Posted on by Jean-Luc Aufranc (CNXSoft) - 2 Comments on Small (45x43mm) system-on-module packs Rockchip RK3562 AIoT SoC, 16GB eMMC, 2GB RAM, and PMIC

Small (45x43mm) system-on-module packs Rockchip RK3562 AIoT SoC, 16GB eMMC, 2GB RAM, and PMIC

Rockchip RK3562 development board

MIYR Tech MYC-YR3562 is a small 45x43mm system-on-module that packs a Rockchip RK3562 or RK3562J quad-core Cortex-A53 AIoT SoC with a 1 TOPS AI accelerator, up to 2GB LPDDR4, 16GB eMMC flash, 32 Kbit EEPROM, and a PMIC. To keep the module small while making no compromise on the number of I/Os offered, the company designed the module with 164 castellated holes (LCC – ) and 58 pads (LGA). That means the MYC-YR3562 system-on-module gets all interfaces from the RK3562(J) SoC, including Gigabit Ethernet, USB 3.0, PCIe 2.1, RGB, LVDS, and MIPI-DSI interfaces, camera inputs (MIPI-CSI), and a range of low-speed I/Os. MYC-YR3562 SoM specifications SoC –  Rockchip RK3562 or RK3562J CPU RK3562 – Quad-core Arm Cortex-A53 quad-core @ 2.0 GHz RK3562J – Quad-core Arm Cortex-A53 quad-core @ 1.2 GHz (stock, overclock up to 1.8 GHz) GPU – Mali-G52-2EE with support for OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.0/1.1 AI accelerator […]

Posted on by Debashis Das - No Comments on Waveshare 8-channel RS485 to Ethernet industrial serial servers work as a Modbus & MQTT gateways, RS485-to-JSON converters

Waveshare 8-channel RS485 to Ethernet industrial serial servers work as a Modbus & MQTT gateways, RS485-to-JSON converters

Industrial Isolated 8 Ch RS485 to RJ45 Ethernet Serial Server

Waveshare has launched the 8-Channel RS485 TO ETH (B) and 8-Channel RS485 TO POE ETH (B) industrial Ethernet serial servers designed for bi-directional transparent data transmission between RS485 and Ethernet networks. The only difference is PoE support, one has it, the other doesn’t, recognizable by their names. It features eight RS485 channels that operate independently, and supports two Ethernet ports (with an optional PoE version compliant with IEEE 802.3af). Key features include working as a serial server, Modbus gateway, MQTT gateway, and RS-485 to JSON converter. It also supports protocols like TCP, UDP, HTTP, DHCP, DNS, and more. It works in the industrial temperature range (-40°C to 85°C), offers power and signal isolation, 2kV surge protection, and comes housed in a durable aluminum alloy enclosure. Additionally, it supports wall-mount or rail-mount installation, multiple power supply methods (DC 7–36V via screw terminal or PoE), and web browser/device library configuration. These features make […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 11 Comments on Mono Gateway – A 10GbE nano-ITX router board powered by NXP Layerscape LS1046A

Mono Gateway – A 10GbE nano-ITX router board powered by NXP Layerscape LS1046A

Mono Gateway 10GbE Nano ITX router board

The Mono Gateway is a nano-ITX router board powered by an NXP LayerScape LS1046A quad-core processor and equipped with two 10GbE SFP+ cages, three gigabit Ethernet RJ45 ports, and M.2 sockets for wireless WiFi 6 and/or tri-band WiFi 5, Bluetooth, and Thread modules. Tomaž Zaman’s YouTube channel description reads “I hate routers”, and that’s exactly why the “Gateway” came to life. He wanted a router that meets his expectations and runs open-source software. The NXP Layerscape LS1046A was selected thanks to its ability to support 10 Gbps Ethernet with up to 26 Gbps line-rate throughput for VLANs, PPPoE, and NAT. Let’s have a look. Mono Gateway specifications: SoC – NXP Layerscape LS1046A quad-core Cortex-A72 processor @ 1.6 GHz System Memory – 8 GB ECC RAM  @ 2100 MT/s Storage 32 GB eMMC flash for the OS 64 MB NOR flash for the bootloader Networking 2x SFP+ 10 Gbps Ethernet cages […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on EDATEC ED-IPC3630 Raspberry Pi CM5-powered industrial PC gets eight DI, eight DO, and two CAN Bus

EDATEC ED-IPC3630 Raspberry Pi CM5-powered industrial PC gets eight DI, eight DO, and two CAN Bus

EDATEC ED-IPC3630

EDATEC ED-IPC3630 is an industrial PC (IPC) built around the Raspberry Pi Compute Module 5 (CM5) with up to 8GB RAM and designed for industrial automation, IoT, and control applications with features like a wide 9V to 36V DC power input and a DIN-rail mount. The industrial computer also offers dual GbE, optional WiFi 5 and/or 4G LTE cellular connectivity, HDMI video output, a few USB ports, eight digital inputs (DI), eight digital outputs (DO), and two CAN Bus interfaces. ED-IPC3630 Specifications: SoM – Raspberry Pi CM5 SoC – Broadcom BCM2712 quad-core Cortex-A76 processor @ 2.4GHz with VideoCore VII GPU System Memory – 2GB, 4GB, or 8GB LPDDR4-4267 SDRAM (the 16GB model is not offered, maybe due to supply issues) Storage – Options for 16GB, 32GB, or 64GB eMMC flash Wireless – Optional dual-band WiFi 5 and Bluetooth LE 5.0 module Storage M.2 Key-B socket optionally fitted with 128GB, 256GB, […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 2 Comments on M5Stack Unit Gateway H2 – A tiny ESP32-H2 Thread/Zigbee gateway selling for $6.50

