ZimaBoard Intel Apollo Lake SBC and micro server goes for $69.99 and up (Crowdfunding)

We’ve had our fair share of low-cost x86 SBCs in recent years, mostly based on Intel Cherry Trail processor, with the likes of Atomic Pi and Rock Pi X. Ice Whale Technology has come up with its own low-cost Intel single board computer with ZimaBoard “single board server” as it mostly has network storage applications in mind, but with a 4K capable mini DisplayPort connector it could also be used as a standard SBC or mini PC. There are two versions of the board both with Apollo Lake processors: ZimaBoard 216 with a dual-core Celeron N3350 coupled with 2GBRAM and 16GB eMMC flash, and ZimaBoard 832 powered by a quad-core Celeron N3450 with 8GB RAM and 32GB storage. Both ZimaBoard SBC shares most of the same specifications in terms of I/Os: SoC – ZimaBoard 216 – Intel Celeron N3350 dual-core processor @ 1.1/2.4GHz (Burst freq.) with 12 EU Intel HD graphics 500 @ 200 MHz / 650 MHz (Burst freq.); […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

2.5-inch “Industrial Pi” Pico-ITX SBC offers PoE , mini DP++ port

Taiwan based DFI has launched the AL05P “Industrial Pi + PoE” 2.5-inch Pico-ITX SBC powered by an Apollo Lake processor that reminds me of last year’s DFI GHF51 SBC based on AMD Ryzen Embedded R1606G processor but with a larger, and more standard form factor that’s also part of the “Industrial Pi” family. The board also comes with 4GB RAM, up to 64GB eMMC, a mini DisplayPort video output, two USB 3.1 ports, Gigabit Ethernet with isolated PoE, a mini-PCIe, and more. DFI AL05P SBC specifications: SoC (one or the other) Intel Atom x5-E3940 quad-core processor @ 1.6/1.8 GHz with 2MB cache, Intel HD Graphics; 9.5W TDP Intel Atom x5-E3930 dual-core processor @ 1.3/1.8 GHz with 2MB cache, Intel HD Graphics; 6.5W TDP Intel Pentium N4200 quad-core processor @ 1.1/2.5 GHz with 2MB cache, Intel HD Graphics; 6W TDP Intel Celeron N3350 dual-core processor @ 1.1/2.4 GHz with 2MB cache, Intel HD Graphics6W TDP System Memory – Up to 4GB […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

IP69K-Rated Stainless Steel Panel PCs Run Windows 10 or Ubuntu 16.04

There are already several industrial dust and waterproof panel PCs on the market, but with its Intel Apollo Lake powered Titan-AL Series, ADLINK goes a step further with IP69K-rated stainless steel panel PCs that provide resistance against corrosion from all sort of chemicals. Titan-AL series panel PCs can be washed with high-pressure water or steam to meet high-hygiene standards required in special production environments including food, pharmaceutical, and chemical production. ADLINK Titan-AL series panel PC specifications: SoC  – Intel Atom x7-E3950 quad-core Apollo Lake processor @ 1.60 GHz  / 2.00 GHz (Boost) with Intel HD Graphics 505; 12W TDP System Memory – 4GB DDR3L default (up to 8GB) Storage – 2.5″ SATA drive bay Available Displays Configurations Titan-15W-AL – 15.6-inch display with 1366 x 768 resolution, optional capacitive touchscreen; viewing angle: 80/80/85/85° (U/D/R/L) Titan-21W-AL – 21.5-inch display with 1920 x 1080 resolution, optional capacitive touchscreen; viewing angle: 89° in all directions Titan-24W-AL – 23.9-inch display with 1920 x 1080 resolution, […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

PICO317 Fanless Atom x5-E3940 Pico-ITX SBC Powers Industrial IoT Applications

Axiomtek has launched a 2.5-inch Pico-ITX Atom x5-E3940 Apollo Lake SBC supporting two independent video outputs and designed for Industrial IoT (IIoT) applications for industrial automation and in the transportation and retail sectors. The PICO317 single board computer is equipped with up to 8GB SO-DIMM RAM, supports SATA and mSATA storage, Gigabit Ethernet, and dual video output is achieved via HDMI and LVDS interfaces. Axiomtek PICO317 specifications: SoC – Intel Atom x5-E3940 quad-core Apollo Lake processor @  1.6 GHz / 1.8 GHz (Turbo) with 2 MB cache, 12 EU Intel HD graphics; 9.5W TDP System Memory – Up to 8GB RAM via 1x 204-pin DDR3L-1867 SO-DIMMto Storage – SATA 3.0 connector, mSATA socket (see Expansion section), flash for AMI BIOS Video Output – 1x HDMI up to 4K, 1x dual-channel 18/24-bit LVDS Audio – Realtek ALC662 HD Codec audio; Line-out jack Networking – Gigabit Ethernet via Intel i211-AT and supporting Wake-on-LAN, PXE Boot ROM USB – 2x USB 2.0 via […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

