OpenEmbed Launches $99 em3399 Rockchip RK3399 SoM, and a Compact Evaluation Kit

Looking for a system-on-module based on Rockchip RK3399 processor? So far, you had at least four options with either edge connectors or castellated holes: Theobroma RK3399-Q7 (Qseven) SoM, 9Tripod X3399 core, Boardcon PICO3399 CPU module,  or Firefly-RK3399 CoreBoard. OpenEmbed now offers another RK3399 system-on-module with their em3399 SoM using board-to-board connectors interfacing with the carrier board. OpenEmbed em3399 system-on-module specifications: SoC – Rockchip RK3399 hexa-core processor with 2x Cortex-A72 cores, 4x Cortex-A53 cores, and a Arm Mali-T860MP4 GPU System Memory –  2GB or 4GB DDR3L RAM Storage – 16GB to 128GB eMMC 5.1 flash Connectivity – Gigabit Ethernet transceiver (Atheros AR8033) Power Management – Rockchip RK808D PMIC 2x 120-pin board-to-board connectors (0.8mm pitch) with: Display: HDMI 2.0 port with audio for up to 4K @ 60Hz DisplayPort 1.2 with audio for up to 4K @ 60Hz MIPI-DSI (dual-channel) at up to 2560×1600 @ 60 Hz eDP 1.3 (4-lane) Camera – […]

OpenEmbed SOM6360 is a $69 Freescale i.MX6 SoloX System-on-Module

Apart from UDOO Neo development board, which is currently shipping Kickstarter backers, I hadn’t seen many Freescale i.MX 6SoloX based hardware so far. But Shenzhen OpenEmbed has now launched a system-on-module powered by Freescale Cortex A9 and Cortex-M4 SoC with their SOM6360 CPU module. OpenEmbed SOM6360 Rev. A computer-on-module specifications: SoC – Freescale i.MX 6SoloX ARM Cortex-A9 core @ 1GHz with ARM Cortex-M4 Core @ 200 MHz, and 2D and 3D multimedia accelerators System Memory – 512MB DDR3L (1GB optional) Storage – 4GB to 32GB eMMC flash, 32MB QSPI  flash Video Input/Output 18-bit digital RGB 24-bit LVDS (up to WXGA) Analog/digital camera interface (YUV4:2:2 CCIR-656) Connectivity – 2x Gigabit Ethernet interfaces (2x on-board AR8033 PHYs) Other I/Os via 2x 120-pin connectors: 1x USB 2.0 host, 1x USB 2.0 device 5x serial,2x CAN 2.0 2x I2C, 2x SPI 2x SDIO PWM Optional 12-bit ADC PCIe 2.0 Misc – Watchdog Power Supply – […]
