January 10, 2019 by Jean-Luc Aufranc (CNXSoft) - No Comments

Mictrack MT825 is a Waterproof LTE Cat M1 & NB-IoT GPS Tracker

We’ve previously covered Mictrack MT600 4G LTE GPS tracker with support for various GPS software such as the open source OpenGTS and Traccar programs, as well as Android & iOS mobile apps. Since then the company released MT550 model with NB-IoT and LTE Cat M1 (eMTC) connectivity, as well as an OBD-II model that are currently sold for respectively $99 and $69 on Aliexpress. More recently a waterproof LTE IoT module called Mictrack MT825, which we’ll look into more details in this post. Mictrack MT825 key features and specifications: Cellular Connectivity LTE Cat M1 (eMTC) LTE FDD: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B26/B28 LTE TDD: B39 LTE Cat NB1 (NB-IoT) – LTE FDD: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B26/B28 2G – GSM: 850/900/1800/1900Mhz SIM Card interface – Nano SIM Internal LTE CAT M1 & NB-IoT antenna Location U-blox MAX-7 GPS chip GPS sensitivity – -162dBm Channel – 56 Positioning Accuracy – 10m Cold Start – 30s. Warm start – 15s […]

December 20, 2018 by Jean-Luc Aufranc (CNXSoft) - No Comments

Qualcomm 9205 NB-IoT & Cat M1 LTE Modem Lowers Costs, Power Consumption

Qualcomm has introduced a new LTE IoT chipset with Qualcomm 9205 LTE modem that supports Cat M1 (eMTC), NB2 (NB-IoT), 2G/E-GPRS fallback, as well as GNSS. Qualcomm 9205 comes at a lower price, smaller footprint, and up to 70% lower power consumption in standby mode compared to its predecessor (MDM9206). Qualcomm 9205 LTE modem key features and specifications: Processor / OS – Arm Cortex A7 up to 800MHz with support for ThreadX and AliOS Things real-time operating systems Connectivity Standards 3GPP release 14 Category M1 and NB2; 2G/E-GPRS fallback where Cat M1 / NB2 is not available. Category M1 mode supports voice for applications such as monitored security panels, and mobility for applications such as asset trackers. RF transceiver Bandwidth support from 450 MHz to 2100 MHz Built-in RF front-end, a first in the cellular IoT space Geolocation Integrated GNSS (Global Navigation Satellite Systems) support for GPS, Beidou, Glonass, and […]

November 5, 2018 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Arduino Support for Quectel BC66 NB-IoT Module

Quectel has several LTE IoT modules such as BG96 with NB-IoT + eMTC connectivity, but the company has also a smaller, cheaper NB-IoT only module called Quectel BC66, and Georgi Angelov (Wiz-IO) informed me he implemented Arduino support for the module with BC66-DVK board. Let’s first have a look at BC66 specifications: Frequency Bands Available now – B1/B3/B5/B8/B20 Under development – B2/B12/B13/B17/B18/B19/B25/B26/B28/B66 Output Power – 23dBm ±2dB Sensitivity – -129dBm Data Data Rate Single-Tone: 25.5kbps (DL)/16.7kbps (UL) Multi-Tone: 25.5kbps (DL)/62.5kbps (UL) Protocol Stacks – UDP/TCP/CoAP/LwM2M/SNTP/MQTT/PPP/TLS/DTLS/HTTP/HTTPS/FTP SMS – Text/PDU Mode Interfaces – 1x USIM, 1x PSM _EINT, 3x UARTm 1x ADC, 1x RESET, 1x PWRKEY, 1x NETLIGHT, 1x antenna, 1x SPI, “OpenCPU” version only: 1x I2C, 1x I2S, and configurable GPIO Supply Voltage – 2.1 to 3.63V (3.3 typ.); I/O: 1.8V Power Consumption (Typ.) 3.5μA @PSM 0.29mA @Idle Mode (eDRX=81.92s) 0.43mA @Idle Mode (DRX=2.56s) 110mA @LTE Cat NB1, 23dBm Dimensions – […]

September 18, 2018November 3, 2019 by Jean-Luc Aufranc (CNXSoft) - No Comments

WisCellular Certified Global LTE IoT Arduino Shield Enters Beta Testing

RAK Wireless introduced WisLTE Arduino shield last year based on Quectel BG96 module with support for NB-IoT (Cat NB1), eMTC (Cat M1), and 2G fallback as well as GPS location. WisLTE worked globally, but the company did not go through the certification process, at least not for the global market, meaning the shield could not be used in commercial applications. That’s why Rak Wireless has been working on WisCellular shield, also based on Quectel BG96, but this time with global certification. WisCellular specifications: Cellular Module – Quectel BG96 (based on Qualcomm MDM9206) Cellular Network 2G/GSM (GPRS/EPGRS) 4G/LTE-M (Cat M1) NB-IoT (Cat NB1) Global Bands EDGE/EGPRS: 850/900/1800/1900MHz LTE FDD: B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B26/B28 LTE TDD: B39 (For Cat M1 Only) Data Rate Cat M1: Max. 300Kbps (DL), Max. 375Kbps (UL) Cat NB1: Max. 32Kbps (DL), Max. 70Kbps (UL) EDGE: Max. 296Kbps (DL), Max. 236.8Kbps (UL) GPRS: Max. 107Kbps (DL), Max. 85.6Kbps (UL) Voice – […]

