October 31, 2024 by Jean-Luc Aufranc (CNXSoft) - 15 Comments

Intel Processor N150 and N250, Core i3-N355 Alder Lake-N Refresh SoCs show up in ASUS NUC 14 Essential mini PCs

Intel Processor N150, Processor N250, and Core i3-N355 new Alder Lake-N processors have recently shown up in the upcoming ASUS NUC 14 Essential mini PCs and offer a small performance boost compared to existing variants such as the N100, N200, and Core i3-N305. The upcoming NUC 14 Essential family also includes one model with the existing Processor N97 CPU, supports up to three 4K displays via HDMI, DP, and USB-C connectors, offers 2.5 GbE networking, six USB 3.2 Gen 2 ports, and a single USB 2.0 port. ASUS NUC 14 Essential (NUC14MNK) specifications: Alder Lake-N SoC Intel Processor N97 quad-core processor @ up to 3.4 GHz (Turbo) with 6MB cache, 24EU Intel UHD graphics; TDP: 6W Intel Processor N150 quad-core processor @ up to 3.6 GHz (Turbo) with 6MB cache, Intel graphics; TDP: 6W Intel Processor N250 quad-core processor @ up to 3.8 GHz (Turbo) with 6MB cache, Intel graphics; […]

September 20, 2024September 20, 2024 by Jean-Luc Aufranc (CNXSoft) - 5 Comments

ASUS Tinker Board 3 – A credit-card sized Rockchip RK3566 SBC with 12V to 19V DC input

ASUS Tinker Board 3 is a credit card-sized SBC based on Rockchip RK3566 SoC with an HDMI port, a 3.5mm audio jack, gigabit Ethernet, an M.2 socket for WiFi and Bluetooth, four USB ports, and a 40-pin GPIO header with a layout similar to the Raspberry Pi 3 Model B. When I first wrote about the Tinker Board 3 in 2023, it was a larger (100 x 100 mm) SBC based on Rockchip RK3568 SoC that was later renamed to Tinker Board 3N, now also available as a complete rugged system (more about that in a subsequent post). The new Tinker Board 3 (2024) is a completely different design that competes against Radxa ROCK 3C and Orange Pi 3B boards also based on RK3566 and offered in a business card/credit card form factor similar to the Raspberry Pi 3B. Tinker Board 3 specifications: SoC – Rockchip RK3566 CPU – Quad-core […]

September 16, 2024September 15, 2024 by Sayantan Nandy - 3 Comments

ASUS X7433RE-IM-A 3.5-Inch motherboard features Intel Atom X7433RE Amston Lake SoC, dual Ethernet, three display interfaces

ASUS has launched the X7433RE-IM-A, a 3.5-inch industrial motherboard powered by an Intel Atom X7433RE Amston Lake SoC. The processor supports Intel Deep Learning Boost (DL Boost) and Intel AVX2 SIMD instructions to enhance AI processing and accelerate workloads at the IoT edge. The X7433RE-IM-A single-board computer supports up to 16GB of DDR5 4800MHz In-Band ECC memory via a SO-DIMM slot. The Intel Atom X7433RE processor, with integrated Intel UHD Graphics, supports up to three 4K displays through HDMI 2.0, DisplayPort 1.4, and LVDS/eDP 1.2. For storage, the board includes a SATA 3.0 interface and networking is implemented through two Ethernet controllers – Intel i210IT and i226IT (2.5GbE) – with WOL/PXE support. Previously, we covered the ASRock Industrial SBC-262M-WT, another Intel Atom X7433RE Amston Lake-based 3.5-inch motherboard. We also wrote about other 3.5-inch boards like the ECS ADLN-IE1S, Jetway MF32, ECS RK3568-IS, MSI MS-98M3, and several others. You can check […]

August 28, 2024 by Sayantan Nandy - 3 Comments

ASUS ROG USB-BE92 is a USB 3.2 Gen1 WiFi 7 BE6500 adapter

The ASUS ROG USB-BE92 is a USB 3.2 Gen1-based WiFi 7 adapter that supports IEEE 802.11a/b/n/ac/ax/be standards. It operates in the 2.4GHz, 5GHz, and 6GHz bands, with dual internal antennas for improved signal reception. The device is designed for high-throughput wireless performance in BE6500 networks, supporting MU-MIMO technology. Primarily targeted for Windows 10 and 11 platforms, it enables next-generation wireless connectivity when paired with WiFi 7 routers and compatible client devices. We previously discussed several WiFi 7 modules, SBCs, and chipsets including Compex WLE7002E25, 8Devices Noni, Banana Pi BPI-R4, Fibocom FG370, and MediaTek’s Filogic 860 and Filogic 360. These modules offer different features and performance levels, so I recommend checking them out if you’re interested in WiFi 7 technology. The ASUS ROC USB-BE92 is one of the first WiFi 7 USB dongles that made it to market. ASUS ROG-USB-BE92 specifications: Wi-Fi Bandwidth – Tri-band BE6500 Top Speed – Max 2880Mbps […]

