LOLIN C3 Mini ESP32-C3 board is compatible with Wemos D1 Mini shields

Lolin C3 Mini

Wemos LOLIN C3 Mini board is powered by Espressif ESP32-C3 WiFi and BLE RISC-V microcontroller and follows the company’s earlier Wemos D1 Mini (ESP8266) and LOLIN S2 Mini (ESP32-S2) form factor for compatibility with the original stackable Wemos D1 shields. The tiny board comes with 4MB flash embedded in the ESP32-C3 chip, a USB Type-C connector, reset and user buttons, as well as sixteen through holes for GPIOs, VBUS, 3.3V, and ground signals. LOLIN C3 Mini V1.0.0 specifications: SoC – Espressif Systems ESP32-C3FH4 single-core 32-bit RISC-V (RV32IMC) microcontroller up to 160 MHz with 400 KB SRAM, 4MB Flash Connectivity – 2.4 GHz WiFi 4 and Bluetooth 5.0 LE (in SoC) Expansion headers – 2x 8-pin headers with up to 12x GPIO, ADC, I2C, SPI, UART (3.3V I/O voltage) USB – 1x Type-C USB for 5V power and programming Misc – Reset button and button 0 also used to enter Device […]

$4 Lolin S2 Mini ESP32-S2 WiFi IoT board works with Wemos D1 Mini shields

If you liked Wemos D1 mini ESP8266 board with stackable add-on boards, you’ll probably love Wemos/Lolin S2 Mini board with the same factor, but fitted with an ESP32-S2 single-core WIFi processor, and offering twice the number of I/Os. The board comes with 4MB flash, 2MB PSRAM, a USB-C port for power and programming, as well as two 16 pin headers for GPIOs, ADC, DAC, and more. Lolin S2 Mini V1.0.0 specifications: SoC – Espressif Systems ESP32-S2FN4R2 Xtensa  single-core 32-bit LX7 microprocessor up to 240 MHz with 320 KB SRAM, 4MB Flash, 2MB PSRAM Expansion headers – 2x 16-pin headers with 27x IO, ADC, DAC, I2C, SPI, UART, USB OTG USB – 1x Type-C USB for 5V power and programming Misc – Reset button and button 0 also used to enter Device Firmware Upgrade (DFU) Dimensions – 34.3 x 25.4 mm Weight – 2.4 grams The board is compatible with Lolin/Wemos […]

$2 Wemos W600-PICO WiFi IoT Board Ships with MicroPython Firmware

Wemos has designed some great WiFi IoT boards over the last few years with products like Wemos D1 mini or Lolin32 based on Espressif Systems ESP8266 and ESP32 processors respectively. But the company has recently launched its cheapest board ever, with W600-PICO board going for just $2.10 + shipping. The board is based on Winner Micro W600 Arm Cortex-M3 WiSoC, and comes pre-loaded with MicroPython firmware. Wemos W600-PICO V1.0.0 specifications: SoC – Winner Micro W600 Arm Cortex-M3 MCU @ 80MHz with 1MB Flash Wireless Connectivity – 2.4GHz 802.11 b/g/n WiFi 4 up to 150 Mbps USB – 1x Micro USB port for power and programming (via CH340 USB to TTL chip) Expansion – 2x 10-pin headers with 15x GPIO, 9x PWM, 1x I2C, 1x SPI, 1x UART, Wake Up, Reset, 5V, 3.3V, and GND signals; 3.3V I/O voltage. Misc – Reset button Power Supply – 5V via micro USB port […]

Build an ESP8266 IR Remote Control with LOLIN IR Controller Shield for D1 Mini Board

