January 30, 2020January 30, 2020 by Jean-Luc Aufranc (CNXSoft) - No Comments

Semtech LoRa Asset Tracking Reference Kit Includes one LoRaWAN Gateway, Six Waterproof GPS Trackers

LoRa Asset Tracking Reference Kit Gateway

The Things Conference is taking place now until January 31, so we should expect a few LoRaWAN announcements, and yesterday we covered Semtech LLCC68 LoRa transceiver for smart home applications, but the company also introduced a LoRa asset tracking reference kit to ease the deployment and evaluation of LoRa based tracking solutions. The kit is comprised of one LoRaWAN gateway, and six waterproof trackers with GPS and LoRa connectivity which everything supposed to work out of the box. The gateway, as shown above, comes with LoRa, cellular and GPS antennas, as well as a PoE power supply. It ships with a pre-configured SIM card to connect to the cloud platform over 3G/4G. Six industrial LoRaWAN-based GPS trackers are also included with the kit. Each comes with a battery but the trackers need to be activated by the user. Interestingly they are not using a button to turn on and off […]

January 2, 2020May 17, 2020 by Jean-Luc Aufranc (CNXSoft) - 12 Comments

Xiaomi Smart Multi-mode Gateway Supports Zigbee 3.0, WiFi, Bluetooth, and Bluetooth Mesh

Xiaomi has introduced several inexpensive home automation products over the years, often under their Mijia brands with for example a WiFi to IR blaster, a Zigbee & WiFi smart home kit, a smart door lock, or a smart speaker among other products. Recently, the company has launched the Xiaomi Smart Multi-mode Gateway that supports Zigbee 3.0, WiFi, Bluetooth, and Bluetooth Mesh. Xiaomi Mijia Smart Multi-mode Gateway (model ZNDMWG03LM) key features and specifications: Connectivity ZigBee2.0 / ZigBee3.0 2.4GHz Wi-Fi 2×2 MIMO Bluetooth & Bluetooth Mesh Compatible with Apple Homekit Max range – 200 meters (Line-of-Sight) Up to 32 devices Power Supply – 5V/1A Dimensions – 90x25mm Temperature Range – -5℃-50℃ Humidity – 0%-95%RH, non-condensing The gateway can be controlled via Mi Home app running on Android 5.0 or iOS 12.0 smartphones. It’s compatible with Apple Homekit, Xiaomi Mi AI speaker, and the earlier Zigbee/WiFi kit with Aqara gateway and Zigbee sensors […]

December 30, 2019 by Jean-Luc Aufranc (CNXSoft) - 17 Comments

ESPRESSOBin ULTRA Gateway Features 5 Gigabit Ethernet Ports, WiFi 5, Supports 4G LTE Cellular Connectivity

Marvell ESPRESSOBin networking board launched in 2016 for as little as $39 with an Armada 3700LP (88F3720) dual-core Arm Cortex A53 processor, up to 1GB RAM, three Gigabit Ethernet ports, SATA, and a mPCIe slot for wireless connectivity. Globalscale Technologies is now back with ESPRESSOBin ULTRA with a similar base but more features, a metal enclosure, and a much higher price point. ESPRESSOBin ULTRA specifications: SoC – Marvell Armada 3720 dual-core Arm A53 processor clocked up to 1.2 GHz with packet accelerator System Memory – 1GB DDR4 (option up to 2GB) Storage – 8GB eMMC flash, 4Mbit SPI NOR flash, 1x M.2 2280 slot for SATA SSD Connectivity Switch – Marvell Topaz 6341 (88E6341) Networking Switch 1x GbE WAN with 30W POE 4x Gigabit Ethernet ports (LAN) 802.11ac Wi-Fi 5 2×2 MIMO module + Bluetooth 4.2 Optional 4G LTE cellular connectivity via mini PCIe and NanoSIM card slot USB – […]

December 23, 2019December 23, 2019 by Jean-Luc Aufranc (CNXSoft) - 6 Comments

Tasmota Open Source ESP8266 Firmware Now Supports Zigbee Connectivity

Tasmota Zigbee to WiFi Gateway Prototype

Sonoff-Tasmota is a popular open-source firmware designed to run on ESP8266 hardware for home automation projects. It was initially designed to run on devices from ITEAD Studio Sonoff family but now supports more products, boards, and modules from other brands such as Shelly, Wemos, Blitzwolf, and others. So the first news is that the project has recently been renamed from Sonoff-Tasmota to just Tasmota, and documentation has been moved from Github Wiki to Github.io. Tasmota Zigbee Support A piece of more important news is that Tasmota now supports Zigbee. More specifically, the Z2T (Zigbee to Tasmota) concept allows you to make your own Zigbee to WiFi bridge by combining Z-Stack-firmware on CC2530 and Tasmota firmware on ESP8266 / ESP82xx hardware. Basically all you need is ESP82xx hardware connected to a Texas Instruments C2530 based Zigbee device over a serial. Note that C2531 based device won’t work since they are connected […]

