odrive micro
Posted on

ODrive Micro is a compact, brushless motor controller designed for space-constrained robotics applications (Crowdfunding)

ODrive Micro is a high-performance servo motor drive from ODrive Robotics that comes in an ultra-compact, 32 x 32mm form factor. The controller provides up to 100W continuous power for driving brushless servo motors. The ODrive Micro is the latest in a series of motor controllers from ODrive and builds on the company’s established software and hardware ecosystem. This includes support for CAN Bus, programming libraries, and a web-based graphic user interface for easy and intuitive setup. The Micro features a CAN interface for daisy-chaining other controllers and an onboard 12-bit magnetic encoder for direct mounting without needing an external encoder. It also offers the option to mount hall, quadrature, and SPI external encoders via the J1 header on the board. The ODrive Micro is aimed at robotics applications where space is premium, including hobbyist and professional use. It is similar to the Wukong 2040, ClearCore, and the Serial Bus […]

Flipper Zero Add On CANBus
Posted on

Flipper Zero hacking tool gets CAN bus add-on board for vehicle diagnostics and security research

Electronic Cats’ Flipper Add-On CANBus is a new add-on board for the Flipper Zero adding CAN bus communication to the popular wireless hacking tool. Built around the MCP2515 CAN controller chip this add-on card communicates with the Flipper Zero through an SPI interface. It allows users to sniff, send, and log CAN bus packets directly from the Flipper Zero, which means now you can analyze and manipulate CAN bus traffic for vehicle diagnostics, security research, and DIY projects. Previously we have seen Flipper Zero add an RP2040-powered video game module, and before that, we noted the developers launched their own app store with open-source apps. Additionally, we have written about Flipper Zero alternatives such as the M1 multitool so feel free to check those to know more about those solutions. Electronic Cats Flipper Add-On CANBus specifications Compatibility – Flipper Zero CAN Controller – Microchip MCP2515 CAN bus controller with SPI […]

ArmSoM RK3588 AIModule7 NVIDIA Jetson Nano-compatible SOM
ESP32-S3 display RS485 CAN Bus terminal block
Posted on

4.3-inch ESP32-S3 wireless touchscreen display features terminal block with RS485, CAN Bus, I2C, DIO

Waveshare “ESP32-S3-Touch-LCD-4.3B” is a capacitive touch display development board built around an ESP32-S3 SoC with RS485, CAN Bus, I2C, and isolated DIO interfaces provided through a terminal block. The devkit features a 4.3-inch capacitive touch display that has an 800×480 resolution, RTC, and a microSD card slot. Combined with a wide input voltage range of 7-36V DC, the ESP32-S3-Touch-LCD-4.3V is suitable for IoT HMI, smart home automation, and more. Previously we have written about similar development boards from Waveshare like the ESP32-S3 1.69-inch touch display, the $15 Waveshare 1.69-inch IPS touch LCD module, the Waveshare RP2040-LCD-0.99-B rounded display but they would offer no expansion pins or GPIO through pads or 4-pin connectors, while the ESP32-S3 display features a terminal block with additional interfaces like RS485 pr CAN Bus that should make wiring more convenient and versatile for the target applications. Waveshare ESP32-S3 touch LCD specifications: Wireless MCU – Espressif Systems ESP32-S3R8 […]

Sparkfun RTK EVK
Posted on

SparkFun RTK EVK offers GNSS with centimeter accuracy, WiFi, Bluetooth, 4G LTE Cat 1, and Ethernet connectivity

SparkFun RTK EVK is a fully-enclosed GNSS platform designed for fixed or mobile high-precision positioning and navigation applications with centimeter accuracy thanks to RTK (real-time kinematic) technology implemented with modules from u-blox. About two months ago, Sparkfun introduced the RTK Torch waterproof GNSS surveyor with Unicore UM980 GNSS module with RTK support, ESP32 for WiFi/Bluetooth, and an STM32WLE5C LoRa SoC. The  SparkFun RTK EVK (evaluation kit) may drop LoRa connectivity, but it’s a more versatile platform with WiFi, Bluetooth, Ethernet, and LTE Cat 1 cellular connectivity, besides support for L1 + L2 RTK GNSS with L-Band correction. Sparkfun RTK EVK specifications: GNSS Receiver – u-blox ZED-F9P Concurrent reception of GPS, GLONASS, Galileo, and BeiDou Receives both L1C/A and L2C bands 184-channel u-blox F9 engine Time to First Fix: 25s (cold), 2s (hot) Max Navigation Rate: 20Hz / 25Hz depending on mode Horizontal Position Accuracy: 2.5m without RTK; 0.010m with RTK […]

