2.5GbE News - CNX Software - Embedded Systems News

April 23, 2025 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Zimaboard 2 – An Intel N150 micro server and mini PC with dual SATA, dual 2.5GbE, PCIe slot, miniDP (Crowdfunding)

ZimaBoard 2 is a compact Intel Processor N150 “Twin Lake” mini PC and micro server with two 2.5Gbps Ethernet ports, two SATA ports, two USB 3.1 ports, and a 4K-capable miniDP video output. It built upon the company’s ZimaBoard introduced in 2021 with an Apollo Lake processor, but offers a much faster Intel N150 CPU, LPDDR5x memory, 2.5GbE networking instead of gigabit Ethernet, and a PCIe Gen 3.0 x4 slot as opposed to a PCIe Gen 2.0 x4 slot. Two variants are offered: one with 8GB RAM and 32GB eMMC flash and the other in a 16GB/64GB configuration. Zimaboard 2 specifications: SoC – Intel Processor N150 quad-core “Twin Lake” processor @ up to 3.6 GHz (Turbo) with 6MB cache, 24EU Intel UHD graphics @ 1000 MHz; PBP: 6W (but set to 10W here) System Memory and Storage ZimaBoard 2 832 – 8GB LPDDR5X 4800MHz; 32GB eMMC flash ZimaBoard 2 1664 […]

April 22, 2025April 22, 2025 by Jean-Luc Aufranc (CNXSoft) - 12 Comments

Banana Pi BPI-RV2 is a low-cost RISC-V router with a 2.5GbE port and five gigabit Ethernet ports

We briefly mentioned the Banana Pi BPI-RV2 router in our article about the Siflower SF21H8898 quad-core 64-bit RISC-V SoC designed for industrial gateways, routers, and controllers. But we now have more information about Banana Pi’s latest RISC-V router, and it’s available for purchase for $34.50 on AliExpress. So let’s have a closer look. The Banana Pi BPI-RV2 ships with 512MB DDR3 RAM, 128 MB SPI NAND, and 16 MB SPI NOR flash for storage redundancy. The router features one 2.5GbE port with optional PoE support, five gigabit Ethernet ports, an M.2 2242/2230 PCIe Gen 2 x1 interface for NVMe SSD storage, and a mini PCIe socket for a WiFi module. Banana Pi BPI-RV2 specifications: SoC – Siflower SF21H8898 quad-core 64-bit RISC-V @ 1.25GHz System Memory – 512MB DDR3 Storage 128 MB SPI NAND Flash for U-Boot and Linux 16 MB SPI NOR flash for U-Boot and Linux; write protected by […]

April 17, 2025 by Jean-Luc Aufranc (CNXSoft) - 6 Comments

HoneyComb Ryzen V3000 – An AMD Ryzen V3C18I mini-ITX motherboard with dual 10Gbps SFP+, 2.5GbE, dual SATA III

SolidRun HoneyComb Ryzen V3000 is a mini-ITX motherboard powered by an AMD Ryzen Embedded V3C18I processor, supporting up to 64GB of DDR5 memory and M.2 PCIe NVMe SSD storage, and equipped with two 10 Gbps Ethernet SFP+ cages, a 2.5GbE RJ45 jack, and two SATA III ports for advanced networking and storage applications. The solution is comprised of a mini-ITX motherboard and a Ryzen V3000 CX7 COM Express module, which the company introduced in 2022. As an industrial motherboard, it’s designed to operate in the -40°C to +85°C temperature range. HoneyComb Ryzen V3000 specifications: Ryzen V3000 CX7 COM Express module SoC – AMD Ryzen Embedded V3C18I octa-core/16-thread processor clocked at 1.9 GHz / 3.8 GHz (Turbo) with 4 MB L2 cache and 16 MB L3 cache; TDP: 15W System Memory – Up to 64GB (2x 32GB), ECC/Non-ECC DDR5 memory up to 4800 MT/s via two SODIMM sockets. Dimensions – 125 […]

April 11, 2025April 11, 2025 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Radxa Dual 2.5G Router HAT adds 2.5GbE networking and M.2 NVMe storage support to Raspberry Pi 5-compatible SBCs

The Radxa Dual 2.5G Router HAT is an expansion board adding 2.5GbE networking and an M.2 PCIe x1 socket for NVMe SSD storage to the Raspberry Pi 5 and compatible SBCs with a PCIe FFC connector. We had previously seen Raspberry Pi 5 HATs with 2.5GbE such as the Pineberry HatNET! 2.5G, or even one with 2.5GbE and NVMe SSD (52Pi W01 U2500 HAT), but the Radxa Dual 2.5G Router HAT is the first to implement two 2.5 Gbps Ethernet ports to enable routing, and also features an NVMe SSD as a bonus. Radxa Dual 2.5G Router HAT specifications: Supported SBCs – Raspberry Pi 5, Radxa ROCK 2F, Radxa ROCK 2A, Radxa ROCK 5C, the upcoming Radxa 4D (RK3576), and potentially others PCIe Switch – ASM2806 PCIe 3.0 switch chip with PCIe Gen3 x2 upstream and four PCIe 3.1 lanes downstream up to 8GT/s Storage – 1x M.2 M-Key socket […]

