Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on Geniatech DS-3566 digital signage board is powered by a Rockchip RK3566 SoC

Geniatech DS-3566 digital signage board is powered by a Rockchip RK3566 SoC

Geniatech DS-3566

Geniatech DS-3566 is a board based on Rockchip RK3566 designed for digital signage applications with a low-profile, multiple video interfaces such as HDMI, LVDS, eDP, and MIPI DSI, and plenty of headers and connectors for expansion. The single board computer ships with up to 8GB RAM, 128GB eMMC flash, and supports Gigabit Ethernet, WiFi 5, Bluetooth 4.1, as well as cellular connectivity as an option. Some of the interfaces available through connectors include RS232, RS485, CAN Bus, I2C, SPI, etc… Geniatech DS-3566 specifications: SoC – Rockchip RK3566 quad-core Arm Cortex-A55 processor @ 1.8 GHz with Arm Mali-G52 EE GPU, 0.8 TOPS NPU System Memory – 2GB to 8GB LPDDR4 Storage – 16GB to 128GB eMMC flash, MicroSD card slot Video Interfaces 1x HDMI 2.1 up to 4Kp60 1x LVDS header and backlight header 1x eDP header and backlight header 1x 4-lane MIPI DSI connector Camera – 1x 4-lane MIPI CSI […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on Geniatech unveils SMARC 2.1 compliant Rockchip RK3568 system-on-module

Geniatech unveils SMARC 2.1 compliant Rockchip RK3568 system-on-module

We’ve seen Rockchip RK3568 system-on-modules before, but the Geniatech SOM-3568-SMARC core board is the first to comply with the SMARC 2.1 standard with a 314-pin MXM connector exposing the many I/Os from the quad-core Cortex-A55 processor. The module comes with up to 8GB RAM, 128GB eMMC flash, integrates a WiFi and Bluetooth module as well as two Gigabit Ethernet transceivers, and is designed to be used in advanced NVRs, cloud terminals, industrial automation, IoT applications, digital signage, and more. Geniatech SOM-3568-SMARC specifications: SoC – Rockchip RK3568 quad-core Cortex-A55 processor @ 2.0 GHz with Arm Mali-G52 2EE GPU with support for OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1, 1 TOPS NPU for AI acceleration, 4Kp60 H.265/H.264/VP9 video decoding, and 1080p100 H.265/H.264 video encoding; 22nm process System Memory – 2GB, 4GB or 8GB DDR4 Storage – 32GB, 64GB, or 128GB eMMC 5.1 flash Networking 2x RTL8211F Gigabit Ethernet PHY WT6354 wireless module […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 9 Comments on Geniatech DB982 – An 8K TV motherboard with Amlogic T982 CPU, ATSC 3.0 TV tuner

Geniatech DB982 – An 8K TV motherboard with Amlogic T982 CPU, ATSC 3.0 TV tuner

Geniatech DB982 is a development board/motherboard powered by an Amlogic T982 quad-core Cortex-A55 processor designed for 8K televisions and equipped with an ATSC 3.0 TV tuner. The board ships with up to 4 GB RAM and up to 128 GB eMMC flash, and also includes three 4K HDMI inputs, LVDS and ultra-high-definition VX1 LCD screen interfaces, as well as Fast Ethernet and WiFI 5 connectivity.   Geniatech DB982 specifications: SoC – Amlogic T982 CPU – Quad-core Arm Cortex-A55 processor up to 1.8GHz GPU – Arm Mali-G52 MP2 (2EE) GPU supporting OpenGL ES 3.2, Vulkan 1.1 and OpenCL 2.0 APIs AI accelerators – 2x NNA accelerators with INT8 inference performance up to 2.6 TOPS Manufacturing process – 12nm System Memory – 2GB (4GB optional) Storage – 16GB eMMC flash (8 to 128GB optional) Video Output 1x VX1 up to 8K resolution (CNXSoft: I suppose it stands for V-By-One interface) 1x 30-pin […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Wireless M-Bus & LTE Cat 1 sensor board also supports Zigbee 3.0, Z-Wave, Bluetooth LE 5.0, LoRa…

Wireless M-Bus & LTE Cat 1 sensor board also supports Zigbee 3.0, Z-Wave, Bluetooth LE 5.0, LoRa…

Geniatech SCB32IM is a sensor board based on Silicon Labs EFR32FG14 Arm Cortex-M4 microcontroller with a sub-GHz radio enabling wireless M-Bus (Wireless Meter Bus) designed for remote reading of smart meters, and also equipped with a Quectel EC200S “IoT/M2M-optimized” LTE Cat 1 module. The sensor module does not actually come with any sensor on board, but provides a terminal block to connect any sensor you may need for your product. It’s also possible to extend wireless connectivity options with Zigbee 3.0, Z-Wave, Bluetooth LE 5.0, LoRa, and more through the GT-IoT interface with UART, SPI, and one GPIO. Geniatech SBC32IM specifications: Microcontroller – Silicon Labs EFR32FG14 Aem Cortex-M4 MCU @ 40MHz with up to 256 KB flash, 32 KB RAM, and proprietary 2.4GHz and sub-GHz radios Wireless connectivity Wireless M-Bus S Mode: 868 MHz band T Mode: 868 MHz band C Mode: 868 MHz band N Mode: 169 MHz band […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 2 Comments on Geniatech XPI-3566 is a business-card sized Rockchip R3566 SBC

