Posted on by Debashis Das - 13 Comments on xSDR – A tiny M.2 2230 SDR module with Artix-7 FPGA and LMS7002M RFIC (Crowdfunding)

xSDR – A tiny M.2 2230 SDR module with Artix-7 FPGA and LMS7002M RFIC (Crowdfunding)

xSDR single sided M.2 software defined radio with 2× RX TX channels up to 3.8 GHz

Wavelet Lab’s xSDR is a tiny, single-sided M.2 2230 software-defined radio (SDR) module designed for integration into laptops, embedded systems, and edge computing devices. A successor to the company’s previous uSDR, the “x” in xSDR stands for “extended,” adding 2×2 MIMO support and a wider frequency range to the same tiny footprint. The module is built around the Lime Microsystems LMS7002M RFIC and an AMD Artix-7 XC7A50T FPGA as found in the LimeNET Micro 2.0 Developer Edition board. This combination allows for a tuning range of 30 MHz to 3.8 GHz and a sample rate of up to 122.88 MSPS, making this SDR suitable for cellular research (LTE/5G), spectrum analysis, satellite tracking, and high-speed data links (with two modules). Wavelet Lab’s xSDR specifications: RFIC – Lime Microsystems LMS7002M programmable RF (FPRF) transceiver IC FPGA – AMD Embedded XC7A50T (Artix-7) with 52,160 logic cells RF capabilities Channels – 2×2 MIMO (2x […]

Posted on by Debashis Das - 7 Comments on ESP32-S3 multi-radio Smart Home gateway features Ethernet, Zigbee, Thread, Z-Wave, Wi-Fi, BLE, and optional 4G LTE connectivity

ESP32-S3 multi-radio Smart Home gateway features Ethernet, Zigbee, Thread, Z-Wave, Wi-Fi, BLE, and optional 4G LTE connectivity

SLZB Ultima multi radio smart home gateway with ESP32 S3 Zigbee Z Wave, Matter or Thread

SMLIGHT SLZB-Ultima is an ESP32-S3-based, multi-radio smart-home gateway with dual Zigbee/Thread radios, optional Z-Wave 800, Wi-Fi, Bluetooth LE, Ethernet with PoE, USB host expansion, and optional 4G LTE connectivity designed for advanced Home Assistant and DIY applications. The device also integrates an IR receiver and transmitter for controlling legacy appliances, GPIO and I²C for hardware expansion, a buzzer, physical buttons, service LEDs, and 12 on-board WS2812B RGB LEDs on the front for status indication. These features make it suitable for an all-in-one smart-home and IoT gateway rather than a simple coordinator. SMLIGHT SLZB-Ultima specifications: Main SoC – ESP32-S3 CPU – Dual-core LX7 microprocessor @ up to 240 MHz with Vector extension for machine learning Wireless – WiFi 4 and Bluetooth 5 with LE/Mesh Audio – Built-in buzzer and optional microphone for ESPHome Voice Assist Networking  Wireless Dual Zigbee / Thread radios (Texas Instruments CC2674P10 + Silicon Labs EFR32MG24) Wi-Fi 802.11 b/g/n […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on nRF9151 SMA DK development kit offers cellular IoT, DECT NR+, and 5G NTN satellite connectivity

nRF9151 SMA DK development kit offers cellular IoT, DECT NR+, and 5G NTN satellite connectivity

Nordic nRF9151 SMA DK

Nordic Semiconductor’s nRF9151 SMA DK development kit is designed for building IoT applications using  LTE-M/NB-IoT cellular IoT, DECT NR+, or 5G NTN (Non-Terrestrial Network) satellite connectivity. The development kit offers three ways to connect a SIM card, namely a NanoSIM card slot, an MFF2 SIM footprint for eSIM or software iSIM, and a 10-pin SIM connector. It also includes two SMA connectors for GPS and LTE antennas or lab equipment, multiple current measurement connectors, and Arduino UNO headers for expansion, notably the nRF7002 EK for adding Wi-Fi 6 locationing capabilities. nRF9151-SMA-DK specifications: Wireless System-in-Package – Nordic Semi nRF9151 CPU – Arm Cortex-M33 @ 64 MHz Memory – 256KB RAM Storage – 1MB flash Connectivity Multimode LTE-M/NB-IoT/NB-NTN modem with DECT NR+ support and GNSS. 700-2200 MHz LTE band support. Power Class 5 20 dBm Power Class 3 23 dBm 1.9 GHz and 915 Mhz DECT NR+ band support Security – Arm […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Airgain introduces plug-and-play NimbeLink Skywire Cat 1bis embedded modem for industrial IoT applications

Airgain introduces plug-and-play NimbeLink Skywire Cat 1bis embedded modem for industrial IoT applications

Airgain NimbeLink Skywire Cat 1bis plug and play module

Airgain has recently launched the pre-certified NimbeLink Skywire Cat 1bis Embedded Modem, which it claims is the “industry’s first plug-and-play Cat 1bis modem for end-application use in industrial IoT”. We’ve already seen several Cat 1bis modules for industrial IoT applications such as the u-blox SARA-R10001DE and Cavli C17QS, among others. What Airgain highlights here is its module’s plug-and-play ability through the Skywire interface (two headers), while other modules typically need to be soldered on the PCB. Airgain NimbeLink Skywire Cat 1bis modem specifications: Based on Quectel EG916Q-GL module Cellular 4G LTE Bands LTE-FDD: B1, B2, B3, B4, B5, B7, B8, B12, B13, B18, B19, B20, B25, B26, B28, B66 LTE-TDD: B34, B38, B39, B40, B41 SIM card Micro (3FF) SIM slot Verizon MFF2 SIM Data rates – Up to 10 Mbps downlink and 5 Mbps uplink Variants North America (TC1bisNAG model) – AT&T, Bell, Rogers, Telus, Verizon networks Worldwide (QC1bisWWG […]