April 3, 2025April 3, 2025 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

PocketCloud – Battery-powered, portable NAS takes up to 16TB of storage (Crowdfunding)

Firefly’s PocketCloud is a battery-powered, portable NAS powered by a Rockchip RK3568B2 quad-core Arm Cortex-A55 SoC with 4GB LPDDR5 of RAM and a 32GB eMMC flash for the OS, and supports up to 16TB of NVMe SSD storage. It’s comprised of the battery-powered PocketCloud itself with WiFi 6 and Bluetooth 5.2 connectivity, and an optional dock with 2.5GbE networking and an additional M.2 NVMe socket. Since I’m unable to find a 16 TB M.2 NVMe SSD for now, I suppose the 16TB claim only works with an 8TB + 8TB configuration with one SSD in the main unit, and the other in the dock. PocketCloud specifications: SoC – Rockchip RK3568B2 (as found in ODROID-M1 SBC) CPU – Quad-core Cortex-A55 processor @ up to 2.0 GHz GPU – Arm Mali-G52-2EE AI Accelerator – 1TOPS NPU System Memory – 4GB LPDDR4 Storage 32GB eMMC 5.1 flash M.2 PCIe Gen3 socket for M.2 […]

March 30, 2025March 31, 2025 by Jean-Luc Aufranc (CNXSoft) - 19 Comments

Radxa Orion O6 Preview – Part 2: Debian 12 – What works, what doesn’t

I went through an unboxing and Debian 12 installation on the Radxa Orion O6 at the end of January, but decided to work on other reviews since software support still needed to be worked on. Since then, there’s been some work done, but no new image released. After waiting for almost two months, I’ve decided to carry on with the review by testing the Debian 12 image in a way similar to the Rock 5B SBC preview I did with Debian 11 in 2022 to check what works and what doesn’t on the Orion O6 at the time of the review. That will involve testing all ports, including 5GbE networking and the PCIe slot with an (old) NVIDIA graphics card, running some benchmarks, and also trying the Debian 12 image with a self-built Linux 6.13 kernel using ACPI instead of UEFI for the default image. Orion O6 SBC benchmarks on […]

March 26, 2025March 26, 2025 by Jean-Luc Aufranc (CNXSoft) - No Comments

Teledyne Tetra 2.5 GbE line scan camera supports up to 8K resolution for machine vision applications

Teledyne DALSA has recently announced the Tetra line scan camera family with 2.5GbE networking, up to 8K resolution, a line rate of up to 150 kHz, and offered in monochrome or color versions. Traditional cameras (aka scan camera) will capture a full frame, but line scan cameras will only capture one line at a time to scan an object or scene as it moves past the camera providing higher resolution image provided the speed of the scan and the motion of the object are syncrhonized, for instance, on a production line. Line scan cameras like the Tetra are typically used for quality control at the factory, document scanning, license plate scanning, and scientific research (e.g. satellite imaging). Teledyne Tetra specifications: Color cameras Tetra 2k Color – TL-GC-02K05T-00 Resolution – 2048 x 3 Pixel size – 14 μm Max line rate – 50 kHz x 3 Tetra 4k Color – […]

March 17, 2025March 16, 2025 by Debashis Das - No Comments

Jetway F35-ASL1 – A 3.5-inch Intel Atom x7433RE SBC with dual 2.5GbE, six COM ports, and triple 4K display outputs

Jetwayipc F35 ASL1 3.5 inch subcompact SBC

Jetway F35-ASL1 3.5-inch subcompact SBC is built around the Intel Atom x7433RE (Amston Lake) processor and designed for industrial and embedded applications. This SBC supports up to 32GB of DDR5 4800MHz memory and offers triple display output via two HDMI ports, one USB Type-C DP, and an LVDS/eDP interface. It also includes two 2.5Gbps Ethernet ports, optional WiFi and Bluetooth and/or 4G LTE /5G cellular connectivity via M.2 slots. Storage options include a SATA III port, an M.2 M-Key, and an optional onboard 64GB eMMC. The board provides extensive I/O with one USB 3.2 Gen 2 Type-C, one USB 3.2 Gen 2, eight USB 2.0, and six COM ports. Built for industrial environments, it features a wide DC input range (12–28V) with power protection mechanisms (RVP, OCP, and OVP), and a rugged design supporting shock and vibration resistance. It is suitable for industrial automation, edge computing, IoT, digital signage, and […]