August 19, 2024August 19, 2024 by Sayantan Nandy - 3 Comments

ASUS N97T-IM-A – A thin mini-ITX motherboard powered by an Intel Processor N97 Alder Lake-N CPU

The ASUS N97T-IM-A is a thin Mini-ITX motherboard for industrial and embedded use, featuring the Intel N97 Alder Lake-N processor (4 cores, 2.0–3.6 GHz) with up to 16GB of DDR5 memory at 4800 MHz, and two gigabit Ethernet ports using Realtek RTL8111H controllers. The board also includes two SATA III 6Gbps ports, a PCIe 3.0/2.0 x1 slot, and dual M.2 slots for NVMe and Wi-Fi/Bluetooth. It supports HDMI 2.0, DP++, and LVDS video outputs, with optional eDP, and can handle resolutions up to 4K at 60 Hz. Built for durability, the N97T-IM-A is designed for demanding environments with a seven-year product lifecycle. In one of our last posts, we wrote about the Jetway JNUC-ADN1, another Intel N97-powered SBC, but in a smaller Next Unit of Computing (NUC) form factor and the Jetway JMTX-ADN8 another N97 mini-ITX motherboard. Other than that we have also written about similar motherboards in the mini-ITX form factor including […]

April 30, 2024April 29, 2024 by Jean-Luc Aufranc (CNXSoft) - No Comments

SBC Case Builder v3.0 can create thousands of cases for popular SBCs and standard motherboards (mini-ITX, Pico-ITX, NUC…)

SBC Case Builder V3.0 case design utility has just been released with the ability to create over 1,000 standard cases – not including customization – for popular SBCs from Raspberry Pi, Hardkernel, Orange Pi, Radxa, and others, as well as standard motherboards following Mini-ITX, Pico-ITX, NUC, Nano-ITX, etc.., and SBC adapters following these standards, meaning you could install a Raspberry Pi 5 into a mini-ITX case if needed. SBC Case Builder started as a command line utility for designing DIY case for SBCs relying on OpenSDAD in April 2022, but Edward Kisiel (hominoids) quickly released version 2 with a GUI in October or the same, and has now further improved the utility with the release of SBC Case Builder v3.0. Version 3.0 comes with many improvements but the main focus was to reuse existing and new PC standard form factor cases by creating SBC adapters and custom I/O Shields since […]

April 5, 2024April 6, 2024 by Jean-Luc Aufranc (CNXSoft) - 2 Comments

Kamvas Pro 16 (2.5K) review – A 15.8-inch drawing tablet and stylus with 8192 levels of pressure sensitivity

HUION Kamvas Pro 16 2.5K drawing tablet review

HUION Kamvas Pro 16 (2.5K) is a 15.8-inch drawing tablet with 2.5K resolution that comes with a stylus supporting 8192 levels of pressure. The company sent us a review sample, so I’ll test it as an external display in Windows 11 and Ubuntu 22.04, and check the drawing functions of the Kamvas Pro 16 with the stylus as well as other potential use cases. Kamvas Pro 16 (2.5K) specifications (model GT1602) But before that, let’s list the specifications of the display: Panel – 15.8-inch (diagonal) IPS display at 60 Hz Resolution – 2560 x 1440 (16:9) QHD PPI (Pixels Per Inch) – 186 Active Area – 349.6 x 196.7 mm Contrast Ratio – 1200:1 Brightness – 220nit (Max.) Response Time – 14ms Viewing Angle – 178° (89°/89°(H)/89°/89°(V) (Typ.)(CR＞10)) Color Gamut Volume – 145% sRGB Color Gamut Coverage – 99% sRGB / 99% Adobe RGB Colors – 16.7M (8-bit) Surface Finish […]

February 20, 2024February 20, 2024 by Jean-Luc Aufranc (CNXSoft) - 1 Comment

Rockchip RK3568-powered ASUS Tinker Board 3N is now available in three variants

The ASUS Tinker board 3 was first unveiled in April 2023 before being renamed as Tinker Board 3N later that year, and the three variants of the Rockchip RK3568 single board computer (SBC) are now available. The standard configuration is the Tinker Board 3N in the commercial temperature range, while the Tinker Board 3N Plus has the same features, except it can operate in the industrial temperature range (-40°C to 85°C). The Tinker Board 3N Lite is a cost-down version in the same form factor, but with a single gigabit Ethernet port without PoE support, no M.2 B-key socket for an NVMe SSD or 4G/5G cellular connectivity, no 16MB SPI flash, fewer serial interfaces, and no CAN Bus. You’ll find a comparison of the specifications for the three variants in the table below. Note the prices above are from Amazon with a 10% discount when applicable. ASUS provides support for […]
