semtech

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on Semtech launches AirLink RX400 and EX400 5G RedCap routers for IoT applications

Semtech launches AirLink RX400 and EX400 5G RedCap routers for IoT applications

AirLink RX400 EX400 5G RedCap routers

Semtech has just launched the AirLink RX400 and EX400 5G RedCap routers for industrial and commercial IoT applications. They offer a lower power consumption and lower costs compared to traditional 5G deployment. The routers are powered by an unnamed Arm Cortex-A55 processor, feature up to two Gigabit Ethernet ports, 5G RedCap cellular connectivity (3GPP Release 17 and 5G Standalone) with LTE Cat 4 fallback, dual-band GNSS, optional WiFi 6 connectivity, and optional RS-232 interfaces, among other features. AirLink RX400/RX400 specifications: SoC – Unnamed dual-core Arm Cortex-A55 processor System Memory – 600 MB RAM available to containers Storage – 500 MB flash available to containers Networking AirLink EX400 – 2x Gigabit Ethernet ports AirLink RX400 – Gigabit Ethernet port 5G RedCap (Reduced Capability) cellular connectivity up to 226 Mbps downlink, 120 Mbps uplink, dual SIM (Nano-4FF); 4G LTE fallback Optional dual-band Wi-Fi 6 1×1 MIMO up to 600 Mbps Serial (AirLink RX400 […]

Posted on by Jean-Luc Aufranc (CNXSoft) - No Comments on WisMesh Tag – A thin, IP66-rated Meshtastic GPS tracker for outdoor use

WisMesh Tag – A thin, IP66-rated Meshtastic GPS tracker for outdoor use

WisMesh Tag Meshtastic GPS Tracker

RAKwireless WisMesh Tag is a thin and rugged Meshtastic GPS LoRa tracker designed for off-grid location tracking and messaging. The 7.5mm thick device is pre-flashed with Meshtastic, dust and waterproof (IP66-rated), and powered by a 1,000mAh battery. Internally, it is built around a Nordic Semi nRF52840 wireless SoC and a Semtech SX1262 LoRa transceiver. Contrary to most DIY trackers, the device is fully certified (FCC and CE), so users across Europe and North America can deploy it for personal or professional use. WisMesh Tag specifications: SoC –  Nordic Semiconductor nRF52840 CPU – 32-bit Arm Cortex-M4F microcontroller @ 64 MHz Memory – 256 KB RAM Storage – 1 MB flash Wireless – Bluetooth 5, Thread, ANT, Bluetooth Mesh, 802.15.4 (Zigbee), 2.4 GHz proprietary LoRa – Semtech SX1262 RF transceiver GNSS – AT6558R GNSS module Misc Built-in LoRa, BLE, and GPS antennas Reset/Bootloader button User Button for alarms, alerts, or future customization […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on Semtech LR2021 “LoRa Plus” transceiver supports LoRa Gen 4, Amazon Sidewalk, Meshtastic, wM-BUS, Wi-SUN FSK, and Z-Wave

Semtech LR2021 “LoRa Plus” transceiver supports LoRa Gen 4, Amazon Sidewalk, Meshtastic, wM-BUS, Wi-SUN FSK, and Z-Wave

Semtech LR2021

Semtech LR2021, the first chip in the LoRa Plus family, supports LoRa Gen 4 technology with both terrestrial and satellite networks in the Sub-GHz, 2.4 GHz ISM bands, and licensed S-band, while keeping backward compatibility with previous-generation LoRa devices. But it goes beyond just supporting LoRa and LoRaWAN networks, since it features expanded physical layer modulations for fast long-range communication (FLRC) enabling compatibility with various low-power wireless protocols such as Amazon Sidewalk, Meshtastic, Wireless M-Bus (Wm-BUS), Wi-SUN FSK, and Z-Wave when integrated with third-party stacks. Semtech LR2021 key features and specifications: Terrestrial and non-terrestrial network (NTN), Sub-GHz, 2.4GHz ISM and licensed S-band radio. Frequency Ranges 150-960 MHz 1600-2500 MHz Multi-PHY compatibility enables low-power wireless protocols with third-party stacks. FLRC up to 2.6 Mbps, LoRa up to 200 kbps Modulation – FSK, LoRa, LR-FHSS, FLRC, O-QPSK, OOK Multi-region operation with single switch-less front-end design. +22 dBm to -10 dBm transmitter Rx […]

Posted on by Debashis Das - No Comments on Altair ALT1350 based HL7900 5G LPWA module supports Wi-SUN, GNSS, and NB-IoT over non-terrestrial networks

Altair ALT1350 based HL7900 5G LPWA module supports Wi-SUN, GNSS, and NB-IoT over non-terrestrial networks

Sierra Wireless HL7900 5G LPWA module

The HL7900 5G LPWA module from Semtech (Sierra Wireless) is a globally certified solution built around Sony’s Altair ALT1350 chip and designed for low-power IoT applications. It is certified by major U.S. carriers, including AT&T, T-Mobile, and Verizon, as well as Japan’s KDDI, and has achieved global regulatory certifications (FCC, CE, ISED, etc.) and industry certifications (PTCRB, GCF) for carrier interoperability. This chip features an ultra-low-power sensor hub MCU for efficient environmental monitoring. Additionally, it includes integrated sub-GHz and 2.4GHz radios supporting short-range protocols such as Wi-SUN including U-Bus Air, NB-IoT, and 5G NTN along with GNSS and Wi-Fi-based indoor/outdoor tracking. Furthermore, this chip supports embedded SIM support, secure edge-to-cloud connectivity, and over-the-air updates. These features make this chip useful for applications such as asset tracking, urban navigation, and other IoT solutions requiring reliable, low-power connectivity with global reach. Semtech HL7900 specifications: MCU – Sony ALT1350 5G cellular IoT chip […]