Infrared remote control are still widely with TVs, set-top boxes, air conditioners, and all other sort of appliances with the end result of having many remote control around the house. If you want to cut on the number of remote controls, there are several solutions: Get a smartphone with a Built-in IR transmitter like Xiaomi Mi A1. Add an IR transmitter to your smartphones’s headphone jack using ZazaRemote or USB type C port with ROCK USB type C IR transmitter. Get a WiFi IR blaster in order to control devices remotely, or maybe buy several try control any IR devices from anywhere DIY your own solution for more flexibility, for example using ANAVI Infrared pHAT and a Raspberry Pi board. The smartphone solutions (1 & 2) works as long as you are in the room, but the WiFI IR blaster allows you to control devices even if you are not […]

My Attempt at Getting Started with Zephyr Project OS on ESP32

Zephyr Project is a real-time operating systems for the Internet of Things (IoT) that was introduced in early 2016, and supported/hosted by the Linux Foundation. It runs on a fairly large number of MCU boards from different architecture (x86, Arm, RISC-V, etc..), and Linaro even launched 96boards IoT compliant hardware like BLE Carbon board that are designed to run Zephyr Project. More recently, Linaro CEO revealed several commercial products are shipping with Zephyr Project OS, so I thought it might be a good time to give it a try. Target Board – Wemos Lolin32 I only had STM32 Bluepill, and some ESP32 boards, so I went with the latter since it comes with WiFi. But instead of re-using some of my existing boards, I asked Banggood whether they could send Wemos Lolin32, which they did. They sell it for $7.99 shipped, but any other ESP32 board should do. The board […]

3D Rendering and Video Composite Output on ESP32 Boards

A few years ago, we already saw it was possible to transmit color signals over NTSC using an ESP8266 board with the signal received on a TV with an analog tuner. CNLohr had to connect an antenna to the I2S pin of his ESP8266 module, and disable WiFi. But surely we should be able to do the same with ESP32, and potentially even better thanks to the two cores. That’s exactly what Bitluni successfully managed by connecting his LoLin32 board to the composite input of his TV with one handling the TV signal output (in grayscale) and the other core rendering 3D objects in real-time. But any ESP32 board could be use instead. The hardware connection is very easy. We just need two wires, one connected to the GND pin and outer part of the RCA connector, and the other connected to GPIO 25 (DAC1) and the inner part of […]

ESPurna Firmware Now Supports Power Meters “Augmented” with ESP8266 Modules/Boards

Sonoff-Tasmota and ESPurna are the two main open source firmware used in home automation devices, such as Sonoff wireless switches, based on Espressif ESP8266 WiSoC. Xose Pérez – aka Tinkerman – has recently purchased “dumb” power meters / kill-a-watt meters, added WiFi to them with ESP-01 module and Wemos D1 mini board, and implemented support in ESPurna firmware leveraging earlier reverse-engineering work by Karl Hagström. The power meter above looks exactly like the one I’ve been using for review for over two years, and has been more more reliable than other models, such as Broadlink SP2 (with built-in WiFi) that gave up on me after a few months. Xose actually noticed that old and newer models of the power meters were based on different solutions. Karl’s meter relied on ECH1560, while Xose’s new meter was instead based on Vango V9261F, which has a public datasheet, and was already being worked on by […]

Wemos LOLIN32 Lite Board Powered by ESP32 Rev 1 Chip Sells for $4.90

Wemos introduced the first low cost ESP32 board with LOLIN32 board going for $6.90 plus shipping in April, but the company is now back with a new Lite version of the board switching ESP-WROOM-32 module with their own design around ESP32 Rev 1 chip (with various silicon bug fixes), and a lower $4.90 price tag to which you need to add ~$2 for shipping. Wemos LOLIN32 Lite is also smaller, so we’ll lose some of the pins (mostly extra power pins), but the I/Os look the same: SoC – Espressif ESP32-DOWD6Q Rev 1.0 dual core Tensilica Xtensa LX6 processor with WiFi and BLE Connectivity – 802.11 b/g/n WiFi + Bluetooth LE I/Os via 2x 13-pin headers with digital I/Os, analog inputs, UART, I2C, SPI, VP/VN, DAC… 3.3V I/O voltage Breadboard compatible USB – 1x micro USB port for power and programming/debugging Misc – Reset button Power – 5V via micro […]
