Mini-ITX SBC with Tiger Lake UP3 CPU offers dual 2.5GbE, quad display support

tKINO-ULT6 Mini-ITX SBC

IEI launched tKINO-ULT6 is a Thin Mini-ITX SBC that comes with an 11th generation Intel core processor part of the Tiger Lake-UP3 CPU family. The tKINO-ULT6 Mini-ITX SBC also supports quadruple independent displays, SATA 6Gb/s, dual Intel 2.5GbE, HD audio, and RoHS. It can handle a wide range of input DC power from 9V to 36 V. The tKINO-ULT6 SBC is expected to be found in CNC (Computer Numerical Control) machines, real-time controls, human-machine interfaces, tool applications, medical imaging, and other applications requiring high resolution. Key Features of  the tKINO-ULT6 Mini-ITX SBC Mini-ITX form factor with 11th Gen. Intel Tiger Lake UP3 Embedded processor, support for DDR4-3200 memory Video Output – Four independent displays via HDMI, DP, eDP/LVDS, USB4 Networking Dual Intel 2.5GbE LAN M.2 A key for WIFI+Bluetooth (PCIe x1/USB 2.0), M.2 M key for Storage (PCIe x2/SATA) Expansion – PCIe x8 Gen 4.0 slot  The tKINO-ULT6 Mini-ITX SBC supports up to 64GB DDR4-3200, dual SATA III connection with […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

DBM10 AI SoC is optimized for battery-powered voice and sensor processing

DBM10 AI Devkit

DSP Group announced DBM10 a low-power AI/ML-enabled dual-core SoC. The SoC is equipped with a DSP (Digital Signal Processor) and a dedicated nNetLite NN (Neural Network) processor that improves voice and sensor processing and ensures low-power consumption when working with sufficient-sized neural networks. Key Specifications of NN Processor Form factor: ~4 mm2  Ultra-low-power inference consumption – ~500 µW (typical) for voice NN algorithms Runs Hello Edge 30-word detection model @ 1 MHz (125 MHz available) Allows porting of large models (10s of megabytes) without significant accuracy loss using model optimization and compression. DBM10 AI SoC uses the combined functioning of machine learning, voice, and sensor parameters. This includes voice trigger (VT), voice authentication (VA), voice command (VC), noise reduction (NR), acoustic echo cancellation (AEC), sound event detection (SED), proximity and gesture detection, sensor data processing, and equalization. The DBM10 is suitable for battery-operated devices like smartphones, tablets, and wearables. It is even suitable for true wireless stereo (TWS) headsets, and […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

STM32WB5MMG Wireless Module simplifies Bluetooth LE, Zigbee, OpenThread connectivity

STM32WB5MMG Wireless Module

The STM32WB5MMG (STM32) is a wireless microcontroller module by STMicroelectronics. It is a compact ultra-low-power module that allows customers to design 2-layer PCBs and integrates everything up to the antenna, including an IPD (integrated passive device) for reliable antenna matching in order to reduce the overall costs. The STM32 wireless module is compatible with BLE (Bluetooth Low Energy) 5.0, OpenThread, Zigbee 3.0, dynamic and static concurrent modes, and 802.15.4 proprietary protocols. It also supports simultaneous dual-protocol mode that allows IEEE 802.15.4 radio-based protocols like Zigbee 3.0 and OpenThread for direct connection with any BLE device. Overview of STM32 Wireless Module The STM32 wireless module is a SiP-LGA86 package (System in Package Land Grid Array)  with various external components including:  STMicro STM32WB55 Cortex-M4/M0+ wireless MCU LSE crystal  HSE crystal Passive components for SMPS  Antenna matching and antenna  IPD for RF matching and harmonics rejection Key Features of STM32 Wireless Module Dedicated Arm Cortex-M0+ for radio and security tasks Dedicated Arm Cortex-M4 […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Adafruit Voice Bonnet is meant for DIY Raspberry Pi Smart Speakers

Additional Voice Bonnet Features on PCB

Adafruit Voice Bonnet features two speakers and two mics, that can be used as an audio-voice interface for Raspberry Pi SBC to create a DIY smart speaker or other audio product. The voice bonnet can work with any Raspberry Pi from Pi Zero up to Pi 4, with 40-pin 2 x 20 connector. Two speaker outputs of the voice bonnet have a power rating of 1 Watt. The voice bonnet contains 3.5 mm stereo outputs, headphone stereo, or line-out audio. The Adafruit voice bonnet has an on-board WM8960 low-power stereo codec that uses I2S digital audio for both input and output. The WM8960 codec has a dual analog input, it consists of a left mic and a right mic. The codec integrates a complete microphone interface and a stereo headphone driver. Adafruit says “For DIY speakers, solder any 1W+ speaker to one of these JST 2-PH cables. If you’d like to stack another HAT or bonnet on top, use a […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

