PICO317 Fanless Atom x5-E3940 Pico-ITX SBC Powers Industrial IoT Applications

Intel Atom x5-E3940 Pico-ITX SBC

Axiomtek has launched a 2.5-inch Pico-ITX Atom x5-E3940 Apollo Lake SBC supporting two independent video outputs and designed for Industrial IoT (IIoT) applications for industrial automation and in the transportation and retail sectors. The PICO317 single board computer is equipped with up to 8GB SO-DIMM RAM, supports SATA and mSATA storage, Gigabit Ethernet, and dual video output is achieved via HDMI and LVDS interfaces. Axiomtek PICO317 specifications: SoC – Intel Atom x5-E3940 quad-core Apollo Lake processor @  1.6 GHz / 1.8 GHz (Turbo) with 2 MB cache, 12 EU Intel HD graphics; 9.5W TDP System Memory – Up to 8GB RAM via 1x 204-pin DDR3L-1867 SO-DIMMto Storage – SATA 3.0 connector, mSATA socket (see Expansion section), flash for AMI BIOS Video Output – 1x HDMI up to 4K, 1x dual-channel 18/24-bit LVDS Audio – Realtek ALC662 HD Codec audio; Line-out jack Networking – Gigabit Ethernet via Intel i211-AT and supporting […]

OnLogic Introduces Fanless Apollo Lake Thin Clients Running IGEL Edge OS

OnLogic IGL200 Thin Client with IGEL Edge OS

OnLogic has launched its first two offerings as part of the new IGEL Ready program with IGL200 and IGL300 fanless thin clients powered by various Intel Apollo Lake processors. IGEL Edge OS enables the devices to be used for distributed computing, virtualization, and thin clients, and OnLogic thin clients target users in the manufacturing, energy, automation, and industrial Internet of Things (IIoT) sectors. OnLogic IGL200 Specifications: SoC – Intel Celeron N3350 dual-core Apollo Lake processor @ 1.1 GHz / 2.4 Ghz (Burst freq.) with Intel HD Graphics 500 System Memory – Up to 4GB LPDDR4-2133 Storage – 32GB eMMC flash, MicroSD Card slot, mSATA slot Video Output – 2x Mini DisplayPort outputs with dual independent display support Audio – 1x audio Jack with Line-out and Mic-in Networking 2x Gigabit Ethernet ports via Realtek RTL8111G controller 4x antenna holes for optional cellular modem or/and WiFi USB – 1x USB 2.0 port, […]

Exor GigaSOM GS01 SoM and Devkit Combine Intel Atom E39xx CPU and Cyclone 10 GX FPGA

EXOR Intel Atom + Cyclone FPGA Smart Factory / Industrie 4.0 Development Kit

EXOR International has worked in collaboration with Arrow Electronics to design and manufacture GigaSOM GS01 system-on-module combining an Intel Atom E39xx Apollo Lake processor and Cyclone 10 GX FPGA. The module and corresponding development kit are specifically designed for smart factory & “Industrie 4.0” applications with the processor running Intel’s time-coordinated computing plus a real-time “IoT stack”, and the FPGA supporting IEEE 802.1 time-sensitive networking (TSN) and 10Gbps connectivity. GigaSOM GS01 module specifications: Apollo Lake SoC (one or the other) Intel Atom x5-E3930 dual-core processor @ 1.3 GHz / 1.8 GHz (Turbo) with 12EU Intel HD Graphics 500; 6.5W TDP Intel Atom x5-E3940 quad-core processor @ 1.6 GHz / 1.8 GHz with 12EU Intel HD Graphics 500; 9.5W TDP Intel Atom x7-E3950 quad-core processor @ 1.6 GHz / 2.0 GHz with 18EU Intel HD Graphics 505; 12W TDP FPGA – Intel Cyclone 10 GX up to 220 KLE System Memory […]

ADLink Launches Vizi-AI Development Starter Kit for Industrial Machine Vision & Artificial Intelligence

Vizi-AI Development Kit

ADLINK has recently launched Vizi-AI development starter kit for industrial machine vision and artificial intelligence (AI) at the edge in collaboration with Intel and Arrow Electronics. Vizi-AI is comprised of a carrier board that looks to be the same as used in the company’s I-Pi SMARC development kit equipped with an Intel Movidius Myriad X VPU and combined with LEC-AL Intel Atom Apollo Lake SMARC computer module. Vizi-AI SBC Let’s have a look at the hardware features and specifications of Vizi-AI SBC (aka VIZI-AI LEC-AL-E3940-AI-4G-32G): SoC – Intel Atom x5-E3940 quad-core Apollo Lake-I processor @ up to 1.6 / 1.8 GHz (Turbo) with 12EU Intel HD Graphics 500; 9.5W TDP System Memory – 4GB LPDDR4 (Option up to 8GB) Storage – 1x MicroSD card slot AI Accelerator – Intel Movidius Myriad-X VPU (Vision Processing Unit) Video – 1x HDMI port, single-channel LVDS/eDP interface via flat cable Audio – On-carrier audio […]

