November 10, 2025November 10, 2025 by Debashis Das - 2 Comments

Raspberry Pi CM5 industrial carrier board features dual Ethernet, optional 4G LTE/5G cellular connectivity, metal case, and more

Waveshare CM5-DUAL-ETH-4G/5G-BASE is an industrial carrier board for the Raspberry Pi CM5. It features dual Ethernet (GbE + 2.5GbE), 4G/5G options, and includes an optional metal enclosure, active cooling fan, and power supply, which is an upgrade from the previous CM5-DUAL-ETH-BASE carrier board. The board also offers two HDMI outputs supporting 4K displays, two MIPI DSI/CSI connectors for displays and/or cameras, two USB 3.2 ports, a 40-pin GPIO header, M.2 slots for both NVMe SSDs and 4G/5G modules, and PoE support via an add-on module. The board supports 7V–36V DC input, a PWM fan header, and RTC battery backup, with precise cutouts and labeled connectors for easy integration. Its main benefits over the CM5-DUAL-ETH-BASE are its more compact size and neatly arranged ports on the rear panels, while adding optional support for 4G LTE or 5G connectivity. CM5-DUAL-ETH-4G/5G-BASE specifications: Compatibility – Raspberry Pi Compute Module 5 (CM5) Storage Optional NVMe SSD […]

September 16, 2025September 15, 2025 by Debashis Das - 1 Comment

ESP32-S3 wide touch display development board features a 640×172 touch LCD, AI voice support

ESP32 S3 3.49inch Touch LCD Development Board

Waveshare has recently introduced ESP32-S3-Touch-LCD-3.49, an ESP32-S3-based wide touch display (640×172) development board for HMI and AI voice applications such as handhelds, smart panels, meters, kiosks, and small IoT dashboards. The device comes in two variants, where Case A supports a single 18650 lithium battery and Case B is designed for a 3.7V Li-Po battery. Both models integrate Wi-Fi and Bluetooth connectivity, dual microphones with echo cancellation, speaker output, IMU, RTC, microSD card for storage, USB-C for power and programming, and there are also expansion pads for interactive touch, audio, and sensor-based applications. Waveshare ESP32-S3-Touch-LCD-3.49 specifications: Wireless MCU – Espressif Systems ESP32-S3R8 CPU – Dual-core Tensilica LX7 @ up to 240 MHz with vector instructions for AI acceleration. Memory – 512KB RAM, 8MB PSRAM ROM – 384KB Connectivity – 2.4 GHz WiFi 4 and Bluetooth 5.0 LE with support for long-range, up to 2 Mbps data rate, mesh network. Storage […]

August 21, 2025August 22, 2025 by Debashis Das - No Comments

Raspberry Pi CM5 carrier board supports dual Ethernet (1GbE + 2.5GbE) and wide 7V–36V DC input

Waveshare’s CM5-DUAL-ETH-BASE is a carrier board for the Raspberry Pi CM5, featuring dual Ethernet (1GbE + 2.5GbE), two 4K HDMI outputs, two MIPI CSI/DSI interfaces, and more. It supports NVMe SSDs or AI accelerators via an M.2 slot, offers USB 3.2/2.0 ports, a 40-pin GPIO header, and a wide 7V–36V DC input, making it ideal for industrial networking and edge computing applications. In the past, we have seen other carrier boards such as Seeed Studio’s CM5 MINIMA, Waveshare’s CM5-NANO-B, and CM5-PoE-BASE-A, among others. However, this is the only carrier board that features dual Ethernet with a 2.5GbE option and a wide input voltage range. Waveshare CM5-DUAL-ETH-BASE specifications: Compatibility – Compatible with all Raspberry Pi Compute Module 5 variants Storage M.2 M-Key slot (PCIe Gen2/3 x1) for NVMe SSDs or AI modules MicroSD card slot (for CM5 Lite without eMMC) Display and Camera 2x HDMI ports supporting dual 4K display output […]

March 17, 2025March 19, 2025 by Debashis Das - 9 Comments

Waveshare CM5-NANO-B is a compact Raspberry Pi CM5 carrier board with the same dimensions as the Compute Module 5

Waveshare CM5 NANO B Raspberry Pi CM5 carrier bord with CM5

Waveshare has just released the CM5-NANO-B, a compact Raspberry Pi CM5 carrier board, with the same dimensions as the Compute Module 5 and multiple peripheral interfaces making it suitable for industrial automation, IoT, embedded computing, AI development, and other space-constrained applications. Key features include a Gigabit Ethernet RJ45 port, an unpopulated 40-pin Raspberry Pi GPIO header, a USB 3.2 Gen1 Type-A port, dual MIPI 4-lane interfaces, a mini HDMI port supporting 4K output, a USB audio 3.5mm jack, a microSD card slot, and a 16-pin PCIe Gen2/3 x1 connector. Power is supplied via a USB-C port (5V/5A), and additional features include an RTC battery header, a 4-pin PWM fan header, a dual-color LED indicator, and user-configurable buttons. Waveshare CM5-NANO-B specifications: Compatibility – Raspberry Pi Compute Module 5 (CM5) Storage – MicroSD card slot (for Raspberry Pi CM5 Lite) Display Mini HDMI output up to 4K resolution Up to 2x MIPI […]

