$20 Zigbee & Z-Wave mPCIe module targets Home Assistant gateways

Mixtile Zigbee Z Wave mini PCIe module

Mixtile’s “2-in-1 Zigbee & Z-Wave mPCIe module” is a relatively inexpensive way to add Zigbee and Z-Wave connectivity to a Home Assistant server without having USB dongles sticking out of the server and taking some of its spare USB ports. The module is compatible with any computer, gateway, or SBC with a spare mini PCIe socket featuring a USB 2.0 interface such as Rockchip RK3568-powered Mixtile Edge 2 Kit gateway. You’ll also need some way of mounting the antennas after connecting them to the IPEX-1 antenna connectors on the module, the Edge 2 Kit comes with multiple antenna holes. Mixtile 2-in-1 Zigbee & Z-Wave mPCIe module specifications: Wireless MCUs Silabs EFR32MG24 Arm Cortex-M33 @ 78.0 MHz with 256 kB RAM, 1536 kB flash Radio Frequency – 2.4 GHz (802.15.4 radio) TX Power – up to +19.5 dBm RX sensitivity – -105.4 dBm at 250 kbps Protocols – Zigbee, Matter, Thread […]

Silicon Labs partners with Nabu Casa to support Home Assistant development

Silicon Labs Nabu Casa partnership

Silicon Labs has entered an official partnership with Nabu Casa, the company behind the popular Home Assistant home automation software, to support the development of Home Assistant open-source software and Silicon Labs-based hardware platforms. Most open-source embedded software projects start as a one-person (or a small team) effort as the vendor-provided firmware and related software may not have the features set needed by this user or group of users. So they hack existing hardware to build something that better fits their requirements often without input/help from the silicon vendor or product manufacturer. But sometimes the project becomes popular enough that large companies start to help it with support and funding. That’s apparently the case for Home Assistant project with Silicon Lans and Nabu Case entering an official partnership. The announcement does not provide details about the partnership but explains this should lead to better support and improvements for both Home […]

Linux-based DIN Rail smart controller works with Zigbee, Z-Wave, KNX, and Ajax Systems security solutions

YOCTOCONNECT Smart Home DIN Rail system

CONNECT Y1 Smart Controller in a DIN Rail gateway running Ubuntu Linux and acting as the main control of YoctoCONNECT’s Smart Home/Smart Building solution with YoctoBus (RS485) and Ethernet interfaces, support for expansion blocks, and third-party integration with Zigbee, Z-Wave, KNX, and Ajax Systems security and smart home solutions. The Y1 Smart Controller handles automation algorithms and RS485, Ethernet, and USB communication for automated control systems for lighting, power distribution equipment, ventilation systems, climate control, and other electrical loads in various sectors such as Industry 4.0, Smart Homes, and Smart Cities. CONNECT Y1 Smart Controller specifications: SoC – Quad-core processor @ 1.2 to 2.4 GHz System Memory – 512MB, 1GB, or 2GB DDR3 RAM Storage – 16GB or 32 GB eMMC flash Audio – 3.5mm audio output jack; AirPlay support Connectivity YoctoBUS (RS485) interface via 3-pole terminal block 10/100M Ethernet RJ45 port USB 2.0 interface for Z-Wave or Zigbee Ajax […]

Review of RaZberry 7 Pro Z-Wave Raspberry Pi HAT and Z-Uno2 Z-Wave board

RaZBerry 7 Pro Z-Uno2 Z-Wave Review

Z-Wave.Me has sent us a couple of Smart Home devices based on Z-Wave technology for review, namely the RaZberry 7 Pro Raspberry Pi HAT and the Z-Uno2 board. The Swiss company has primarily developed Z-Wave products for years and is a member of the Z-Wave Alliance. For those who are concerned about the issues of signal interference in the 2.4GHz range (WiFi, Zigbee, Bluetooth, and Thread), Z-Wave technology is an excellent choice because it operates on a less congested frequency range of 800-900MHz and the technology has been around for more than 20 years, resulting in a wide variety of Z-Wave devices available in the market, and they can work well together across different brands due to a proper certification process which is another advantage when compared to other protocols. The two devices we received are RaZberry 7 Pro, which is a shield that plugs into the 40-pin GPIO header […]

