Posted on by Debashis Das - 3 Comments on LILYGO T-LoRa Pager is an ESP32-S3 handheld with support for text messaging, AI motion detection, and NFC

LILYGO T-LoRa Pager is an ESP32-S3 handheld with support for text messaging, AI motion detection, and NFC

LILYGO T Lora Pager (LoRa + ESP32 S3 Handheld AIOT Programmable Development Device)

LILYGO T-LoRa Pager is an ESP32-S3-based IoT handheld device that comes in an old pager form factor but relies on LoRa for text messaging, GNSS for positioning, NFC for contactless communication, and features AI-assisted motion detection with a BHI260AP IMU sensor. The device also includes a 2.33-inch IPS display (480×222), a QWERTY keyboard, a rotary encoder, an audio codec, a microSD slot, a battery management system, and a wireless charging pad. These features make this device suitable for portable, remote sensing, asset tracking, field communication, and edge AI projects, where GNSS, LoRa, and/or NFC functionalities are required. LILYGO’s T-LoRa Pager specifications: Wireless SoC – Espressif Systems ESP32-S3 CPU – Dual-core 32-bit LX7 processor running at 240 MHz Memory – 512 KB SRAM, 8 MB PSRAM. Storage – 16 MB Flash Wireless – WiFi 4 and Bluetooth 5.x Storage – microSD card slot for external storage Display – 2.33-inch IPS display (ST7796), […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 4 Comments on ESP32 Bus Pirate open-source firmware works on off-the-shelf hardware

ESP32 Bus Pirate open-source firmware works on off-the-shelf hardware

ESP32 Bus Pirate

ESP32 Bus Pirate is an open-source firmware inspired by the original Bus Pirate from Dangerous Prototypes, which turns off-the-shelf (ESP32-S3) hardware into a multi-protocol hacker’s tool. It supports sniffing, sending, scripting, and interacting with various digital protocols (I2C, UART, 1-Wire, SPI, etc.) via a serial terminal or web-based CLI. It’s been tested on Espressif ESP32-S3-DevKitC-1 development board, M5Stack Cardputer, M5StickC Plus2, Atom S3 Lite, M5Stamp S3, and LILYGO T-Embed (CC1101) boards. ESP32 Bus Pirate firmware highlights: Interactive CLI via USB serial – For faster performance and high responsiveness Web interface (over WiFi) – No cable needed to the host, works from any web browser Supported Modes HiZ (default) – High-Z is a safe mode where all outputs are disabled and all power supplies are turned off I2C (scan, glitch, slave mode, dump) SPI (flash, SD card, slave mode) UART / Half-Duplex UART (bridge, read, write) 1-WIRE (ibutton, temp sensor) 2-WIRE […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 17 Comments on MeshCore is a lightweight alternative to Meshtastic LoRa-based off-grid messaging

MeshCore is a lightweight alternative to Meshtastic LoRa-based off-grid messaging

MeshCore LoRa off-grid messaging

While Meshtastic is by far the most popular off-grid messaging solution relying on LoRa radios, MeshCore offers an alternative as a lightweight C++ library and firmware designed for multi-hop packet routing and made for developers who want to create resilient, decentralized communication networks that work without the internet. The project’s GitHub repository provides some high-level differences compared to the Meshtastic and Reticulum projects: MeshCore provides the ability to create wireless mesh networks, similar to Meshtastic and Reticulum but with a focus on lightweight multi-hop packet routing for embedded projects. Unlike Meshtastic, which is tailored for casual LoRa communication, or Reticulum, which offers advanced networking, MeshCore balances simplicity with scalability, making it ideal for custom embedded solutions., where devices (nodes) can communicate over long distances by relaying messages through intermediate nodes. This is especially useful in off-grid, emergency, or tactical situations where traditional communication infrastructure is unavailable. MeshCore key features: Multi-hop […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 12 Comments on ESP32-S3 development board integrates SI4732 AM/FM radio receiver

ESP32-S3 development board integrates SI4732 AM/FM radio receiver

ESP32-S3 board with AM/FM radio

LILYGO T-Embed SI4732 is an ESP32-S3 development board with an AM/FM radio, a TFT display, a rotary encoder, a built-in microphone, and a microSD card slot powered through a USB-C port or LiPo battery. As its name implies, it’s based on the earlier LILYGO T-Embed battery-powered WiFi and BLE controller with a display and rotary encoder, but also adds a Skyworks SI4732 AM//FM/SW/LW radio receiver to the mix. LILYGO T-Embed SI4732 specifications: Wireless module – ESP32-S3-WROOM-1 module SoC – ESP32-S3 CPU – Dual-core Xtensa LX7 processor @ 240 MHz  with vector extension for AI/ML Memory – 512 KB SRAM, 8 MB PSRAM Storage – 16MB flash Wireless – 2.4 GHz WiFi 4 and Bluetooth 5.0 LE PCB antenna Storage – MicroSD card slot Display – 1.9-inch IPS color TFT LCD with 320 x 170 resolution (ST7789V SPI driver) Audio – 2x microphones, 8 Ohm @ 1W speaker Radio – Skyworth […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 2 Comments on LILYGO MySondy GO LoRa32 board tracks radiosondes (weather balloons) with a 433MHz LoRa module

