July 18, 2024July 18, 2024 by Jean-Luc Aufranc (CNXSoft) - 6 Comments

MW-100-NAS Intel N100 motherboard features six SATA ports, two M.2 PCIe sockets, 2.5GbE and 10GbE interfaces

The MW-100-NAS mini-ITX motherboard is powered by an Intel Processor N100 Alder Lake-N CPU and seems especially suited for NAS (networked-attached storage) applications with six SATA connectors, two M.2 Key-M sockets for NVMe drivers, one 10GbE port, and two 2.5GbE RJ45 jacks. The motherboard supports up to 32GB DDR5 memory, features HDMI and DisplayPort video output ports, a COM port header, and plenty of external and internal USB interfaces. It takes power from a standard ATX connector. NW-N100-NAS motherboard specifications: SoC – Intel Processor N100 quad-core Alder Lake-N processor @ up to 3.4 GHz (Turbo) with 6MB cache, 24EU Intel HD graphics @ up to 750 MHz; TDP: 6W System Memory – Up to 32GB DDR5-4800 via SO-DIMM socket Storage 2x M.2 sockets for NVMe SSDs onboard 6x SATA connectors MicroSD card slot Video Output – 1x HDMI, 1x DisplayPort Networking 2x 2.5GbE RJ45 ports via Intel i226-V controllers 1x […]

July 9, 2024July 9, 2024 by Jean-Luc Aufranc (CNXSoft) - 16 Comments

QNAP unveils TS-432X and TS-632X Arm-based NAS with 10GbE networking, up to six SATA bays

QNAP has unveiled TS-432X 4-bay and TS-632X 6-bay Tower NAS systems that feature not only 2.5GbE ports but also one or two 10GbE SFP+ cages, as well as one PCIe Gen 3 x4 slot and are powered by an Annapurna Labs Alpine AL524 4-core 64-bit Arm processor. We had seen NAS with 10GbE networking before such as the QNAP HS-453DX and ASUSTOR FLASHSTOR, but those were powered by Intel processors. The new TS-432X and TS-632X NAS systems combine a 64-bit Arm processor and 10GbE networking in a way similar to the earlier QNAP TS-431X-2G-USARM powered by a dual-core 32-bit Arm CPU. QNAP TS-432X/TS-632X specifications: SoC – Annapurna Labs Alpine AL524 4-core 64-bit Arm processor @ up to 2.0 GHz System Memory – 4GB DDR4 (non-ECC), upgradeable up to 16GB DDR4 (ECC memory supported) via SO-DIMM socket Storage 512 MB flash with dual boot OS protection Drive bays TS-432X – […]

June 8, 2024June 8, 2024 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

UP Xtreme i14 SBC offers Intel Core Ultra 5/7 Meteor Lake SoC, up to 64GB LPDDR5 for robotics and AIoT applications

AAEON has launched the UP Xtreme i14 SBC based on a choice of Intel Core Ultra 5/7 Meteor Lake SoCs, up to 64GB LPDDR5, M.2 PCIe sockets and a SATA port for storage, 2.5GbE and GbE interfaces, four 8K capable video output ports (HDMI, DP, and USB-C), a MIPI CSI camera interface, and more. The 14th Intel Core Ultra 5/7 SoC features up to 16 cores, Intel Arc graphics, and an Intel AI Boost NPU that deliver up to 32 TOPS combined and make the UP Xtreme i14 board especially suitable for applications such as Autonomous Mobile Robots (AMR), Smart Retail, and AI-assisted healthcare imaging. UP Xtreme i14 specifications: Meteor Lake-H/U SoC (one of the other) Intel Core Ultra 7 165H 16-core (6P+8E+2LPE) processor @ 1.4 / 5.0 GHz with 24MB cache, Intel 8Xe LPG graphics @ 2.3 GHz, Intel AI Boost NPU; TDP: 28W Intel Core Ultra 7 155H […]

June 7, 2024June 7, 2024 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

Orange Pi 3B V2.1 SBC has been revamped with better WiFi 5 connectivity, M.2 2280 NVMe/SATA SSD socket

Shenzhen Xunlong Software has introduced the Orange Pi 3B V2.1 SBC with an M.2 socket that supports 2280 NVMe or SATA SSDs, and a new Ampak AP6256 WiFi 5 and Bluetooth 5 wireless module replacing the Allwinner AW859A-based CDTech 20U5622 module in the first revision of the board. The Orange Pi 3B SBC was first introduced in August 2023 as a Rockchip RK3566 SBC with Raspberry Pi 3B form factor and support for M.2 2230 and 2242 NVMe or SATA storage. The new Orange Pi 3B V2.1 supports longer M.2 2280 SSDs at the cost of being slightly bigger than a credit card (89×56 mm) and offers better WiFi 5 connectivity. Orange Pi 3B V2.1 specifications: SoC – Rockchip RK3566 CPU – Quad-core Cortex-A55 processor @ up to 1.8 GHz GPU – Arm Mali-G52 2EE GPU with support for OpenGL ES 1.1/2.0/3.2, OpenCL 2.0, Vulkan 1.1 NPU – 0.8 TOPS […]