August 23, 2018 by Jean-Luc Aufranc (CNXSoft) - No Comments

Samsung Introduces Exynos i S111 NB-IoT Modem + GNSS Chip

Samsung has just announced their first NB-IoT solution with Exynos i S111 chipset with a single chip integrating an NB-IoT capable LTE modem, RF IC, an on-chip security sub-system, and a PUF (Physical Unclonable Function) security solution along with various components such as CPU, and SRAM. The chip apparently also integrates GNSS hardware with support for GPS, Galileo, etc… Exynos i S111 specifications: CPU – Arm Cortex-M7 @ 200MHz On-chip Memory – 512KB SRAM Modem – LTE Release 14 NB-IoT GNSS – GPS, Galileo, GLONASS, BeiDou Interfaces / Peripherals – USI, UART, I2C, GPIO, eSIM I/F, SDIO (Host), QSPI(Single/Dual/Quad IO mode), SMC Security – eFuse, AES, SHA-2, PKA, Secure Storage, Security Sub-System, PUF The chip is also said to features Samsung’s “advanced algorithms for wider coverage”. Many NB-IoT GPS trackers currently implement a two modules solution, so the latest Exynos chip should enable more compact designs. Samsung did not publish […]

July 31, 2018July 31, 2018 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

RAK8213 mini PCIe Card Comes with GNSS, NB-IoT & eMTC Connectivity

After launching their first wireless communication mini PCIe card with RAK833 LoRaWAN gateway card last month, RAK Wireless is back with another mPCIe card that supports GNSS (GPS, GLONASS), as well as cellular IoT connectivity thanks to Quectel BG96 NB-IoT + LTE Cat M1 module. RAK8213 mini PCIe card specifications: Wireless Connectivity Module – Quectel BG96 with LTE Cat. M1 (eMTC), LTE Cat. NB1 (NB-IoT), EGPRS, and GNSS Global bands support FDD-LTE – B1/ B2/ B3/ B4/ B5/ B8/ B12/ B13/ B18/ B19/ B20/ B26/ B28 TDD-LTE – B39 (for Cat M1 only) EGPRS – 850/900/1800/1900Mhz Max Data Rate – Cat M1: 375 kbps (UL/DL); Cat NB1: 32 kbps DK, 70 kbps (UL) micro SIM slot u.FL connectors for cellular and GNSS mPCIe connector with USB 2.0, I2C, UART, and PCM Misc – LEDs for network and power status Dimensions – 51 x 30.1 mm The card can be added […]

June 21, 2018 by Jean-Luc Aufranc (CNXSoft) - 7 Comments

SIM7020E 4G NB-IoT Mini Development Board Sells for Just $14

We now have plenty to choose from when it comes to NB-IoT development boards or shields, but so far pricing has not been very attractive, and the cheapest NB-IoT solution I found so far was probably Dragino NB-IoT Bee, a XBee compatible board going for $23. But this morning, I saw an even cheaper NB-IoT board with SIM7020E 4G NB-IOT Mini development board selling for $14.30 on Electrodragon. Not quite the price of 2G solutions, but we’re getting there. Board specifications: NB-IoT Module – SIMCom SIM7020E module working globally with B1/B3/B5/B8/B20/B28 bands supported Nano SIM card holder and u.FL connector for NB-IoT Expansion – 9-pin unpopulated 2.54mm pitch header with 2x UART (3.3V / 5V), ADC, Boot, 3.3V, 5V and GND USB – 1x micro USB port that can be recognized by PC, but as Electrodragon puts it: “not sure how to use it”. Misc – Net LED, power key […]

June 13, 2018June 18, 2018 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

Wio LTE GPS Tracker Board Gets a Cat M1/NB1 Version for $59

Seeed Studio launched a family of GPS tracker boards staring with Wio GPS with 2G cellular connectivity, followed by Wio LTE board offering 4G connectivity several months later. The company is taking pre-order for an LTE Cat M1/NB1 version with NB-IoT / eMTC connectivity, and going for $59 plus shipping. The board is expected to start shipping on July 25th. Wio LTE Cat M1/NB1 board specifications: MCU – STMicro STM32F405RG Arm Cortex-M4 @ 168MHZ with 1M Flash, 192+4KB RAM Connectivity LTE uBlox SARA-R410M module LTE CAT M1 and NB-IoT Cat M1 Half-duplex (375 kb/s DL and UL) Cat NB1 Half-duplex (27.2 kb/s DL, 62.5 UL) Nano SIM and micro SD card 2-in-1 socket GNSS uBlox MAX-M8Q module PS, BeiDou, GLONASS, and Galileo 2.5m CEP(GPS), 4.0m CEP(GLONASS) USB – 1x micro USB port for power supply and DFU Expansions – Grove headers: 2x digital, 2x analog, 1x UART, 1x I2C Misc […]
