March 27, 2023March 26, 2023 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

CM4 Maker Board review – Part 1: specifications, unboxing, and first boot

Cytron CM4 Maker Board is a carrier board for the Raspberry Pi CM4 or CM4 Lite system-on-module with plenty of I/Os, support for one M.2 NVMe SSD, and RTC backup battery, a buzzer, and various LEDs for GPIO status that makes the board especially well suited for the education market and prototyping. The carrier board also comes with the usual Gigabit Ethernet and full-size HDMI port, four USB 2.0 ports, five Grove connectors, one Maker port, the omnipresent 40-pin Raspberry Pi GPIO header, and support power input from 7V-18V DC jack or 5V via a USB Type-C connector. CM4 Maker Board specifications Cytron CM4 Maker Board specifications: Supported SoM – Raspberry Pi Compute Module 4 or Compute Module 4 Lite Storage microSD card slot M.2 PCIe 2.0 socket for NVMe 2232/2242 SSD Video Interfaces Full-size HDMI 2.0 port MIPI DSI display connector Camera – MIPI CSI connector connector Audio – […]

March 24, 2023 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

MIPI CSI camera works with Intel Atom x7000, Processor, and Core i3 Alder Lake-N processors

Alder Lake-N Customer Reference Board MIPI CSI camera

Most Intel processors do not come with a MIPI CSI camera, but some Alder Lake-N processors do, and Leopard Imaging has designed the LI-ADL-ADP-IMX415-MIPI-081H MIPI CSI camera module that is compatible with the Intel ADL-N CRB (Alder Lake-N Customer Reference Board) and custom Alder Lake-N boards equipped with a compatible MIPI CSI connector. The 13MP camera supports resolutions up to 3864 x 2176 and works with boards and embedded systems based on Intel Atom processors x7000E Series, Intel Core i3-N processors, and Intel Processors N-Series processors. LI-ADL-ADP-IMX415-MIPI-081H specifications: Sony IMX415 CMOS image sensor Diagonal – 6.43 mm (Type 1/2.8) Active Pixels – 3864 (H) x 2176 (V) Pixel Size: 1.45 x 1.45 μm Optical Format: 1/2.8″ Effective Focal Length – 4.063 mm Aperture, F/#2.29 ± 5% IR Filter – 650 nm IR cut filter Field of View (FOV) – 81.7˚ horizontal, 44.7˚ vertical; 95.1˚ diagonal Lens Mount – M12 x […]

March 24, 2023 by Jean-Luc Aufranc (CNXSoft) - 7 Comments

Framework modular laptop adds Intel Raptor Lake, AMD Ryzen motherboards, 16-inch laptop frame

Framework Modular Laptop Intel Raptor AMD Ryzen 7040 motherboard

When we first covered the Framework modular laptop in 2021 it came with a choice of 11th generation Intel Tiger Lake Core processors, up to 64GB RAM, up to 4TB SSD storage, a 13.5-inch display, a Full HD webcam, and a 55Wh battery. Modular electronic devices have been worked on by several companies over the years, but such endeavors usually result in failure due to costs and other difficulties. Remember Google’s Project Ara? But Framework may have found something that works, as they’ve now launched 13th Generation Intel Raptor Lake motherboards, AMD Ryzen 7040-series motherboards, updated the 13.5-inch display with a Matte finish, and even unveiled the Framework Laptop 16 with a 16-inch display that should become available in Q3 2023. Intel Raptor Lake and AMD Ryzen 7040 motherboards The Framework modular laptop now supports additional Intel Raptor Lake and AMD Ryzen motherboards with the following processors and key options. […]

March 23, 2023 by Jean-Luc Aufranc (CNXSoft) - No Comments

OSD62x SiP combines TI AM62x processor with LPDDR4, EEPROM, PMIC, and passives into a single package

Octavo Systems OSD62x is a system-in-package (SiP) combining the Texas Instruments AM62x processor with LPDDR4 RAM, EEPROM, power management, oscillators, and passive components, plus optional features such as an RTC and an 8-channel ADC. At least that’s true for the OSD62x Max Integration SiP (22×22 mm BGA), but Octavo Systems also have a smaller 14x9mm package called the OSD62x Size Optimized with “just’ the AM62x processor, LPDDR4 memory, and passive components. OSD62x “Max Integration” specifications: SoC – Texas Instruments AM62x (AM623/AM625) CPU – Up to 4x Arm Cortex-A53 @ 1.4GHz MCU – Arm Cortex-M4F GPU – 3D graphics up to 2048×1080 @ 60 fps (AM625 only) Storage I/F – 1x eMMC, 2x SDIO, 1x GPMC Display I/F – 24-bit RGB MIPI DPI and OLDI/LVDS Camera I/F – 1x MIPI CSI-2 with DPHY 1.2 Networking – 2x 10/100/1000M Gigabit Ethernet with TSN support USB – 2x USB 2.0 interfaces PRU-ICSS Other […]

