$70 MicroNFCBoard Brings NFC Connectivity to Any Board or Device (Crowdfunding)

AppNearMe MicroNFCBoard is a development platform for Near Field Communication (NFC) comprised of an NFC transceiver, an NXP MCU, and all software stack and tools you need for development. This board also exposes various I/Os that allows you to connect to external hardware or devices, and it can be used with an Arduino, Raspberry Pi, mbed or PC/Mac. Let’s go through the board specifications first: MCU – NXP LPC11U34FHN33/421 Cortex M0 MCU @ 48MHz, with 10KB RAM, 48KB FLASH, 4KB EEPROM NFC Transceiver – NXP PN512. Reader/Writer and card operation modes supporting ISO14443A/Mifare and FeliCa schemes.  NFCIP-1 mode Splittable antenna USB – 1x micro USB port for power and programming I/O – 20x through holes with access to serial (UART), I2C, SPI, 4x ADC inputs, IRQ, Boot and Reset, and power pins. (2x pin header that you can solder are provided) Misc – Reset and bootloader enable push-buttons, 2x LEDs. […]

Adafruit mbed and NFC/RFID Starter Pack with µNFC stack & NFC Mood Lamp Demo

If you are looking for a (relatively) low cost NFC development kit, you may interested in Adafruit mbed and NFC/RFID Starter Pack that sells for 134.99 USD. The kit contains the following items: mbed LPC1768 (Cortex M3) development board with mini-B USB cable and reference cards NFC/RFID breakout board based on PN532 NFC transceiver MiFare RFID card with 1K programmable EEPROM Full-sized breadboard 40 x 3″ (75mm) long male/male jumper wires Standard blue & white 16×2 character LCD + contrast potentiometer + header Diffused 5mm RGB LED + 3 x 560 ohm resistors Analog temperature sensor (TMP36) Piezo buzzer 2 x 10K trim potentiometer 5 x Tactile Pushbuttons On the software side, you can use AppNearMe µNFC stack written in C++ that allows you to use a user interface on NFC-enabled smartphone, removing the need for knobs, buttons, screens on your embedded device. During the initial pairing, the NFC board can […]
