Posted on by Debashis Das - 1 Comment on ESP32-C3-based 2-channel Wi-Fi AC relay support energy monitoring with Home Assistant

ESP32-C3-based 2-channel Wi-Fi AC relay support energy monitoring with Home Assistant

Seed Studio 2 Channel Wi Fi AC Relay Module

Seeed Studio has recently launched a 2-channel Wi-Fi AC relay built around the XIAO ESP32C3 WiFI and Bluetooth module. The device is a simple WiFi relay module that can control two independent 100-240V AC appliances and is designed to be compatible with both Home Assistant with ESPHome firmware flashed by default. The device also features a built-in BL0942 power meter with a maximum load capacity of 2400W at 240V for real-time and historical energy consumption monitoring. These features make this device suitable for applications such as energy tracking and remote control of appliances. Seeed Studio 2-channel Wi-Fi AC relay specifications: MCU – XIAO ESP32-C3 with ESP32-C3 WiFi 4 and Bluetooth 5.x RISC-V microcontroller, USB-C port (unused here) Wireless connectivity – 2.4GHz Wi-Fi Relay channels – 2 independent channels Power Input terminals – Neutral (N), Live (L) Input voltage – 100-240V AC, 50/60Hz Output terminals Channel 1: N1 (Neutral), L1 (Live) […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Lattice unveils Nexus 2 small FPGA platform, Lattice Avant 30 and Avant 50 mid-range devices, updated Lattice design software tools

Lattice unveils Nexus 2 small FPGA platform, Lattice Avant 30 and Avant 50 mid-range devices, updated Lattice design software tools

Lattice Nexus 2

Lattice Semiconductors announced several new FPGAs and software tools at the Lattice Developers Conference 2024 which took place on December 10-11. First, the company unveiled the Nexus 2 small FPGA platform starting with the Certus-N2 general-purpose FPGAs offering significant efficiency and performance improvements in this category of devices. The Lattice Avant 30 and Avant 50 were also introduced as mid-range FPGA devices with new capacity options to enable edge-optimized and advanced connectivity applications. Finally, the company releases new versions of Lattice design software tools and application-specific solution stacks to help accelerate customer time-to-market such for edge AI, embedded vision, factory automation, and automotive designs with Lattice Drive. Let’s have a look at the highlights of each announcement. Lattice Nexus 2 small FPGA platform and Certus-N2 FPGA Highlights and benefits of the Lattice Nexus 2 small FPGA platform: Power Efficiency against similar class competitive devices Up to 3x lower power Up […]

ArmSoM CM5 Raspberry Pi CM4 alternative with Rockchip RK3576 SoC
Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on 15 Euros Olimex RP2040pc Raspberry Pi RP2040 computer board supports Apple and Oric Atmos emulation

15 Euros Olimex RP2040pc Raspberry Pi RP2040 computer board supports Apple and Oric Atmos emulation

Olimex RP2040pc

Olimex RP2040pc is an inexpensive “all-in-one” computer board based on a Raspberry Pi RP2040 MCU with support for Apple //e, Apple ][+, and Oric Atmos emulation through the Reload emulator. The board features an HDMI port, stereo audio, four USB ports, and two UEXT expansion connectors. It’s not quite the first RP2040 retrocomputing board from Olimex, as they introduced the RP2040-PICO-PC in 2021 with an HDMI port, a 3.5mm audio jack, and a microSD card slot before launching the Olimex NEO6502, which combines a MOS6502 MCU for Apple II, Oric, and Commodore 64 emulators with an RP2040 for HDMI/DVI video output and a few other things. The RP2040pc is similar to the latter, but with more ports and features, and everything is handled by the Raspberry Pi RP2040 microcontroller. Olimex RP2040pc specifications: Microcontroller – Raspberry Pi RP2040 dual-core Cortex-M0+ MCU @ 133 MHz with 264 KB SRAM Storage – 16MB […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 2 Comments on Sfera Labs Strato Pi Max DIN rail industrial controllers now support the Raspberry Pi Compute Module 5

Sfera Labs Strato Pi Max DIN rail industrial controllers now support the Raspberry Pi Compute Module 5

Raspberry Pi Compute Module 5 industrial controllers

The Raspberry Pi Compute Module 5 (CM5) was launched at the end of last month, and we are starting to see companies slowly announce upgraded CM4 designs. Yesterday, we wrote about EDATEC ED-IPC3100 DIN-Rail mountable industrial computers, and today, we’ll cover Sfera Labs’ addition of the Raspberry Pi Compute Module 5 to their Strato Pi Max DIN rail industrial controllers. The controllers still feature a gigabit Ethernet port, a 10/100M Ethernet port, two USB 2.0 ports, a Raspberry Pi RP2040 microcontroller for power management and boot sequence control, and support expansion modules for up to sixteen RS-485 or RS-422 ports, four CAN V2.0B ports, digital and analog I/O, and more. Strato Pi Max specifications (as of December 2024): Base Module Raspberry Pi Compute Module 5 Raspberry Pi Compute Module 4 Zymbit SCM options. Microcontroller – Raspberry RP2040 dual ARM Cortex-M0+ at 133 MHz. Storage – eMMC, microSD (dual for XL), M.2 PCIe […]

Posted on by Debashis Das - No Comments on Waveshare Double Eye LCD module is a high-tech alternative to googly eyes