March 23, 2023 by Li Zexi - 1 Comment

100ASK-T113-Pro Allwinner T113-S3 industrial board, and Allwinner T113-S4 with 256MB DDR3

Last year, Jean-Luc introduced the T113-S3 processor and the small MangoPi-Dual board with T113-S3. This time, I will introduce a development board with relatively rich resources, the 100ASK-T113-PRO, which consists of a core board with T113-S3 and a carrier board with a large number of peripheral interfaces, and the upcoming Allwinner T113-S4 SoC with 256MB DDR3. 100ASK-T113-Pro Allwinner T113-S3 industrial board While the T113-S3 and D1s/F133 RISC-V processors are pin-to-pin compatible, the T113-S3 is a dual-core Arm Cortex-A7 processor with HiFi4 DSP, CAN interfaces added (CAN is not mentioned publicly, but can be seen in the T113-S3 Datasheet) and 128MB DDR3 on-chip memory. 100ASK-T113-PRO preliminary specifications: T113-S3 Core Lite: SoC – Allwinner T113-S3 Dual-core Arm Cortex-A7 with 32 KB L1 I-cache + 32 KB L1 D-cache per core, and 256 KB L2 cache DSP – Single-core HiFi4 Memory – 128 MB DDR3 (SIP) Storage – 16MB SPI NandFlash Video decoding […]

March 23, 2023 by Jean-Luc Aufranc (CNXSoft) - No Comments

Half-size mini PCIe card adds up to 4 CAN FD interfaces to embedded systems

esd electronics CAN-PCIeMiniHS/402 is a half-size mini PCIe card with four CAN FD Interfaces designed for embedded systems with one model adding extended temperature range support from -40C to 85°C. The company also introduced the CAN-Mini/402-4-DSUB9-150mm adapter to more easily connect the four CAN network interfaces via DSUB9 connectors. It comes with four individual small adapter boards, each equipped with a DSUB9 plug and a jumper for selectable onboard CAN termination, as well as 150 mm long wires. CAN-PCIeMiniHS/402 highlights: 4x CAN FD interfaces according to ISO 11898-2, no galvanic isolation, bit rates from 10 Kbit/s up to 8 Mbit/s Bus mastering and local data management by FPGA (Intel Cyclone IV EP4CGX) PCIe Mini interface according to Mini Card Electromechanical Spec. R1.2 Supports MSI (Message Signaled Interrupts) HW-Timestamp capable Dimensions – 30 mm x 27 mm (Half-size mini PCIe form factor) Temperature Range Standard – 0°C … +75°C Extended range: […]

March 23, 2023March 22, 2023 by Jean-Luc Aufranc (CNXSoft) - 18 Comments

Orange Pi 5B SBC adds up to 256GB eMMC flash, built-in WiFi 6 and Bluetooth 5.0 module

Orange Pi 5B is a variant of the Rockchip RK3588S powered Orange Pi 5 SBC with up to 256GB eMMC flash and a soldered-on wireless module offering WiFi 6 and Bluetooth 5.0 connectivity, at the cost of losing the M.2 2242 socket and 16MB QSPI NOR flash found in the original board. The board still comes with HDMI 2.1, DisplayPort 1.4 (USB-C), and MIPI DSI display connectors, three camera connectors, a Gigabit Ethernet interface, a few USB ports, and a 26-pin GPIO header for expansion. Orange Pi 5B specifications with the new features highlighted in bold, and the missing ones as strikethrough text: SoC – Rockchip RK3588S octa-core processor with 4x Cortex-A76 cores @ up to 2.4 GHz, 4x Cortex-A55 cores @ up to 1.8 GHz, Arm Mali-G610 MP4 GPU, 6 TOPS AI accelerator System Memory – 4GB, 8GB, or 16GB LPDDR4/4x (32GB RAM is also listed, but not for […]

March 22, 2023 by Jean-Luc Aufranc (CNXSoft) - 14 Comments

MeLE Quieter2D ultrathin fanless mini PC is now available without an operating system

Barring barebone models, most mini PCs sell with Windows 10 or Windows 11 pre-installed, and that’s not ideal for people wanting to run Linux only since they also pay extra for the license of an operating system they are not going to use. But MeLE is now selling the Quieter2D mini PC with an Intel Celeron N4000 dual-core processor, 4GB RAM, and 64GB or 128GB eMMC storage for $139.99 and up without an operating system or a Windows key. The ultrathin fanless mini PC also features M.2 2280 SATA/NVMe socket, a microSD card reader, two HDMI 2.0 ports, Gigabit Ethernet and WiFi 5 connectivity, four USB 3.0 ports, and takes 12V power input through a USB Type-C port. MeLE Quieter2D specifications: SoC – Intel Celeron N4000 dual-core Gemini Lake processor @ 1.1GHz / 2.6GHz (Turbo) with Intel UHD Graphic 600; 6W TDP System Memory – 4GB LPDDR4 Storage – 64GB […]
