Nuvoton NuMicro MA35D0 is a low-cost dual-Core Arm Cortex-A35 microprocessor for industrial edge applications

NuMaker IoT-MA35D0-A1 Dev Board

The Nuvoton NuMicro MA35D0 series is a cost-effective, dual-core Arm Cortex-A35 MPU designed specifically for edge IoT applications. The specifications of this MPU are very similar to the Nuvoton MA35H0, and it looks more like a low-power low-cost version of the NuMicro MA35D1. The MPU features integrated, stacked DDR SDRAM options (128MB or 256MB) to reduce PCB complexity and BOM costs. It also offers some security options with Arm TrustZone, secure boot, cryptographic accelerators, and a True Random Number Generator, making it ideal for industrial applications. The MPU also offers various peripherals and connectivity options including 2x Fast Ethernet (IEEE 1588 v2) interfaces, high-speed USB, SD3.0/eMMC, three CAN FD, eleven UART, and more. Additionally, the MA35D0 MPU supports touchscreens and a TFT LCD controller with resolutions up to 1280×800. Nuvoton NuMicro MA35D0 Series specifications: CPU Sub-system  2x Arm Cortex-A35 cores running at up to 650 MHz L1 Cache – 32 Kbytes instruction […]

Nuvoton MA35H0 is a cost-optimized dual Cortex-A35 MPU for industrial HMI applications

Nuvoton MA35H0 develoment board

Nuvoton MA35H0 is a 650 MHz dual-core Cortex-A35 MPU designed for industrial HMI applications with up to 1280×800 resolution that offers a cost-down alternative to the 800 MHz Nuvoton MA35D1 microprocessor handling up to 1920×1080 resolutions. The MA35H0 integrates 128MB DDR memory, supports 2D graphics acceleration, JPEG and H.264 video decoding up to 1280×800 at 60 FPS, and is equipped with a range of interfaces such as Fast Ethernet, CAN FD, UART, and up to 154 GPIOs. It is designed to operate in an extended temperature range between -40 and 125°C. Nuvoton NuMicro MA35H0 specifications: CPU sub-system – 2x Cortex-A35 cores running at up to 650 MHz Memory sub-system On-chip 384 KB SRAM 128MB Multi-Chip Package (MCP) DDR Storage Quad SPI NAND flash controller Secure Digital Host Controller (SDHC) Display and Video Sub-system 18-bit 24-bit RGB TFT-LCD display interface up to 1280×800 @ 60 Hz 2D Graphic Engine (GFX) H.264 […]

STMicro unveils STM32MP2 Arm Cortex-A35/M33 MPU family starting with STM32MP25

STM32MP25 block diagram

STMicro has introduced its second generation of its STM32 MPUs (microprocessors) with the STM32MP2 moving to a 64-bit Arm architecture with Edge AI acceleration, multimedia features, graphics processing, and digital connectivity targeting industrial and IoT edge applications. The new family follows the STM32MP1 Arm Cortex-A7/M4 series introduced in 2019, and the first member of the family is the STM32MP25 with up to two 1.5 GHz Cortex-A35 cores coupled with an Arm Cortex-M33 real-time core clocked at 400 MHz, a 3D GPU, and a 1.35 TOPS NPU for AI acceleration. STM32MP25 key features and specifications: CPU – Single or dual Arm Cortex-A35 cores running up to 1.5 GHz Real-time MCU – Arm Cortex-M33 core running up to 400 MHz GPU – Unnamed 3D GPU for “advanced HMI” with support for the Vulkan API VPU – H.264 hardware video decoder and encoder AI accelerator – 1.35 TOPS NPU (Neural processing unit) System […]

Khadas VIM1S low-profile SBC features Amlogic S905Y4 quad-core Cortex-A35 SoC

Khadas VIM1S

Khadas VIM1S is an upcoming low-profile single board computer powered by an Amlogic S905Y4 quad-core Cortex-A35 processor that’s meant to provide an upgrade to the Amlogic S905X-powered Khadas VIM SBC introduced in 2016, and since then renamed to Khadas VIM1. Khadas has been teasing two new SBCs: the low-end Khadas VIM1S with S905Y4 SoC, and the most powerful Khadas Edge2 board equipped with a Rockchip RK3588S octa-core Cortex-A76/A55 processor. I have received both as you can clearly see from the photo above :), but I’m only allowed to write about information available publicly at this time, so today I’ll introduce the Khadas VIM1S which looks just like the VIM1 board. Khadas VIM1S specifications with highlights in bold showing the differences against the VIM1 Pro model: SoC – Amlogic S905Y4 quad-core Arm Cortex-A35 @ up to 2.0 GHz (real frequency) with Arm Mali-G31 MP2 GPU @ up to 850 MHz MCU – […]