M5Stack Unit Gateway H2 – A tiny ESP32-H2 Thread/Zigbee gateway selling for $6.50

M5Stack Gateway H2

M5Stack’s Unit Gateway H2 is a small Thread/Zigbee gateway powered by the ESP32-H2-MINI-1 module with an 802.15.4 radio for Zigbee 3.0, Thread 1.3, and Matter connectivity. The Unit Gateway H2, also known as Gateway H2 Unit…, can operate as a gateway (e.g. a Thread Board Router) or a terminal device that communicates with a M5Stack device via serial/UART through the Grove interface.  It also features a USB-C port for power, firmware flash, and debugging. M5Stack says it’s suitable for smart homes, environmental monitoring, sensor networks, and low-power wireless communication nodes.   M5Stack Gateway H2 Unit specifications: Wireless module – ESP32-H2-MINI-1-N2 SoC – Espressif Systems ESP32-H2 CPU – 32-bit RISC-V SoC clocked at up to 96 MHz RAM and storage – 320 KB SRAM, 128 KB ROM, 4 KB LP memory Wireless – 802.15.4 radio with Zigbee 3.0, Thread 1.3, and Matter support. (Note: the ESP32-H2 also supports Bluetooth 5.2 LE/Mesh, […]

Posted on by Debashis Das - No Comments on ASRock iEP-7040E fanless industrial IoT controllers feature Intel Core Ultra Arrow Lake-H CPU, 36V DI/DO

ASRock iEP-7040E fanless industrial IoT controllers feature Intel Core Ultra Arrow Lake-H CPU, 36V DI/DO

iEP 7040E Series

ASRock has recently released the iEP-7040E series which are Arrow Lake-H industrial IoT controllers powered by Intel Core Ultra “Arrow Lake-H” SoCs with Intel Arc graphics and Intel AI Boost. They feature a fanless design, 9V to 36V or 19V to 36V DC input, three Gigabit Ethernet ports, and two optional Intel GbE ports with PoE. Depending on the variant, the iEP-7040E supports 4x DI/4x DO or 8x DI/8x DO (with 36V isolation), up to 96GB DDR5 5600MHz with In-Band ECC (IBECC), and Intel In-Band Manageability with TPM 2.0. Expansion options include an M.2 B-Key socket and Nano SIM card slot for cellular, an M.2 E-Key socket for WiFi/BT, and an M.2 2280 M-key socket for storage. I/O options include HDMI 2.0b, VGA, three USB 3.2 Gen2 ports, one USB 2.0 port, three RS232/422/485, audio I/O, and multiple power options with OVP, UVP, OCP, and 80V surge protection. Certified for […]

Posted on by Debashis Das - 2 Comments on Femtofox Pro v1 LoRa and Meshtastic development board runs Linux-based Foxbuntu OS on Rockchip RV1103 SoC

Femtofox Pro v1 LoRa and Meshtastic development board runs Linux-based Foxbuntu OS on Rockchip RV1103 SoC

Femtofox Pro v1 kit LoRa and Meshtastic development board

The Femtofox Pro v1 kit is a compact, low-power LoRa and Meshtastic development board running Linux specially designed for Meshtastic networks. Built around the Luckfox Pico Mini (Rockchip RV1103) SBC, this compact development platform supports USB host/device functionality, Ethernet, WiFi over USB, GPIO interfaces, I2C, UART, and a real-time clock (RTC). The most unique feature of this board is that it operates at very low power (0.27-0.4W), making it ideal for solar-powered applications. Additionally, Femtofox supports native Meshtastic client control, USB mass storage, and network reconfiguration via a USB flash drive. It also includes user-configurable buttons for WiFi toggling and system reboot, enhancing its usability. These features make Femtofox particularly useful for applications such as emergency response and off-grid messaging. Femtofox Pro v1 kit specifications Mainboard – Luckfox Pico Mini A SoC  – Rockchip RV1103 SoC CPU – Arm Cortex-A7 processor @ 1.2GHz + RISC-V core Memory – 64MB DDR2 […]

Posted on by Debashis Das - No Comments on SparkFun Digi X-ON LoRaWAN development kit combines Digi HX15 gateway with RP2350 IoT node and environmental sensors module

SparkFun Digi X-ON LoRaWAN development kit combines Digi HX15 gateway with RP2350 IoT node and environmental sensors module

SparkFun Digi X ON Kit

SparkFun has recently released the Digi X-ON LoRaWAN development kit an all-in-one IoT development kit designed to simplify the setup and deployment of LoRa-based IoT systems. It includes the Digi HX15 Gateway, SparkFun IoT Node for LoRaWAN, and the ENS160/BME280 environmental sensor, enabling rapid prototyping and connectivity with the help of the Digi X-ON cloud platform. The SparkFun IoT Node is built around the Raspberry Pi RP2350 microcontroller, which features 16MB flash, 8MB PSRAM, multiple GPIOs, LiPo battery support, microSD storage, and USB-C connectivity. It also integrates the Digi XBee LR module for long-range LoRaWAN communication with pre-activated cloud connectivity. With an onboard Qwiic connector and Arduino support, this development kit is ideal for applications like industrial monitoring, environmental sensing, smart agriculture, remote data collection, and more. Digi HX15 gateway specifications Microprocessor – STMicro STM32MP157C MPU with dual-core Cortex A7 @ 650 MHz, Cortex-M4 @ 209 MHz with FPU/MPU, 3D […]
