802.11ac

Posted on by Jean-Luc Aufranc (CNXSoft) - 16 Comments on Intel Processor N95 Alder Lake-N CPU shows up in entry-level mini PC with 2.5GbE, dual HDMI

Intel Processor N95 Alder Lake-N CPU shows up in entry-level mini PC with 2.5GbE, dual HDMI

2.5GbE Alder Lake-N mini PC

We’ve started to see Intel Alder Lake-N processors in mini PCs such MSI Cubi ADL N and Morefine M9 based on announced SKUs, but the Intel Processor N95 processor, which Intel has yet to unveil, is now found in a mini PC sold for various Aliexpress sellers starting at $187 for a barebone system and going up to $384 for a model with 32GB RAM and a 1TB SSD preloaded with an activation version of Windows 10 or Windows 11. The Processor N95 is a quad-core processor clocked at up to 3.4 GHz (Turbo) with 6MB cache, and 16EU Intel UHD graphics clocked up to 1.2 GHz. The 15W processor’s base frequency is shown to be 1.7 GHz in GeekBench while the 6W Alder Lake-N processors have a sub-GHz base frequency. That could mean the CPU performance is quite higher than the 6W N100 and N200 parts, but the GPU […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 8 Comments on $96+ Banana Pi BPI-M2S Amlogic A311D/S922X SBC offers dual GbE, optional PoE and WiFi 5

$96+ Banana Pi BPI-M2S Amlogic A311D/S922X SBC offers dual GbE, optional PoE and WiFi 5

The Banana Pi PPI-M2S is a single board computer (SBC) powered by either Amlogic A311D or S922X processor with 4GB RAM, 16GB eMMC flash, HDMI 2.1 and MIPI DSI display interfaces, one MIPI CSI camera connector, two Gigabit Ethernet ports with one PoE capable, as well as optional WiFi 5 & Bluetooth support. When we first covered the Banana Pi BPI-M2S over a year ago, all we had were some 3D renders of the board and some preliminary specifications. The company has now manufactured the board, provided some documentation, and started to take orders for the board on Aliexpress for $95.79 or $100 depending on whether Amlogic S922X or A311D is selected. Banana Pi BPI-M2S specifications: SoC – Amlogic A311D or S922X hexa-core processor with 4x Arm Cortex-A73 cores @ 2.21 GHz, 2x Arm Cortex-A53 cores @ 1.8 GHz, Arm Mali-G52 MP4 (6EE) GPU with OpenGL ES 3.2, Vulkan 1.0 […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 3 Comments on WisGate Connect Raspberry Pi CM4 gateway supports 2.5GbE, WiFi 6, BLE, LoRaWAN, 4G, 5G, and more

WisGate Connect Raspberry Pi CM4 gateway supports 2.5GbE, WiFi 6, BLE, LoRaWAN, 4G, 5G, and more

RAKwireless has just introduced the WisGate Connect gateway based on Raspberry Pi CM4 system-on-module with support for Gigabit and 2.5Gbps Ethernet plus various optional wireless connectivity option that can be added through Mini PCIe or M.2 sockets as well as expansion through WisBlock IO connectors. Wireless options include LoRaWAN, 4G LTE, 5G, WiFi 6, Zigbee, WiFi HaLoW, and more, while WisBlock modules enable features such as methane sensor, motor current sensor, temperature sensor, pressure control, and valve control among many others. WisGate Connect (RAK7391) specifications: SoM – Raspberry Pi CM4 with Broadcom BCM2711 quad-core Cortex-A72 processor @ 1.5GHz, 1 to 8Gb DDR4, optional 8 to 32GB eMMC flash, optional WiFi 5 and Bluetooth 5.0 LE Storage – MicroSD card socket for CM4 Lite modules only Video Output – HDMI 2.0 up to 4Kp60, 22-pin MIPI DSI connector Camera I/F – 2x 22-pin MIPI CSI connectors Networking Wired – Gigabit Ethernet […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 8 Comments on $55+ Orange Pi 4 LTS SBC features YT8531C Ethernet PHY, CDW 20U5622-00 wireless module

$55+ Orange Pi 4 LTS SBC features YT8531C Ethernet PHY, CDW 20U5622-00 wireless module

Orange Pi 4 LTS is a cost-optimized (and availability-optimized) variant of the Rockchip RK3399 powered Orange Pi 4 single board computer that was introduced in 2019 with 4GB RAM for $49.90 and up. Shenzhen Xunlong Software mainly kept the same design with the cost savings involving a choice of 3GB or 4GB RAM, and the replacement of Realtek Ethernet PHY and Ampak wireless module with the equivalent MotorComm YT8531C Ethernet chip and CdTech wireless module with WiFi and Bluetooth 5.0 connectivity. Orange Pi 4 LTS specifications with changes highlighted in bold: SoC – Rockchip K3399 hexa-core big.LITTLE processor with two Arm Cortex A72 cores @ up to 1.8 GHz, four Cortex A53 cores, and an ARM Mali-T860 MP4 GPU System Memory – 3GB or 4GB LPDDR4 Storage – MicroSD card socket, optional 16 GB eMMC flash Video Output/Display Interface HDMI 2.0 up to 4K @ 60 Hz LCD connector for […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 6 Comments on Amlogic S905W4 TV Box ships with Amlogic W1 WiFi 5 module

