LoRa & LoRaWAN support in Zephyr OS

The story of LoRa began in 2009 when Cycleo, a French company, invented LoRa. LoRa (Long Range) support for Zephyr OS goes back to December 2019. Since then, there has been a huge interest among the community to extend their support for it. More recently, LoRaWAN (low-power wide-area network) support was added to Zephyr OS. This will provide true networking support to Zephyr OS over LoRa. It operates in licensed free Sub Gigahertz frequencies (865 MHz-India, 868 MHz-Europe, etc…). It makes the perfect choice for low data rates and long-range applications. What is LoRaWAN? LoRaWAN is a MAC layer that sits on top of the LoRa. According to the OSI model, LoRaWAN is the MAC (media access control) layer while LoRa is the PHY (physical) layer. LoRa protocol is closed, meaning it is proprietary to Semtech, while LoRaWAN specifications are open to the public. The reference implementation is available at the GitHub repository. The end nodes transmit data to the […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Penguino Feather 4260 LoRa development board features RAK4260 module

Adafruit Feather form factor has become more popular in recent years with third-parties introducing Feather compatible boards such as the Giant Board (Linux capable), OrangeCrab (FPGA), or FeatherS2 (ESP32 WiFi + Bluetooth), and as well as FeatherWing add-on boards. Azerbaijan based MakerTronika Labs has launched their own Feather compatible board with LoRa connectivity: Penguino Feather 4260. The development board is powered by a RAK4260 module based on SAMR34 LoRa SiP and supports both 868 and 915 MHz bands. Penguino Feather 4260 specifications: LoRa module – Rak wireless RAK4260 module with: SiP – Microchip ATSAMR34J18 SiP with SAML21 Arm Cortex M0+ MCU @ 48 MHz, 40 KB RAM, 256 KB Flash, Semtech SX1276 LoRa Connectivity Frequency Range – 862 to 1020 MHz High level of accuracy and stability (32MHz TXCO) Max Tx Power: 20dBm; Max Sensitivity: -148dBm; Rx Current: 17mA (typical) Compliant with LoRaWan 1.0.2 Power Consumption Low RX current of 13.6mA 790 nA in sleep mode Antenna – SMA and […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

NuMaker-IoT-M263A board is the Swiss army knife of IoT development

If you’d like an MCU board to experiment with various wireless (and wired) protocols used for Internet of Things applications, the Nuvoton NuMaker-IoT-M263A development board may be worth a look. Powered by a NuMicro M263KIAAE Arm Cortex-M23 CPU microcontroller, the board offers WiFi, Bluetooth, and LoRa connectivity, plus an mPCIe socket for 3G, 4G, or NB-IoT cellular connectivity. It also comes with various sensors, as well as CAN and RS485 transceivers for industrial control applications. NuMaker-IoT-M263A key features and specifications: MCU – Novoton NuMicro M263KIAAE Arm Cortex-M23 microcontroller @ 64 MHz with 96KB SRAM, 512 KB  dual-bank flash for OTA upgrade, 4 KB LDROM; LQFP128 package Storage – MicroSD card connector On-board wireless modules ESP12-F (ESP8266) 802.11b/g/n module MDBT42Q-PAT Bluetooth 4.2/5.0 LE module APC1278 (for 408 / 433 / 470 MHz)  LoRa module plus antenna Serial – CAN and RS485 transceiver USB – 1x Micro USB OTG connector (to M263 MCU) Sensors BME680 4-in-1 air quality sensor measuring relative humidity, […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Modberry 500 CM4 DIN Rail Industrial Computer Features Raspberry Pi Compute Module 4

We’ve been writing about Techbase Modberry industrial embedded computers with DIN-Rail enclosures such as Modberry M500 or M2000 for several years. Most of their systems are powered by SBC’s like Raspberry Pi 4 or AAEON Up Squared, but they’ve also made models based on Raspberry Pi Compute Module 3+, and with the launch of Raspberry Pi CM4, the company has now introduced Modberry 500 CM4 industrial computer powered by Raspberry Pi Compute Module 4 with up to 8GB RAM and 32GB eMMC flash. Modberry 500 CM4 key features and specifications: SoM – Raspberry Pi Compute Module 4 with Broadcom BCM2711 quad-core Cortex-A72 processor @ 1.5 GHz, 1 to 8GB RAM, up to 32GB eMMC flash. Storage – Optional NVMe SSD via PCIe 2.0 (mini PCIe or optional M.2 slot) Video Output – Optional HDMI port Connectivity Optional Gigabit Ethernet port Optional Wi-Fi (IEEE 802.11 b/g/n/ac) & Bluetooth 5.0 Optional 5G, 4G/LTE, 3G, or NB-IoT modem plus on-board SIM card socket […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Rakwireless Launches WisBlock IoT Modular System Beta Testing Program

