop processors up to a maximum TDP of 65W. The review model came with an Intel Core i5 9500F Coffee Lake processor pre-installed which is a six-core 6-thread […]

October 23, 2020October 23, 2020 by Jean-Luc Aufranc (CNXSoft) - No Comments

E3K all-in-one wireless bio-sensing platform supports EMG, ECG, and EEG sensors (Crowdfunding)

Over the year, The maker community has designed several platforms to monitor vital signs with boards like Healthy Pi v4 or HeartyPatch both of which are powered by an ESP32 WiFi & Bluetooth wireless SoC. WallySci has designed another all-in-one wireless bio-sensing platform, called E3K, that also happens to be powered by Espressif Systems ESP32 chip, and can be connected to an electromyography (EMG) sensor to capture muscle movements, an electrocardiography (ECG) sensor to measure heart activity, and/or an electroencephalography (EEG) sensor to capture brain activity. The board also has an extra connector to connect a 9-axis IMU to capture motion. E3K main board which the company refers to as “Data Communication and Processing Unit” (DCPU) comes with the following specifications: Supported wireless board – ESP32-DevKitC with ESP32-D0WD-V3 dual-core 32-bit LX6 microprocessor, up to 240 MHz, Integrated 520 KB SRAM, 16 MByte SPI flash. 2.4 GHz WiFI 4, and Bluetooth […]

October 20, 2020 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

SwarmDrive is an ESP32 motor driver board for brushless motors (Crowdfunding)

Netherlands based NickStick BV has developed a motor driver board powered by an ESP32 dual-core WiFI and Bluetooth module and capable of controlling brushless DC motors. The SwarmDrive board targets users who want to start experimenting with motor control, and learn about commutation strategies, PID for balance plateau or balance robots, cartesian gantries and spatial navigation, drive by wire and wireless, swarm intelligence experiments, etc. SwarmDrive specifications: Wireless module – Espressif Systems ESP32-WROOM-32D module with ESP32 dual-core processor @ 240 MHz, 4 Mbit flash Connectivity 2.4 GHz 802.11 b/g/n WiFi up to 150 Mbps Bluetooth v 4.2 BR/EDR and BLE Motor Control L6234 triple half-bridge motor driver, 5 A peak current 3-pin terminal block for motor output 3x enable pins are broken out to a bridging connector Programming and debugging – Micro USB serial port via USB to UART bridge, Misc – Boot and reset push-buttons Power Supply Supply Voltage – […]

October 14, 2020January 23, 2021 by Ian W MORRISON (Linuxium) - 7 Comments

MINISFORUM X35G review – An Intel Core i3-1005G1 Mini PC tested with Windows & Ubuntu

MINISFORUM have recently launched their X35G mini PC on Indiegogo which differentiates itself from the many Gemini Lake mini PCs by using a 10th generation Intel “Ice Lake” Core mobile processor with Gen11 graphics. Available as a barebones device and in various configurations MINISFORUM sent a fully configured model for review. MINISFORUM X35G Hardware overview Also known as DeskMini X35G, the MINISFORUM X35G is a slightly larger mini PC physically consisting of a 136.5 mm x 121.5 mm x 40.5 mm (5.37 x 4.78 x 1.59 inches) rectangular metal case with a plastic base. It is an actively cooled mini PC that uses Intel’s second-generation 10 nm+ Core i3-1005G1 processor which is a dual-core 4-thread 1.2 GHz processor boosting to 3.4 GHz with Intel’s Gen11 UHD graphics. The front panel has a power button, a Thunderbolt 3/Type-C USB port that supports video, and two 3.1 USB ports. Also on the […]

