LIVA Q1L Review – pfSense, Ubuntu 20.04, Windows 10 tested on a dual Ethernet “Ultra Tiny PC”

pfsense LIVA Q1L review

Elitegroup Computer Systems (ECS) have a series of mini PCs called LIVA which includes the diminutive Q range from which the LIVA Q2 was previously reviewed. Now it is the turn of the LIVA Q1L which although announced over a year ago has just been received for review and the results from various testing are detailed below. Hardware Overview The Q1L physically consists of a 74 x 74 x 34.6 mm (2.91 x 2.91 x 1.36 inches) rectangular plastic case. It is an actively cooled mini PC that uses slightly older Apollo Lake processors and the review model came with an N4200 CPU which is a quad-core 4-thread 1.10 GHz processor boosting to 2.50 GHz with Intel’s HD Graphics 505. The front has a power button, two USB 3.2 Gen 1×1 ports, and one USB 2.0 port whilst the rear includes an HDMI port, two gigabit Ethernet ports, and the […]

3.5-inch SBC targets industrial applications with 9-36V wide-range DC-in

ECM-3455J 3.5-inch SBC

BCM Advanced Research ECM-3455J is an upcoming 3.5-inch SBC designed for industrial application with 9-36V wide range DC-in support, an Intel Celeron J3455 quad-core Apollo Lake processor, up to 8GB SO-DIMM memory, and 32GB on-board eMMC flash. The single board computer also comes with HDMI and LVDS video out, dual Gigabit Ethernet, an M.2 socket a micro SIM socket for cellular connectivity, as well as up to eight USB interfaces, and a thick and large heatspreader for fanless operation. ECM-3455J specifications: SoC – Intel Celeron J3455 quad-core Apollo Lake processor @ 1.5GHz / 2.3GHz (Burst Frequency) with Intel HD graphics 500; 10W TDP System Memory – 1x 204-pin SO-DIMM DDR3L-1600MHz socket for up to 8GB RAM Storage – 32GB eMMC flash (option: 64GB), 1x SATA III port, mSATA socket (See expansion), 64Mbit SPI flash for AMI UEFI BIOS Video Output 18/24-bit dual-channel LVDS through Chrontel CH7511B embedded DisplayPort to LVDS […]

$300 NANOTE P8 is a 7-inch mini laptop with an Apollo Lake processor

NANOTE P8

NANOTE P8 is an affordable mini laptop powered by an Intel Pentium N4200 Apollo Lake processor coupled with 8GB RAM, 64GB storage, and equipped with a 7-inch Full HD display. While there are now plenty of mini laptops from companies like GPD or One Netbook they tend to be relatively pricey as they offer hardware with specifications suitable for gaming. Nanote mini laptop launched last year offered a low-cost option for $185, but with an Atom x5 Cherry Trail processor performance was really on the low-side, and the new Nanote P8 offers a mid-range option so-to-speak. NANOTE P8 (UMPC-02-SR) specifications: SoC – Intel Pentium N4200 quad-core Apollo Lake processor @ 1.1 / 2.5 GHz (Turbo) with 2MB cache, Intel HD 505 graphics; 6W TDP System Memory – 8GB RAM Storage – 64GB eMMC flash, MicroSD card slot Display – 7-inch touchscreen display with 1920×1200 resolution, 360-degree hinge Video Output – […]

UP Squared Pro SBC gets more I/Os, 3x M.2 sockets, TPM 2.0 security chip

UP Squared Pro SBC

UP Squared Apollo Lake SBC was launched in 2016 via a crowdfunding campaign with a price starting at just 89 Euros for the model with 2GB RAM 16GB storage, and a dual-core Intel Celeron N3350 processor. AAEON has now announced an update simply called UP Squared Pro with many of the same features, but greater expandability and I/O features, for example, to add 5G modules and AI accelerators through one of the three M.2 sockets, as well as improved security via a TPM 2.0 chip. UP Squared Pro (UPN-APL01) specifications with highlights in bold or strikethrough in comparison to the UP Squared specifications (in 2016): SoC (one or the other) Intel Celeron N3350 dual-core “Apollo Lake” processor @ 1.1 GHz / 2.4 GHz with 12 EU Intel HD graphics 500 @ 200 MHz / 650 MHz (6W TDP) Intel Pentium N4200 quad-core “Apollo Lake” processor @ 1.1 GHz / 2.5 […]