January 13, 2025 by Debashis Das - 7 Comments

Fully enclosed ESP32-S3 board features 1.8-inch AMOLED, microphone & speaker for AI audio applications

ESP32 S3 1.8inch AMOLED display development board

Waveshare ESP32-S3-Touch-AMOLED-1.8 is an ESP32-S3 development board with an AMOLED display and AI audio support fully housed in a plastic enclosure. The most interesting feature of this devkit is its 1.8-inch AMOLED display with a 100000:1 contrast ratio and a wide 178° viewing angle, plus support for AI speech using its built-in microphone and speaker, and a built-in battery for IoT and AI applications. Other features include a QMI8658 6-axis IMU for motion detection, a PCF85063 RTC for time, and an ES8311 audio codec for high-quality audio. The ESP32-S3 provides Bluetooth and Wi-Fi connectivity and the board also features a USB-C port for power and programming. The AXP2101 power management IC enables battery charging and optimization, while GPIO, I2C, and UART pads allow expansion. Waveshare ESP32-S3-Touch-AMOLED-1.8 specifications Wireless MCU – Espressif Systems ESP32-S3R8 CPU – Dual-core Tensilica LX7 @ up to 240 MHz with vector instructions for AI acceleration. Memory – […]

January 6, 2025January 6, 2025 by Debashis Das - 8 Comments

PiSugar3 is a low-cost Raspberry Pi UPS module with RTC, hardware battery protection, and power management features

PiSugar Kitchen’s PiSugar3 is a compact Raspberry Pi UPS module with integrated power management features that make Raspberry Pi Zero boards portable. This new module is an upgraded version of the PiSugar S and PiSugar S Pro, which we previously wrote about. The PiSugar S features a compact 1,200mAh battery for Raspberry Pi Zero, and the PiSugar S Pro comes with a 5,000mAh battery for Raspberry Pi 3/4. The PiSugar3 adds new features to these models with upgrades including an RTC, and a fully functional UPS functionality with customizable wake-up options. It also includes an anti-mistaken touch switch to avoid accidental shutdowns, a software watchdog, and hardware battery protection to extend battery longevity. The UPS module gets attached to the bottom of the Pi and there are pogo pins on the UPS module that deliver the power while the GPIO pins of the Pi remain free for other tasks, on top […]

December 12, 2024December 13, 2024 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Sfera Labs Strato Pi Max DIN rail industrial controllers now support the Raspberry Pi Compute Module 5

Raspberry Pi Compute Module 5 industrial controllers

The Raspberry Pi Compute Module 5 (CM5) was launched at the end of last month, and we are starting to see companies slowly announce upgraded CM4 designs. Yesterday, we wrote about EDATEC ED-IPC3100 DIN-Rail mountable industrial computers, and today, we’ll cover Sfera Labs’ addition of the Raspberry Pi Compute Module 5 to their Strato Pi Max DIN rail industrial controllers. The controllers still feature a gigabit Ethernet port, a 10/100M Ethernet port, two USB 2.0 ports, a Raspberry Pi RP2040 microcontroller for power management and boot sequence control, and support expansion modules for up to sixteen RS-485 or RS-422 ports, four CAN V2.0B ports, digital and analog I/O, and more. Strato Pi Max specifications (as of December 2024): Base Module Raspberry Pi Compute Module 5 Raspberry Pi Compute Module 4 Zymbit SCM options. Microcontroller – Raspberry RP2040 dual ARM Cortex-M0+ at 133 MHz. Storage – eMMC, microSD (dual for XL), M.2 PCIe […]

August 9, 2024August 9, 2024 by Debashis Das - 1 Comment

DFI RPP051 Pico-ITX SBC features 13th Gen Intel Core embedded SoC from Processor U300E to Intel Core i7-1365UE

DFI RPP051 is a 2.5-inch Pico-ITX SBC built around 13th Gen Intel Core processors ranging from the dual-core Intel Processor U300E to the 10-core Intel Core i7-1365UE. It supports up to 32GB DDR5 SO-DIMM memory and accommodates M.2 NVMe and SATA storage devices. Connectivity options include a 2.5GbE LAN port, DP++ and eDP display interfaces, USB 3.2 Gen 2 and USB 2.0 ports, RS-232/422/485 interfaces, along with I2C and GPIO for expansion. The DFI RPP051 first came to our attention while covering the AAEON PICO-RAP4 which is also an SBC with a Pico-ITX form factor, we have also written about many x86 and Arm Pico-ITX boards including AAEON PICO-MTU4, the AAEON RICO-3568, the GIGAIPC PICO-N97A and many other feel free to check them out if you are looking for compact and powerful SBCs. DFI RPP051 Pico-ITX SBC Specification 13th gen Raptor Lake SoC (one or the other) Intel Core i7-1365UE 10C/12T […]