OnLogic Introduces Fanless Apollo Lake Thin Clients Running IGEL Edge OS

OnLogic has launched its first two offerings as part of the new IGEL Ready program with IGL200 and IGL300 fanless thin clients powered by various Intel Apollo Lake processors. IGEL Edge OS enables the devices to be used for distributed computing, virtualization, and thin clients, and OnLogic thin clients target users in the manufacturing, energy, automation, and industrial Internet of Things (IIoT) sectors. OnLogic IGL200 Specifications: SoC – Intel Celeron N3350 dual-core Apollo Lake processor @ 1.1 GHz / 2.4 Ghz (Burst freq.) with Intel HD Graphics 500 System Memory – Up to 4GB LPDDR4-2133 Storage – 32GB eMMC flash, MicroSD Card slot, mSATA slot Video Output – 2x Mini DisplayPort outputs with dual independent display support Audio – 1x audio Jack with Line-out and Mic-in Networking 2x Gigabit Ethernet ports via Realtek RTL8111G controller 4x antenna holes for optional cellular modem or/and WiFi USB – 1x USB 2.0 port, 2x USB 3.0 ports Serial – 1x COM port (RS-232) […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

Exor GigaSOM GS01 SoM and Devkit Combine Intel Atom E39xx CPU and Cyclone 10 GX FPGA

EXOR International has worked in collaboration with Arrow Electronics to design and manufacture GigaSOM GS01 system-on-module combining an Intel Atom E39xx Apollo Lake processor and Cyclone 10 GX FPGA. The module and corresponding development kit are specifically designed for smart factory & “Industrie 4.0” applications with the processor running Intel’s time-coordinated computing plus a real-time “IoT stack”, and the FPGA supporting IEEE 802.1 time-sensitive networking (TSN) and 10Gbps connectivity. GigaSOM GS01 module specifications: Apollo Lake SoC (one or the other) Intel Atom x5-E3930 dual-core processor @ 1.3 GHz / 1.8 GHz (Turbo) with 12EU Intel HD Graphics 500; 6.5W TDP Intel Atom x5-E3940 quad-core processor @ 1.6 GHz / 1.8 GHz with 12EU Intel HD Graphics 500; 9.5W TDP Intel Atom x7-E3950 quad-core processor @ 1.6 GHz / 2.0 GHz with 18EU Intel HD Graphics 505; 12W TDP FPGA – Intel Cyclone 10 GX up to 220 KLE System Memory CPU – Up to 8GB LPDDR4 FPGA – Up to […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

ADLink Launches Vizi-AI Development Starter Kit for Industrial Machine Vision & Artificial Intelligence

ADLINK has recently launched Vizi-AI development starter kit for industrial machine vision and artificial intelligence (AI) at the edge in collaboration with Intel and Arrow Electronics. Vizi-AI is comprised of a carrier board that looks to be the same as used in the company’s I-Pi SMARC development kit equipped with an Intel Movidius Myriad X VPU and combined with LEC-AL Intel Atom Apollo Lake SMARC computer module. Vizi-AI SBC Let’s have a look at the hardware features and specifications of Vizi-AI SBC (aka VIZI-AI LEC-AL-E3940-AI-4G-32G): SoC – Intel Atom x5-E3940 quad-core Apollo Lake-I processor @ up to 1.6 / 1.8 GHz (Turbo) with 12EU Intel HD Graphics 500; 9.5W TDP System Memory – 4GB LPDDR4 (Option up to 8GB) Storage – 1x MicroSD card slot AI Accelerator – Intel Movidius Myriad-X VPU (Vision Processing Unit) Video – 1x HDMI port, single-channel LVDS/eDP interface via flat cable Audio – On-carrier audio codec; stereo audio jack; digital audio via HDMI Networking –  […]

Support CNX Software – Donate via PayPal or cryptocurrencies, become a Patron on Patreon, or buy review samples

2.5-inch Pico-ITX SBC Offers LVDS, HDMI & DisplayPort Video Interfaces, Dual Gigabit Ethernet

Today I learned that Pico-ITX boards were also called 2.5-inch boards since they are about the size of a 2.5-inch SATA drive. Kontron pITX-APL V2.0 is one such 2.5-inch Pico-ITX SBC powered by an Intel Atom E39XX or Celeron Apollo Lake processor. The board can drive three independent displays via its 24-bit LVDS interface, HDMI and mini DisplayPort 1.2 output, comes with two Gigabit Ethernet ports and support for 4G LTE connectivity via M.2 slot and SIM card socket. Those features make it suitable for a wide range of applications including industrial client applications, kiosk, infotainment, digital signage, and POS systems. Kontron pITX-APL V2.0 specifications: Apollo Lake SoC variants Intel Atom x7-E3950 quad-core processor @ up to 2.0 GHz with 18EU Intel HD graphics; 12W TDP Intel Atom x5-E3940 quad-core processor @ up to 1.8 GHz with 12EU Intel HD graphics; 9.5W TDP Intel Atom x5-E3930 dual-core processor @ up to 1.8 GHz with 18EU Intel HD graphics; 6.5W TDP […]
