Posted on by Jean-Luc Aufranc (CNXSoft) - 14 Comments on ASM2362 USB 3.1 Gen2 to PCIe Chip is Designed for USB NVMe SSD Drives

ASM2362 USB 3.1 Gen2 to PCIe Chip is Designed for USB NVMe SSD Drives

ASM2362

Most USB enclosure or expansion drive are designed with a SATA interface that tops out at 6 Gbp. That’s fine in most cases,  but if your host computer comes with USB 3.1 Gen2 SuperSpeed 10 Gbps (SuperSpeed+) port capable of even better performance, ASMedia now has a solution for faster USB drives with their ASM2362 USB 3.1 Gen2 to PCIe NVMe SSD chip. The solution is pretty new, and ASMedia has not setup a product page on their website yet, but they showcased a demo at Computex 2018.  In the photo above a Samsung 960 Pro SSD M.2 is connected to  another USB board  ASMedia – likely based on AS3142 Gen2 xHCI Host Controller – itself connected to a computer with a USB 3.1 Gen2 port.  The photo below shows CrystalDiskMark benchmark results comparing ASM2362 USB to NVMe solution to a standard USB to SATA enclosure. While the USB to SATA SSD achieves around 550 MB/s, the USB 3.1 to […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on IC Nexus SBC3100 Rockchip RK3399 SBC Supports Variable DC Input (9 to 36V)

IC Nexus SBC3100 Rockchip RK3399 SBC Supports Variable DC Input (9 to 36V)

SBC3100

Earlier this year, we got flooded with announcements for new Rockchip RK3399 SBC’s or development boards with products like RockPro64 or Orange Pi RK3399. Here’s another one launched last year by Taiwan based IC Nexus, which showcased their SBC3100 board at Computex 2018 this past week. IC Nexus SBC3100 SBC specifications: SoC – Rockchip RK3399 hexa core big.LITTLE processor with two Arm Cortex-A72 cores up to 2.0GHz, four Cortex-A53 cores up to 1.5GHz, and a Mali-T864 GPU with OpenGL ES1.1/2.0/3.0/3.1, OpenVG1.1, OpenCL, DX11, and AFBC System Memory – 1 GB, 2GB or 4GB RAM Storage –  8 or 16GB eMMC flash, 1x microSD slot Display Interfaces / Video Output HDMI 2.0 up to 4K @ 60Hz DisplayPort 1.2 up to 4K @ 60 Hz via USB Type-C connector 1x eDP 1.3 up to 2560 x 1600 @ 60 Hz MIPI-DSI up to 2560 x 1600 @ 60 Hz I2C capacitive touch screen interface Video – Hardware decoder up to 4Kx2K […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - 7 Comments on Close Up Photos of UDOO Bolt Ryzen Embedded V1000 Development Board

Close Up Photos of UDOO Bolt Ryzen Embedded V1000 Development Board

UDOO-Bolt-Board-Top

The first AMD Ryzen Embedded V1000 development board – UDOO Bolt  – was  launched on Kickstarter last week, but for whatever reasons, the company did not provide close up photos of the board. But luckily for us, TLS – regular reader & commenter, and occasional contributor for CNX Software – is now at Computex 2018 and spent some time at UDOO’s booth where he took time to take some photos and share with us. The top view of the board shows the two SO-DIMM slots and Ryzen Embedded processor, as well as an better looks at the ports and headers around the boards. The board should support up to 4 displays via its two HDMI 2.0a ports, and two USB type C ports with DP alternate mode. While, AMD Ryzen Embedded V1000 SoCs support 10 GbE, UDOO selected TRXCOM TRJG19901DNL Gigabit Ethernet jack, probably to keep costs under control. The bottom side reveals the M.2 Key B 2260 socket for SATA […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on ASUS VivoWatch BP is a Fitness Tracker that Measures Blood Pressure

ASUS VivoWatch BP is a Fitness Tracker that Measures Blood Pressure

If you need to monitor your blood pressure regularly, you may have used one of those blood pressure monitors that you wraps around your upper arm, and display results on an LCD display, and in some cases, synchronize the data with your smartphone Bluetooth. Those devices do the job, but they may be inconvenient to use daily, and some people just forgo measurements. Omron first introduced a more user-friendly solution with their Project Zero BP6000 blood pressure monitor-in-a-watch in 2016, further refined with Project Zero 2.0 watch in 2017. That’s all good, except for the same details that neither versions of the watch – to be called Heartvue – are for sale, as the company is still working on FDA approval… ASUS has filled the void with VivoWatch BP watch, and IMHO has taken a more clever approach to launching their product, since the watch will be available in Asia this summer, and in the US after FDA approval, which […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - 3 Comments on ASUS Announces 802.11ax WiFi Routers at Computex 2018