AI digital signage system combines Apollo Lake SoC with Myriad X AI accelerators

AI digital signage system

Digital signage players were traditionally used to display photos and text, play some videos, or PowerPoint presentations. But like with so many other devices, they can also be enhanced with artificial intelligence with, for instance, facial recognition enabling more personalized information, weather detection showing targeted advertisement (umbrella when it rains, sunglasses on sunny days…), and other data collection. IEI IDS-310AI fanless AI digital signage system can enable these types of features thanks to an Intel Celeron J3455 Apollo Lake processor combined with two Myriad X VPU’s, and the ability to drive three displays through HDMI. IDS-310AI digital signage mini PC specifications: SoC – Intel Celeron J3455 quad-core processor @ 1.5GHz / 2.3GHz (Turbo);  10W TDP System Memory – 1 x 204-pin DDR3L SO-DIMM, 8 GB pre-installed Storage – 128GB SATADOM, MicroSD card slot Video Output – 3x HDMI 1.4b ports up to 3840×2160 @ 30Hz each Audio – 1x Mic […]

ZimaBoard Intel Apollo Lake SBC and micro server goes for $69.99 and up (Crowdfunding)

ZimaBoard

We’ve had our fair share of low-cost x86 SBCs in recent years, mostly based on Intel Cherry Trail processor, with the likes of Atomic Pi and Rock Pi X. Ice Whale Technology has come up with its own low-cost Intel single board computer with ZimaBoard “single board server” as it mostly has network storage applications in mind, but with a 4K capable mini DisplayPort connector it could also be used as a standard SBC or mini PC. There are two versions of the board both with Apollo Lake processors: ZimaBoard 216 with a dual-core Celeron N3350 coupled with 2GBRAM and 16GB eMMC flash, and ZimaBoard 832 powered by a quad-core Celeron N3450 with 8GB RAM and 32GB storage. Both ZimaBoard SBC shares most of the same specifications in terms of I/Os: SoC – ZimaBoard 216 – Intel Celeron N3350 dual-core processor @ 1.1/2.4GHz (Burst freq.) with 12 EU Intel HD […]

2.5-inch “Industrial Pi” Pico-ITX SBC offers PoE , mini DP++ port

Industrial Pi PoE Pico-ITX SBC

Taiwan based DFI has launched the AL05P “Industrial Pi + PoE” 2.5-inch Pico-ITX SBC powered by an Apollo Lake processor that reminds me of last year’s DFI GHF51 SBC based on AMD Ryzen Embedded R1606G processor but with a larger, and more standard form factor that’s also part of the “Industrial Pi” family. The board also comes with 4GB RAM, up to 64GB eMMC, a mini DisplayPort video output, two USB 3.1 ports, Gigabit Ethernet with isolated PoE, a mini-PCIe, and more. DFI AL05P SBC specifications: SoC (one or the other) Intel Atom x5-E3940 quad-core processor @ 1.6/1.8 GHz with 2MB cache, Intel HD Graphics; 9.5W TDP Intel Atom x5-E3930 dual-core processor @ 1.3/1.8 GHz with 2MB cache, Intel HD Graphics; 6.5W TDP Intel Pentium N4200 quad-core processor @ 1.1/2.5 GHz with 2MB cache, Intel HD Graphics; 6W TDP Intel Celeron N3350 dual-core processor @ 1.1/2.4 GHz with 2MB cache, […]

IP69K-Rated Stainless Steel Panel PCs Run Windows 10 or Ubuntu 16.04

IP69K Stainless Steel Panel PC

There are already several industrial dust and waterproof panel PCs on the market, but with its Intel Apollo Lake powered Titan-AL Series, ADLINK goes a step further with IP69K-rated stainless steel panel PCs that provide resistance against corrosion from all sort of chemicals. Titan-AL series panel PCs can be washed with high-pressure water or steam to meet high-hygiene standards required in special production environments including food, pharmaceutical, and chemical production. ADLINK Titan-AL series panel PC specifications: SoC  – Intel Atom x7-E3950 quad-core Apollo Lake processor @ 1.60 GHz  / 2.00 GHz (Boost) with Intel HD Graphics 505; 12W TDP System Memory – 4GB DDR3L default (up to 8GB) Storage – 2.5″ SATA drive bay Available Displays Configurations Titan-15W-AL – 15.6-inch display with 1366 x 768 resolution, optional capacitive touchscreen; viewing angle: 80/80/85/85° (U/D/R/L) Titan-21W-AL – 21.5-inch display with 1920 x 1080 resolution, optional capacitive touchscreen; viewing angle: 89° in all […]