Posted on by Sayantan Nandy - 3 Comments on T1000-E Card Tracker is a thin, credit card-sized GPS tracker with Meshtastic support

T1000-E Card Tracker is a thin, credit card-sized GPS tracker with Meshtastic support

SenseCAP Card Tracker T1000 E

Seeed Studio has introduced the T1000-E, an updated version of the SenseCAP T1000 Card Tracker, built for Meshtastic. This rugged tracker is compact, about the size of a credit card, making it easy to carry or attach to assets. It uses Semtech LR1110 RF transceiver, Nordic Semi nRF52840 wireless SoC, and MediaTek/Aihora AG3335 GPS module for precise, low-power tracking and communication. With an IP65 rating for dust and water resistance, the T1000-E is ideal for reliable asset tracking. The T1000-E supports LoRa and Bluetooth v5.1 for communication and includes a 3-axis accelerometer, an LED, a buzzer, and a button for operation. It has internal antennas for GNSS, LoRa, Wi-Fi, and BLE communication range of 2 to 5 km, depending on the environment. SenseCAP Card Tracker T1000-E specifications: SoC – Nordic Semiconductor nRF52840 CPU – 32-bit Cortex-M4 core with FPU running at 64 MHz Flash – 1 MB RAM – 256 kB […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 6 Comments on Semtech AirLink XR60 is the world’s smallest rugged 5G router

Semtech AirLink XR60 is the world’s smallest rugged 5G router

Airlink XR60 world smallest rugged 5G router

Semtech AirLink XR60 is a tiny 5G router powered by a quad-core Cortex-A53 processor with up to two Ethernet ports (1Gbps and 5 Gbps), WiFi 6 connectivity, GNSS navigation, and an optional RJ45 serial port. Semtech is better known for its LoRa low-power transceivers, but the company acquired Sierra Wireless last year, so they’ll now have a wider range of wireless products to offer, and the AirLink XR60 5G gateway is the first we cover here on CNX Software since the merger between the two companies. Semtech Airlink XR60 specifications: SoC – Quad-core Arm Cortex-A53 processor Memory – 1.2 GB RAM (that should be the free memory) Storage –  1.7 GB (available storage) Networking 5G cellular Sierra Wireless EM9291 5G NR Sub-6 M.2 module Peak downlink – 2800 Mbps Peak uplink – 300 Mbps 4×4 MIMO 4x SMA antenna connectors Dual SIM (Nano-4FF) Carrier – AT&T, FirstNet 4G, T-Mobile, Verizon, […]

Posted on by Jean-Luc Aufranc (CNXSoft) - 1 Comment on Semtech LR1120 enables global asset tracking with multi-band LoRa, WiFi, and GNSS

Semtech LR1120 enables global asset tracking with multi-band LoRa, WiFi, and GNSS

Semtech LR1120

Semtech LoRa Edge LR1120 is an ultra-low-power multi-band chip designed for global geolocation and asset tracking applications including direct satellite-connected Internet of Things (IoT) applications in supply chain management and logistics. Not only does the LR1120 features the usual sub-GHz LoRa radio found in most other chips from the company, but also comes with 2.4GHz LoRa and SATCOM S-Band support for satellite, as well as a GNNS radio compatible with GPS and Beidou, and a WiFi radio for indoor positioning (but no WiFi RTT/802.11mc support). Semtech LR1120 key features and specifications: Low-power high-sensitivity LoRa/(G)FSK half-duplex RF transceiver Worldwide ISM frequency bands support in the range 150 – 960MHz (Sub-GHz) and 2.4GHz, as well as 1.9-2.1GHz (S-Band) Low Noise Figure RX front-end High power PA path +22dBm in the Sub-GHz band Up to +11.5dBm in the 2.4GHz band LR-FHSS modulator Integrated PA regulator supply selector to simplify dual power +15/+22dBm with […]

Posted on by Ayo Ayibiowu - 6 Comments on Semtech LoRa Edge Uses LR1110 Single Chip with LoRa, WiFi, and GNSS

Semtech LoRa Edge Uses LR1110 Single Chip with LoRa, WiFi, and GNSS

LoRa Edge

Semtech, a leader in LoRa and RF technology, is continuing its support for the LoRa ecosystem with the launch of a new portfolio of solutions called LoRa Edge to simplify and accelerate IoT applications for the Edge. LoRa Edge is a new highly versatile and low power software-defined LoRa-based platform that will enable a wide portfolio of applications for indoor and outdoor asset management, targeting industrial, building, home, agriculture, transportation, and logistics markets. The LoRa Edge platform is launching with a geolocation solution targeted to IoT applications for asset management. It features an ultra-low power LoRa transceiver, GNSS sniffing capabilities, Wi-Fi scanning technologies all in one single package called Semtech LR1110. “Semtech continually delivers Internet of Things (IoT) solutions that simplify and accelerate the development of LPWAN applications,” said Pedro Pachuca, Director of IoT Wireless in Semtech’s Wireless and Sensing Products Group. “LoRa Edge and LoRa Cloud geolocation services enable customers […]