S805X2 AV1 Android TV dongles and TV boxes are starting to show up

S805X2 TV box tv dongle

Amlogic S805X2 AV1 capable processor was first teased as an update to S805X and S805Y Full HD TV box processors in 2019 with very little details. But companies have started to list some S805X2 based Android dongles and TV boxes. That means we also have additional details for the processor, and we’ll look into SDMC DV9035 TV box and SEI Robotics SEI103 dongle, neither of which should be sold to end-users, but instead OEM’s or content providers. SDMC DV9035 S805X2 TV box Specifications: SoC – Amlogic S805X2 quad-core Arm Cortex-A35 processor with Mali-G31 MP2 GPU System Memory – 1GB DDR4 Storage – 8GB eMMC flash Video Output – HDMI up to 1080p60 with HDR support Video Codecs – AV1, VP9, H.265, H.264 High-dynamic Range – HDR 10, HLG, HDR10+Optional Connectivity 10/100M Ethernet Dual-band 2.4GHz/5GHz 802.11a/b/g/n/ac WiFI 5 with optional 2×2 MIMO, Bluetooth 4.2 or higher USB – 2x USB 2.0 ports DRM – […]

4K AV1 Android TV dongles surface with Amlogic S905Y4 Cortex-A35 processor

S905Y4 Android TV Dongle

Amlogic S905X4 is a quad-core Cortex-A55 SoC for 4K TV boxes and set-top boxes with H.265, H.264, VP9, and AV1 hardware video decoding. The silicon vendor usually provides a lower cost version of the processor for dongles without Ethernet, but keeping most of the same features, as we’ve seen in the past with S905X2 and S905Y2 processors for instance. S905X4 has now its own cost-down version with S905Y4 for Android TV (certified) dongles relying on WiFi for connectivity, but instead of keeping Cortex-A55 cores, the processor features four low-power Cortex-A35 cores. We do not have the full details about S905Y4 processor just yet, but it has start to show in dongles from SEI Robotics and SDMC that appears idendical. SDMC DV6071Z / SEI Robotics  SEI450 TV dongle specifications: SoC – Amlogic S905Y4 quad-core 64-bit Arm Cortex-A35 processor with Mali-G31 MP2 GPU System Memory – 2GB DDR (4GB optional) Storage – […]

Rockchip RK1808 Cortex-A35 NPU Delivers up to 3.0 TOPS

RK1808 NPU AIoT Solution

Rockchip RK3399Pro was expected to be the first processor from the company featuring an NPU (Neural Processing Unit) to accelerate artificial intelligence workloads, but eventually went through a redesign, and the community found it gave birth to RK1808 NPU by looking at a device tree file in the Linux kernel. Rockchip has now made the NPU official at CES 2019, and we now know a little bit more. Here are the specifications shared by the company: Dual-core Arm Cortex-A35 CPU NPU computing performance up to 3.0TOPs supporting INT8/INT16/FP16 hybrid operation VPU supporting 1080P video codec Built-in 2MB system-level SRAM Display – MIPI/RGB video output Camera – MIPI/CIF/BT1120 Camera video signal input with built-in ISP Audio Microphone array support with hardware VAD function for low-power monitoring and far-field wake-up Audio output I/O PWM/I2C/SPI /UART USB3.0/USB2.0 PCIe interface Support for Gigabit Ethernet and external WiFi/Bluetooth modules Manufacturing – 22nm FD-SOI process It […]

Rockchip PX30 Processor Powers Android 8.1 Car Infotainment Systems

Rockchip PX30 Android 8.1 Car System

Rockchip RK3326 and RK3308 are the first Arm Cortex A35 processors from the company, and are designed for smart AI solutions such as smart speakers and smart displays. It turns out RK3326 processor has a sibling called Rockchip PX30 with most of the same features, but with dual VOP (Video Output Processor) support to handle up to two independent displays, as well as an Ethernet MAC and a USB host block. Rockchip RK30 key features and specifications: CPU – Quad-core Arm Cortex-A35 GPU – Mali-G31 MP2 GPU Memory I/F – DDR4/DDR3/DDR3L/LPDDR3/LPDDR2 Storage I/F – MLC NAND, eMMC 4.51, Serial Nor FLASH Video 1080p H.265/H.264/VC-1/MPEG/VP8 video decoder 1080p H.264/VP8 video encoder Display Interfaces – MIPI-DSI/LVDS/RGB interface, dual VOP Audio I/F – 1x8ch I2S/TDM, 1x8ch PDM, 2x2ch I2S Camera I/F – MIPI CSI and DVP; built-in 8MP ISP Networking – 10/100M Ethernet Other Peripherals – SDIO3.0, USB2.0 HOST & OTG, 4x I2C, […]
