NXP i.MX 94 octa-core Cortex-A55/M33/M7 processor targets Edge AI industrial and automotive applications

NXP i.MX 94

NXP i.MX 94 is an octa-core Arm SoC with up to four Cortex-A55 application cores, two Arm Cortex-M33 real-time/functional safety cores, two Arm Cortex-M7 real-time/functional safety cores, and an NXP eIQ Neutron NPU designed for Edge AI industrial and automotive applications I initially thought it would be a cost-down version of the NXP i.MX 95, and while it shares many of the same features, it’s more an application-specific processor designed specifically for industrial and automotive applications, lacking a 3D GPU, camera input interfaces, a MIPI DSI display interface, and 10GbE networking, but increasing the number of real-time cores (at the cost of application cores) and adding several networking features such as an Ethernet time-sensitive networking (TSN) switch, 2.5GbE interface, an Ethercat controller, and support for industrial protocols like Profinet or OPC-UA FX. NXP i.MX 94 specifications: CPU Up to 4x Arm Cortex-A55 cores 2x Arm Corex-M7 cores, one for functional […]

Qualcomm introduces IQ9, IQ8, and IQ6 industrial IoT SoC families with up to 100 TOPS of AI performance

Qualcomm IQ9 IQ8 IQ6 industrial IoT processors

Qualcomm Technologies has introduced the new industrial-grade IQ chipset family with the IQ9, IQ8, and IQ6 series offering on-device AI performance of up to 100 TOPS, industrial temperature range, and built-in safety features such as SIL-3 (safety and integrity level). Qualcomm IQ series of chipsets target a range of premium (IQ9), mid-tier (IQ8), and entry-level (IQ6) applications such as industrial and agricultural robots, drones, industrial inspection and automation, edge AI boxes with computer vision capabilities, edge gateway analytics solutions, and more. Qualcomm IQ9 Series – IQ-9100, IQ-9075 Key features and specifications: CPU IQ-9075 – Octa-core Kryo Gen 6 scaling from 1.632 to 2.55 GHz IQ-9100 – Octa-core Kryo Gold Prime @ 2.36 GHz (CNXSoft: The specs are not clear for the CPU part…, both SKUs could be the same for the CPU part) GPU – Adreno 663 GPU Audio DSP (LPASS) 1980 MPPS, 7x TDM/I2S 3x High-Speed I2S for Radio […]

Toshiba TCKE9 reusable e-fuse features a fixed over-voltage clamp with adjustable overcurrent limit

Toshiba TCKE9 eFuse Series

Toshiba has recently introduced the Toshiba TCKE9 reusable e-fuse (electronic fuse) series, a new lineup of e-fuse ICs that can be used repeatedly, to protect power supply lines from various electrical faults like overcurrent, overvoltage, overtemperature, and short circuits. These new chips integrate various protection features into a single chip which simplifies circuit design and reduces component count compared to how a traditional protection circuit with multiple components is designed. This new line of products offers different ICs with different voltage ratings and adjustable current settings, alongside two reset modes auto-retry and latching. All these features make this e-fuse useful for applications like laptops, wearables, audio/video equipment, and industrial applications like automation systems, robotics, and many other applications. Toshiba TCKE9 reusable e-fuse Specification Input Voltage – 2.7V to 23V (Maximum – 25V) Output Current – 0 to 4.0A (Adjustable overcurrent limit – 0.5A to 4.0A via external resistor) ON Resistance […]

Twotrees SK1 3D printer review – Part 2: Enclosure kit and AI camera

Twotrees SK1 Enclosure Kit AI camera review

We reviewed the Twotrees SK1 CoreXY 3D printer capable of delivering high printing speeds last March, but here’s a second part of the review as the company sent us additional accessories namely the enclosure kit For SK1 and the AI camera for SK1 which we will report on today. The main structure of the enclosure is made of metal sheets plus a door that opens from the front and a top plate made of tempered glass. The SK1 3D printer enclosure makes the 3D printer more beautiful, protects it from dust, is easy to install, and features a fan and air filter system. It’s also designed to mount the AI Camera for SK1 to help users monitor the SK1 while printing is in progress. TwoTrees Enclosure Case Kit For SK1 The interior of the Twotrees SK1 3D printer enclosure is mostly made of metal and includes a tempered glass door […]

