Posted on by Jean-Luc Aufranc (CNXSoft) - 21 Comments on Olimex Teres I A64 DIY Open Source Hardware Laptop Kit Design Complete, To Sell for 225 Euros

Olimex Teres I A64 DIY Open Source Hardware Laptop Kit Design Complete, To Sell for 225 Euros

Olimex has been working on an open source hardware Olimex A64 laptop for a little over a year, and the company has now complete thed hardware design of their TERES I laptop, and are working on finalizing the software design before accepting orders for 225 Euros for TERES-A64-BLACK and TERES-A64-WHITE models. As explained in the instructions manual, Olimex laptop will not be sold assembled, but as a kit to let the users assemble the following parts themselves: TERES-006-Keyboard QWERTY keyboard TERES-023-Touch touchpad with TERES-022-Touch-Cover and TERES-010-Touch-Btns TERES-014-Screw-Set with 42 pieces of different kind of screws. TERES-PCB3-Touch PCB TERES-PCB2-IO PCB with headphone jack, micro SD slot, and a USB port TERES-PCB4-Btn PCB for the power button together with TERES-009-Pwr-Btn plastic and TERES-013-LED-pipe TERES-PCB1-A64 motherboard based on Allwinner A64 processor. TERES-PCB5-KEYBOARD keyboard control board Display parts: TERES-008-LCD-Back, TERES-016-Hinge-Set, TERES-007-LCD-Frame, and TERES-015-LCD 11.6″ LCD panel TERES-019-Camera & TERES-020-Camera-Lens for the webcam Speakers, battery,WiFi […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on MacroFAB FX Development Board is an Open source Audio Electronics Prototyping Platform (Crowdfunding)

MacroFAB FX Development Board is an Open source Audio Electronics Prototyping Platform (Crowdfunding)

A couple of years ago, I wrote about a Linux multi-effects guitar pedal, and if you are interested in such audio projects, another company called MacroFab, specializing in manufacturing & assembling PCBs & electronic device, has now designed open source FX development board for audio electronics prototyping, that can be used for audio effects “guitar” pedals, and let you design your own tones. Key features of FX development board: Potentiometers 9V battery holder ¼” Input and output jacks connected to breadboard True bypass 3PDT switch User selectable power supply connections Dual solderless breadboards with power rails selectable by jumpers Adjustable 9 V power supply Power supply with 2.1 mm dc input jack for use with AC-to-AC wall wart; +/- 15 volt @ 200 mA power supplies with over-current protection; +1.25 to 9 V @ 150 mA adjustable power supply; Split voltage rail (1/2*9 Volt Rail) @ 15 mA for use […]
