4g

Posted on by Debashis Das - No Comments on Raspberry Pi 5 PCIe HAT+ board features gigabit Ethernet, 4G LTE (mini PCIe), two USB 3.2 ports

Raspberry Pi 5 PCIe HAT+ board features gigabit Ethernet, 4G LTE (mini PCIe), two USB 3.2 ports

Waveshare PCIe TO MiniPCIe GbE USB3.2 HAT+

Waveshare has recently introduced the PCIe to MiniPCIe GbE USB3.2 HAT+ for Raspberry Pi 5 adding gigabit Ethernet, a mini PCIe socket for 4G LTE, and two USB 3.2 Gen1 ports to the popular Arm single board computer. The HAT+ is compatible with IM7600G-H-PCIE/EG25-G-mPCIe series 4G LTE modules with 4G/3G/2G global band and GNSS positioning. Additionally, it has a gigabit Ethernet with an onboard RJ45 port, two USB 3.2 Gen1 ports, an onboard power monitoring chip, and EEPROM. All these features make this HAT useful for applications such as industrial routers, home gateways, set-top boxes, industrial laptops, industrial PDAs, and much more. We have previously written about many different types of HATs for the Raspberry Pi 5 designed by Waveshare including the Waveshare UPS HAT (E), the Waveshare PoE HAT (G), the Waveshare PCIe to USB 3.2 HAT+, and many other products. Feel free to check those out if you […]

Posted on by Debashis Das - No Comments on Makerfabs SenseLora 4G gateway supports LTE Cat 1 and WiFi 4 connectivity, features solar battery charger

Makerfabs SenseLora 4G gateway supports LTE Cat 1 and WiFi 4 connectivity, features solar battery charger

SenseLoRa 4G LTE CAT1 Gateway

The Makerfabs SenseLora 4G Gateway is a device that collects data from LoRa sensors (like temperature and humidity sensors) and sends that data over a 4G network to a cloud service or directly to your phone via SMS, this is ideal for applications where installing a LoRaWAN device is unnecessary or expensive. The application for this gateway includes monitoring soil humidity in your backyard or greenhouse conditions on your farm. Previously we have written about similar smart agriculture sensors including AgroSense LoRaWAN sensors and WisGate Soho Pro RAK7267 LoRaWAN gateway feel free to check those out if you are looking for LoRa-based agricultural products. Makerfabs SenseLora 4G gateway specifications SoC – Espressif ESP32-S3R8 CPU – Dual-core Tensilica LX7 microcontroller up to 240 MHz with vector instructions for AI acceleration Memory – 8MB PSRAM Wireless – WiFi 4 and Bluetooth 5.0 LE + Mesh connectivity LPWAN connectivity LoRaWAN SX1276 LoRa module Frequencies 868 […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Rockchip RK3568 fanless industrial PC offers Ethernet, 4G LTE, WiFi, BLE connectivity, RS485, RS232, and CAN Bus interfaces

Rockchip RK3568 fanless industrial PC offers Ethernet, 4G LTE, WiFi, BLE connectivity, RS485, RS232, and CAN Bus interfaces

Rockchip RK3568 fanless industrial PC

MYiR MYD-LR3568-GK-B is a fanless industrial PC Box powered by Rockchip RK3568 quad-core Cortex-A55 Ai SoC with up to 4GB RAM,  32GB GB eMMC flash, support for M.2 NVMe storage, and communication interfaces such as RS232, RS485, and CAN Bus. The device also offers dual gigabit Ethernet and optional WiFI, BLE, and 4G LTE connectivity, two video outputs, and five USB ports with a set of features and capabilities that makes it suitable for edge AI, video analytics, industrial control, protocol conversion, communication management, and more. MYiR MYD-LR3568-GK-B specifications: SoC – Rockchip RK3568J CPU – Quad-core Cortex-A55 processor at up to 1.4 GHz (An “overdrive” version at 1.8 GHz is available upon request) GPU – Mali G52 2EE GPU with support for OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1 VPU 4Kp60 H.264, H.265, VP9, 1080p60 MPEG-4/-2/-1, VP8, and VC1 video decoder 1080p60 H.264/H.265 video encoder AI accelerator – Up to […]

Posted on by Sayantan Nandy - 1 Comment on NBIOT/LTE-M Air Monitor – A solar-powered ESP32-S3 multi-sensor board with SIM7080G NB-IoT & LTE-M modem

NBIOT/LTE-M Air Monitor – A solar-powered ESP32-S3 multi-sensor board with SIM7080G NB-IoT & LTE-M modem

nbiotlte m air monitor air temperature humidity light co2

The NBIOT/LTE-M Air Monitor is a solar-powered device that utilizes a combination of ESP32-S3 and SIM7080G modules for remote environmental monitoring. It monitors and transmits environmental parameters such as temperature, humidity, CO2, TVOC, and light intensity using low-power wide-area network (LPWAN) technology ensuring efficient power consumption, durability, and reliable data transmission. Previously we have written about similar environment monitor devices like the Airlytix ES1,  Sonoff SC WiFi, V-Air Monitro, and devices like Arduino MKR IoT Carrier Rev2, Radair mini gateway, and Nicla Sense ME  designed for environment monitoring applications. Feel free to check those out if you are interested in this type of product. NBIOT/LTE-M Air Monitor specification Wireless Module – ESP32-S3-WROOM-1-N16R8 Espressif Systems ESP32-S3R8 – Dual-core Tensilica LX7 @ up to 240 MHz with vector instructions for AI acceleration, 512KB RAM, 8MB PSRAM Storage – 16 MB flash Wireless – 2.4 GHz WiFi 4 and Bluetooth PCB antenna Cellular connectivity Module – SIMCom SIM7080G LTE Cat […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 22 Comments on Upgraded Radxa ROCK 5B+ SBC gets LPDDR5 memory, eMMC flash, WiFi 6, two M.2 M-Key sockets, 4G LTE/5G support, and more