TOOCAA L2 Review – A fully enclosed 20W laser engraver & cutter with a focus on safety

TOOCAA L2 review 20W laser engraver cutter

TOOCAA L2 is a fully enclosed laser engraver and cutter with a 10W or 20W laser module using orange acrylic covers and various sensors for additional safety. The laser module complies with Class 1 Laser Safety certification and the engraving and cutting machine works with a range of materials suitable for creators who want to cut or/and carve workpieces or manufacture high-resolution parts. The company sent us a sample of the TOOCAA L2 with a 20W laser model, an air assist pump, a honeycomb plate, and a few consumables for review. We’ll first go through an unboxing of all items and assembly, before testing the laser engraver and cutter under various scenarios. TOOCAA L2 unboxing The review kit we received includes three packages from TOOCAA. Each package contains various components. with foam drilled into shape to support each part and right-angled cardboard along all four corners of the package to […]

Semtech AirLink XR60 is the world’s smallest rugged 5G router

Airlink XR60 world smallest rugged 5G router

Semtech AirLink XR60 is a tiny 5G router powered by a quad-core Cortex-A53 processor with up to two Ethernet ports (1Gbps and 5 Gbps), WiFi 6 connectivity, GNSS navigation, and an optional RJ45 serial port. Semtech is better known for its LoRa low-power transceivers, but the company acquired Sierra Wireless last year, so they’ll now have a wider range of wireless products to offer, and the AirLink XR60 5G gateway is the first we cover here on CNX Software since the merger between the two companies. Semtech Airlink XR60 specifications: SoC – Quad-core Arm Cortex-A53 processor Memory – 1.2 GB RAM (that should be the free memory) Storage –  1.7 GB (available storage) Networking 5G cellular Sierra Wireless EM9291 5G NR Sub-6 M.2 module Peak downlink – 2800 Mbps Peak uplink – 300 Mbps 4×4 MIMO 4x SMA antenna connectors Dual SIM (Nano-4FF) Carrier – AT&T, FirstNet 4G, T-Mobile, Verizon, […]

Luxonis OAK Thermal – A PoE thermal camera with Myriad X AI accelerator, waterproof M12 and M8 connectors

Luxonis OAK Thermal camera

Luxonis has announced its first thermal camera with the OAK Thermal (OAK-T) based on the company’s OAK-SoM Pro AI module featuring an Intel Movidius Myriad X, and two waterproof ports with an M12 PoE/Ethernet connector and an M8 auxiliary connector. Luxonis has been making AI cameras based on Myriad X AI accelerator and its Depth AI solution at least since 2019, and its module is also found in third-party cameras as we’ve recently found out with the Arducam PiNSIGHT AI camera. But they had never made a thermal model, and following customers’ requests to fuse thermal and RGB data, they’ve now developed the OAK Thermal, or OAK-T for shorts, that is suitable for detecting leaks and fires or more accurately detect humans & animals than traditional vision-only based cameras. OAK Thermal camera specifications: System-on-Module – Luxonis OAK-SoM Pro with AI accelerator – Intel Movidius Myriad X AI vision processing unit […]

Microsoft open-sources Eclipse ThreadX real-time operating system

Eclipse ThreadX components

Microsoft will soon open-source Eclipse ThreadX real-time operating system that has been deployed on more than 12 billion embedded devices worldwide since its first release in 1997 and, for instance, it is found in Broadcom processors powering Raspberry Pi SBCs. ThreadX was a commercial, safety-certified real-time operating system developed Express Logic which was acquired by Microsoft in 2019 and renamed to Azure RTOS. Last year, Microsoft decided to start the process to fully open-source Azure RTOS under an MIT license and managed by the Eclipse Foundation. Hence its new name: “Eclipse ThreadX“. The Eclipse ThreadX project is not simply comprised of the RTOS itself, but also includes other components: ThreadX – Real-time operating system (RTOS) designed for deeply embedded applications NetX Duo – Industrial-grade TCP/IP network stack designed for deeply embedded real-time and IoT applications FileX – FAT-compatible file system integrated with ThreadX kernel GUIX – Embedded graphical user interface […]