Posted on by Debashis Das - No Comments on Inventia MT-718 PS battery-powered IP68 industrial telemetry logger integrates environmental sensors, cellular IoT connectivity

Inventia MT-718 PS battery-powered IP68 industrial telemetry logger integrates environmental sensors, cellular IoT connectivity

Inventia MT 718 PS battery operated telemetry logger with IP68 protection

Inventia MT-718 PS is a compact, battery-powered industrial telemetry logger designed for monitoring, logging, and data transmission in industrial and environmental applications, especially in areas where grid power supply and access to infrastructure are limited. It supports 2G/4G LTE Cat 1 or NB-IoT/LTE Cat M1 (eMTC) connectivity, and comes with an IP68-rated waterproof housing, allowing operation under 2 meters of water for up to 24 hours. Key features include five binary/counter inputs, two analog inputs (0–5V with 4–20mA conversion option), and built-in pressure (0–10 bar), temperature, and humidity sensors, as well as RS-485 with Modbus RTU support. The logger also features two digital outputs, can store up to 60,000 records at 1-second intervals, offers an optional OLED display, and supports OTA firmware updates. It is powered by replaceable alkaline or lithium batteries for long-term, maintenance-free operation and includes tamper detection via a lid sensor. The MT-718 OS can be used […]

Posted on by Debashis Das - No Comments on Jetway F35-MTU1 3.5-inch SBC features Intel Core Ultra 7 155U or Ultra 5 125U Meteor Lake SoC

Jetway F35-MTU1 3.5-inch SBC features Intel Core Ultra 7 155U or Ultra 5 125U Meteor Lake SoC

jetwayipc F35 MTU1 3.5 Inch SubCompact SBC

Jetway recently launched the F35-MTU1 3.5-inch SubCompact SBC, built around the Intel Core 5 125U and Ultra 7 155U (Meteor Lake) processors which also integrates an NPU for AI acceleration. It supports up to 96GB of DDR5 memory, features dual Intel 2.5GbE LAN with TSN, and supports WiFi 6 and 4G LTE connectivity via M.2 sockets. The board has several 4K display outputs, including DP Type-C, DP, HDMI, and LVDS/eDP. For storage, it offers M.2 slots supporting NVMe, PCIe, and CNVi, along with a SATA III port with RAID 0/1 support for data redundancy. I/O options include USB 3.2, USB 2.0, and four COM ports for serial communication, which can be used to connect external peripherals. With a wide operating temperature range and support for both Windows and Linux, the SBC is well-suited for AI workloads, IoT edge devices, and industrial control systems that demand high performance, connectivity, and reliability. […]

Posted on by Debashis Das - 3 Comments on GL.iNet Spitz Plus GL-X2000 – An affordable WiFi 6 cellular router with GbE, dual SIM, and load balancing capabilities

GL.iNet Spitz Plus GL-X2000 – An affordable WiFi 6 cellular router with GbE, dual SIM, and load balancing capabilities

Spitz Plus (GL X2000) Wi Fi 6 4G LTE CAT 12 Router

GL.iNet Spitz Plus GL-X2000 is a Wi-Fi 6 cellular router with GbE networking, two nano SIM slots, interchangeable high-gain antennas, and more. It is built around a Qualcomm IPQ5018 dual-core 1 GHz SoC and supports AX3000 Wi-Fi speeds with data rates of up to 574 Mbps on 2.4GHz and 2402 Mbps on 5GHz. Other features include support for multi-WAN connectivity, failover, and load balancing for stable connections, it also comes with preinstalled VPN support for over 30 providers. It also has remote management features that allow users to monitor data usage, update firmware, and troubleshoot through a centralized interface. The device is available in different LTE variants for North American and international markets, supporting region-specific bands. These features make this router useful for applications such as remote work, mobile offices, industrial IoT, and backup connectivity in areas with unreliable broadband. GL-X2000 (Spitz Plus) specifications: SoC – Qualcomm IPQ5018 dual-core Cortex-A53 […]

Posted on by Debashis Das - No Comments on Altair ALT1350 based HL7900 5G LPWA module supports Wi-SUN, GNSS, and NB-IoT over non-terrestrial networks

Altair ALT1350 based HL7900 5G LPWA module supports Wi-SUN, GNSS, and NB-IoT over non-terrestrial networks

Sierra Wireless HL7900 5G LPWA module

The HL7900 5G LPWA module from Semtech (Sierra Wireless) is a globally certified solution built around Sony’s Altair ALT1350 chip and designed for low-power IoT applications. It is certified by major U.S. carriers, including AT&T, T-Mobile, and Verizon, as well as Japan’s KDDI, and has achieved global regulatory certifications (FCC, CE, ISED, etc.) and industry certifications (PTCRB, GCF) for carrier interoperability. This chip features an ultra-low-power sensor hub MCU for efficient environmental monitoring. Additionally, it includes integrated sub-GHz and 2.4GHz radios supporting short-range protocols such as Wi-SUN including U-Bus Air, NB-IoT, and 5G NTN along with GNSS and Wi-Fi-based indoor/outdoor tracking. Furthermore, this chip supports embedded SIM support, secure edge-to-cloud connectivity, and over-the-air updates. These features make this chip useful for applications such as asset tracking, urban navigation, and other IoT solutions requiring reliable, low-power connectivity with global reach. Semtech HL7900 specifications: MCU – Sony ALT1350 5G cellular IoT chip […]