Upgraded Radxa ROCK 5B+ SBC gets LPDDR5 memory, eMMC flash, WiFi 6, two M.2 M-Key sockets, 4G LTE/5G support, and more

Radxa ROCK 5B+

The Radxa ROCK 5B+ (“ROCK 5B Plus”) is an upgrade to the Rockchip RK3588-powered ROCK 5B Pico-ITX SBC with the same form factor but various changes including a switch from LPDDR4x to LPDDR5, optional built-in eMMC flash, and an onboard WiFi 6 and Bluetooth 5.2 module instead of one connected through an M.2 Key-E connector. Other changes include replacing the M.2 Key-M PCIe Gen 3 x4 socket with two M.2 Key-M PCIe Gen3 x2 sockets, adding a SIM card slot and M.2 Key-B socket for 4G LTE or 5G cellular connectivity, adding an extra USB-C port for power only (was multiplexed with USB-C Display Port connected in ROCK 5B), and the HDMI input relies on a full-size HDMI port instead of a micro HDMI port. Other small changes can be found in the specifications below with differences highlighted in bold and strikethrough. Radxa ROCK 5B+ specifications: SoC – Rockchip RK3588 […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 2 Comments on $39 Acelink SM81 MediaTek Filogic 820 WiFi 6 system-on-module runs OpenWrt 23.05 or Debian 11

$39 Acelink SM81 MediaTek Filogic 820 WiFi 6 system-on-module runs OpenWrt 23.05 or Debian 11

ACELINK SM81 MediaTek Filogic 820 system-on-module

Acelink SM81 is a compact (50x36mm) system-on-module based on the MediaTek Filogic 820 (MT7981A/B) processor with WiFi 6 and Ethernet connectivity designed for IoT applications such as routers, access points, and gateways. The wireless module ships with up to 1GB DDR4 memory, a 2MB NOR flash for the bootloader, a 32GB eMMC flash for Linux or an optional NAND flash, and exposes various I/Os such as gigabit Ethernet, USB 3.0, PCIe 2.1, UART, and more through castellated holes. Acelink SM81 specifications: SoC (one or the other) MediaTek MT7981AA (Filogic 820) dual-core processor @ 1.3 GHz MediaTek MT7981BA (Filogic 820) dual-core processor @ 1.3 GHz without PCIe interface System Memory – 1GB DDR4 @ 2133 Mbps Storage 2MB NOR flash for bootloader 16GB or 32GB eMMC flash for main OS (OpenWrt) Footprint for NAND flash Wireless Radio Mode – 2.4GHz 2×2 + 5GHz 3×3  MIMO via MT7976CN RF IC Radio Frequency […]

Posted on by Debashis Das - No Comments on STMicro ST4SIM-300 eSIM complies with SGP.32 GSMA eSIM Standard for IoT

STMicro ST4SIM-300 eSIM complies with SGP.32 GSMA eSIM Standard for IoT

ST4SIM 300 embedded SIM IC

STMicroelectronics has recently released the ST4SIM-300 eSIM, the first embedded SIM (eSIM) IC that complies with the new GSMA eSIM IoT Technical Specification (SGP.32). The chip is fully compliant with remote SIM provisioning of the GSMA eSIM IoT standards, so it works with 2G, 3G, 4G (LTE), CDMA, NB-IoT, and Cat-M networks. It is designed for small IoT devices and allows system operators to remotely program device subscriber identities over the air (OTA), making it a plug-and-play solution for seamless integration and management. Previously, we have written about Hologram’s IoT eSIM Chip that provides global connectivity and comes with 2FF, 3FF, 4FF, and Mff2- M2M form factors. We have also written about the Conexio Stratus Pro battery-powered nRF9161 development kit that supports eSIM as an option. ST4SIM-300 eSIM specifications Microcontroller – ST33K1M5M 32-bit Arm Cortex-M35P MCU Designed based on eSIM + eSE (embedded Secure Element) I/O Asynchronous serial I/O port […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 3 Comments on SparkFun RTK EVK offers GNSS with centimeter accuracy, WiFi, Bluetooth, 4G LTE Cat 1, and Ethernet connectivity

SparkFun RTK EVK offers GNSS with centimeter accuracy, WiFi, Bluetooth, 4G LTE Cat 1, and Ethernet connectivity

Sparkfun RTK EVK

SparkFun RTK EVK is a fully-enclosed GNSS platform designed for fixed or mobile high-precision positioning and navigation applications with centimeter accuracy thanks to RTK (real-time kinematic) technology implemented with modules from u-blox. About two months ago, Sparkfun introduced the RTK Torch waterproof GNSS surveyor with Unicore UM980 GNSS module with RTK support, ESP32 for WiFi/Bluetooth, and an STM32WLE5C LoRa SoC. The  SparkFun RTK EVK (evaluation kit) may drop LoRa connectivity, but it’s a more versatile platform with WiFi, Bluetooth, Ethernet, and LTE Cat 1 cellular connectivity, besides support for L1 + L2 RTK GNSS with L-Band correction. Sparkfun RTK EVK specifications: GNSS Receiver – u-blox ZED-F9P Concurrent reception of GPS, GLONASS, Galileo, and BeiDou Receives both L1C/A and L2C bands 184-channel u-blox F9 engine Time to First Fix: 25s (cold), 2s (hot) Max Navigation Rate: 20Hz / 25Hz depending on mode Horizontal Position Accuracy: 2.5m without RTK; 0.010m with RTK […]