BHI260AP is an AI smart sensor with built-in IMU by Bosch Sensortec

BHI260AP AI smart sensor

BHI260AP AI smart sensor integrates a 6-axis IMU, a 32-bit customizable programmable microcontroller, and various software functionalities. The AI smart sensor has embedded AI with on-sensor applications such as fitness tracking, navigation, machine learning analytics, and orientation estimation. The dimensions of the miniaturized AI smart sensor are 4.1mm x 3.6mm x 0.83 mm. Hardware Features of BHI260AP AI Smart Sensor ARC EM4 CPU includes ARCv2 16/32 bit instruction set working up to a frequency of 3.6 MHz. The core also integrates Floating Point Unit (FPU) and Memory Protection Unit (MPU) with 4 channel micro DMA controller. CPU has two modes of AI functioning at 25Hz and 50Hz with 249µA and 386µA of current consumption respectively. Integrated sensor (6-DoF IMU) includes 16-bit 3 axis accelerometer and 16-bit 3 axis gyroscope. The sensor works at an operating voltage of 1.8 V with a standby current value of 8µA, hence the power consumption is only 0.014 mW in standby mode. Self Learning AI […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

IoT development board comes with AVR or PIC MCU, WiFi module

AVR-IoT and PIC-IoT Development Boards

Microchip AVR-IoT and PIC-IoT development boards have AVR and PIC MCUs respectively, which enables a simple interface between embedded applications and the cloud. The IoT development boards can securely transfer data to Amazon Web Services (AWS) IoT platform with a WiFi connection. The IoT development boards also include an onboard debugger which can be used to program and debug the MCUs without any need for external hardware. The IoT development boards also have an integrated lithium battery charger, which makes it a rechargeable device and allows easier deployment for a “ready-to-go solution.” The AVR-IoT WA development board integrates the ATECC608A CryptoAuthentication chip for security protocols and the ATWINC1510 Wi-Fi network controller for connectivity. The development board combines the ATmega4808 MCU 8-bit AVR MCU running at up to 20 MHz and offers a wide range of flash sizes up to 48 KB. The unit uses a “flexible and low-power architecture, including Event System and SleepWalking, accurate analog features, and advanced peripherals.” […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Tiny mmWave radar sensor embeds Cortex-R4F core for object tracking, classification

tiny mmwave radar sensor

The 1″ cube mmWave RS-6843AOPUA radar sensor, announced by D3 Engineering, is a miniature radar device that enables easy integration of radar algorithms for industrial applications. The RS-6843AOPUA radar sensor is an AECQ-100-qualified 60 GHz device that integrates a Texas Instruments C674x DSP for algorithms and an Arm Cortex-R4F microcontroller unit for decision-making and interfacing. It also has a radar accelerator and an “on-package antenna array.” The RS-6843AOPUA radar sensor features a 1-inch cube form factor, heat-spreading metal body, mounting tabs, and a USB-Serial interface. The USB-Serial interface could be used to test and evaluate the radar sensor. Functions and Applications of the Radar Sensor TI C674x DSP: FMCW (Frequency Modulated Continuous Wave) signal processing, Implementation of algorithms Radar Accelerator: Radar data processing Arm Cortex-R4F MCU: Object tracking, Classification, Communications “The RF front end integrates a PLL, three transmitters, four receivers, and baseband ADC, and allows the sensor to cover up to 4 GHz at a 12 dBm transmit power […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

LG launches LG8111 AI SoC and development board for Edge AI processing

LG8111 AI Soc Development Board Eris

LG Electronics has designed LG8111 AI SoC for on-device AI inference and introduced the Eris Reference Board based on the processor. The chip supports hardware processing in artificial intelligence functions such as video, voice, and control intelligence. LG8111 AI development board is capable of implementing neural networks for deep learning specific algorithms due to its integrated “LG-Specific AI Processor.” Also, the low power and the low latency feature of the chip enhances its self-learning capacity. This enables the products with LG8111 AI chip to implement “On-Device AI.” Components and Features of the LG8111 AI SoC LG Neural engine, the AI accelerator has an extensive architecture for “On-Device” Inference/Leaning with its support on TensorFlow, TensorFlow Lite, and Caffe.  The CPU of the board comes with four Arm Cortex A53 cores clocked at 1.0 GHz, with an L1 cache size of 32KB and an L2 cache size of 1MB. The CPU also enables NEON, FPU, and Cryptography extension. The camera engine has […]
