copter

Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on Manifold mini PC Powered by Nvidia Tegra K1 Processor is Designed for Drones

Manifold mini PC Powered by Nvidia Tegra K1 Processor is Designed for Drones

DJI is known for their high-end drones such as Phantom 3 quadcopter, but the company has now launched Manifold mini PC powered by Nvidia Tegra K1 quad core Cortex A15 processor and running Ubuntu 14.04 in order to allow developers run their own applications performing complex computing tasks and advanced image processing “on the fly”. DJI Manifold specifications: SoC – Nvidia Tegra K1 quad core Cortex-A15 processor @ up to 2.2 GHz with 192-core Kepler GPU System Memory – 2GB DDR3L Storage – 16GB eMMC 4.51 flash, micro SD slot Video Output – mini HDMI port Audio I/O – mini HDMI, combo audio jack for microphone and headphone Connectivity – Gigabit Ethernet port USB – 2x USB 3.0 ports, 2x USB 2.0 host ports, 1x micro USB port (supports Force Recovery mode and Host mode) ,  and a non-standard USB 2.0 interface with the drone. Camera – Camera In and […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 4 Comments on STMicro Introduces $35 STM32 Motor Control Nucleo Pack

STMicro Introduces $35 STM32 Motor Control Nucleo Pack

STMicroelectronics has recently launched P-NUCLEO-IHM001 motor control starter kit with NUCLEO-F302R8 Cortex M4 MCU board, X-NUCLEO-IHM07M1 driver board for BLDC (Brushless DC) and PMSM (Permanent Magnet Synchronous Motor) electric motors, as well as a Bull Running motor often used in RC helicopters and quadcopters. Technical specifications of the three hardware “blocks” of the kit: X-NUCLEO-IHM07M1 driver board: Three-phase driver board for BLDC/PMSM motors based on L6230 Nominal voltage range from 8 V to 48 V DC 2.8 A output peak current (1.4 A RMS) Non dissipative overcurrent detection and protection Compatible with ST 6-step or ST FOC control algorithm Support for sensorless and sensor mode Hall / encoder motor sensor connector and circuit Configurable jumpers for motor current sensing Potentiometer available for speed regulation ST morpho connectors (found in Nucleo boards) NUCLEO-F302R8 MCU board: STMicro STM32F302R8 Cortex-M4 @ up to 72 MHz with 64KB Flash memory and 16KB SRAM Expansion […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Arduino Compatible Microduino JoyPad with TFT Display Lets You Play Games, Control Devices, and More (Crowdfunding)

Arduino Compatible Microduino JoyPad with TFT Display Lets You Play Games, Control Devices, and More (Crowdfunding)

Last year, Microduino successfully launched their tiny Arduino board and shields via Kickstarter, and they are now back on Kickstarter with Microduino Joypad, an other Arduino compatible board that also happens to be a gamepad with a small OLED display. It can be used in standalone to control games on the tiny display, as a gamepad for PC or game console, a control interface for quadcopters and robots etc… Microduino Joypad (main board) specifications: MCU – Atmel ATMega328p/1284p/644p or 32U4 via Microduino Core, Core+, CoreUSB boards. (Not part of board but included in all perks) Display I/F – TFT and OLED headers. Separate TFT display board included in all perks. Controls – Left and right joysticks, 4 buttons, and left and right switches. Audio – Microphone Sensors – Light sensor, temperature sensor USB – 2x micro USB ports: one for power and one for charging Expansions – 2x UPin27 headers for […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on $25 Flutter is a Wireless Arduino compatible Board with Up to 1 km Range

$25 Flutter is a Wireless Arduino compatible Board with Up to 1 km Range

There are already several ways to add wireless connectivity to your hardware project. For short ranges, we can use protocols such as Bluetooth (e.g. RFDuino, BLEDuino projects, or Bluetooth USB dongle), for much longer ranges 3G/4G connectivity may be required, and achievable via a 3G/4G USB dongle, or SparqEE CELLv1.0 project for example. But what if you want something in the middle with a range closer to 1km? Flutter boards using the 915MHz band (US only) can provide such range, and are software compatible with the Arduino. There are two version of the board: Flutter Basic – Board with an low-profile integrated antenna. It features micro USB for power, an LED, and a button, as well as several digital and analog I/O. Flutter Pro – Board with external antenna (and probably longer range). It comes with all features found in Flutter Basic, and adds battery charging, an additional button, and […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 6 Comments on $49 (and up) Hex is an Arduino-compatible, Soon-to-be Open Source Nanocopter Kit