ASUS Announces 802.11ax WiFi Routers at Computex 2018

802.11ax is a new WiFi standard offering better performance, especially in high-density scenario, where average per usage bandwidth may be improved by up to 4 times, so city dwellers should benefit the most. Last year, we started to see 802.11ax compliant chips from Broadcom, Marvell, Qualcomm, and others, so it should come as no surprise that some of first 802.11ax WiFi routers are launched this year. ASUS introduced two 802.11ax WiFi routers at Computex 2018 with ROG Rapture GT-AX11000 tri-band 802.11ax router, RT-AX88U dual band 802.11ax router , and the AX6100 WiFi System for mesh networking. ROG Rapture GT-AX11000 The ROG Rapture GT-AX11000 is a high-end router with a peak aggregate throughput of about 11000 Mbps. Specifications: Processor – Quad core processor @ 1.8 GHz System Memory – 1 GB RAM Storage – 256 MB flash Connectivity WiFi 802.11a/b/g/n/ac/ax,  IPv4, IPv6 Tx/Rx – 2.4 GHz 4×4, 5 GHz-1 4×4,  5 GHz-2 4×4 Data Rates 802.11ax (2.4GHz) – up to 1148 […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - 8 Comments on Qualcomm Snapdragon 850 is Designed for Windows 10 Mobile PCs

Qualcomm Snapdragon 850 is Designed for Windows 10 Mobile PCs

Snapdragon 850

As you all probably know, Qualcomm and Microsoft worked together and  launched always-on, always-connected Windows 10 mobile PCs powered by Qualcomm Snapdragon 835 Arm processor earlier this year. Battery life is spectacular, but considering the fairly high price of such devices, many were disappointed by performance which in many cases is not much better than much cheaper Intel Apollo Lake laptops. But performance of future Qualcomm based Arm laptops will improve significantly thanks to Snapdragon 850 Mobile Compute Platform featuring eight Kryo 385 cores clocked to close to 3 GHz, and other enhancements. Qualcomm Snapdragon 850 “Mobile Compute Platform” specifications: CPU – 8x Kryo 385 Arm cores clocked @ up to 2.96 GHz GPU – Adreno 630 Visual Processing Subsystem with Open GL ES 3.2, Open CL 2.0, Vulkan, DirectX 12 Ultra HD Premium video playback and encoding @ 4K (3840×2160) 30fps, Slow motion HEVC video encoding of FHD (1080p) up to 120fps H.264 (AVC), H.265 (HEVC), VP9 DisplayPort over […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - 5 Comments on NVIDIA Introduces Jetson Xavier Devkit and Isaac Robotics Software

NVIDIA Introduces Jetson Xavier Devkit and Isaac Robotics Software

NVIDIA Jetson Xavier

NVIDIA Xavier was first unveiled in September 2016 as an artificial intelligence SoC with eight NVIDIA Custom 64-bit Arm cores, a 512-core Volta GPU,  8K video encoding and decoding, and a computer vision accelerator (CVA) now called NVDLA (NVIDIA Deep Learning Accelerator). Earlier this year, the company announced Xavier was sampling,  and DRIVE IX & DRIVE AR SDKs for the automotive market. On the eve of Computer 2018, NVIDIA has introduced Jetson Xavier development kit, as well as Isaac robotics software for autonomous machines. Jetson Xavier key specifications: SoC – NVIDIA Xavier with 8-core ARMv8.2 64-bit CPU, 8MB L2 + 4MB L3 512-core Volta GPU with Tensor Cores 2x NVDLA engines for deep learning 7-way VLIW Processor for vision acceleration VPU with dual 4Kp60 video decoding and encoding System Memory – 16GB 256-bit LPDDR4x | 137 GB/s Storage – 32GB eMMC 5.1 flash Display – 3x eDP/DP/HDMI at 4Kp60 | HDMI 2.0, DP HBR3 Camera 16x CSI-2 Lanes (40 Gbps […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Tibbo-Pi is a Wirefree Modular IoT Prototyping Platform for Raspberry Pi Board

Tibbo-Pi is a Wirefree Modular IoT Prototyping Platform for Raspberry Pi Board

Tibbo-Pi

Tibbo Project System (TPS) is a modular Linux IoT prototyping platform based on the same Texas Instruments Sitara AM335x processor used in BeagleBone Black or a PocketBeagle boards, and comprised of a main board, Tibbit blocks to add features as needed, and an enclosure. I’ve now been informed the company will be at Computex 2018 to showcase their new products including Tibbo-Pi, following the same concept as Tibbo Project System, but leveraging Raspberry Pi 3 board and ecosystem instead. While an English brochure is said to be available, all information in the webpage listed in the photo above is in Japanese. But basically, Tibbo-Pi is said to be an IoT edge device for industrial use, made for build a prototypes, or small scale production system  thanks to a choice a 60 different Tibbit Blocks sensor and I/O module blocks, all wire free.  Programming of the system is typically done with with Node-RED (Javascript) on the Raspberry Pi, but the company also […]