Zvidar Z-GW-V01 Smart Gateway runs Home Assistant on Allwinner A133 processor

Allwinner A133 SBC Home Assistant Gateway

Shenzhen Zvidar Technologies’ Z-GW-V01, also known as the Zvidar Smart Gateway is a single board computer powered by an Allwinner A133 quad-core Cortex-A53 processor and running Ubuntu with the Home Assistant open-source automation framework. The SBC provides Gigabit Ethernet, WiFi 5, and Bluetooth connectivity by default, but also supports plenty of optional wireless modules with Z-Wave, Zigbee, Thread/Matter, LoRa, or 4G LTE connectivity that are either soldered to the board connected by a mini PCIe socket. The board also includes a few USB ports, and it’s apparently possible to connect a 7-inch display and/or audio interfaces if needed. Zvidar Smart Gateway (Z-GW-V01) specifications: SoC – Allwinner A133 quad-core Cortex-A53 processor @ up to 1.6GHz with Imagination PowerVR GE8300 GPU with support for OpenGL ES3.2, Vulkan 1.1, OpenCL 1.2 System Memory – 1GB RAM (option for 512MB, 2GB, or 4GB) Storage – 8GB eMMC flash (option for 4GB, 16GB, or 32GB), […]

Silicon Labs FG28 Sub-GHz wireless and 2.4 GHz BLE SoC supports Amazon Sidewalk, Wi-SUN, etc…

Silicon Labs FG28 block diagram

Silicon Labs dual-band FG28 Cortex-M33 SoC comes with sub-Gigahertz and 2.4 GHz Bluetooth LE radios that support long-range networks and protocols like Amazon Sidewalk, Wi-SUN, and other proprietary protocols, as well as a built-in AI/ML accelerator for machine learning inference and SiLabs Secure Vault technology. The chip looks to be an update to the sub-GHz FG25 Cortex-M33 microcontroller with an additional 2.4 GHz BLE radio, but somehow less program memory (up to 256KB) and storage (up to 1024 KB). The peripherals implemented in the chip are almost the same, as the microcontroller gains support for predictive maintenance with a small matrix vector processor for AI/ML acceleration. Silicon Labs FG28 (EFR32FG28) specifications: MCU core – Arm Cortex-M33 @ 78 MHz with DSP instructions and FPU On-chip memory – Up to 256 kB RAM data memory On-chip storage – Up to 1024 kB flash program memory AI accelerator – Matrix Vector Processor […]

Add Z-Wave LR (Long Range) to Raspberry Pi or Home Assistant Yellow with Zooz 800 Series USB stick or GPIO Module

Z-Wave Long Range Raspberry Pi Home Assistant Yellow

We wrote about the new Z-Wave Long Range (LR) standard aka “Z-Wave Plus LR” promising four times the range and 10-year battery life in September 2020 but hadn’t heard much about it since then, at least until now, as Zooz has launched the ZST39 LR USB Stick and ZAC93 LR GPIO module based on a Z-Wave 800 Series chip, with the GPIO module compatible with Home Assistant Yellow and Raspberry Pi SBCs. Zooz 800 Series Z-Wave Long Range GPIO Module ZAC93 LR ZAC93 LR specifications: Z-Wave Frequency  – 908.42 MHz (US, CA, MX) / 921.4 MHz (AU, NZ) / 868.42 MHz (EU) Wireless Range – Up to 1 mile/1.6 km in open space with Long Range enabled (up to 300 meters in open space, up to 76 meters indoors in traditional mesh networks) Support for up to 200 devices in a single network Host interface – 10-pin header to Raspberry […]

Wireless M-Bus & LTE Cat 1 sensor board also supports Zigbee 3.0, Z-Wave, Bluetooth LE 5.0, LoRa…

Geniatech SBC32IM

Geniatech SCB32IM is a sensor board based on Silicon Labs EFR32FG14 Arm Cortex-M4 microcontroller with a sub-GHz radio enabling wireless M-Bus (Wireless Meter Bus) designed for remote reading of smart meters, and also equipped with a Quectel EC200S “IoT/M2M-optimized” LTE Cat 1 module. The sensor module does not actually come with any sensor on board, but provides a terminal block to connect any sensor you may need for your product. It’s also possible to extend wireless connectivity options with Zigbee 3.0, Z-Wave, Bluetooth LE 5.0, LoRa, and more through the GT-IoT interface with UART, SPI, and one GPIO. Geniatech SBC32IM specifications: Microcontroller – Silicon Labs EFR32FG14 Aem Cortex-M4 MCU @ 40MHz with up to 256 KB flash, 32 KB RAM, and proprietary 2.4GHz and sub-GHz radios Wireless connectivity Wireless M-Bus S Mode: 868 MHz band T Mode: 868 MHz band C Mode: 868 MHz band N Mode: 169 MHz band […]
