gsm News - CNX Software - Embedded Systems News

November 8, 2023November 10, 2023 by Jean-Luc Aufranc (CNXSoft) - 211 Comments

Giveaway Week 2023 – WisBlock IoT Starter Kit with LoRaWAN and LTE-M/NB-IoT or GSM connectivity

RAKwireless is joining CNX Software Giveaway Week for the third year running with the company offering a free WisBlock IoT Starter Kit with LoRaWAN and LTE-M/NB-IoT or GSM connectivity following giveaways for the WisBlock Kit 2 LoRa-based GPS Tracker with Solar Panel in 2021 and RAK Developer Kit (Air Quality Kit) in 2022. The WisBlock IoT Starter Kit enables prototyping with LoRaWAN and cellular IoT connectivity plus display modules (OLED and RGB) and plenty of sensors such as accelerometers, light sensors, VOC sensors, temperature and humidity sensors, and more. WisBlock IoT Starter Kit content: 1x RAK4631 WisBlock Core module SoC – Nordic nRF52840 Arm Cortex-M4F microcontroller @ 64 MHz with 1 MB Flash, 256 KB RAM, Bluetooth Low Energy 5.0 protocol stack LoRaWAN – Semtech SX1262 LoRa Transceiver with LoRaWAN 1.0.2 protocol stack (supports Class A & C), global coverage support: RU864, IN865, EU868, US915, AU915, KR920, AS923 1x RAK11200 […]

July 22, 2017July 22, 2017 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

Sonoff G1 AC Powered Smart Power Switch Works Over 2G GSM/GPRS

Today, I’ve searched for AC powered wireless switched similar to Sonoff devices, but with ESP32 instead in order to get WiFi and Bluetooth, since the latter is better to use with a battery powered buttons. I did find a DC powered board, but no AC powered ones yet. However, as I visited ITEAD website to check if they had anything of the sort, I discovered they had a new model called Sonoff G1, similar to Sonoff TH16, but instead of using WiFi, you can use 2G GSM/GPRS to control the switch remotely. Sonoff G1 specifications: Wireless Module – ST86 quad band GSM/GPRS module GSM/GPRS connectivity GSM850, EGSM900, DCS1800 and PCS1900 MHz support GPRS multi-slot class 10, GPRS mobile station class B 1.8V, 3V SIM card slot Transmit power: Class 4 (2W): GSM850, EGSM900; Class 1 (1W): DCS1800, PCS1900 Relay – Up to 16A (3000 Watts max) Terminals – 6 terminals […]

April 21, 2017June 7, 2017 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Wio GPS is a $40 Grove & Arduino Compatible Bluetooth 3.0 + GSM/GPRS + GPS Tracker Board

After Wio Link and Wio Node boards, Seeed Studio has added a new board to their Wio (Wireless Input Output) family with Wio GPS board based on Microchip SAMD21 Cortex M0+ MCU for Arduino compatibility, and Mediatek MT2503 ARM7 processor for GPS, Bluetooth 3.0, and 2G (GPRS) connectivity. Wio GPS board specifications: MCU – Microchip ATSAMD21G18A-MU ARM Cortex M0+ MCU @ 48 MHz with 256KB flash, 32KB SRAM Wireless SoC – Mediatek MT2503 ARM7EJ-S processor @ 260 MHz Storage – micro SD slot (shared with nano SIM slot) Connectivity (built-in MT2503 in Quectel MC20 module) Bluetooth 2.1 + EDR, 3.0 with SPP Profile and HFP-AG Profile; u.FL connector for external antenna Quad band 2G GSM/GPRS with u.FL connector for external antenna and nano SIM card slot GNSS – GPS + BeiDou + QZSS with u.FL connector for external antenna Audio – Speaker footprint (+/-), 3.5mm AUX jack with mic and stereo audio […]

May 26, 2016May 26, 2016 by Jean-Luc Aufranc (CNXSoft) - 7 Comments

Shenzhen Alpha M009 Smartwatch is Powered by Mediatek MT2503 SoC with Integrated Bluetooth, GSM Modem, and GPS