Geniatech XPI-3566 is a business-card sized Rockchip R3566 SBC

Geniatech has added a new member to its XPI SBC family with the business card-sized XPI-3566 board powered by a Rockchip RK3566 quad-core Cortex-A55 processor, and mostly following the Raspberry Pi 3 form factor like its predecessors. The single board computer comes with 1GB to 8GB RAM, up to 64GB eMMC flash, HDMI 2.0 video output, Gigabit Ethernet, dual-band WiFi, a few USB ports, and the 40-pin GPIO header. It is said to target retail, “interactive communication”, and education applications. Geniatech XPI-3566 specifications: SoC – Rockchip RK3566 quad-core Cortex-A55 processor @ up to 1.8 GHz with Arm Mali-G52 2EE GPU, 0.8 TOPS AI accelerator System Memory – 2GB DDR (1GB, 4GB, or 8GB optional） Storage 16GB eMMC flash (8GB, 32GB, 64GB optional） MicroSD card socket Video Output HDMI 2.0 up to 4Kp60 MIPI DSI connector (not listed in the specs, but it can clearly be seen on the board) Camera […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 6 Comments on Geniatech launches OSM Size-L modules with Renesas RZ/G2L, Rockchip RK3566

Geniatech launches OSM Size-L modules with Renesas RZ/G2L, Rockchip RK3566

Geniatech has introduced LGA system-on-modules compliant with the SGET OSM (Open Standard Module) Size-L standard and designed to be soldered directly on the carrier board. Two models have been launched with the SOM-G2L-OSM equipped with Renesas RZ/G2L Arm Cortex-A55/M33 processor, and the SoM-3566-OSM powered by a Rockchip RK3566 quad-core Cortex-A55 SoC. SOM-G2L-OSM module Specifications: SoC – Renesas RZ/G2L dual-core Cortex-A55 processor, Cortex-M33 real-time core,  Arm Mali-G31 GPU, H.264 video encoder/decoder System Memory – 1GB RAM (2GB/4GB optional) Storage – 8GB eMMC flash (16GB/32GB optional) 662 contacts with Display – 1x MIPI DSI, 1x RGB Camera – 1x MIPI CSI Audio – I2S Networking – 2x Gigabit Ethernet USB – 1x USB OTG 2.0, 1x USB 2.0 host Serial – 2x CAN bus SDIO 3.0 Low-speed I/Os – 5x UART including debug, 2x I2C, 3x SPI, 3x PWM, 16x GPIO, 2x ADC Dimensions – 45 x 45 mm (OSM Size-L form […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 2 Comments on Renesas RZ/G2L or RZ/V2L AI development board comes with built-in LTE Cat M1 modem, 96boards form factor

Renesas RZ/G2L or RZ/V2L AI development board comes with built-in LTE Cat M1 modem, 96boards form factor

Geniatech “AHAURA” RS-G2L100 / “AKITIO” RS-V2L100 is a Renesas RZ/G2L and RZ/V2L Cortex-A55/M33 development board that follows 96boards CE Extended v2.0 form factor, and is equipped with a Renesas LTE Cat M1 modem. Both RZ/G2L and RZ/V2L processors are basically the same, but the latter adds the “DRP-AI” (dynamically reconfigurable processor) AI accelerator for computer vision applications. The board also comes with up to 4GB RAM, two Gigabit Ethernet ports, a wireless WiFi and Bluetooth module, as well as Full HD HDMI video output, plus some USB ports, and the usual low-speed and high-speed expansion connectors from the 96Boards standard. Geniatech AHAURA RS-G2L100 and AKITIO RS-V2L100 specifications: SoC – Renesas RZ/G2L or RZ/V2L with dual-core Cortex-A55 processor @ 1.2 GHz, Arm Cortex-M33 core @ up to 200 MHz, Arm Mali-G31 GPU, and DRP-AI vision accelerator (RZ/V2L only) System Memory – 4GB (default) or 8GB LPDDR4 Storage – 8GB, 16GB, 64GB, […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Rockchip RK3568 SBC to power 4G/5G, WiFI 6 connected smart displays, features an optional tuner

Rockchip RK3568 SBC to power 4G/5G, WiFI 6 connected smart displays, features an optional tuner

Geniatech is back with another Rockchip RK3568 SBC. The K3-3568 single board computer is designed specifically for smart displays with 4G LTE, 5G, or WiFi 6 connectivity, and follows last year’s “Geniatech RK3568 development board” (aka DB3568) offered as a full-featured development kit for Rockchip RK3568 SoC. K3-3568 SBC ships with up to 8GB RAM, up to 64GB eMMC flash, and offers multiple display interfaces with HDMI, MIPI DSI, LVDS, eDP, plus and an internal HDMI input connector, as well as support for an optional DVB-T2, ISDB-T, DMBT, or ATSC digital tuner. Geniatech K3-3568 specifications: SoC – Rockchip RK3568 quad-core Cortex-A55 processor up to 1.5/2.0 GHz with Arm Mali-G52 GPU supporting OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1, 0.8 TOPS NPU for AI acceleration System Memory – 2GB, 4GB, or 8GB LPDDR4 Storage 16GB, 32GB, or 64GB eMMC 5.1 flash MicroSD card slot M.2 socket for NVMe SSD (See expansion […]
