ODROID-HC4 low-cost dual NAS comes with 4GB RAM, supports 2.5-inch and 3.5-inch SATA drives

Low-cost Linux NAS dual SATA Drive

[Edit: Hardkernel has now updated their documentation to clarify the NAS uses ASM1061 PCIe to SATA controller instead of JMB582] It’s hard to find low-cost NAS platforms often because of the mechanism to insert drives and the enclosure add to the cost. An alternative is to use boards like Hardkernel ODROID-HC1 for 2.5-inch drives or ODROID-HC2 for 2.5- and 3.5-inch drives, but each board supports only one drive. The designs are stackable, but you’d need one Linux board per drive, so it’s not ideal. The Korean company has now launched a new model with ODROID-HC4 powered by an Amlogic S905X3 processor and shipping with a case supporting two 2.5-inch or 3.5-inch SATA drives that will start selling later this month for just $65 and up. ODROID-HC4 specifications: SoC – Amlogic S905X3 quad-core Cortex-A55 processor @ 1.8 GHz with Mali-G31 MP2 GPU System Memory – 4GB DDR4 Storage 128 Mbit SPI […]

Pine64 Launches a $45 Dual SATA NAS Enclosure for ROCKPro64 Board

ROCKPro64 Dual SATA Drive NAS Kit

ROCKPro64 is one of the most affordable Rockchip RK3399 boards, as you can purchase it for as low as $60 with 2GB RAM, and $80 with 4GB RAM. Pine64 – the company behind the board – also offers add-on boards such as a PCIe card to connect up to two SATA drives. The company has now leveraged the latter in their ROCKPro64 metal desktop/NAS casing specifically designed for ROCKPro64 boards, and capable of holding two 2.5″/3.5″ SATA drives.Key features  of ROCKPro64 Desktop/NAS case: Compatible with ROCKPro64 boards only SATA – Accommodates either 2x 2.5″ SATA drives or 2x 3.5″ SATA drives or a mix of 2x 2.5″/3.5″ SATA drives Power Supply – 12V DC Dimensions –  232.4mm (Width) x 105.0mm (Height) x 145.2mm (Depth) The case also ships with 2 SATA data cables, and a custom designed power supply cable as shown below. However, the company also notes that ROCKPro64 […]

Popcorn Hour Transformer Media Computer / NAS Launched for $95.90 and Up

Last month, we wrote about Cloud Media’s Popcorn Hour Transformer, a platform based on Rockchip RK3328 processor that could be used a 2.5″ drive NAS, and/or a 4K HDR TV box, and looked like an interested alternative  to ODROID HC1 NAS system. The company has now officially launch the device, and is taking orders for $95.90 or $115.90 for respectively the 2GB RAM/16GB flash, or 4GB/32GB versions. Popcorn Hour Transformer specifications: SoC – Rockchip RK3328 quad core Cortex A53 processor with Mali-450MP GPU System Memory – 2GB or 4GB LPDDR3 Storage micro SD slot 16 or 32GB eMMC flash (removable and upgradeable) 128 Mbit SPI NOR flash SATA interface via USB 3.0 to SATA bridge chipset for 2.5″ HDD/SSD Network Connectivity – Gigabit Ethernet Video Output – HDMI 2.0a up to 4K 60Hz with HDR (HDR10/HLG) support Audio Output – Via HDMI, and 3.5mm audio jack (analog stereo or optical […]

More Low Cost ARM Linux NAS Platforms Coming Soon: Popcorn Hour Transformer (XL), ODROID-HC2

Last summer, Hardkernel launched ODROID-HC1 Home Cloud 1 taking a single 2.5″ hard drive, and based on a modified version of their popular Exynos 5422 powered ODROID-XU4 board where they removed HDMI, and added a SATA interface (via USB 3.0), but based on the initial announcement, we also knew the Korean company was working on ODROID-HC2 supporting 3.5″ drives instead. The device is not available yet, but guys at Armbian got an early unit, so we should not be waiting too long. Hardkernel will also have some competition for their ODROID-HC1 NAS, as Cloud Media (and Pine64?) are working on Rockchip RK3328 based Popcorn Hour Transformer & Transformer XL with support for 2.5″ and 3.5″ drives respectively. Hardkernel ODROID-HC2 ODROID-HC2 preliminary specifications: SoC – Samsung Exynos 5422 octa-core processor with 4x ARM Cortex-A15 @ 2.0 GHz, 4x ARM Cortex-A7 @ 1.4GHz, and Mali-T628 MP6 GPU supporting OpenGL ES 3.0 / […]