Mediatek MT2502 “Aster” SoC for wearables and IoT was released in 2014 with an ARM7 MCU, built-in Bluetooth, PMIC, and GSM/GPRS modem, and support for external WiFi and GPS chips. The upcoming MT2503 integrates functionality even further as GPS is now embedded inside the SoC, and Shenzhen Alpha Telecom Technology demonstrated their M009 smartwatch based on the latest Mediatek SoC at CES Asia 2016 in Shanghai. M009 smartwatch specifications: SoC – Mediatek MT2503 ARM7 processor with GSM/GPRS modem, Bluetooth 3.0 + EDR 2.1, GPS (MT3333), PMIC Display – 1.22″ or 1.3″ 240×240 resolution TFT display Cellular Connectivity – SIM card Sensors – HRM, pressure sensor Misc – 2x buttons Dimensions – 36 x 32 x 11 mm There will be two version of the processor MT2503A and MT2503D with the former supporting external serial flash. If you’d like to integrate a ready to use module in your design, ATS Link provides […]

April 17, 2016April 17, 2016 by Jean-Luc Aufranc (CNXSoft) - 4 Comments

RTU-5025 GSM Relay Controller Supports Up to 64 Phone Numbers

We’ve already seem boxed WiFi and Bluetooth wireless relays that can be used to turn on and off appliances using a smartphones or web applications, but I’ve just been made aware that GSM relay controllers such as RTU 5025 could also be a good options since they allow for authentication using the mobile number, can be used with any phone, not only smartphones, and don’t cost anything to operate, beside the eventual maintenance cost of the SIM card inside the device, since the relay does not actually answer calls. It can also send an SMS to the owner each time the relay is activated, in which case the cost of SMS might have to be considered. RTU 5025 specifications and key features: Connectivity – GSM PHASE 2/2+@ 850/900/1800/1900 MHz with SIM card slot + GSM antenna Output Relay – 3A/240V Rated Voltage – 12V/1A Working Temperature – -10 to 60 […]

April 7, 2016 by Jean-Luc Aufranc (CNXSoft) - 4 Comments

BPI-GSM Arduino Compatible Board Integrates a GSM & GPS Module, Sensors and an OLED Display

Banana Pi team has come up with another board, but this time it does not run Linux or Android, as they’ve made an Arduino compatible board called BPI-GSM based on Atmel ATmega2560 MCU with a light sensor, DHT22 temperature and humidity sensor, and a GSM/GRPS & GPS module powered by a LiPo battery. BPI-GSM board specifications: MCU – Atmel ATmega2560 8-bit AVR MCU @ 16 MHz with 256 KB flash, 8KB SRAM, 4KB EEPROM Connectivity – Simcom SIM808 GSM, GPRS, and GPS module + SIM card slot + Sensors – DHT22 temperature and humidity sensor, light sensor Display – OLED display Expansion headers – 54x digital I/O (including 14x PWM), 16x analog input, 4x UART. Max DC current per I/O: 40 mA. Misc – Reset button, LEDs Power Supply 5V via micro USB port 3.7V LiPo battery (2,500 mAh battery included in kit) Dimensions – TBD The board can be […]

September 23, 2015 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

RePhone Kit Create is a DIY Phone and Cellular Development Kit (Crowdfunding)

Seeed Studio has design a modular and open source phone it calls RePhone Kit Create. The kit allows you, or/and your kid(s), to assemble their own phone based on building blocks including a 2G or 3G core module, a touchscreen display module, an audio module, and pre-cut, seawable, washable, and easily drawable Kraft paper to make the case. The kit can also be used for IoT applications using cellular and Bluetooth connectivity, and extra Xadow modules GPS, NFC, motion sensors, camera and more.. Two cellular “core” module can be used: RePhone GSM + BLE module with the “world’s smallest System-on-Chip (SOC) for Wearables and Internet Of Things”, GSM, GPRS and Bluetooth 2.1 and 4.0 support. RePhone Core Module 3G with a “powerful microcontroller”,a standard Xadow interface (USB, GPIO, I2C, SPI, UART, EINT), support for speaker, two microphones and a headset, a Nano SIM, and support for HSPA/WCDMA:850/1900 and GPRS/EDGE:850/1900. Voltage: […]