$49 (and up) Hex is an Arduino-compatible, Soon-to-be Open Source Nanocopter Kit

Do you remember Mecam, an upcoming $49 nanocopter with a camera? AFAIK, it’s not there yet, but a similar product with a similar price point is now “available” on Kickstarter. Hex nanocopters (quadcopter and hexacopter versions) are not voice-controlled, and do not come with a camera by default, but you can control them with iOS or Android mobile devices, and a camera can be fitted if needed. It comes as a kit, so you’ll have to assemble it yourself, and since it’s fully open source, you could even customize it to your taste. Hex specifications: Propellers – Size: 56×8.5 mm, Fits shaft: 1.0 mm Motors – Diameter: 7.0 mm, Length: 20 mm, Shaft diameter: 1.0 mm, Over 50,000 rotations per minute (rpm) Flight Control System: Flight control – Microwii Copter Processor – Atmel ATMega32u4 Gyro and Accel – InvenSense MPU6050 (6-axis) Battery – 350mAh battery (Flight Time – 7 minutes) […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 12 Comments on Sky Drone FPV HD Video Solution For Drones Uses 3G or 4G/LTE Networks and the BeagleBone Black

Sky Drone FPV HD Video Solution For Drones Uses 3G or 4G/LTE Networks and the BeagleBone Black

Earlier this week, I wrote about SparqEE CELLv1.0 a low cost cellular module to allow applications such as RC helicopter with extended range thanks to cellular networks. It turns out there’s currently a crowdfunding campaign that aims to bring such solution to market, but using 3G/4G USB dongles instead. Sky Drone FPV (First Person View) is an HD video system that can be controlled using 3G or 4G/LTE networks, and features the BeagleBone Black as the controller board. It would usually be attached to a quadcopter, by there’s not reason why you could not also use it with RC ground vehicles. Let’s start with the technical specifications: Controller Board – BeagleBone Black 3G/4G LTE Modem: Option 1 – Huawei E397Bu-501 for US / Americas (4G LTE FDD 1700/2100MHz and 700MHz) Option 2 –  Huawei E398u-1 for Europe / Asia (4G LTE FDD  900/2600 MHz) Camera: Option 1 – Full HD […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 2 Comments on Crazyflie Nano Quadcopter Open Source Development Kit

Crazyflie Nano Quadcopter Open Source Development Kit

If you can’t wait until 2014 to get the MeCam, Seeedstudio has something for you: The Crazyflie Nano Quadcopter, which looks similar to the MeCam, but does not feature a camera, its control board is powered by STM32F103CB MCU @ 72 MHz with 128kb flash and 20kb RAM (so, no it won’t run Linux), and at $173 the price is significantly higher. Here are Crazyflie key features: Small and lightweight, around 19g and about 90mm motor to motor Flight time up to 7 minutes with standard 170mAh Li-Po battery Standard micro-USB connector for charging which takes ~20min for the stock 170mAh Li-Po battery On-board low-energy radio@1mW based on the nRF24L01+ chip. Up to 80m range (environment dependent) when using the Crazyradio 2.4 GHz USB dongle Radio bootloader which enabled wireless update of the firmware 32 bit Cortex M3 MCU: STM32F103CB @ 72 MHz (128kb flash, 20kb RAM) 3-axis high-performance MEMs […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 6 Comments on Always Innovating MeCam is a $49 Voice-Controlled Nanocopter Camera

Always Innovating MeCam is a $49 Voice-Controlled Nanocopter Camera

Earlier today, I’ve posted a list of some interesting sessions for the upcoming ELC 2013, and one of the talk entitled “Lessons Learned in Designing a Self-video Self-hovering Nano Copter” by Gregoire Gentil, Always Innovating CEO, caught my attention. In this presentation, he will talk about the technical challenges the company encountered when they designed MeCam, a self video nano copter to point-and-shoot yourself, that should sell for just $49 retail. The MeCam launches from the palm of a hand and hovers instantly. It streams video to an Android or iOS phone or tablet that can be easily shared on social media platforms such as YouTube, Facebook, Google+ and Twitter. There’s no remote control for the MeCam as it’s either controlled by voice commands, or it can be setup to follow you around thanks to the follow-me feature. It can also do panorama shots automatically. The products is still in […]