Giveaway Week – NanoPi NEO NAS Kit with NEO 2 Board

Time has come to organize another giveaway week. I used to mainly give away TV boxes, but due to recent regulations that will not be possible anymore, and instead this giveaway week will include Linux and IoT development boards, and other accessories. I’ll start with NanoPi NEO NAS Kit v1.2. NanoPi NEO NAS Kit v1.2 is a low cost kit NanoPi NEO or NEO 2 board that takes a 2.5″ hard drive. I’ve tested it with NanoPi NEO 2 board and OpenMediaVault, and found to perform optimally for this type of device (USB 2.0 to SATA), with SAMBA reads & writes achieving 40 MB/s. The hardware given away includes the NAS Kit v1.2 and a NanoPi NEO 2 board. You’ll just need to add a micro SD card with the OMV image, a hard drive, and a 12V/2A (or greater) power supply. To enter the draw simply leave a comment […]

GNUBee Personal Cloud 2 is a DIY NAS Supporting up to Six 3.5″ SATA Drives (Crowdfunding)

GNUBee Personal Cloud 1 is a DIY NAS powered by Mediatek MT7621A MIPS processor that supports up to 2.5″ SATA drives, and runs free and open source software. It was first introduced in March of this year through a CrowdSupply campaign. The developers are now back with GNUBee Personal Cloud 2 (GB-PC2) with pretty much the same features, but instead of being designed for 2.5″ drives, it supports up to six 3.5″ drive that should offer either more capacity, or a lower total price for an equivalent capacity. GB-PC2 NAS specifications: Processor – MediaTek MT7621A dual core, quad thread MIPS processor @ 880 MHz, overclockable to 1.2 GHz System Memory – 512 MB DDR3 (max supported by MT7621) Storage – SD card slot tested up to 64 GB, 6x 3.5” SATA HDD or SSD (recommended RAID 0 or 1 under LVM, MD, or Linux MD RAID 10) Connectivity – 3x […]

Hardkernel ODROID-HC1 Home Cloud One Stackable NAS is now available for $49

Hardkernel has just launched their ODROID-HC1 stackable NAS system based on a cost-down version of ODROID-XU4 board powered by Samsung Exynos 5422 octa-core Cortex-A15/A7 processor, which as previously expect, you can purchase for $49 on Hardkernel website, or distributors like Ameridroid. We now have the complete specifications for ODROID-HC1 (Home Cloud One) platform: SoC – Samsung Exynos 5422 octa-core processor with 4x ARM Cortex-A15 @ 2.0 GHz, 4x ARM Cortex-A7 @ 1.4GHz, and Mali-T628 MP6 GPU supporting OpenGL ES 3.0 / 2.0 / 1.1 and OpenCL 1.1 Full profile System Memory – 2GB LPDDR3 RAM PoP @ 750 MHz Storage UHS-1 micro SD slot up to 128GB SATA interface via JMicron JMS578 USB 3.0 to SATA bridge chipset capable of achieving ~300 MB/s transfer rates The case supports 2.5″ drives between 7mm and 15mm thick Network Connectivity – 10/100/1000Mbps Ethernet (via USB 3.0) USB – 1x USB 2.0 port Debugging […]

$25 NanoPi NEO Plus2 Board Adds 8GB Flash, WiFi & Bluetooth, More RAM, and an extra USB Port

NanoPi NEO 2 board has just got an update with NEO Plus2 board featuring the same Allwinner H5 processor and Gigabit Ethernet connectivity, but FriendlyELEC updated the RAM from 512MB to 1GB, added an 8GB eMMC flash, a WiFi & Bluetooth module, and an extra USB port. NanoPi NEO Plus2 specifications: SoC – Allwinner H5 quad core Cortex A53 processor with an ARM Mali-450MP GPU System Memory – 1 GB DDR3 Storage – 8GB eMMC flash (Samsung KLM8G1WEPD-B031) +  micro SD card slot Connectivity – Gigabit Ethernet (via RTL8211E-VB-CG chip), 802.11 b/g/n WiFi and Bluetooth 4.0 (via Ampak AP6212A wireless module) USB – 2x USB 2.0 host ports, 1x micro USB port (for power only), 2x USB via headers Expansion headers 24-pin header with I2C, 2x UART, SPI, and GPIOs 12-pin header with 2x USB, IR pin, I2S, and GPIOs 5-pin audio 2.0mm pitch header with microphone and LINE out […]