Amlogic S905W4 TV Box ships with Amlogic W1 WiFi 5 module

As I just posted about MediaTek Filogic 830/630 WiFi 6/6E chip, I was informed that Amlogic may have its own WiFi chip as “W1” module showed up in the SDK’s source code. It turns out there’s at least one TV box with Amlogic W1 802.11b/g/n/ac module/chip?, namely X96 Mini+, that also happens to come with an Amlogic S905W4 quad-core Cortex-A53 processor we’ve never covered on CNX Software. Apart from the new processor and WiFI module, X96 Mini Plus is your typical entry-level 4K TV box with up to 2GB RAM, 16GB storage, HDMI 2.0 video output, composite video output, Ethernet, and a couple of USB ports. X96 Mini Plus specifications: SoC – Amlogic S905W4 quad-core Arm Cortex A53 @ 1.2GHz with penta-core Mali-450MP GPU @ 750MHz System Memory – 1 or 2GB DDR3 Storage – 8GB or 16GB eMMC flash, microSD card slot Video Output – HDMI 2.0a up to […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 4 Comments on Cellular gateway board takes up to five 4G mini PCIe cards, one 5G M.2 module, seven SIM cards

Cellular gateway board takes up to five 4G mini PCIe cards, one 5G M.2 module, seven SIM cards

One Banana Pi customer asked them to customize Banana Pi BPI-R64 Linux router board based on MediaTek MT7622 WiFi processor as part of their “BPI 4.0 server” OEM/ODM customization service. Specifically, they were asked to design a cellular gateway board with the same five Gigabit Ethernet ports as on the original board, but adding five mini PCIe sockets and SIM card slots for 3G/4G cards, and one M.2 socket plus two SIM cards for a 5G module. Here’s the result! Banana Pi “GrassRouter” cellular gateway board specifications: SoC – MediaTek MT7622E dual-core ARM Cortex-A53 processor @ 1.35GHz System Memory – 1 or 2GB RAM Storage – 8GB eMMC flash, MicroSD card slot Connectivity Cellular 1x 5G via M.2 Key-B module (USB 3.0 or PCIe bus), 2x SIM card slots. Up to 5x 3G/4G LTE via  mPCIe expansion socket, 5x SIM card slots Ethernet – 5x Gigabit Ethernet ports (4x LAN […]

Posted on by Sponsored Post - 3 Comments on Wallys WiFi 5 (802.11ac) mini PCIe cards deliver higher Tx power and performance (Sponsored)

Wallys WiFi 5 (802.11ac) mini PCIe cards deliver higher Tx power and performance (Sponsored)

Wallys is offering two mini PCIe cards to add WiFI 5 (802.11ac) to existing gateways, computers, or boards. Both 802.11ac modules are powered by Qualcomm Atheros QCA9880 chipset, with DR600VX mPCIe module delivering up to up to 867Mbps thanks to 2×2 MIMO, and DR900VX mPCIe module up to 1.3 Gbps using 3×3 MIMO technology. Both modules share most of the same key features & specifications: Chipset – Qualcomm Atheros QCA9880 wireless local area network (WLAN) system-on-chip (SoC) for 5 GHz 802.11ac or 2.4/5 GHz 802.11n WLAN WiFi 2.4GHz max 26dBm & 5GHz max 25dBm output power IEEE 802.11ac compliant & backward compatible with 802.11a/b/g/n IEEE 802.11d, e, h, i, k, r, v time stamp, and w standards DR600VX – 2×2 MIMO technology up to 867 Mbps DR900VX – 3×3 MIMO technology up to 1.3 Gbps Supports Spatial Multiplexing, Cyclic-Delay Diversity (CDD), Low-Density Parity Check (LDPC) Codes, Maximal Ratio Support for […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 4 Comments on Geniatech XPI 3128 RK3128 SBC is Equipped with an NXP WIFi 5 Module

Geniatech XPI 3128 RK3128 SBC is Equipped with an NXP WIFi 5 Module

Geniatech XPI family of single board computers was first introduced in 2018 with the launch of the XPI-S905X development board following many of Raspberry Pi 3 Model B features and form factor. The company has now added another board to the family with XPI 3128 single board computer powered by a Rockchip RK3128 quad-core Cortex-A7 processor coupled with up to  2 GB RAM and 64 GB flash, as well as an NXP WiFi 5 and Bluetooth 4.2 module. Geniatech XPI 3128 specifications: SoC – Rockchip RK3128 quad-core Cortex-A7 processor @ up to 1.2GHz GPU with Arm Mali 400 MP2 GPU (See datasheet) System Memory – 512MB DDR3L (1GB, 2GB optional） Storage – 8GB flash (16GB, 32GB, 64GB optional), and MicroSD card slot Video Output – HDMI up to 1080p60 Video – 1080p60 H.264/H.265 video decoding Connectivity 10/100M Ethernet port Dual-band 802.11b/g/n/ac WiFi 5 and Bluetooth 4.2 via Marvell/NXP 88W8897 module, […]