Rockchip RK3588 RKLLM
Posted on

Rockchip RKLLM toolkit released for NPU-accelerated large language models on RK3588, RK3588S, RK3576 SoCs

Rockchip RKLLM toolkit (also known as rknn-llm) is a software stack used to deploy generative AI models to Rockchip RK3588, RK3588S, or RK3576 SoC using the built-in NPU with 6 TOPS of AI performance. We previously tested LLM’s on Rockchip RK3588 SBC using the Mali G610 GPU, and expected NPU support to come soon. A post on X by Orange Pi notified us that the RKLLM software stack had been released and worked on Orange Pi 5 family of single board computers and the Orange Pi CM5 system-on-module. The Orange Pi 5 Pro‘s user manual provides instructions on page 433 of the 616-page document, but Radxa has similar instructions on their wiki explaining how to use RKLLM and deploy LLM to Rockchip RK3588(S) boards. The stable version of the RKNN-LLM was released in May 2024 and currently supports the following models: TinyLLAMA 1.1B Qwen 1.8B Qwen2 0.5B Phi-2 2.7B Phi-3 […]

Waveshare ESP32-S3 LCD Driver Board
Posted on

ESP32-S3 LCD Driver Board supports both circular and square displays

Waveshare ESP32-S3 LCD Driver Board is a compact development board designed to simplify the GUI development process. The company mentions that the board supports 2.1-inch, 2.8-inch, and 4-inch displays and with an additional SPI and I2C header it can support a wide range of LCD panels. Additionally, the board features an onboard lithium battery charger and 15 usable GPIO pins for added flexibility. These features make this device suitable for applications like smart home devices, industrial control panels, and interactive kiosks. It seems like the board supports the 4-inch LF40 square touchscreen display that we wrote about just yesterday. other than that it also supports 2.1-inch and 2.8-inch circular displays. Seeking off circular displays, we have previously written about some ESP32-powered development boards with circular displays like the Waveshare 1.69-inch IPS touch LCD, the Waveshare RP2040-LCD-0.99-B, the Waveshare ESP32-S3-LCD-1.28 and many other types of displays. Feel free to check those […]

Rockchip RK3568, RK3588 and Intel x86 SBCs and SoMs in 2025
Marauder Unit with Case showing ports
Posted on

The ESP32 Marauder Pocket Unit v2 is a wireless penetration device with an onboard GPS module and touchscreen

The ESP32 Marauder Pocket Unit with GPS v2 is a portable Wi-Fi and Bluetooth penetration tool powered by an ESP32 module and used to test and analyze wireless networks. It features a 2.8-inch touchscreen, two 18650 batteries, an SD card slot, an LED battery indicator, and two external antennas for 2.4GHz Wi-Fi and GPS. ESP32 Marauder Pocket Unit v2 specifications: Microcontroller – ESP32 Wi-Fi & Bluetooth SoC Storage – MicroSD card slot for file sharing, backup, and firmware updates (8GB SanDisk memory card included) Display – 2.8-inch capacitive touchscreen USB – USB-C port for charging GNSS – Embedded GPS module Antenna – External dual antenna SMA connectors for WIFI and GPS Misc 1x battery status indicator Reset and Power buttons Power – 2x 18650 batteries Dimensions – 92 x 71 x 46mm The ESP32 Marauder device is based on JustCallMeKoko’s ESP32Marauder Project, a suite of Wi-Fi/Bluetooth offensive and defensive tools […]

GEEKOM GT13 Pro mini PC review Windows 11 Pro
Posted on

GEEKOM GT13 Pro Core i9-13900H mini PC review with Windows 11 and Ubuntu 24.04

GEEKOM GT13 Pro is a Windows 11 mini PC powered by a 13th Gen Intel Core i9-13900H or Core i7-13620H processor with Intel Xe Iris graphics, two Thunderbolt 4 ports, a 2.5GbE port, WiFi 6E and Bluetooth 5.2 connectivity. GEEKOM sent us a review sample of the GEEKOM GT13 Pro mini PC with a Core i9-13900H 14-core/20-thread processor, 32GB RAM, and a 2TB NVMe SSD. We would usually do a three-part review, but the GEEKOM GT13 Pro uses the same motherboard as the GEEKOM Mini IT13 reviewed at the end of last year. So we’ll do a more condensed one-part review focusing on the differences between the two models in terms of features and performance in both Windows 11 Pro and Ubuntu 24.04. GEEKOM GT13 Pro specifications SoC – Intel Core i9-13900H 13th Gen Raptor Lake processor with 14 cores, 20 threads up to 5.40 GHz, 24MB Cache, Iris Xe […]

Boardcon CM3588 Rockchip RK3588 System-on-Module designed for AI and IoT applications