December 19, 2019December 19, 2019 by Jean-Luc Aufranc (CNXSoft) - No Comments

RAK7244 LoRaWAN Developer Gateway Combines Raspberry Pi 4 with LoRa HAT, Optional 4G LTE Connectivity

After launching RAK831 Lite LoRaWAN gateway based on Raspberry Pi 3 board in 2018, RAK Wireless introduced Pilot Gateway Pro RAK7243 gateway with the more recent Raspberry Pi 3B+ SBC earlier this year. But with the launch of Raspberry Pi 4 last June, the Raspberry Pi 3B+ has become much harder to procure, so RAK has now launched an updated LoRa gateway featuring Raspberry Pi 4 SBC together with the company’s RAK2245 Pi Hat Edition LoRaWAN gateway concentrator module. RAK7244 LoRaWAN Developer Gateway specifications: SBC – Raspberry Pi 4 Model B with 2GB RAM Connectivity LoRa RAK2245 Pi Hat LoRaWAN gateway concentrator module with 1x SX1301 baseband processor, 2x SX125x Tx/Rx front-ends LoRaWAN v1.0.2 support Support for 8 channels and spreading factors SF7 to SF12 Bands – 433MHz, 470MHz, 865MHz, 868MHz, 915MHz, 920MHz, 923MHz Tx Power: 27 dBm Max RX Sensitivity: -139dBm Cellular – Optional 4G LTE support via RAK2013 […]

November 28, 2019February 16, 2020 by Jean-Luc Aufranc (CNXSoft) - 6 Comments

esp32MX-E ESP32 Board Comes with Ethernet and USB-C Ports (Crowdfunding)

We’ve already covered several ESP32 boards with Ethernet including Olimex ESP32-GATEWAY and Silicognition wESP32, and I’ve just noticed Espressif also made its own with ESP32-Ethernet-Kit. Modtronix Engineering has another take with esp32MX-E board that beside Ethernet also exposes a USB-C port, a MicroSD card slot, and also adds an STM32F0 microcontroller acting as an I2C I/O expander. esp32MX-E specifications: Wireless Module ESP32 dual-core LX6 microprocessor at 160 or 240 MHz, 4 MB Flash, 520 KB SRAM Wi-Fi 4 802.11 b/g/n Bluetooth 4.2 BR/EDR & BLE Storage – MicroSD card slot USB – USB Type-C connector for programming, power, and Virtual COM port Expansion via 14-pin and 20-pin female headers 22x I/O pins of which 4 are inputs only. 4x 5 V tolerant I/O pins Not all I/Os are available when the SD Card is used Programmable pull-up and pull-down resistors on most inputs Secondary MCU – I²C I/O expander implemented […]

November 11, 2019November 11, 2019 by Jean-Luc Aufranc (CNXSoft) - 21 Comments

NanoPi R1S Dual Gigabit Ethernet Router Comes with 32-bit or 64-bit Arm Processor

FriendlyELEC launched NanoPi R1 SBC & Gateway earlier this year with Allwinner H3 processor, two Ethernet ports, as well as WiFi and Bluetooth connectivity. The design makes use of both Ethernet on the processor, but that also means on Gigabit Ethernet port had to be combined with a Fast Ethernet processor. The company has now added a USB to Gigabit Ethernet bridge to their latest NanoPi R1S board meaning it’s now a dual Gigabit Ethernet SBC, but with the caveat that the port behind the USB bridge is limited to USB 2.0 speed (480 Mbps), and with overhead the USB Ethernet bandwidth is around 330 Mbps. There are two versions of the board, namely NanoPi R1S-H3 and R1S-H5 with respectively Allwinner H3 32-bit processor, and Allwinner H5 64-bit processor. Apart from the different processors, both boards share the same PCBA and specifications: SoC NanoPi R1S-H3 – Allwinner H3 quad-core Arm […]

October 16, 2019October 16, 2019 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

Semtech SX1302 LoRa Transceiver to Deliver Cheaper, More Efficient Gateways

After our interview with Rak Wireless CEO, we received a comment inquiring about the availability of SX1302 gateways. Semtech so far had two LoRa transceivers for gateways namely SX1301 and SX1308, but I had never heard about a third one. Semtech SX1302 is brand new, the latest generation of baseband LoRa chip for gateways that is said to reduce current consumption in order to simplify the thermal design of gateways, as well as the BoM (bill of materials) costs), while being capable of handling a higher amount of traffic. Semtech SX1302 LoRa Transceiver Key features: Up to -141 dBm sensitivity with SX1250 Tx/Rx front-end 125 kHz LoRa reception with: 8 x 8 channels LoRa packet detectors 8 x SF5-SF12 LoRa demodulators 8 x SF5-SF10 LoRa demodulators 125 /250 / 500 kHz LoRa demodulator (G)FSK demodulator Direct interface to Semtech transceivers SX1255, SX1257 and SX1250 SPI host interface Single 32 MHz […]