May 26, 2024May 26, 2024 by Jean-Luc Aufranc (CNXSoft) - 16 Comments

ODROID-H4 Plus review – Part 2: Intel N97 NAS Kit and fanless SBC tested in Ubuntu 24.04

In the first part of the ODROID-H4+ kit review, I checked out the hardware and showed how to install the Intel N97 SBC into the H4 Type 3 case taking up to four 2.5-inch SATA drives. I’ve now had time to test the ODROID-H4 Plus with Ubuntu 24.04 both as an actively cooled NAS kit and a fanless SBC and will report benchmark results, 2.5GbE and storage test results, 4K and 8K YouTube video playback capability, check IBECC memory support, measure power consumption, and more in the second part of the review. Ubuntu 24.04 installation on ODROID-H4 Plus The ODROID-H4 Plus SBC does not come with any preinstalled OS since there’s no storage by default, so I installed Ubuntu 24.04 on the 128GB M.2 NVMe SSD I inserted into the board. The installation went relatively smoothly, but in hindsight, I would have probably installed the OS before installing the SBC […]

May 11, 2024May 26, 2024 by Jean-Luc Aufranc (CNXSoft) - 12 Comments

ODROID-H4+ kit review – Part 1: Unboxing, H4 Type 3 case assembly, and first boot

I’ve just received a kit comprised of an ODROID-H4+ SBC along with a Type 3 enclosure taking up to four 2.5-inch SATA drives and related accessories for review. I’ll start with an unboxing, followed by an assembly guide, and a quick first boot in the first part of the review, before testing performance, features such as IBECC memory, power consumption, and more in the second part of the review. ODROID-H4+ kit unboxing The package I received included small packages for the “H4 Type 3” enclosure and the ODROID-H4 PLUS SBC, a 15V/4A (60W) power supply with US plug adapter, a large fan with screws, as well as four sets of SATA data and power cables. We’ve already provided the ODROID-H4, H4+, and H4 Ultra specifications in the announcement post, but let’s have another quick look at the Intel Processor N97 fanless SBC. The rear panel comes with a DC jack, […]

May 6, 2024May 5, 2024 by Debashis Das - No Comments

Nano-ITX motherboard is powered by Intel Atom x7000RE Series “Amston Lake” SoC

NANO 6064 ASL An Intel Atom x7000RE Series SoC based NANO ITX Board with Triple Display, 2.5GbE LAN, USB 3.2 Gen2, M.2, SATA III

Portwell NANO-6064-ASL is an Intel Atom “Amston Lake” x7000RE-powered Nano-ITX motherboard. The board looks very similar to the Portwell Nano-6062 and features an operating temperature of -40°C to 85°C. The motherboard can support a max of 16GB DDR4 memory and features triple display output, dual 2.5Gbps Ethernet, USB, M.2, SATA, GPIO, and more, and takes power from a 12V external power input. Previously, we’ve written about a range of Nano-ITX boards and SoMs with Amston Lake SoCs, including the ASRock SBC-262M-WT, conga-SA8 SMARC modules, ADLINK Atom x7000RE & x7000C COM Express and SMARC 2.1 modules and others. If you’re looking for similar options, feel free to check out those articles. Portwell NANO-6064-ASL Specifications SoC (one or the other) Amstom Lake Intel Atom x7211RE dual-core processor with 6MB cache, 16EU Intel UHD graphics; 6W TDP Intel Atom x7213RE dual-core processor with 6MB cache, 16EU Intel UHD graphics; 9W TDP Intel Atom x7433RE […]

April 29, 2024April 29, 2024 by Jean-Luc Aufranc (CNXSoft) - No Comments

QNAP TS-216G 2-bay NAS features a quad-core Arm processor with NPU for image sorting and searching

QNAP TS-216G 2-bay NAS features a quad-core Arm Cortex-A55 processor with an NPU for AI-powered photo management, 4GB RAM, 2.5GbE and GbE networking ports, two hot-swappable 3.5-inch SATA bay, and a few USB ports. It looks to be an update to the Rockchip RK3566-powered QNAP TS-133/TS-223 with more memory (4GB vs 2GB) and more advanced networking capability (2.5GbE+GbE vs GbE only), while still keeping the object and face recognition capabilities. QNAP TS-216G specifications: SoC – Unnamed but likely Rockchip RK3566 CPU – Quad-core Cortex-A55 clocked at up to 2.0 GHz GPU – Mali-G52 Neural Processing Unit (NPU) Hardware-accelerated Transcoding Encryption Engine System Memory – 4 GB RAM Storage 4 GB eMMC flash (dual boot OS protection) 2x 3.5-inch SATA III bay also supporting 2.5-inch SATA SSDs; hot-swappable Networking 2.5GbE RJ45 jack Gigabit Ethernet jack Wake-on-LAN (WoL) and Jumbo Frame support Number of Concurrent Connections (CIFS) – Up to 200 USB […]