Rakwireless has launched several IoT evaluation boards such as RAK4260 LoRaWAN EVB relying on WisBlock modules comprised of a carrier board and a module. So far, those were always sold as part of evaluation boards, but now the company is trying to expand WisBlock use as a modular system, so users can easily build their custom systems, LEGO style. The modular system is based on four different block types: WisBlock Base – A carrier board with connectors for other block types, power supply, some ports WisBlock Core – Module with a microcontroller/processor WisBlock Sensor – Modules with environmental sensors, motion sensors, ambient light sensors, or others WisBlock IO – Adds more inputs, outputs, or connectivity options including  LTE-M / NB-IoT, cellular and Wi-Fi modules, NFC reader, and interfaces for I2C, UART, ADC, and GPIO. The company is just getting started with the solution, and initially will be offering one WisBlock baseboard, an improved version of the one used with RAK4260 […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

RAK7431 RS485 Bridge Relays ModBUS Data over the LoRaWAN Network

Last year with covered Dragino RS485-LN RS485 to LoRaWAN converter that extends the range of RS485 wirelessly up to 15+km thanks to LoRaWAN connectivity. Rakwireless has now launched a similar product with RAK7431 Modbus RS485 to LoRaWAN bridge. RAK7431 key features and specifications: MCU- STM32L071 industrial-grade MCU with low-power consumption (4uA sleep) LoRa Semtech SX1272 LoRa transceiver Frequencies – RU864, IN865, EU868, US915, AU915, KR920, AS923 Tx Power – 20dBm (Max) LoRaWAN 1.0.3 protocol stack, supports Class A, Class B & C Polling mode, transparent mode and packet mode RS485 6-pin RS485 terminal block Support up to 16x RS485 devices, with up to 32 instruction sets Baud rate – Configurable 9600 to 115200bps Can power RS485 devices via a dedicated output USB – 1x Micro USB configuration port Misc – Reset key, 3x LEDs Input Voltages – 8-48V DC input via 2-pin terminal block; 5V via Micro USB Dimensions – 93.6 x 100.3 x 24mm Protection Grade – IP31 (Protected […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Helium Hotspot LoRaWAN Gateway also Earns Cryptocurrency

We covered MatchX M2 Pro LPWAN Crypto-miner yesterday, and at first, I really thought that combining LoRaWAN gateway with cryptocurrency mining was really just a gimmick. But after talking with others, I found out that MXC Foundation HashDash used with the MatchX gateway was not the only such solution, and I was introduced to Helium Hotspot. A Helium Hotspot is a LoRaWAN gateway that also allows you to earn HNT cryptocurrency, and it could more than just prove a way to fund the deployment of public LoRaWAN networks, as as we’ll see below some people or companies are making some serious money, while others not so much. A DIY Helium Hotspot can also be made from a Raspberry Pi 3/4 and a RAK2245 Pi HAT. Helium Hotspot key features and specifications: SoC – Quad-core Arm Cortex-A53 application processor System Memory – 1GB RAM Storage – 64GB Storage Connectivity Ethernet Dual-band Wi-Fi Bluetooth 4.2 LE LoRaWAN bands – RF: 902-928MHz (US), […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

RAK2287 Mini PCIe LoRaWAN Concentrator Module Supports up to 500 Nodes per km2

RAK Wireless launched its first Mini PCIe LoRaWAN concentrator module in 2018 with RAK833 mPCIe card featuring Semtech SX1301 LoRa baseband chip. It was soon followed by RAK2247 mPCIe with a very similar design but some tweaks to increase its maximum transmission power and range, and improve thermals and stability with the addition of a heatsink. The company has now introduced a new version with RAK2287 Mini PCie LoRaWAN concentrator module being mostly inspired by RAK2247 module but replacing Semtech SX1301 by Semtech SX1302 LoRa transceiver that’s suppose to reduce current consumption (and heat), lower the BoM cost, and able to handle a higher amount of traffic. The new mini PCIe card also adds u-blox ZOE-M8Q GPS system-in-package to provide GNSS functionality. RAK2287 key features and specifications: LoRa Connectivity Semtech SX1302 LoRa Transceiver with 2x SX1250 Tx/Rx front-end Tx power – up to 27dBm Rx sensitivity – down to -139dBm @ SF12, BW 125 kHz LoRaWAN® 1.0.2 compatible. LoRa band coverage […]