LILYGO MySondy GO LoRa32 board tracks radiosondes (weather balloons) with a 433MHz LoRa module

LILYGO MySondy GO

“LILYGO MySondy GO LoRa32” is a small ESP32-PICO-D4 board with a 433 MHz LoRa module and a 0.96-inch OLED designed to track (RS41) radiosondes, which are units attached to weather balloons used to collect meteorological data like temperature, humidity, and atmospheric pressure. It looks to be an older TTGO T3 board with a 433 MHz LoRa32 module from the company preloaded with the MySondo firmware that allows hobbyists in the amateur radio and weather enthusiast communities to track weather balloons and potentially recover them. LILYGO MySondy GO LoRa32 specifications: SiP – Espressif Systems ESP32-PICO-D4 system-in-package with ESP32 dual-core Xtensa processor @ 240 MHz, 2.4GHz Wi-Fi and Bluetooth 4.2 dual-mode, 4MB flash LoRa module – LORA32 RF Transceiver – Semtech SX1268 connected over SPI to the ESP32 SiP Frequency – 433 MHz (The T3 board has options for 868 and 915 MHz, which I suspect are not suitable for radiosondes) Tx […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on LILYGO T-Echo Lite – A 1.22-inch e-Paper display board with nRF52840 SoC, LoRa transceiver, GPS

LILYGO T-Echo Lite – A 1.22-inch e-Paper display board with nRF52840 SoC, LoRa transceiver, GPS

LILYGO T-Echo Lite

LILYGO T-Echo Lite is a small Nordic Semi nRF52840 board with a 1.22-inch e-Paper display, a Semtech SX1262 LoRa transceiver, and an L76K GPS module, that’s especially suitable for Meshtastic off-grid messaging firmware. It looks like it could even serve as the base for a Meshtastic watch. The T-Echo Lite is a lightweight version of the earlier T-Echo that ships with a larger 1.54-inch e-paper display. Three Lite versions are available: T-Echo Lite Core – Castellated module with nRF52840, LoRa, power, and battery management T-Echo Lite Base – A breakout board for the Core module with battery and solar panel connectors, Qwiic connector, USB port, an interface for a 1.22-inch e-paper display, and an optional GPS expansion header T-Echo Lite Main Unit – Complete solution built around the Base version, a 1.22-inch e-paper display, and an acrylic enclosure. The L76K GPS module is still an option. T-Echo Lite specifications: LILYGO […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on T-Pico-2350 is a fully integrated devkit with Raspberry Pi RP2350, ESP32-C6, 2.33-inch color touchscreen display, and HDMI video output

T-Pico-2350 is a fully integrated devkit with Raspberry Pi RP2350, ESP32-C6, 2.33-inch color touchscreen display, and HDMI video output

T-Pico-RP2350

LILYGO T-Pico-2350, also called the T-Pico2, is a fully enclosed devkit based on Raspberry Pi RP2350 MCU, an ESP32-C6 SoC for wireless connectivity, a 2.33-inch capacitive color touchscreen display, and an HDMI (DVI) video output port. The design is an update to the T-PicoC3 introduced in 2022 with the case design of the T-Display S3 Pro, and the devkit also features a microSD card slot, a USB-C port for power and programming, two GPIO headers, a 13-pin GPIO FPC connector, two Qwiic I2C/UART connectors, and a PMU for battery management. T-Pico-2350 specifications: Microcontroller – Raspberry Pi RP2350A CPU Dual-core Arm Cortex-M33 @ 150 MHz with Arm Trustzone, Secure boot OR Dual-core RISC-V Hazard3 @ 150 MHz Up to two cores can be used in any combination Memory – 520 KB on-chip SRAM Storage 16MB SPI flash connected to RP2350 MicroSD card slot Display – 2.33-inch color IPS LCD (ST7796S SPI […]

Posted on by Debashis Das - 1 Comment on LILYGO T-Watch S3 Plus smartwatch gets GPS and 940mAh battery

LILYGO T-Watch S3 Plus smartwatch gets GPS and 940mAh battery

LILYGO T Watch S3 Plus

LILYGO has recently introduced the T-Watch S3 Plus, an ESP32-S3 smartwatch which can be considered an upgrade from the previous generation T-Watch S3, adding a u-blox MIA-M10Q GPS and a larger 940mAh LiPo battery for extended battery life. The T-Watch S3 Plus smartwatch still supports Wi-Fi, Bluetooth LE, and LoRa connectivity, and integrates a 1.54-inch 16-bit full-color TFT LCD display with capacitive touch and a wide-viewing angle. The smartwatch also features an infrared (IR) transmitter that can be used for remote control or proximity detection. T-Watch S3 Plus specifications Wireless MCU – Espressif Systems ESP32-S3 CPU – Dual-Core 32-bit Tensilica LX7 @ up to 240 MHz with vector instructions for AI/ML acceleration Memory – 512KB SRAM, 8MB PSRAM Storage – 16MB flash, 384KB ROM Wireless – Wi-Fi 4 and Bluetooth 5 LE/Mesh Display – 1.54-inch 16-bit full color TFT LCD display with 240×240 resolution, capacitive touch; ST7789V SPI controller Audio – […]
