Tiger Lake UP3 single board computer offers quad displays, 2.5 GbE, PCIe Gen4, up to 32GB RAM

tiger lake up3 single board computer

Taiwan Commate Computer Inc, also known as just Commell, has unveiled LE-37O 3.5-inch single board computer based on Intel Tiger Lake UP3 embedded processors for industrial applications. The SBC supports up to 32GB DDR4 single-channel memory, up to four displays through DisplayPort, HDMI, VGA, and LVDS interfaces, and offers both Gigabit Ethernet and 2.5 GbE ports, as well as PCIe Gen4 via an M.2 socket. Commell LE-37O specifications: SoC – Intel Tiger Lake UP3 processor with Iris Xe graphics; FBCGA1449 package; 12-28W TDP; default: Core i7-1185G7E quad-core/octa-thread processor; option: Celeron 6305E dual-core processor System Memory – 1x 260-pin DDR4 3200 MHz SO-DIMM up to 32GB non-ECC, unbuffered memory Storage – 2x SATA III ports with RAID 0,1 support, M.2 and mSATA storage (see Expansion section) Video Outputs HDMI port DisplayPort port 24-bit dual channel LVDS connector with +3.3V/+5V/+12V supply; 1x LCD inverter connector VGA connector Quad independent display support Optional […]

Commell LP-179 Pico-ITX motherboard ships with Intel Tiger Lake UP3 embedded processor

Intel first introduced Core i3/i5/i7 Tiger Lake UP3 processors with Intel Xe graphics in early September 2020, soon followed with embedded versions of Tiger Lake UP3 a couple of weeks later, and then Celeron 6305E, still for embedded & IoT applications, with support for features such as 2.5GbE and quad-display support. We’ve already seen some Tiger Lake UP3 motherboards with AAEON UP Xtreme i11 (122 x 120 mm) and IEI tKINO-ULT6 mini-ITX SBC, but if you’d like a more compact Tiger Lake solution, Commell LP-179 Pico-ITX motherboard may be an option with a choice of Core i7-1185G7E or Celeron 6305E processor. Commell LP-179 specifications: SoC (one or the other) Intel Core i7-1185G7E quad-core/octa-thread Tiger Lake UP3 embedded processor @ 1.8 GHz / 4.4 GHz (Turbo) with 12MB cache, 96EU Intel Iris Xe graphics; 12 to 28W TDP Intel Celeron 6305E dual-core Tiger Lake UP3 embedded processor @ 1.8 GHz (No […]

Commell Unveils LP-178 Whiskey Lake Pico-ITX SBC

We’ve previously covered several Intel Whiskey Lake-U SBCs in various form factors such as the Commell LE-37N 3.5″ board, ASRock IMB-1216 mini-ITX motherboard, or UP Xtreme with a custom 122×120 form factor. But if your project or application requires a more compact form factor, Commell has just announced LP-178 Whiskey Lake Pico-ITX SBC with either  Intel Core i7-8665UE or Celeron 4305UE 8th generation embedded processor. LP-178 board  specifications: SoC (one or the other) Intel Core i7-8665UE quad-core/octa-thread processor @ 1.7GHz / 4.4GHz (Turbo) with Intel UHD Graphics 620; 8MB cache; 15W TDP Intel Celeron 4305UE dual-core processor @ 2.0GHz with Intel UHD Graphics 610; 2MB cache; 15W TDP FCBGA1528 package System Memory – SO-DIMM socket for up to 16GB DDR4 RAM Storage – 1x SATA 3.0 interface Video Output / Display I/F HDMI port up to 4K resolution DisplayPort output DP to VGA or LVDS via an optional adapter Triple […]

Commell LE-37N 3.5″ SBC is Powered by Intel Whiskey Lake-U Core i7-8665UE Processor

Commell has announced its 3.5” LE-37N SBC run by the 8th generation Whiskey Lake-U quad-core processor. The board has support for triple displays, 4x USB 3.1 Gen 2, 2x SATA III 2x GbE, M2 and Mini-PCIe. Previously we reported on the ASRock IMB-1216 mini-ITX board powered by a choice of Whiskey Lake-U SoCs, as well as the crowdfunded UP Xtreme Whiskey Lake-U SBC. LE-37N Whiskey Lake-U SBC The LE-37N miniboard platform is specifically designed for the Whiskey Lake-U Intel processors with the FCBGA1528 sockets. But it was built with the quad-core, 8-thread, 1.7 GHz Core i7-8665UE with an 8MB cache, 15W TDP and 24 EU Intel Generation 9.5 HD Graphics. It supports DDR4 memory in two SO-DIMM 2400 MHz slots for up to a total of 32GB.  The 8th Generation Whiskey Lake-U i7 processor is more power-efficient and supports Linux and Windows OSes. Extra Features and Display Options There is […]
