Izitron I-SEN1 Environmental Sensors Board Works with XBee Modules

Izitron, a start-up based in the South of France, has designed a board with temperature, pressure, humidity and light sensors and a XBee header to provide a way to monitoring environmental variables for weather monitoring, agriculture, industrial applications, and more. I-SEN1 technical specifications: Sensors Temperature – Microchip MCP9700-E/T0; accuracy: ±4°C Accuracy from 0°C to +70°C | -4°C/+6°C Accuracy from -40°C to +150°C; temperature range: -40 to 125 °C Pressure – Infineon KP236N6165; accuracy: 2%; pressure range: 60 kPa to 165 kPa; temperature range: -40 to 125 °C Humidity – Honeywell HIH-5030-001; accuracy: ±3% RH; range: 0 to 100% RH; temperature range: -40 to 85 °C Light – AMS TSL14S-LF; reponsivity: 16 mV/ (uW/cm2); temperature range: 0 to 70 °C Header for XBee RF module Power Supply 5V via micro USB 5 to 12V via Wago terminal block 2x batteries No power management chip Power on/off button Power consumption – Up […]

Renesas GR-PEACH mbed Board Features RZ/A1H Processor with 10MB On-chip Memory

Renesas RZ/A1 ARM Cortex A9 processors were unveiled in 2013, and one of the differentiating feature was the large amount of on-chip SRAM with up to 10MB for RZ/A1H model. The following year, Renesas’ RZ/A1 professional development kit, and some RZ/A1H modules were launched, and I’ve now just seen a tweet about Renesas GR-PEACH development board that is mbed compatible, feature Renesas RZ/A1H processor, and happens to be pink. There are actually two models based on the same PCB: GR-PEACH normal without header, and a “WiFi” connector, and GR-PEACH Full with female headers and an Ethernet port. Both basically share the same specifications: SoC – Renesas RZ/A1H ARM Cortex-A9 Core @ 400 MHz with 10MB on-chip RAM, NEON and FPU, and 128KB L2 cache Storage – 8MB FLASH + micro SD slot Connectivity – Normal: Optional BP3595 WiFi module; FULL: 1x 10/100M Ethernet(Microchip LAN8710A); Both: Xbee connector (unpopulated) USB – […]

Digi Launches XBee Modules Examples Website To Get Started with IoT Development

Digi International has launches an example section on their website to showcase what can be done with their XBee 805.15.4, ZigBee and WiFi Modules, as well as their IoT gateway. They provide examples to use different type of sensors, control lights, motors, and more. They show demos on the website and explain how each components can be linked together, hooked to computers and connected to the internet. They currently just have a few tutorials only, but plan to add more overtime: Basic XBee 802.15.4 & Zigbee Chat 802.15.4 PWM and Digital Output with an LED 802.15.4 Digital Input with a Button 802.15.4 Analog Input with a Potentiometer Light Switch XBee – A wireless wall switch that can control lamps, fans, motors or your homemade robot The first four examples look good to get started, but the Light Switch XBee is the most interesting, and they describe 8 steps to show […]