2.5-inch Pico-ITX SBC Offers LVDS, HDMI & DisplayPort Video Interfaces, Dual Gigabit Ethernet

2.5-inch Pico-ITX SBC: pITX-APL v2.0

Today I learned that Pico-ITX boards were also called 2.5-inch boards since they are about the size of a 2.5-inch SATA drive. Kontron pITX-APL V2.0 is one such 2.5-inch Pico-ITX SBC powered by an Intel Atom E39XX or Celeron Apollo Lake processor. The board can drive three independent displays via its 24-bit LVDS interface, HDMI and mini DisplayPort 1.2 output, comes with two Gigabit Ethernet ports and support for 4G LTE connectivity via M.2 slot and SIM card socket. Those features make it suitable for a wide range of applications including industrial client applications, kiosk, infotainment, digital signage, and POS systems. Kontron pITX-APL V2.0 specifications: Apollo Lake SoC variants Intel Atom x7-E3950 quad-core processor @ up to 2.0 GHz with 18EU Intel HD graphics; 12W TDP Intel Atom x5-E3940 quad-core processor @ up to 1.8 GHz with 12EU Intel HD graphics; 9.5W TDP Intel Atom x5-E3930 dual-core processor @ up […]

HiGole F11APL Apollo Lake Industrial Mini PC Comes with a 11.6″ Touchscreen Display

HiGole F11APL

We’ve previously reviewed a few unusual mini PCs and tablets from Shenzhen Qianhai Gole Technology Co., Ltd – better known as just GOLE – such as GOLE F7 rugged tablet very recently, and before that some mini PCs with built-in display as GOLE 10. The company has now come up with an update to the latter with a more powerful Apollo Lake processor. HiGole F11APL comes with a slightly larger 11.6″ touchscreen display, but the Intel Celeron N3450 processor combined with 4GB RAM and 64GB eMMC flash storage will provide much better performance than the previous Cherry Trail-based solution. HiGole F11APL specifications: SoC – Intel Celeron N3450 quad-core Apollo Lake processor @ 1.1 GHz / 2.2 GHz (Burst frequency) and 12 EU Intel HD Graphics 500 @ 200 MHz / 700 MHz (Burst freq.); 6W TDP System Memory – 4GB LPDDR4 Storage – 64 GB eMMC flash,  micro SD slot […]

NEXCOM In-vehicle Computers Enable 24/7 Monitoring of Trains, Buses, and Trucks

NEXCOM nROK 6222

Taiwan based NEXCOM has introduced two new mobile computing solutions specifically designed for transportation with nROK 6222/VTC 6222 Intel Apollo Lake computers enabling 24/7 monitoring of trains, buses, trucks, and other vehicles. The computers come with five Ethernet ports, including four PoE enable, in order to connect IP cameras, and two HDMI output, one VGA output to let drivers monitor the front and back of the vehicle, and passengers view travel-related or other information. NEXCOM nROK 6222/VTC 6222 key features and specifications: SoC – Intel Atom x7-E3950 quad-core Apollo Lake processor clocked at 1.6 GHz / 2.0GHz with Intel HD Graphics 505 System Memory – 4GB DDR3L 1866 SO-DIMM (default) up to 8GB Storage –  2x 2.5″ SATA 3.0 SSD up to 15mm thick, SD card slot, internal USB DOM Video Output – VGA, 2 x HDMI Connectivity nROK 6222 – 1x Gigabit Ethernet (M12) port, 4x Ethernet (M12) ports […]

ECS Unveils LIVA Q1L Mini PC with Dual Gigabit Ethernet, LIVA Q1D with HDMI & DisplayPort

LIVA Q1D

ECS introduces one of the smallest Intel mini PCs with LIVA Q Apollo Lake mini PC in 2017, followed by LIVA Q2 Gemini Lake micro PC the following year both just 70x70x31~33mm in size. Ian reviewed LIVA Q2 Micro PC with Windows 10 and Ubuntu 18.10 last year, and he was impressed with the performance considering the form factor, with the mini PC being perfectly suitable for browsing the web, home or office use, or as a digital signage solution. ECS has now updated its original LIVA Q model with the same processor options, but with LIVA Q1L offering two Gigabit Ethernet ports and one HDMI output, while LIVA Q1D comes with two video outputs (HDMI and DisplayPort) and a single Ethernet port. ECS LIVA Q1L/Q1D specifications: SoC (one or the other) Intel Apollo Lake Pentium N4200 quad-core processor @ 1.1 / 2.5 GHz with 18EU Intel HD graphics; 6W […]
