infineon News - CNX Software - Embedded Systems News

October 14, 2024 by Sayantan Nandy - 1 Comment

Infineon XENSIV game controller features PSoC 6 MCU, magnetic sensors, and OPTIGA Trust M security

Infineon Technologies XENSIV game controller is a reference design that integrates XENSIV magnetic position sensors for precise joystick control without sensor drift and XENSIV Hall switch triggers for reliable operation. The controller also features capacitive CAPSENSE buttons, CAPSENSE presence detection, and a SPIDER+ rumble driver. These components work together with the PSoC 6 BLE microcontroller to create a low-power, plug-and-play solution. The onboard display allows users to monitor joystick movements, connection status, configurations, and battery information. The controller connects to PCs or smartphones as a USB human interface device (HID) without requiring manual configuration or driver installation. It also supports Bluetooth Low Energy and uses capacitive presence detection to optimize battery life. The design includes a PSoC 6 debugger and supports customizable shields providing flexibility for software and hardware integration. Previously, we covered an Arduino Nano Matter-powered game controller that successfully ported Quake, a popular first-person shooter game. We’ve also […]

October 8, 2024October 8, 2024 by Tomisin Olujinmi - No Comments

Infineon EZ-USB FX20 programmable USB controller supports up to 20Gbps speeds, features LVDS interfaces

EZ-USB FX20 programmable controller BGA package

The EZ-USB FX20 is a programmable USB controller supporting speedy transfers via USB 20Gbps and LVDS interfaces. It is the latest addition to Infineon’s EZ-USB line designed to add USB connectivity to devices with high-performance requirements in AI, image processing, and other demanding applications. It offers up to six times the bandwidth of its predecessor, the EZ-USB FX3. The FX20 is powered by a dual-core MCU subsystem, with ARM Cortex-M4F and ARM Cortex-M0+ cores. It features 512KB flash, 128KB SRAM, 128KB ROM, and seven serial communication blocks (SCBs). The cryptography accelerator and high-bandwidth data subsystem enable Direct Memory Access (DMA) data transfers via the supported interfaces. The programmable USB controller includes 1MB of SRAM for USB data buffering. EZ-USB FX20 specifications: CPU – Dual-core, ARM Cortex-M4F core@ 150 MHz, ARM Cortex-M0+ core @ 100 MHz Memory – 512KB flash, 1024 + 128KB SRAM USB – USB 3.2 Gen 2 x2 […]

October 4, 2024October 3, 2024 by Debashis Das - 1 Comment

Infineon PASCO2V15 CO2 sensor achieves ±50 ppm accuracy with built-in microphone and IR emitter

Infineon’s PASCO2V15 CO2 sensor is a compact and precise carbon dioxide sensor that uses photoacoustic spectroscopy (PAS) leveraging its built-in microphone and IR emitter to detect CO2 levels by measuring pressure changes caused by the absorption of infrared light by CO2 molecules. The sensor is highly precise (±50 ppm ±5%) and can cover a wide range (0 to 32,000 ppm). it also includes features like pressure compensation and automatic baseline offset correction for reliability. With its small size and low power consumption, the PASCO2V15 can be integrated into HVAC systems, room controllers, smart thermostats, air purifiers, and other devices to optimize ventilation and improve energy efficiency. PASCO2V15 CO2 sensor specifications Sensor technology – Photoacoustic Spectroscopy (PAS) with Non-Dispersive Infrared (NDIR) principles Gas measured – Carbon Dioxide (CO2) Measurement range – 0 to 32,000 ppm Accuracy – ± (50 ppm +5%) of reading between 400 ppm and 3000 ppm Output Interfaces […]

August 21, 2024 by Debashis Das - No Comments

Infineon AIROC CYW20829 Bluetooth LE 5.4 MCU and module family targets industrial, consumer, and automotive applications

Infineon AIROC CYW20829 Bluetooth Low Energy 5.4 microcontrollers

Infineon has recently released the AIROC CYW20829 Bluetooth LE (Low Energy) 5.4 family which now includes SoCs and modules. These SoCs include two Cortex-M33 MCU cores: one 48 or 96 MHz application core for the peripherals, security, and system resources, and one communication core for the 2.4 GHz RF transceiver with up to 10 dBm transmit power and -98 dBm receive sensitivity. This high integration reduces bill-of-material (BOM) costs for a wide variety of applications, including PC accessories, low-energy audio, wearables, solar micro inverters, asset trackers, home automation, and others. Back in 2021, we saw Infineon release the AIROC CYW5557x family of Wi-Fi 6/6E SoCs for IoT and streaming devices with features like enhanced range and improved network efficiency. More recently, Infineon announced the PSOC Edge E81, E83, and E84 MCU based on Cortex-M55/M33 microcontrollers. Feel free to check those out if you are looking for Infineon-specific MCUs. Infineon AIROC […]