October 14, 2020 by Jean-Luc Aufranc (CNXSoft) - No Comments

ASRock NUC 1100 BOX Series mini PC Offers 2.5GbE, WiFI 6, and quad 4K output

The new Tiger Lake UP3 embedded processors have enabled industrial mini PCs and motherboards to get higher-end features including 2.5 GbE, WiFI 6, USB 4.0, and support for up to four independent 4K displays. ASRock industrial already unveiled ASRock iBOX 1100 rugged mini PC last month, but the company is now back with an even more compact Tiger Lake UP3 mini PC that offers quad 4K video output, 2.5GbE, and WiFi 6 connectivity. Meet ASRock NUC 1100 BOX Series industrial computer designed for entertainment, gaming, office collaboration, content creation, retail, and business applications. ASRock NUC 1100 specifications: SoC NUC BOX-1165G7 – Intel Core i7-1165G7 quad-core/octa-thread Tiger Lake UP3 processor @ up to 1.2 GHz / 4.7 GHz (Turbo) with 96EU Iris Xe Graphics; 15W TDP (Configurable between 12 and 28W) NUC BOX-1135G7 – Intel Core i5-1135G7 quad-core/octa-thread Tiger Lake UP3 processor @ up to 0.9 GHz / 4.2 GHz (Turbo) […]

October 13, 2020October 13, 2020 by Jean-Luc Aufranc (CNXSoft) - No Comments

BBC micro:bit v2 board Unveiled with Nordic nRF52833 SoC, Microphone and Speaker

The original BBC micro:bit educational board was launched in July 2015 with a Nordic nRF51822 Arm Cortex-M0 MCU @ 16 MHz providing Bluetooth LE connectivity, a few I/Os, some buttons, and a LED matrix acting as a small display. The British company has now launched a new update with BBC micro:bit v2 with the same form factor, but equipped with a more powerful Nordic Semi nRF52833 Bluetooth 5.1 Arm Cortex-M4 MCU clocked at 64 MHz and adding a microphone and a speaker. BBC micro:bit v2 specifications: Wireless MCU – Nordic Semi nRF52833 Arm Cortex-M4 MCU clocked at 64 MHz with 128 KB RAM, 512 KB flash, Bluetooth 5.1 LE connectivity “Display” – 25x red LED indicator lights in a 5×5 matrix USB – 1x micro USB port for power and programming via NXP Kinetis KL27Z Cortex-M0+ microcontroller Audio – Built-in MEMS microphone and speaker Expansion 25 pins on edge connector […]

October 9, 2020October 9, 2020 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

$16 Banana Pi BPI-EAI80 Cortex-M4F Board Embeds AI Accelerator, WiFi Module

Banana Pi BPI-EAI80 AI MCU Development Board

Last April, we wrote about Edgeless EAI-Series dual Arm Cortex-M4 MCU equipped with a 300 GOPS CNN-NPU for AI at the very edge as we had discovered the chip in an upcoming Banana Pi board. It turns out Banana Pi BPI-EAI80 development board powered by Edgeless EAI80 AI microcontroller has just launched for $16 on Aliexpress, or you could get a complete kit with a touchscreen display, a camera, and a USB power supply for $80. Banana Pi BPI-EAI80 development board specifications: System-in-Package – Edgeless EIA80 dual-core Cortex-M4F microcontroller @ 200MHz with 300GOPS AI accelerator (CNN-NPU), 384KB of SRAM including 256KB for CNN-NPU, and 8MB SDRAM Storage – SPI flash Display I/F – LCD connector up to 1024×768 Camera I/F – 1x DVP camera interface Audio – 2x onboard microphones Connectivity – 2.4GHz 802.11b/g/n WiFI 4 using ESP8266 module USB – 1x USB 2.0 Type-C port Expansion 40-pin GPIO header […]

October 7, 2020October 7, 2020 by Jean-Luc Aufranc (CNXSoft) - 8 Comments

Teracube 2e is a user-serviceable, sustainable phone with a 4-year “premium care warranty”

Most smartphones have limited software support, but in my experience with Xiaomi smartphones part of Android One, the hardware tends to fail even earlier than the 18 to 24-month support window for such phones. It’s also close to impossible to repair those by yourself. So it would be nice to have a phone with a longer warranty, software support, and that the user can service himself. If it was made of recycled materials, it would be a bonus too. That’s exactly what Teracube 2e phone provides with recycled materials, a fully biodegradable case, and a 4-year “premium care warranty” for hardware repairs, and since it runs Android 10 stock, you’d get 3-years of Android and security updates. Teracube 2 phone is also meant to be affordable going for $99 and up on Indiegogo with the following specifications: SoC – Mediatek Helio A25 octa-core Cortex-A53 processor @ 1.8GHz with IMG PowerVR […]