Waveshare Double Eye LCD module is a high-tech alternative to googly eyes

Waveshare 0.71inch DualEye LCD Module

Waveshare has recently launched the Double Eye LCD module (also known as the 0.71inch DualEye LCD module), a high-tech alternative to googly eyes, with two 0.71-inch round IPS displays with 160×160 pixels of resolution and 65K color depth. It uses the GC9D01 driver and communicates via an SPI interface. The module operates at a 3.3V or 5V and is designed so that both ESP32 and Arduino boards can drive it. These features make this device useful for applications like wearables, robotics, IoT devices, etc… Waveshare Double Eye LCD module specifications: Display Type – Dual 0.71-inch round LCD displays Resolution – 160×160 pixels Panel – IPS (wide viewing angle) Colors – 65K colors Pixel Pitch – 37.5 × 112.5 µm Controller and Driver Driver – GC9D01 Interface – SPI Operating Voltage – 3.3V / 5V Dimensions Display – 18 mm ∅ per round LCD Module  – 51 x 20 mm The […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on EDATEC ED-IPC3100 Raspberry Pi CM5-based industrial computers offers RS232/RS485, dual Ethernet, 4G LTE, and more

EDATEC ED-IPC3100 Raspberry Pi CM5-based industrial computers offers RS232/RS485, dual Ethernet, 4G LTE, and more

Raspberry Pi CM5 industrial computers

EDATEC ED-IPC3100 is a range of four DIN-Rail mountable industrial computers based on the new Raspberry Pi CM5 (Compute Module 5) with two Ethernet ports, and various RS232 or RS485 COM port options depending on the selected model. The ED-IPC3100 computers are offered with the CM5 with up to 16GB LPDDR5, 64GB eMMC flash, and optional WiFI 5 and Bluetooth 5. All also feature one HDMI port, two USB 2.0 ports, 9V to 36V DC input, and the EDC-IPC3120 model also adds a 3.5mm audio jack and internal connectors for a speaker, MIPI DSI and HDMI video output interfaces, and a MIPI CSI camera. EDATEC ED-IPC3100 specifications: SoM – Raspberry Pi CM5 SoC – Broadcom BCM2712 quad-core Cortex-A76 processor @ 2.4GHz with VideoCore VII GPU System Memory – 2GB, 4GB, 8GB, or 16GB LPDDR4-4267 SDRAM Storage – Options for 16GB, 32GB, or 64GB eMMC flash Wireless – Optional dual-band WiFi […]

Rockchip RK3568, RK3588 and Intel x86 SBCs abd SoMs
Posted on by Sayantan Nandy - No Comments on SenseCAP Indicator – An ESP32-S3 and RP2040-based Meshtastic LoRa device with a 4-inch touchscreen display

SenseCAP Indicator – An ESP32-S3 and RP2040-based Meshtastic LoRa device with a 4-inch touchscreen display

ESP32S3 Meshtastic LoRa Indicator

The SenseCAP Indicator is a 4-inch capacitive touchscreen device designed for IoT connectivity and Meshtastic applications powered by Espressif Systems ESP32-S3 and Raspberry Pi RP2040 microcontrollers. It supports Wi-Fi (802.11b/g/n) and Bluetooth 5.0 LE connectivity, as well as LoRa using the Semtech SX1262 chip. The device also provides Grove connectors for expansion and a microSD slot supporting up to 32GB. Preloaded with Meshtastic firmware, the SenseCap Indicator is ready to function as a Meshtastic desktop or car node and can be reconfigured into a LoRaWAN Single-Channel Gateway. It features a 3.95-inch RGB touchscreen with 480×480 resolution, which is larger than most other Meshtastic solutions we’ve covered. Previously, we reviewed the SenseCAP Indicator D1Pro, which shares many features with the SenseCAP Indicator. However, the D1Pro integrates tVOC and CO2 sensors, along with an external Grove AHT20 TH sensor for precise temperature and humidity measurements. With real-time air quality monitoring from the […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 13 Comments on MeLE QuieterDL – An ultrathin fanless Intel N100 mini PC with dual 2.5 GbE, HDMI, DisplayPort, and USB-C video outputs

MeLE QuieterDL – An ultrathin fanless Intel N100 mini PC with dual 2.5 GbE, HDMI, DisplayPort, and USB-C video outputs

MeLE QuiterDL mini PC

MeLE QuieterDL is a fanless mini PC with an ultrathin design similar to the MeLE Quieter4C, albeit larger, and featuring two 2.5GbE RJ45 ports and supporting triple display setups via HDMI, DisplayPort, and USB-C connectors. The computer also comes with up to 16GB LPDDR4 RAM, 512GB storage, a microSD card slot, a 3.5mm audio jack, three USB 3.2 ports, one USB 2.0 port, WiFi 5 and Bluetooth 5.1 wireless connectivity, and Kensington lock slot for theft prevention. MeLE QuieterDL specifications: SoC – Intel Processor N100 CPU – Quad-core Alder Lake-N processor @ up to 3.4 GHz (Turbo) GPU – 24EU Intel HD graphics @ 750 MHz Cache – 6MB cache TDP: 6W System Memory – 4GB, 8GB, or 16GB LPDDR4X Storage Up to 512GB storage;  support up to 4GB (unclear where it’s an eMCM flash + SSD configuration, or SSD only) MicroSD card reader Video Output 1x HDMI 2.0 port […]