June 28, 2024June 28, 2024 by Debashis Das - 2 Comments

Infineon CY8CKIT-062S2-AI PSoC 6 Edge AI evaluation kit features multiple sensors, Arduino headers, Pmod connectors

Infineon CY8CKIT-062S2-AI evaluation kit is a hardware platform built around the PSoC 6 family of MCUs and designed to help developers easily create and test edge AI applications. The dev board features an array of sensors including radar, microphone, magnetometer, IMU, and an air pressure sensor, which make it easy for data collection applications. The board also features Wi-Fi and Bluetooth connectivity and includes an additional expansion header that can be used to connect other modules and sensors. All of these features make this board useful for building a wide range of AI-powered applications, including smart home automation, industrial monitoring, wearables, healthcare devices, and robotics. Previously we have written about similar low-power edge AI modules such as the Digi ConnectCore MP25, the Axiomtek AIE110-XNX, and the Arducam KingKong feel free to check those out if you are interested in such low-power modules. Infineon CY8CKIT-062S2-AI Evaluation Kit specifications: MCU – Infineon […]

April 19, 2024April 19, 2024 by Jean-Luc Aufranc (CNXSoft) - No Comments

Infineon PSOC Edge E81, E83, E84 Cortex-M55/M33 MCUs target Machine Learning-enhanced IoT, consumer and industrial applications

Infineon PSOC Edge E81, E83, and E84 MCU series are dual-core Cortex-M55/M33 microcontrollers with optional Arm Ethos U55 microNPU and 2.5D GPU designed for IoT, consumer, and industrial applications that could benefit from machine learning acceleration. This is a follow-up to the utterly useless announcement by Infineon about PSoC Edge Cortex-M55/M33 microcontrollers in December 2023 with the new announcement introducing actual parts that people may use in their design. The PSOC Edge E81 series is an entry-level ML microcontroller, the PSOC Edge E83 series adds more advanced machine learning with the Ethos-U55 microNPU, and the PSOC Edge E84 series further adds a 2.5D GPU for HMI applications. Infineon PSOC Edge E81, E83, E84-series specifications: MCU cores Arm Cortex-M55 high-performance CPU system up to 400 Mhz with FPU, MPU, Arm Helium support, 256KB i-TCM, 256KB D-TCM, 4MB SRAM (Edge E81/E83) or 5MB SRAM (Edge E84) Arm Cortex-M33 low-power CPU system up […]

August 31, 2022August 30, 2022 by Jean-Luc Aufranc (CNXSoft) - 4 Comments

Infineon XENSIV PAS CO2 Shield2Go board enables carbon dioxide measurements

Infineon has added new a shied to its Shield2Go ecosystem with the XENSIV PAS CO2 Shield2Go board integrating the company’s XENSIV PAS CO2 sensor capable of measuring carbon dioxide levels. We first wrote about the Shield2Go module with the OPTIGA Trust-M evaluation kit integrating a security module, but the family also includes various sensors shield and microcontroller boards notably the XMC 2Go board. The new Shield2Go board can be used for both air quality monitoring and controlled ventilation for energy savings. XENSIV PAS CO2 Shield2Go board specifications: XENSIV PAS CO2 sensor: Accuracy – ±30 ppm ±3% “Advanced compensation and self-calibration algorithms” Host interfaces – UART, I2C, PWM Dimensions – 14 x 13.8 x 7.5 mm 19x through holes and castellated holes with I2C, UART, PWM, interrupt, 5V, 3.3V, GND, plus SWD interface Power Supply 5V DC input 12V DC DCDC boost converter to power the IR transmitter in […]

November 24, 2021 by Jean-Luc Aufranc (CNXSoft) - No Comments

Arrow launches PSA Certified PSoC 64 IoT Security Workshop Development Kit

In 2019, we wrote that Cypress PSoC 64 microcontrollers for Secure IoT applications was one of the first microcontrollers compliant with Arm’s Platform Security Architecture (PSA) designed to secure the Internet of Things. Arrow has now launched the PSoC 64 IoT Security Workshop Development Kit, its first PSA Certified platform, which happens to be based on Cypress PSoC 64, and developed in collaboration with Infineon who purchased Cypress Semiconductor last year. Designed to help developers quickly create PSA Certified solutions, the development kit includes the Infineon PSoC 64 Secure AWS IoT Pioneer Kit, Arrow PSoC 6 IoT Sensor Shield, Shield2Go kits, and AWS cloud enablement with certified functional APIs and integrated dashboard for monitoring and visualization. There are three levels for PSA certification: level 1 for device manufacturers involves the evaluation of an IoT device to assess whether it adheres to security best practice, level 2 with a laboratory evaluation […]
