September 1, 2020September 1, 2020 by Jean-Luc Aufranc (CNXSoft) - 6 Comments

M5Stack Launches Core2 ESP32 IoT Development Kit with 2-inch Touch Display

M5Stack has just launched an upgrade to its M5Stack Core development with M5Stack Core2 based on the same Espressif ESP32 WiFI + Bluetooth SoC, but adding capacitive touchscreen support to the 2-inch TFT LCD, as well as a motion sensor and a microphone. The new version also adds 8MB PSRAM, a larger 390 mAh battery, and targets IoT terminals for Smart Home, industrial automation or robotics, STEM Education, and DIY prototyping. M5Stack Core2 specifications: SoC – Espressif ESP32-D0WD-V3 dual-core Xtensa LX6 processor clocked at up to 240MHz with 520KB SRAM, Wi-Fi, and dual-mode Bluetooth connectivity External Memory – 8MB PSRAM Storage – 16MB flash storage, MicroSD card slot up to 16GB Display – 2-inch IPS LCD screen with 320×240 resolution (ILI9342C driver), and touchscreen support (via FT6336U controller) Audio – 1W speaker (1W-0928), SPM4123 microphone, NS4168 I2S power amplifier Antenna – 2.4GHz 3D antenna USB – 1x USB Type-C port […]

June 5, 2020November 3, 2020 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

M5Stack Atom Echo Coin-Sized Bluetooth Speaker is Powered by ESP32-PICO-D4 SiP

M5Stack has just launched Atom Echo, a coin-sized programmable Bluetooth speaker based on Espressif Systems ESP32-PICO-D4 system-on-package. The company sent me an early sample to play with before launch… but let’s have a look at the specification before checking the device further. Specifications: SiP – Espressif Systems ESP32-PICO-D4 system-in-package with ESP32 dual-core processor @ 240MHz Wi-Fi, BLE 4.0 and 4MB flash Audio 0.5W/NS4168 I2S speaker SPM1423 PDM microphone Expansion 5-pin + 4-pin headers with 6x GPIOs, UART, 5V, 3.3V, GND 4-pin digital Grove header with 2 I/Os, 5V and GND Misc – RGB LED (SK6812), Function (Top – G39 pin) and reset buttons (side), IR LED Power Supply – 5V/500mA via USB-C port Dimensions – 24 x 24 x 17mm (plastic material) Weight – 10 grams The Bluetooth speaker is really small, but you may think CNXSoft has big hands and fat fingers so it makes the speaker smaller than […]

March 26, 2020June 29, 2021 by Jean-Luc Aufranc (CNXSoft) - 3 Comments

M5Stack ATOM is a Compact, Fully Integrated ESP32 Development Kit

When working on a project you may need an MCU or MCU board, an external display, a breadboard, and other accessories like sensors and jumper cables. It does the job, but it can be messy. Recently, we wrote about M5Stack M5StickV AI camera, but the company is better known for its ESP32 IoT development kits enabling neater project thanks to hardware that integrates MCU, I/O headers, display, and sensors into an enclosure. Their latest offerings are ATOM series toolkits that come in two versions: ATOM Lite and ATOM Matrix. Let’s have a look at both. M5Stack ATOM Lite Specifications: SiP – ESP32-PICO-D4 system-in-package with ESP32 dual-core processor with WiFi 4 and Bluetooth 5.0/5.1 Storage – 4 MB flash Crystal oscillator and passive components USB – 1x USB Type-C port Expansion 9-pin header with 6 GPIOs compatible with jumper cables 4-pin PH2.0 connector with 2x GPIO, 5V and GND Misc – […]

August 17, 2019August 17, 2019 by Jean-Luc Aufranc (CNXSoft) - 9 Comments

M5Stack M5StickV is a Tiny AI Camera for Maker Projects

I’ve just started to play with Maixduino board based on ESP32 WiSoC and Sipeed M1 module that enables AI tasks such as object detection thanks to built-in AI accelerators found in Kendryte K210 RISC-V processor and noticed references to M5Stack M5StickV in firmware file names. Somehow I never wrote about M5Stack, but the company provides modular ESP32 IoT development boards that can be stacked with various modules to easily and quickly build prototypes. M5StickV is one of those modules and is similar to Maixduino kit with camera and display, minus WiFi + Bluetooth connectivity, except that everything nicely packed into a cute module. M5StickV hardware specifications: SoC – Kendryte K210 dual-core 64-bit RISC-V processor @ 400MHz with dual independent double-precision FPU, 8MB on-chip SRAM, Neural Network Processor (KPU) @ 0.8Tops, Field-Programmable IO Array (FPIOA), and more Storage – 16MB flash, microSD card slot Display -1.14″ SPI display with 240×135 resolution […]
